Black & Decker D2530 User manual

MODEL/MODELO
❍ D2030
❍ D2530
DIGITAL ADVANTAGE® IRON
PLANCHA DIGITAL ADVANTAGE®
Customer Care Line:
USA 1-800-231-9786
Accessories/Parts (USA)
1-800-738-0245
For online customer service
and to register your product, go to
www.prodprotect.com/applica
Servicio para el cliente:
México 01-800 714-2503
Accesorios/Partes (EE.UU)
1-800-738-0245
Para servicio al cliente y para
registrar su garantía, visite
www.prodprotect.com/applica
When using your iron for the first time, you may
notice water residue inside the unit. This is normal.
Cuando use su plancha por primera vez, notará que
hay agua adentro de la plancha. Esto es normal.

2
Please Read and Save this Use and Care Book.
IMPORTANT SAFEGUARDS
When using your iron, basic safety precautions should always be followed,
including the following:
❍ READ ALL INSTRUCTIONS BEFORE USING
❍ Use iron only for its intended use.
❍ To protect against a risk of electric shock, do not immerse the iron in
water or other liquids.
❍ The iron should always be turned to the minimum (min) setting
before plugging or unplugging from outlet. Never yank cord to
disconnect from the outlet; instead grasp plug and pull to disconnect.
❍ Do not allow cord to touch hot surfaces. Let iron cool completely
before putting away. Loop cord loosely around iron when storing.
❍ Always disconnect iron from electrical outlet when filling with water
or emptying, and when not in use.
❍ Do not operate iron with a damaged cord, or if the iron has been
dropped or damaged. To avoid the risk of electric shock, do not
disassemble the iron; take it to a qualified service person for
examination and repair, or call the appropriate toll-free number
on the cover of this manual. Incorrect reassembly can cause a risk
of electric shock when the iron is used.
❍ Close supervision is necessary for any appliance being used by or
near children. Do not leave iron unattended while connected or on an
ironing board.
❍ Burns can occur from touching hot metal parts, hot water or steam.
Use caution when you turn a steam iron upside down or use the
surge of steam – there may be hot water in the reservoir. Avoid rapid
movement of iron to minimize hot water spillage.
❍ The iron must not be left unattended while it is connected to the
supply mains.
❍ The plug must be removed from the socket-outlet before the water
reservoir is filled with water.
❍ The iron must be used and rested on a stable surface.
❍ When placing the iron on its stand, ensure that the surface on which
the stand is placed is stable.
❍ The iron is not to be used if it has been dropped, if there are visible
signs of damage or if it is leaking.

3
ENGLISH
SPECIAL INSTRUCTIONS
❍ To avoid a circuit overload, do not operate another high-wattage
appliance on the same circuit.
❍ If an extension cord is absolutely necessary, a cord rate at
15-ampere cord should be used. Cords rated for less amperage
may overheat. Care should be taken to arrange the cord so that it
cannot be pulled or tripped over.
SAVE THESE INSTRUCTIONS.
This product is for household use only.
POLARIZED PLUG
This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit
into a polarized outlet only one way. If the plug does not fit fully into
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician. Do not attempt to modify the plug in any way.
TAMPER-RESISTANT SCREW
Warning: This appliance is equipped with a tamper-resistant screw
to prevent removal of the outer cover. To reduce the risk of fire or
electric shock, do not attempt to remove the outer cover. There are
no user-serviceable parts inside. Repair should be done only by
authorized service personnel.
Note: If the power supply cord is damaged, it should be replaced by
qualified personnel; in Latin America, by an authorized service center.

