Black & Decker KA89 User manual

KA89E
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Black&Decker KA89
KA89EK-QS o cerca il tuo prodotto tra le migliori offerte di Elettroutensili

2
English (Original instructions) 5
Deutsch (Übersetzung der Originalanleitung) 10
Français (Traduction des instructions d'origine) 16
Italiano (Traduzione delle istruzioni originali) 22
Nederlands (Vertaling van de originele instructies) 27
Español (Traducción de las instrucciones originales) 32
Português (Tradução das instruções originais) 38
Svenska (Översättning av de ursprungliga anvisningarna) 44
Norsk (Oversettelse av de opprinnelige instruksjonene) 49
Dansk (Oversættelse af de originale instruktioner) 54
Suomi (Alkuperäisten ohjeiden käännös) 59
Ελληνικά (Μετάφρασητωναρχικώνοδηγιών) 64

3
A
C
B
D
E F

4
G

5
ENGLISH
Intended use
Your Black & Decker sander has been designed for sanding
wood, metal, plastics and painted surfaces. This tool is
intended for consumer use only.
Safety instructions
General power tool safety warnings
@Warning! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions listed below may result in electric shock,
re and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in all of the warnings listed below refers
to your mains operated (corded) power tool or battery
operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
b. Do not operate power tools in explosive atmospheres,
suchasinthepresenceofammableliquids,gases
or dust. Power tools create sparks which may ignite the
dust or fumes.
c. Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs
with earthed (grounded) power tools. Unmodied plugs
and matching outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces
such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body is
earthed or grounded.
c. Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
d. Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a power
toolwhileyouaretiredorundertheinuenceofdrugs,
alcohol or medication.Amoment ofinattention while
operating power tools may result in serious personal injury.
b. Usepersonalprotectiveequipment.Alwaysweareye
protection. Protective equipment such as dust mask,
non-skidsafetyshoes,hardhat, or hearing protectionused
for appropriate conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is in
the off-position before connecting to power source
and/or battery pack, picking up or carrying the tool.
Carrying power tools with your nger on the switch or
energising power tools that have the switch on invites
accidents.
d. Remove any adjusting key or wrench before turning
the power tool on.A wrench or a key left attached to a
rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
f. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair
can be caught in moving parts.
g. If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can
reduce dust-related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power
tool for your application. The correct power tool will do
the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it
on and off.Any power tool that cannot be controlled with
the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the
battery pack from the power tool before making any
adjustments, changing accessories, or storing power
tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d. Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool or
these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
e. Maintainpowertools.Checkformisalignmentor binding
of moving parts, breakage of parts and any other
condition that may affect the power tools operation.
If damaged, have the power tool repaired before use.
Many accidents are caused by poorly maintained power
tools.

6
ENGLISH
f. Keep cutting tools sharp and clean. Properlymaintained
cutting tools with sharp cutting edges are less likely to
bind and are easier to control.
g. Use the power tool, accessories and tool bits etc.,
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
5. Service
a. Haveyourpowertoolservicedbyaqualiedrepair
person using only identical replacement parts. This will
ensure that the safety of the power tool is maintained.
Additional power tool safety warnings
@Warning!Additional safety warnings for sanders
uHold the power tool by insulated gripping surfaces,
because the sanding belt / sanding base may contact
its own cord. Cutting a "live" wire may make exposed
metal parts of the power tool "live" and could give the
operator an electric shock.
uUse clamps or another practical way to secure and
support the workpiece to a stable platform. Holding the
work by hand or against your body leaves it unstable and
may lead to loss of control.
uWarning! Contact with or inhalation of dusts arising from
sanding applications may endanger the health of the
operator and possible bystanders. Wear a dust mask
specically designed for protection against dust and fumes
and ensure that persons within or entering the work area
are also protected.
uThoroughly remove all dust after sanding.
uTake special care when sanding paint which is possibly
lead based or when sanding some woods and metal which
may produce toxic dust:
- Do not let children or pregnant women enter the work
area.
- Do not eat, drink or smoke in the work area.
- Dispose of dust particles and any other debris safely.
uThis tool is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety. Children should be supervised to ensure
that they do not play with the appliance.
uThe intended use is described in this instruction manual.
The use of any accessory or attachment or performance
ofanyoperationwiththistoolotherthanthose recommended
in this instruction manual may present a risk of personal
injury and/or damage to property.
Safety of others
uThis appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
uChildren should be supervised to ensure that they do not
play with the appliance.
Residual risks.
Additional residual risks may arise when using the tool which
may not be included in the enclosed safety warnings. These
risks can arise from misuse, prolonged use etc.
Even with the application of the relevant safety regulations
and the implementation of safety devices, certain residual
risks can not be avoided. These include:
uInjuries caused by touching any rotating/moving
parts.
uInjuries caused when changing any parts, blades or
accessories.
uInjuries caused by prolonged use of a tool. When
using any tool for prolonged periods ensure you take
regular breaks.
uImpairment of hearing.
uHealth hazards caused by breathing dust developed
when using your tool (example:- working with wood,
especially oak, beech and MDF.)
Vibration
The declared vibration emission values stated in the technical
data and the declaration of conformity have been measured in
accordance witha standard testmethod providedby EN 60745
and may be used for comparing one tool with another.
The declared vibration emission value may also be used in a
preliminary assessment of exposure.
Warning! The vibration emission value during actual use of
the power tool can differ from the declared value depending
on the ways in which the tool is used. The vibration level may
increase above the level stated.
When assessing vibration exposure to determine safety
measures required by 2002/44/EC to protect persons regularly
using power tools in employment, an estimation of vibration
exposure should consider, the actual conditions of use and the
way the tool is used, including taking account of all parts of
the operating cycle such as the times when the tool is
switched off and when it is running idle in addition to the
trigger time.

