Bischoff & Bischoff TSE-A / O User manual

Enjoy mobility.
TSE-A / O
Bis hoff & Bis hoff
Instru tion manual

2
TSE-A/O
(Toilet seat raiser)
Dear ustomer,
with the purchase of this B+B toilet aid you are now the
owner of a high-quality German product, thousands of
which are already in professional use.
This instruction manual will familiarise you with the use
and maintenance of your B + B toilet aid and make your
life safer.
We hope you enjoy our product.
2

TSE-A / O
English
1. Attention safety instru tions!
(Risk analysis as per DIN EN 13485)
• Max. load capacity 150 kg
• The load capacity is not based on the cover of the
commode seat. The cover is not suitable for use
as a seat.
• The toilet seat raiser is not suitable for continuous
use as a seat.
• Make sure that the arm rests are fully locked
in position.
• When unfolding the arm rests make sure that
you do not jam parts of the body or clothing.
• Make sure that the fixation screws are tight.
• Set the front and back height adjustment
to the same height.
Bis hoff & Bis hoff GmbH • 04.05.2011 3

2
4
2. Installing the arm rests
(TSE-A only)
Insert the arm rests into the hole in the rear housing
section of the toilet seat raiser. ress the spring button
with your thumb and hold it down until the spring
button is inserted through the hole.
Before lowering the arm rests make sure that no parts
of your body or clothing are jammed. It is also important
to note that the arm rests are fully locked before
supporting it.
3. Adjusting the height of the seat
The toilet seat raiser can beset to three heights (8, 12
and 16 cm). To adjust the height of the seat unscrew
the two knurled screws at the back of the TSE.
• Remove the plastic caps in the required position.
• Lift the aluminium rod into the desired position
and tighten the knurled screws again.
• ress the remaining plastic caps into the open holes.
• roceed as described above at the front of the TSE.
Make sure that the back and front aluminium rods are set
to the same height.

TSE-A / O
Bis hoff & Bis hoff GmbH • 04.05.2011 5
English
Fig. 1
Fig. 2
4. Installing the toilet seat raiser
• Unscrew the cover of the toilet.
• Screw the two long plastic nuts to the back aluminium
rod. Insert the two threaded rods into the holes in the
toilet.
• Screw the two long plastic nuts to the threaded rods
from below.
Depending on the size of the toilet, it is necessary to
mount the rear aluminium support rod rotated with the
fixation screws rotated 180° to prevent the front support
rod from slipping of the toilet bowl (see photos to
the right).
Make sure that the nuts are tight to hold the TSE-Easy
firmly on the toilet
Minimum distance between toilet
and wall 18 cm.

2
6
5. Arm rests (TSE-A only)
The arm rests can be folded back. The arm rests can be
locked in the down position by lightly pressing down on
them (click noise).
The arm rest must be folded back for transfer from a
wheelchair. Follow instructions in section 1 (installing the
arm rests).
6. Care and maintenan e
Clean and disinfect the toilet seat raiser with standard
cleaners and disinfectants.Do not use aggressive cleaning
agents.The toilet seat raiser is maintenance-free.
7. Te hni al data
Depth: 49 cm
Width: 58 cm
Height: 37 cm
Arm rest height (from toilet seat): 21 cm
Seat width: 40 cm
Seat depth: 40 cm
Weight of TSE-A: 6,3 kg
Weight of TSE-O: 4,4 kg
Max. user weight 150 kg

TSE-A / O
Bis hoff & Bis hoff GmbH • 04.05.2011 7
English
Model: TSE-A/O toilet seat raiser
serial number:*
(to be entered by dealer)
Dealer:
Date and stamp
* See the side frame for information stickers
Warranty ertifi ate
(Please note our general terms and onditions)

Bis hoff & Bis hoff GmbH
Be ker-Goering-Strasse 13 • D-76307 Karlsbad
Tel.: [phone] • Fax: [phone]
www.bis hoff-bis hoff. om
info@bis hoff-bis hoff.de