4
Product may vary slightly from what is illustrated.
1. Spray nozzle
2. Water-fill opening
3. Digital display
4. Power / temperature setting button
5. Steam button
6. Spray button
7. Power indicator light
8. Heel rest
9. Water tank
10. Variable steam dial










5
How to Use
This appliance is intended for household use only.
GETTING STARTED
• Remove any labels, stickers or tags attached to the body or soleplate of the iron.
Important: For warranty verification, do not remove the line cord sticker.
• Please go to www.prodprotect.com/applica to register your warranty.
Note: Use ordinary tap water for ironing. Do not use water processed through a home
softening system.
Important: For optimum performance, let the iron stand for 90 seconds before
beginning to iron.
FILLING WATER TANK
1. Tilt the iron and using a clean measuring cup, pour water into water-fill opening
until the water reaches the MAX mark on the water tank. Refill as needed.
Note: If you need to add water while ironing, unplug the iron and follow above steps.
SELECTING A TEMPERATURE SETTING
1. Plug in the iron. The power indicator light turns on and a beep sounds;
Temperature setting 1 (ACRYL) appears in the digital display.
2. To select a temperature setting, press the temperature setting button below the
digital display until you reach your desired setting–from 1 to 7.
3. The digital display will show the setting number and
fabric type; these will flash on the display until the
set temperature is reached (A).
4. When your set temperature is reached, the iron will
keep once and the word “READY” will appear in
the display. The temperature setting, number and
“READY” will be displayed as you iron.
Note: See the fabric guide on the iron and read garment's label
to help you determine which temperature setting to use (B).
Tip: If unsure of a garment’s fiber, test a small area (on an
inside seam or hem) before ironing.
5. To change temperature settings while ironing, just push the
temperature button. When a lower setting is selected, fabric
type will flash until the iron temperature has lowered to the
correct level for that setting. The iron will beep once and
"READY" will appear in the bottom of the display window.
IRONING WITH STEAM
1. For steam ironing, be sure the water tank is filled to MAX.
2. Turn the variable steam dial to the appropriate steam
setting for your fabric (C).
Note: See the fabric guide on the iron and read garment's label
to help you determine which steam setting to use.
3. For optimum performance when using steam, stand iron
on its heel rest until the selected temperature setting is
reached.
4. When finished ironing, turn the variable steam dial to the steam off setting.
ENGLISH
A
C
B

6
SURGE OF STEAM
Horizontal
Tip: Use to remove stubborn creases.
1. With the water tank filled to the MAX mark, set temperature setting and variable
steam to the appropriate settings for your fabric. See fabric guide on the iron and read
garment's label to help you determine fabric type.
2. For best performance, press the steam button at 5-second intervals.
3. When finished ironing, turn the variable steam dial to the steam off setting and
unplug the iron.
Important: Always stand the iron on its heel rest when powered on but not in use.
Vertical
Tip: Use for removing wrinkles from hanging clothes and drapes.
1. With the water tank filled to the MAX mark, set temperature setting and variable
steam to the appropriate settings for your fabric. See fabric guide on the iron and read
garment's label to help you determine fabric type.
2. Hang the garment to be steamed on a clothes hanger. (Curtains or drapes can be
steamed once they are hung.)
3. Hold the iron close to, but not touching, the fabric.
4. Pull the fabric tight in your free hand and pump the steam button as you move the
iron over the fabric.
5. When finished ironing, turn the variable steam dial to the steam off setting and
unplug the iron.
DRY IRONING
1. To iron without steam, set the variable steam dial to steam off .
USING SPRAY
Tip: Use to dampen tough wrinkles at any setting.
1. Be sure the iron is filled with water.
2. On first use, pump the spray button several times.
10-MINUTE AUTO SHUTOFF
The automatic shutoff feature in your iron works as follows:
• Once the iron reaches appropriate temperature, it will turn off after 10 minutes of
inactivity. Before turning off, the iron will beep once and “AUTO OFF” will flash in the
digital display.
• Once turned off, the digital display will go dark, but the words “AUTO OFF” will
continue to show in the display.
• As soon as you pick up the iron, it will beep once and start heating again to the set
temperature setting. Wait for iron to reheat completely before resuming operation.
• To turn the iron off manually, press the power / temperature setting button for
2 seconds; this can be done from any temperature setting.
EMPTYING WATER TANK (OPTIONAL)
Note: It is not necessary to empty the water after each use.
1. Unplug the iron and let it cool.
2. To empty the water, hold the iron over a sink with the tip pointing down. Water will
empty out the water-fill opening.

