BJ G2150 User manual

捷时计电子
www.szbaojie.com
2006-11-20 Model：G2150 Page: 1 /3 Edition : A
A . Features
11 Digits LCD Display，Display Hour ,Minute ,Second ,Month , Day, year(2000~2020)
Daily Alarm and Chime hourly
12 H format，Auto Calendar
1/100 second Chronograph with
Heart rate and Calories burned while exercise
Keytone function
B . Operational Manual
1. Real Time
Press Ｄkey for about 2s to enter Time Setting , Press Ｄkey continue to select in turn of
"Year(2000~2020)" "Month" "Day" "Hour" "Minute" ;Birth of "Year(1920~2010)" "Month" "Day"
"Sex" (F: female,M:man), "Weight(50~600Pounds)"；Press Ｃkey to adjust the flashing digital ; When
setting "Weight"，press Ａkey to select unit of ＫＧ or POUND.
2. Daily Alarm Mode
Alarm setting: Press Ｄkey for about 2s to enter Alarm Setting ,and it auto ON( ) ; Press Ｄ
key again to select "Hour" or "Minute" setting ; Press Ｃkey to adjust the flashing digital .
Press Ａkey to be ON/OFF Hourly Chime( )；Press Ｃkey to be ON/OFF Alarm( ).
It will auto stop 3m later when Alarm sounding .
3. Chronograph Mode
Press Ｃkey to Start/Stop counting ;
When stop ,press Ａkey to counting zero ;
Press Ａkey when counting , the time will stop on the LCD , but continue running internally .
4. Pulse Mode
Press Ｄkey for about 2s to test Pulse ,showing "TOUCH SENSOR"；then put the finger on the
"finger print" area of SENSOR ,and hold until pulse read out is given .
If the method is error ,showing "RETRY" after alarming ;.
Chronograph Mode
Real Time MODE DailyAlarm Mode Exercise Mode Pulse Mode
B Key B Key B Key B Key
ST/SP
（
（（
（C key
C keyC key
C key）
））
）
SENSOR
SENSORSENSOR
SENSOR
（
（（
（D key
D keyD key
D key）
））
）
SET
L
RESET
（
（（
（A key
A keyA key
A key）
））
）
L
MODE
（
（（
（B
BB
B key
keykey
key）
））
）

捷时计电子
www.szbaojie.com
2006-11-20 Model：G2150 Page: 2 /3 Edition : A
5. Exercise Mode
Press Ｃkey to Start counting and Start exercise ;.
Press Ｃkey to Stop counting when finishing exercising ;
Then press Ｄkey entering a blank mode with a heart icon ;
And then press Ｄkey for about 2s to test Pulse ,put the finger on the "finger print" area of SENSOR;
5s later ,showing average calories burned during workout based on age ,weight ,sex ,work out
time ,and a set of bars indicating what work out zone( ) exercised in (one bar being the lowest
zone and five bars being the highest zone ).
Press Ａkey to return to Exercise Mode ,and press Ａkey to zero .
You can press Ｂkey and leave the Exercise Mode to take your pulse of check the time .When you
return to the Exercise Mode ,the counter will have kept track of your total exercise time.
6. Basic requirements
To get reliable test results ,there are the following basic requirements:
You should be relaxed and calm.
The test can take place anywhere-home, office, health club -as long as the testing environment is
peaceful. No disturbing noises(e.g. television, radio or telephone),no other people talking to you.
Keep the testing place , time of day and environment the same every time the test is repeated.
Avoid eating a heavy meal or smoking 2-3 hours prior to testing.
Avoid heavy physical effort, alcoholic beverages or pharmacological stimulants on the test day and the
day before.
7. sport strength account
Be engaged in 3-4 times every week, and the Aerobic of every time 20-40 minute is quite
the cheese, sport strength the inside etc. or inside etc. is above for proper, sport
biggest heart rate roughly 130-170 times/ cent, not of an age sport the heart rate make
selection different, generally not exceed most heart rate( use 220 subtract the age,
namely biggest heart rate) of 80%.For example:35 years old and biggest heart rate is
220-35=185 times/ the cent, rate of biggest sport heart should not exceed 185 X80%=148
times/ cent;50 years old and biggest heart rate is 220-50=170 times/ the cent, rate of
biggest sport heart not exceed 170 X80s%=136 times/ cent;60 years old and biggest heart
rate is 220-60=160 times/ the cent, rate of biggest sport heart should not exceed 160
X80%=128 times/ cent.
C. Importance clew
SPHYGMUS TEST CONDITION：AT the temperament of 1700 LUX in the room under the light.
SPHYGMUS ERROR：±5%
Electric appliances light source interference
If be placed in the place that television, computer, light or other have flicker light
source, would suffer the interference
calorie watch is photoelectricity sensor, and through the size of blood flux to realize the pulse signal
transfers but if there is a disturb of above mention with happen a error digital.

捷时计电子
www.szbaojie.com
2006-11-20 Model：G2150 Page: 3 /3 Edition : A
D. Specifications
Module Dimension
Module Thickness(without buzzer)
Operational Temperature Range
Operational Voltage
Accuracy
Battery Code
Static current
Alarm Current
Heartbeat Current
Battery life
Prepared
Checked Approve
Name 冯碧颜
韦章龙 刘成恒
Date 06/11/20 06/11/20 06/11/20
： Ф33±0.05mm
： 10.1±0.2mm
：-10℃~60℃
：3.0V
：±90sec/month
：CR2032(Japanese battery)
：≤3.0 u A(T=25℃)
：≤3.5 u A(T=25℃)
：≤6.0 m A
：18 months
30 seconds of alarm operation per day
30 seconds of test Pulse per day
