Kohler K-3900X Assembly instructions

Homeowner’s Guide
Integrated Toilet
1153043-X5-C ©2012 Kohler Co.
Homeowner’s Guide
Integrated Toilet


K-3900X

1153043-X5-C 2 Kohler Co.
Table of Contents
IMPORTANT SAFEGUARDS................................................................................................................................... 3
Specications................................................................................................................................................................ 4
Thank You For Choosing Kohler Company............................................................................................................ 4
Features......................................................................................................................................................................... 5
Remote Control............................................................................................................................................................ 7
Back Panel..................................................................................................................................................................... 9
Flushing Your Toilet.................................................................................................................................................. 10
Using the Bidet Functions.......................................................................................................................................... 11
Using the Music Function......................................................................................................................................... 13
Using the Heating and Lighting Functions............................................................................................................ 15
Creating a User Prole.............................................................................................................................................. 16
Seings - Remote Control Screen Backlight and Language................................................................................. 18
Seings - Date and Time........................................................................................................................................... 19
Seings - Remote Control Power Save................................................................................................................... 20
Seings - Toilet Sleep Mode..................................................................................................................................... 21
Seings - User Seing............................................................................................................................................... 23
Seings - Auto Open, Auto Flush, Deodorizer..................................................................................................... 24
Seings - Sounds and Lighting................................................................................................................................ 26
Using the Manual Clean Seings............................................................................................................................ 27
Seing - Automatic Bidet Wand Cleaning............................................................................................................. 28
Remote Control to Toilet Connection and Remote Control Power................................................................... 30
Reseing the Users or Toilet.................................................................................................................................... 31
Manual Operation...................................................................................................................................................... 32
Servicing the Toilet.................................................................................................................................................... 33
Servicing the Bidet Wand......................................................................................................................................... 35
Care and Cleaning..................................................................................................................................................... 35
Troubleshooting Information................................................................................................................................... 36

Kohler Co. 3 1153043-X5-C
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS

 WARNING:Riskofelectricshock,re,orpersonalInjury.This product must be grounded. Connect
only to a dedicated 220~240Va.c, 50/60Hz, circuit protected by Ground-Fault Circuit-Interrupter (GFCI) or
Earth-Leakage Circuit-Breaker (ELCB).
WARNING:Riskofelectricshockorproductdamage.Do not immerse or ush the product with water.
IMPORTANT!Riskofproductdamage. Do not install this seat in a location where water might be splashed on
the product.
IMPORTANT!Risk ofproduct damage. Do not install this seat in a location exposed to excessive moisture
where condensation might form on the product surface. Please ensure sucient ventilation in your surroundings
to prevent possible damage to electronic components.
IMPORTANT!Riskofproductorpropertydamage. Pushing or pulling on the water connection may cause
water leakage.
IMPORTANT!Riskofproductdamage. Do not apply excessive force to the spray wands. Product may break.
IMPORTANT!Riskofproductdamage. In areas where water may freeze in the pipes, make arrangements to
keep the pipes warm. Any water remaining in the seat may freeze during storage during the winter. Allow the
unit to warm to room temperature before reinstalling or using.
IMPORTANT!Risk ofproductdamage. Do not supply electrical power to the unit until the plumbing installation
work has been completed; it could cause the product to malfunction.
NOTE: The thermal protectors may trip during storage or transportation in warm weather causing the unit to not
operate. Allow the unit to cool to room temperature before installation or operation.
Whenusingelectricalproducts,especiallywhenchildrenarepresent,basicsafetyprecautionsshouldalways
befollowed,includingthefollowing:
DANGER-Toreducetheriskofelectrocution:
¨ Do not place or store this appliance where it can fall or be pulled into a bath or sink.
¨ Do not place in or drop into water or other liquid.
¨ Do not reach for a product that has fallen into water. Unplug immediately.
WARNING-Toreducetheriskoflowgradeburns,electricshock,reorinjurytopersons:
¨ Close supervision is necessary when this appliance is used by or near the very young, the elderly, or invalids.
Children should not be permied to use or touch this appliance. Do not leave children unaended in any room
where this product is installed.
¨ For children and aged people who are unable to regulate temperature by themselves, help is required to
regulate temperatures of the toilet, water and wind to the suitable grade.
¨ Use this appliance only for its intended purpose as described in the manual. Do not use aachments not
recommended by Kohler Co.