7
ENGLISH
Care and Cleaning
This product contains no user serviceable parts. Refer service to qualified service
personnel.
CLEANING
1. Make sure iron is unplugged and has cooled completely. Wipe the soleplate
and outer surfaces with a soft cloth dampened with water and mild household
detergent. Never use abrasives, heavy-duty cleansers, vinegar or scouring pads
that may scratch or discolor the iron.
2. After cleaning, steam iron over an old cloth to remove any residue from the steam
vents.
AUTO CLEAN® SYSTEM
To keep the steam vents free of any buildup, follow these instructions when the word
“CLEAN” appears in the digital display:
1. Fill the water tank well below the MAX line. Plug in the iron.
2. Press the temperature setting button to 6 and stand the iron on its heel rest. Allow
it to heat about 3 minutes.
3. Unplug the iron and hold over a sink with the soleplate facing down.
4. Move and hold the variable steam dial in the CLEAN position. Be careful, as
hot water and steam will come out of the steam vents.
5. Continue to hold the variable steam dial to CLEAN until all the water has emptied.
If necessary, rock iron side-to-side and front-to-back.
6. When finished, move the variable steam dial to steam off , stand the iron on its
heel rest and plug it in. Heat for about 2 minutes to dry out any remaining water.
STORING
1. Unplug the iron and let it cool completely.
2. Check that the variable steam dial is set to steam off .
3. Store iron on its heel rest. Storing iron on its soleplate can cause leaks or damage.

8
NEED HELP?
For service, repair or any questions regarding your appliance, call the appropriate
800 number on the cover of this book. Please DO NOT return the product to the
place of purchase. Also, please DO NOT mail product back to manufacturer, nor
bring it to a service center. You may also want to consult the website listed on the
cover of this manual.
TWO-YEAR LIMITED WARRANTY
(Applies only in the United States and Canada)
What does it cover?
• Any defect in material or workmanship provided; however, Applica’s liability
will not exceed the purchase price of product.
For how long?
• Two years from the date of original purchase with proof of such purchase.
What will we do to help you?
• Provide you with a reasonably similar replacement product that is either new
or factory refurbished.
How do you get service?
• Save your receipt as proof of date of sale.
• Visit the online service website at www.prodprotect.com/applica, or call toll-
free 1-800-231-9786, for general warranty service.
• If you need parts or accessories, please call 1-800-738-0245.
What does your warranty not cover?
• Damage from commercial use
• Damage from misuse, abuse or neglect
• Products that have been modified in any way
• Products used or serviced outside the country of purchase
• Glass parts and other accessory items that are packed with the unit
• Shipping and handling costs associated with the replacement of the unit
• Consequential or incidental damages (Please note, however, that some
states do not allow the exclusion or limitation of consequential or incidental
damages, so this limitation may not apply to you.)
How does state law relate to this warranty?
• This warranty gives you specific legal rights. You may also have other rights
that vary from state to state or province to province.
is a registered trademark of The Black & Decker Corporation,
Towson, Maryland, USA
Made in People’s Republic of China
Printed in People’s Republic of China

