Bissell AEROSWIFT 2612 Series User manual

AEROSWIFT®
Vacuum
___________
USER GUIDE
2612 SERIES
More of a video
person? Look for this
icon and go online
for an instructional
how-to video at
www.BISSELL.com

www.BISSELL.com
2
IMPORTANT SAFETY INSTRUCTIONS
WARNING
TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK OR INJURY:
» Do not leave vacuum cleaner
when it is plugged in. Unplug
from outlet when not in use
and before servicing.
» Do not use outdoors or on
wet surfaces.
» Do not allow to be used as a toy.
Close attention is necessary when
used by or near children.
» Do not use for any purpose
other than described in this user
guide. Use only manufacturer’s
recommended attachments.
» Do not use with damaged cord or
plug. If appliance is not working
as it should, has been dropped,
damaged, left outdoors, or
dropped into water, have it repaired
at an authorized service center.
» Do not pull or carry by cord, use
cord as a handle, close a door on
cord, or pull cord around sharp
edges or corners. Do not run
appliance over cord. Keep cord
away from heated surfaces.
» Do not unplug by pulling on
cord. To unplug, grasp the plug,
not the cord.
» Do not handle plug or vacuum
cleaner with wet hands.
» Do not put any object into
openings. Do not use with any
opening blocked; keep openings
free of dust, lint, hair, and anything
that may reduce air flow.
» Keep hair, loose clothing, fingers,
and all parts of body away from
openings and moving parts.
» Turn OFF all controls before
plugging or unplugging
vacuum cleaner.
» Use extra care when cleaning
on stairs.
» Do not use to pick up flammable
or combustible materials (lighter
fluid, gasoline, kerosene, etc.)
or use in areas where they may
be present.
» Do not use vacuum cleaner in an
enclosed space filled with vapors
given off by oil-based paint, paint
thinner, some moth-proofing
substances, flammable dust, or
other explosive or toxic vapors.
» Do not use to pick up toxic
material (chlorine bleach,
ammonia, drain cleaner, etc.).
» Do not pick up anything that is
burning or smoking, such as
cigarettes, matches or hot ashes.
» Do not use without filters in place.
» Do not pick up hard or sharp
objects such as glass, nails, screws,
coins, etc.
» Use only on dry, indoor surfaces.
» Keep appliance on a level surface.
» Do not carry the vacuum cleaner
while it is running.
» Unplug before connecting
or disconnecting the
TurboBrush® Tool.
READ ALL INSTRUCTIONS BEFORE USING YOUR VACUUM.
Always connect to a polarized outlet (one slot is wider than the other). Unplug from outlet when not in use and before conducting maintenance.
When using an electrical appliance, basic precautions should be observed, including the following:
THIS APPLIANCE HAS A
POLARIZED PLUG
To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than the other). This plug will fit in a
polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install a proper outlet. Do not change the plug in any way.
This model is for household use only.
SAVE THESE INSTRUCTIONS
FOR FUTURE USE

www.BISSELL.com 3
NOTE: Standard accessories may vary by model. To identify what should be included with
your purchase, please refer to the “Carton Contents” list located on the carton top flap.
What’s In The Box?
Upper
Handle
Safety Instructions...........2
Product View ................4
Assembly ...................5
Operations ..................6
Maintenance & Care .......7-9
Troubleshooting ............10
Warranty ....................11
Service ......................11
Contact Information .........11
Product Registration........12
Base Unit
Hose
TurboBrush®
Tool
Lower
Cord Wrap
Extension
Wand
Crevice
Tool
Combination
Dusting/Upholstery
Tool
Thanks for buying a BISSELL® vacuum!
We love to clean and we’re excited to share one of our innovative products
with you. We want your vacuum to work like new for the years to come, so this
guide has tips on how to use, maintain and, if there’s a problem, troubleshoot.
Your vacuum needs a little assembly before getting to work, so flip to the
“Assembly” section and let’s get started!

www.BISSELL.com
4
Product View
Twist Cord Release
down to quickly
remove cord
Cord Release
and Storage
3
2
1
8
45
6
9
14
13
10
11
12
1 Handle
2 TurboBrush® Tool (select models)
3 Crevice Tool
(stored inside Extension Wand)
4 Tank Release Button
5 Stretch Hose
6 Carry Handle
7 Filter
8 Extension Wand
9 Power Cord
10 Bottom-Empty Dirt Bin
11 Height Adjustment Knob
12 Combination Dusting/Upholstery Tool
13 Lower Hose
14 ON/OFF Pedal
15 Recline Pedal
15
7

www.BISSELL.com 5
Assembly
WARNING
Do not plug in your vacuum until you are familiar with all instructions and operating
procedures.
Push Lower Cord
Wrap in, aligning
two tabs, then turn
clockwise (down)
to lock into place.
Push hose end into
vacuum base until
you hear a “click”.
1
Store TurboBrush® Tool on front in
holder.
Store Crevice Tool inside Extension
Wand and store Extension Wand
on side of vacuum.
Store the Combination Dusting/
Upholstery Tool on opposite side.
2
3
5
Insert Handle into
vacuum base until
you hear a “click”.
Wrap the hose up and
around, then slide end
into vacuum base.
4
NOTICE
Brush Roll continues to turn while product is turned ON and handle is in upright position. To
avoid damage to carpet, rugs, furniture and flooring, avoid tipping vacuum or setting it on
furniture, fringed area rugs, or carpeted stairs during tool use.
NOTICE
With Brush Roll ON, do not allow cleaner to sit in one location for an extended period of
time, as damage to floor can result.