1153043-X5-C 4 Kohler Co.
IMPORTANT SAFEGUARDS (cont.)
¨ Do not lean on lid when using product.
¨ Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has been
dropped, damaged, or dropped into water.
¨ Install this product properly by following the installation procedure.
¨ Only authorized persons can install or repair the unit. Do not aempt to service this appliance yourself, doing
so could void the warranty.
¨ Keep the cord away from heated surfaces.
¨ Never drop or insert any objects into any opening or hose.
¨ Do not use outdoors or where aerosol spray products are being used or where oxygen is administered.
¨ Always follow the grounding instructions in this manual before plugging in the unit.
¨ Do not splash water on power plug.
¨ Please avoid long time siing on the heated-seat for the prevention of low temperature burns.
¨ If the power cord was damaged, in order to avoid dangerous, replace it by the manufacturer, the Maintenance
Department or a similar department professionals is necessary.
Specications
Thank You for Choosing Kohler Company
SKU Electrical Water Supply Pressure
K-3900X 220~240 V, 50/60 Hz, 2000W 0.20~0.74MPa.
Thank you for choosing Kohler. Kohler crasmanship oers you a rare combination of proven performance
and graceful sophistication that will satisfy you for years to come. The dependability and beauty of your Kohler
product will surpass your highest expectations. We’re very proud of our products here at Kohler and we know
you will be too.
Please take a few minutes to review this manual before you start installation. If you encounter any installation
or performance problems, please don’t hesitate to contact us. Our phone numbers and website are listed on back
cover.
All information in this manual is based upon the latest product information available at the time of publication.
At Kohler, we constantly strive to improve the quality of our products. We reserve the right to make changes
in product characteristics, packaging or availability at any time without notice.
Thank you for choosing Kohler Company.

Manual
Controls
Auto Open Ring
Motion Sensor
Air Outlet
Feet Heater
Remote Control
Docking
Station
AUX IN
Ambient Light
Bidet Wand
Bidet Light
Lid
Ring
Kohler Co. 5 1153043-X5-C
Features
NOTICE: Many of the features listed here can be adjusted, enabled or disabled using the remote. Specic
directions for these procedures are listed later in this manual.
Toilet
¨AutomaticFlushing-When enabled, this feature automatically ushes the toilet six seconds aer the user
stands up or 60 seconds aer standing user leaves (when ring is open).
¨AnimatedFlush- When animated ush is enabled, a graphic will appear on the remote detailing the progress
of the ushing process. The toilet arrives with this feature enabled.
¨FrontMotionSensor- When auto open/close is enabled, the lid may be opened without contact. Activating the
motion sensor by moving your foot before the toilet. The sensitivity of the front motion sensor, which opens
the lid, can be adjusted using the remote control. The toilet arrives with this feature enabled.
¨SideMotionSensor- The blue light on the right side of the toilet that is projected on the oor is designed to
allow the ring to be raised and lowered without touching the toilet. Break the beam of light using your foot to
open or close the ring.
¨Bidet - Front and rear wash, adjustable position, pressure, water temperature and pulsate, oscillate and
wave water action.
¨Dry-Warm air blows out from the wand, adjustable air temperature and pressure.
¨HeatedFeet- When activated, warm air emanates from the air outlet to warm the users feet.
¨Heatedseat- Adjustable seat temperature.
¨Deodorizer- Embedded deodorizer set.

1153043-X5-C 6 Kohler Co.
Features (cont.)
¨ToiletSleepMode- The toilet can be programmed to conserve energy. The toilet arrives with this feature
disabled.
¨ManualControls- Allows the user to control basic toilet features without the remote control.
Remote Control
¨RemoteControl- The wireless, touch activated, rechargeable remote control is used to control the toilet.
¨RemoteControlDockingStation- Wall mounted magnetic dock for the remote. Charges the remote when it
is docked.
¨RemoteControlSleepMode-The remote can be programmed to conserve energy. The toilet arrives with this
feature enabled, set for enter sleep aer two minutes of no use.
Lighting
¨AmbientLight- Light located on the back sides of the toilet. Gently illuminates the area around the toilet.
Brightness is adjustable.
¨BowlLight- Light located on the end of the bidet wand. This light can be set to be activated when a sensor
detects low light, the night light feature. The toilet arrives with this feature enabled.
¨WelcomeLight-when enabled, the ambient light will automatically turn on when the toilet is activated. The
toilet arrives with this feature enabled.
¨Night Light - The Ambient Light will automatically turn on in low light conditions when this feature
is enabled. The toilet arrives with this feature enabled.
Music and Sounds
¨Music-Your toilet is equipped with FM radio, pre-loaded music, and the ability to play music from external
sources.
¨WelcomeMusic-When enabled, welcome music will play upon activation of the toilet. The toilet arrives with
this feature enabled.
¨KeySounds-When enabled, sounds will help indicate the activation of some toilet functions.
¨AuxIn-Any type of standard auxiliary music player can be connected to one of the two locations on the
docking station or the back of the toilet through the presented aux-in cable. Music from the player can be
played on the toilet.
Cleaning
¨AutomaticUVWandCleaning-UV wand cleaning can be programmed using your remote. This feature
comes enabled, scheduled to occur at 2 am every day.