9
Por favor lea este instructivo antes de usar el producto.
INSTRUCCIONES IMPORTANTES
DE SEGURIDAD
Cuando se usan aparatos eléctricos, siempre se deben respetar las
siguientes medidas básicas de seguridad:
❍ POR FAVOR LEA TODAS LAS INSTRUCCIONES ANTES DE USAR.
❍ A fin de protegerse contra el riesgo de un choque eléctrico, no
sumerja la plancha en agua ni en ningún otro líquido.
❍ La plancha siempre debe estar en la posición de calor mínimo antes
de enchufar o desconectarla del tomacorriente. Nunca tire del cable
para desconectar la plancha del tomacorriente; sujete el enchufe y
hale con cuidado.
❍ No permita que el aparato entre en contacto con superficies
calientes. Espere que la plancha se enfríe por completo antes de
guardarla. Para guardar, enrolle el cable holgadamente en torno a
la plancha.
❍ No permita que el cable cuelgue del borde de la mesa o del
mostrador ni que entre en contacto con las superficies calientes.
❍ Siempre desconecte la plancha del tomacorriente cuando no esté en
uso y antes de llenar o vaciar el tanque de agua.
❍ No use la plancha si tiene averiado el cable, si la ha dejado caer o
presenta cualquier otro daño. Para evitar el riesgo de un choque
eléctrico, no desarme ni trate de reparar la plancha personalmente.
Acuda a un centro de servicio autorizado para que la examinen,
reparen o ajusten, o llame gratis al número correspondiente en la
cubierta de este manual. El reensamblaje o reparación incorrecta
podría ocasionar el riesgo de incendio, choque eléctrico, o lesiones
a las personas al usar el aparato nuevamente.
❍ Todo aparato eléctrico usado en la presencia de los niños o por
ellos mismos requiere la supervisión de un adulto. No desatienda la
plancha cuando esté conectada o sobre la tabla de planchar.
❍ Las partes metálicas calientes de este aparato, al igual que el agua
caliente o el vapor pueden ocasionar quemaduras. En vista de que
puede haber agua caliente en el tanque, tenga cuidado al invertir
una plancha de vapor o al bombear el botón de vapor. Evite los
movimientos rápidos de la plancha para disminuir el goteo de agua
caliente.
❍ El hierro no debe dejarse desatendido mientras esté conectado a la
red de alimentación.
ESPAÑOL

10
❍ El enchufe debe ser retirado de la toma de corriente antes de que el
depósito de agua esté lleno de agua.
❍ La plancha debe ser utilizada y apoyada sobre una superficie estable.
❍ Al depositar la plancha en su soporte, asegúrese de que la superficie
sobre la que se colocará el soporte es estable.
❍ El hierro no debe ser utilizado si se ha caído, si hay signos visibles de
daños o si tiene fugas.
INSTRUCCIONES ESPECIALES
❍ Para reducir la posibilidad de una sobrecarga eléctrica, no opere otro
aparato de alto consumo en el mismo circuito.
❍ Si es indispensable el uso de un cable de extensión, se debe usar uno
con régimen nominal de 15 amperios. Los cables de menor amperaje
se pueden sobrecalentar. Se debe tener cuidado de acomodar el cable
de manera que no interfiera para que nadie se tropiece ni lo pueda
halar.
CONSERVE ESTAS INSTRUCCIONES.
Este aparato eléctrico es para uso doméstico solamente.
ENCHUFE POLARIZADO
Este aparato cuenta con un enchufe polarizado (un contacto es más ancho que
el otro). A fin de reducir el riesgo de un choque eléctrico, este enchufe encaja
en un tomacorriente polarizada en un solo sentido. Si el enchufe no entra en el
tomacorriente, inviértalo y si aun así no encaja, consulte con un electricista.
Por favor no trate de alterar esta medida de seguridad.
TORNILLO DE SEGURIDAD
Advertencia: Este aparato cuenta con un tornillo de seguridad para evitar
la remoción de la cubierta exterior del mismo. A fin de reducir el riesgo de
incendio o de choque eléctrico, por favor no trate de remover la cubierta
exterior. Este producto no contiene piezas reparables por el consumidor.
Toda reparación se debe llevar a cabo únicamente por personal de servicio
autorizado.
Nota: Si el cordón de alimentación esta dañado, en América latina debe
sustituirse por personal calificado o por el centro de servicio autorizado.