www.BISSELL.com
6
Power ON & Settings
Turn the dial on the foot of the vacuum to desired
setting. If dial is difficult to turn, tilt vacuum back.
WARNING
Before using your vacuum, make sure that the Dirt Tank is in locked position and that the
filter is in place. DO NOT operate your vacuum without the filter.
Above Floor Cleaning
Bare Floor Setting -
For bare floors or low
pile carpet.
High Carpet Setting -
For high pile and most
shag carpet.
1
For extended reach, attach the
Extension Wand to the hose first
and then your desired tool.
Pull hose up and out of
vacuum base to attach
your desired tool.
12
2
Installing the Febreze Filter*
Replace standard yellow
foam filter with Febreze
black foam filter to freshen
as you vacuum.
Press top of Dirt Tank
to release it from the
vacuum base.
*Select models.
NOTE: Your vacuum comes with a standard foam filter (yellow) located in the top of of the
Dirt Tank. A separate Febreze foam filter (black) may also be packed in the box. Both are
washable. Over time, the Febreze filter will begin to lose scent after use and washing.
To access the filter, twist
the top of tank counter-
clockwise to unlock and
reveal filter.
123
Certain trademarks used under license from The Procter & Gamble Company or its affiliates.
Press down once on the red ON/
OFF Pedal located on the lower
back of the vacuum to turn ON.
Press down again to turn OFF.

www.BISSELL.com 7
Emptying the Dirt Tank
Press the release button at
the top of the Dirt Tank to
remove it from the vacuum.
Empty once tank is full.
1
Hold Dirt Tank over a trash
container and press lid release
button to empty. Close lid and
return tank to vacuum base.
23
Cleaning the Tank & Cyclone
Grab the top of the Cyclone
assembly to remove. Clean
with warm water and mild
detergent. Wipe inside of
tank with a damp cloth.
Do not reassemble until
completely dry.
Remove the Dirt
Tank and twist
its top counter-
clockwise to
unlock and pull
up to separate.
12
WARNING
To reduce the risk of electrical shock, turn Power Switch OFF and disconnect polarized plug
from electrical outlet before performing maintenance or troubleshooting checks.
Place the top back on
the Dirt Tank by aligning
the tab, then twist
clockwise to lock.
Align tabs on Cyclone
assembly with tank to
replace.
3
Return the fully assembled
tank to the vacuum base
and press firmly until you
hear a “click”.
45
click
NOTE: Let parts dry completely before returning them to vacuum for use.

www.BISSELL.com
8
WARNING
Do not operate vacuum with damp or wet filters, as well as without filters or the Dirt Tank in
place. Allow components to dry before reassembling the Dirt Tank.
To access filter, turn top
of tank counter-clockwise
and pull up to separate.
Remove foam filter. Hand
wash in warm water; mild
detergent may be used if
desired. Rinse well and air
dry thoroughly. Replace
filter if necessary.
Cleaning the Filter
Make sure the filter is
completely dry before
placing it back into the
tank top.
Press Tank Release Button
and remove Dirt Tank.
123
456
Return the
tank’s top,
aligning
tabs and
twisting
clockwise
to lock.
Return tank, pressing
firmly until you hear
a “click”.

www.BISSELL.com 9
Pull Brush Roll straight out
and slide belt off.
Inspect Brush Roll by placing
it on its end and spinning. It
should spin freely, multiple
times by one flick. If it
doesn’t, replace Brush Roll.
Inspect belt, replace if it
appears damaged.
Maintaining the Brush & Belt
Place belt back on motor gear. Pull belt over the
Brush Roll and place back in. Position the Brush Roll
end opposite of the belt to line up with tab. The
end closest to the belt will slide in the tab without
needing any rotation.
Unplug vacuum, turn
over and unscrew 5 silver
Phillips-head screws and
remove bottom cover.
13
45
Reattach bottom replacing
the 5 screws. Spin the brush
by hand one revolution to
self-center the belt.
In Step 1 and 5, you will need a
Phillips-head screwdriver.
2