A
GH
D
C
B
QP
K
I
J
N
LM
OR
E
F
Kohler Co. 7 1153043-X5-C
Remote Control
IMPORTANT!For a detailed interactive users guide for this product, go to Kohler.com.
A. ush-eco-Activates a 0.6 (2.3 l) gallon ush for liquid waste.
B. ush-full-Activates a 1.28 (4.8 l) gallon ush for solid waste.
C. seat-Opens the cover and seat when both are closed, or seat only when the cover is already open.
D.cover-Opens the cover only or close seat when seat is already open.
E. close-Closes the cover and seat when both are open, or cover only when the seat is already closed.
F. rear-Takes the user to the rear bidet screen, where bidet water pressure, position and temperature can be
adjusted and activated.
G.front-Takes the user to the front bidet screen, where bidet water pressure, position and temperature can be
adjusted and activated.
H.dryer - Takes the user to the bidet dryer screen, where air pressure and air temperature can be adjusted
and activated.
I. heating - Takes the user to the heating screen, where the heated seat and foot warmer features can be
adjusted and activated.
J. music-Takes the user to the music screen, where the user can choose between playing audio through a
built-in FM radio, portable devices through an auxiliary-input, or listen to the pre-loaded music.
K. lighting-Takes the user to the lighting screen, where the ambient light or the bowl light can be activated
and adjusted.
L. users-Takes the user to the user preset screen, where personalized seings can be activated.

1153043-X5-C 8 Kohler Co.
Features - Remote Control (cont.)
M.seings-Takes the user to the seings screen, where the user can change system seings and feature seings.
N.stop-Click “STOP” will stop the in-progress bidet, music, feet heating, the light will turn o unless night
light is on.
O.clock-Indicates current time.
P. userindicator-Indicates current user-preset seings.
Q.signalindicator-Indicates remote control to toilet signal strength.
R. baeryindicator-Indicates remote control baery remaining capacity.

Power Button
Deodorizer Outlets
Remote Dock
Power Cord Socket
External Speaker Output
Air Filter
Supply Hose
Speakers
Auxiliary Input
Exteral FM Antenna Socket
Kohler Co. 9 1153043-X5-C
Back Panel
¨PowerBuon-Turns the power on and o.
NOTE: Press the power buon to shut down the toilet. The remote control connected with the toilet will
shut down, too. When the toilet is powered on again, the remote control will start up if put on dock.
NOTE:When power failure or unplugged, aer 10 seconds, the drain valve will be opened by using backup
baery. When there’s sound of “BiBi”, if Power Buon is pressed, the valve open command can be cancelled to
save baery electricity.
¨AuxiliaryInput-Plug in any standard external music source to play the music through the speakers.
¨Deodorizer-The deodorizer reduces or eliminated unpleasant smells. When enabled it is activated when the
user sits down.
¨Speakers-Internal speakers.
¨SupplyHose-Water supply hose.
¨AirFilter-Filters air before it enters the blower for the bidet dryer and heated feet option. The lter should be
cleaned periodically.
¨ExternalSpeakerOutput-Allows additional speakers to be connected to the system.
¨ExternalFMAntenna-If radio receiver is in environment that the signal is not good, external antenna can be
used to improve the receiving capability.
¨RemoteControlDockPowerCord-Connect toilet and dock.

1153043-X5-C 10 Kohler Co.
Flushing Your Toilet
IMPORTANT!The ush for your toilet is unique. It is a two stage ush designed for superior performance while
using a small amount of water. It will seem as if your toilet is ushing twice. This is proper operation.
NOTE: When you receive your toilet, it is set to ush automatically. The toilet will ush automatically aer
each use. The toilet will determine the appropriate ush type (ush-eco or ush-full) automatically. Refer to the
“Seing - Auto Open, Auto Flush, Deodorizer ″ section for instructions on enabling or disabling the auto ush
feature.
NOTE: There are two ushing options. The [ush-eco] option uses 0.6 (2.3 l) gallons of water and is intended for
liquid removal. The [ush-full] option uses 1.28 (4.8 l) gallons of water and is intended for solid waste removal.
¨For liquid waste remove, select [ush-eco]. The ush takes approximately 30 seconds.
¨For solid waste removal, select [ush-full]. The ush takes approximately 45 seconds. There is a rst-stage
ush, the bowl is partially relled, and a second stage ush takes place.
