BJ BJ3214 User manual

捷时计电子
www.szbaojie.com
2009-08-10 Model：BJ3214 Page: 1 / 2 Edition : A
A . Features
12 Digits LCD Display，Display Hour ,Minute ,Second ,Month ,Day and Week
Daily Alarm and Chime hourly
Snooze
12 / 24H format selectable
1/100 second Chronograph with split functions
EL backlight
B . Operational Manual
1. At any state ,press Ａ
ＡＡ
Ａkey EL backlight for 3s .
2. Chronograph
Press Ｄkey to Start/Stop running ;
When stop ,press C key to zero .
When running ,press Ｃkey to split count. indicator "SP" showing
Then press Ｄkey to exit split count ,and stop counting ; press Ｃkey again to zero ;
When running ,press Ｂkey to return to Real Time Mode ,and it running at back .
3.
Daily Alarm
Turn On / Off Alarm and Chime
Press Ｄkey to turn on/offAlarm ( ) or Chime ( )
Alarm setting : Press C key to select "Hour " or "Minute "setting, Press D key to adjust the flashing item,
Press C key to confirm, Press Ｂkey to return to Real Time mode.
Alarm Snooze ON/OFF
At Alarm sounding state ,press Ｃkey or D key to stop sounding ,and press B key to ON/OFF snooze
function .When Snooze function be ON ,it will sound five minutes later ,and auto stop after sounding
for 20 Second.
4. Time Setting
"Second " flashing when loading ,press D key to zero ; Press C key to select item as following
sequence :
Hour Minute Month Day Day of Week Second
When setting "Hour " ,"Ｈ" display for ２４H format ;"Ａ" or "Ｐ" for １２H format .
Press D key while the seconds are in the range of 30 to 59 resets them to 00 and adds 1 to the minutes .
In the range of 00 to 29,the minutes are unchanged.
（
（（
（C Key
C KeyC Key
C Key）
））
）
RESET
（
（（
（D
DD
D Key
KeyKey
Key）
））
）
START
LIGHT
（
（（
（A
AA
A K
KK
K ey
eyey
ey）
））
）
L
MODE
（
（（
（B
BB
B Key
KeyKey
Key）
））
）
Real Time
Chronograph
Alarm
Time setting
B Key B Key B Key

捷时计电子
www.szbaojie.com
2009-08-10 Model：BJ3214 Page: 2 / 2 Edition : A
C. Specifications
Module Size
Module Thickness
Operational Temperature Range
Operational Voltage
Accuracy
Battery Code
Current Consumption for Digit （ maxima ）
Current Consumption for Digit （ averagely ）
Alarm Current
EL Current
Battery life
Prepared
Checked Approve
Name 冯碧颜
徐治中 宋检望
Date 09/08/10 09/08/11 09/08/11
：
Φ
33.15mm
： 9.6 ±0.15 mm
：-10℃~60℃
：3.0V
：±90sec/month
：CR2025 (Content：170mAh)
：≤3.5u A(T=25℃)
：≤2.5u A(T=25℃)
：≤2.5 m A
：≤10 m A
：≥24month(Japan Lithium)
2 backlight operation (6 seconds) per day
20 seconds of alarm operation per day