www.BISSELL.com
10
Problem Possible causes Remedies
Brush Roll
doesn’t
rotate
Belt is broken or stretched. Follow maintenance instructions on
checking brush and belt (page 9).
Brush Roll has lodged debris or
other entanglements, keeping the
brush from rotating.
Check the Brush Roll and
remove debris, also check the belt
for any breaks or tears and replace if
necessary.
Vacuum
won’t pick
up dirt
Filter is dirty. Remove and rinse pre-motor filter,
allowing enough time for them to
dry completely before reinserting.
The main hose is not connected. Locate the hose and reconnect
by pushing the hose connection
to secure the latch and secure
the other end of the hose into the
vacuum base.
There is a crack or hole in the
main hose.
If there is a crack or hole, order a
new hose from BISSELL.com/parts.
Brush Roll is not turning. Remove brush and clean brush &
brush ends, see page 9.
There is a clog in the vacuum. Check for debris build-up or clogs in
the inner tank, hose and foot/lower
hose; see online video for more help.
The Dirt Tank is not seated
correctly.
Press the Tank Release Button to
release the Dirt Tank and reseat
properly.
Dirt is
escaping
from the
vacuum
The Dirt Tank is full. Empty the Dirt Tank.
Filters are missing. Check to see if the filter is in place.
The Dirt Tank is not seated
properly.
Press the Tank Release Button
and remove the Dirt Tank, then
return it inserting the bottom first
and pivoting the tank towards the
vacuum until it “clicks” into place.
Vacuum is
hard to push
Incorrect height adjustment. Adjust knob to higher setting.
Troubleshooting
WARNING
To reduce the risk of electric shock, turn Power Switch OFF and disconnect plug from
electrical outlet before performing maintenance or troubleshooting checks.

www.BISSELL.com 11
This warranty gives you specific legal rights,
and you may also have other rights which
may vary from state to state. If you need
additional instruction regarding this warranty
or have questions regarding what it may
cover, please contact BISSELL Consumer
Care by E-mail or telephone as described
below.
It may be necessary to obtain some of your
personal information, such as a mailing
address, to fulfill terms of this warranty. Any
personal data will be handled pursuant to
BISSELL’s Privacy Policy, which can be found
online at www.BISSELL.com/privacy-policy.
Limited Two Year Warranty
Subject to the *Exceptions and Exclusions
from the Terms of the Limited Warranty,
upon receipt of the product BISSELL will
repair or replace (with new, refurbished,
lightly used, or remanufactured components
or products), at BISSELL’s option, free
of charge from the date of purchase by
the original purchaser, for two years, any
defective or malfunctioning part.
See information below on "If your BISSELL
product should require service”.
This warranty applies to product used for
personal, and not commercial or rental,
service. This warranty does not apply to
fans or routine maintenance components
such as filters, belts or brushes. Damage or
malfunction caused by negligence, abuse,
neglect, unauthorized repair, or any other use
not in accordance with the user guide is not
covered. This warranty will only be valid if the
product is used in the same country in which
it was sold.
BISSELL is not liable for incidental or
consequential damages of any nature
associated with the use of this product.
BISSELL’s liability will not exceed the
purchase price of the product.
Some states do not allow the exclusion or
limitation of incidental or consequential
damages, so the above limitation or
exclusion may not apply to you.
*Exceptions and Exclusions from the
Terms of the Limited Warranty
This warranty is exclusive and in lieu of
any other warranties, either oral or written.
Any implied warranties, which may arise
by operation of law, including the implied
warranties of merchantability and fitness for
a particular purpose, are limited to the two-
year duration from the date of purchase as
described above.
Some states do not allow limitations on how
long an implied warranty lasts, so the above
limitation may not apply to you.
Warranty
NOTE: Please keep your original sales receipt. It provides proof of date of purchase in the
event of a warranty claim.
If your BISSELL® product should
require service:
Contact BISSELL Consumer Care if you need
information about repairs or replacement parts,
or if you have questions about your warranty.
Service
Please do not return this product
to the store.
Other maintenance or service not included
in the manual should be performed by an
authorized service representative.
Website:
www.BISSELL.com/support
E-mail:
www.BISSELL.com/email-us
Call:
BISSELL Consumer Care
1-800-237-7691
Monday – Friday: 8am - 10pm ET
Saturday: 9am - 8pm ET
Sunday: 10am - 7pm ET

12
©2019 BISSELL Inc.
Grand Rapids, Michigan
All rights reserved. Printed in China.
Part Number 161-8279 03/19 RevA
Visit our website at: www.BISSELL.com
Registering is quick, easy and offers you benefits over the lifetime of your product.
You’ll receive:
Visit www.BISSELL.com/registration!
Visit the BISSELL website: www.BISSELL.com
When contacting BISSELL, have model number of cleaner available.
Please record your Model Number: ___________________
Please record your Purchase Date: ___________________
NOTE: Please keep your original sales receipt. It provides proof of purchase
date in the event of a warranty claim. See Warranty page for details.
BISSELL Rewards Points
Automatically earn points for
discounts and free shipping on
future purchases.
Faster Service
Supplying your information now
saves you time should you need
to contact us with questions
regarding your product.
Product Support
Reminders and Alerts
We’ll contact you with any
important product maintenance
reminders and alerts.
Special Promotions
Optional: Register your email
to receive notice of offers,
contests, cleaning tips, and more!
Love yr BISSELL®product?
Don’t keep it a secret.
Let us, and millions of others, know what you think!
Leave your star-rating on BISSELL.com
www.BISSELL.com
Parts & Supplies
For Parts and Supplies, go to www.BISSELL.com and enter your model
number in the search field.
Register your product today!