7
ENGLISH
Labels on tool
The following pictograms are shown on the tool:
:Warning! To reduce the risk of injury, the user must read the instruction manual.
Electrical safety
#This tool is double insulated; therefore no earth wire is required.Always check that the power supply
corresponds to the voltage on the rating plate.
uIf the supply cord is damaged, it must be replaced by the
manufacturer or an authorised Black & Decker Service
Centre in order to avoid a hazard.
Features
1. On/off switch
2. Lock-on button
3. Variable speed control knob
4. Adjustable handle
5. Tension lever
6. Retractable hood
7. Centring knob
8. Dust extraction outlet
Assembly
Warning! Before assembly, make sure that the tool is
switched off and unplugged.
Fittingasandingbelt(g.A)
Warning! Never use the tool without a sanding belt.
uPull the tension lever (5) outward to release the tension on
the sanding belt (9).
uRemove the old sanding belt.
uPlace a new sanding belt over the rollers. Ensure that the
arrow on the sanding belt points in the same direction as
the arrow on the tool.
uPushthetensionlever(5)inwardtotensionthesandingbelt.
Adjustingthesandingbelttracking(g.B)
To ensure a correct tracking, the sanding belt must be centred
over the rollers.
uSwitch on the tool while holding it upside down.
uTurn the centring knob (7) as required until the tracking of
the belt is centred over the rollers.
Adjustingthehandle(g.C)
The handle is adjustable to 3 positions.
uUnlock the handle (4) by pulling the locking handle (10)
outward.
u Adjust the handle in the desired position.
uLock the handle by pushing the locking handle inward.
Retractingthehood(g.D)
The hood can be retracted for sanding in conned spaces.
Warning! The hood can only be retracted when the adjustable
handle is in the up position.
u Adjust the handle (4) in the straight-up position.
uLift the hood (6) up.
u To close the hood, pull the tab (11) sideways rst.
Fittingandremovingthedustcassette(g.E)
uSlidethedustcassette(12)overthedustextractionoutlet(8).
uTo remove the dust cassette, slide it off the outlet.
Connectingavacuumcleaner(g.F)
uSlide the adaptor (13) over the dust extraction outlet (8).
uConnect the hose of the vacuum cleaner to the adaptor.
Use
Warning! Let the tool work at its own pace. Do not overload.
Variable speed control
The variable speed control allows you to adapt the speed of
the tool to the workpiece material.
uSet the control knob (3) to the desired setting. Use a high
speed for wood, medium speed for veneer and synthetics
and low speed for acrylic glass, non-ferrous metals and for
removing paints.
Switching on and off
u To switch the tool on, press the on/off switch (1).
uFor continuous operation, press the lock-on button (2) and
release the on/off switch.
u To switch the tool off, release the on/off switch. To switch
the tool off when in continuous operation, press the on/off
switch once more and release it.
Emptyingthedustcassette(g.E&G)
The dust cassette should be emptied every 10 minutes of use.
uRemove the dust cassette (12) to the rear and off the tool.
uRemove the cover (14) by twisting it clockwise.
u Hold dust cassette with the lter (15) facing down and
shake the cassette to empty the contents. Shake the
cover to empty the contents.
u Ret the cover (14) onto the dust cassette, twisting it
counterclockwise until it locks into place.
u Ret the dust cassette onto the tool.
Cleaningthedustcassettelter
The dust cassette lter is re-usable and should be cleaned
regularly.
uEmpty the dust cassette (12) as described above.
u Pull the lter (15) off the dust cassette.

8
ENGLISH
Warning! Do not twist the lter.
u Shake off excess dust by tapping the lter into a dustbin.
Warning! Do not brush or use compressed air or sharp
objects to clean the lter. Do not wash the lter.
u Replace the lter.
u Ret the cover.
u Ret the dust cassette onto the tool.
Hints for optimum use
uAlways hold the tool with both hands.
uDo not exert too much pressure on the tool.
uRegularly check the condition of the sanding belt.
Replace when necessary.
uAlways sand with the grain of the wood.
uWhen sanding new layers of paint before applying another
layer, use extra ne grit.
uOn very uneven surfaces, or when removing layers of
paint, start with a coarse grit. On other surfaces, start with
a medium grit. In both cases, gradually change to a ne
grit for a smooth nish.
uConsult your retailer for more information on available
accessories.
Accessories
The performance of your tool depends on the accessory used.
Black & Decker and Piranha accessories are engineered to
highqualitystandardsanddesignedtoenhancetheperformance
of your tool. By using these accessories you will get the very
best from your tool.
Maintenance
Your tool has been designed to operate over a long period of
time with a minimum of maintenance. Continuous satisfactory
operation depends upon proper tool care and regular cleaning.
Warning! Before performing any maintenance, switch off and
unplug the tool.
uRegularly clean the ventilation slots in your tool using
a soft brush or dry cloth.
uRegularly clean the motor housing using a damp cloth.
Do not use any abrasive or solvent-based cleaner.
Mainsplugreplacement(U.K.&Irelandonly)
If a new mains plug needs to be tted:
uSafely dispose of the old plug.
uConnectthebrownleadtotheliveterminalinthenewplug.
uConnect the blue lead to the neutral terminal.
Warning! No connection is to be made to the earth terminal.
Follow the tting instructions supplied with good quality plugs.
Recommended fuse: 5A.
Protecting the environment
ZSeparate collection. This product must not be disposed of with normal household waste.
Should you nd one day that your Black & Decker product
needs replacement, or if it is of no further use to you, do not
dispose of it with household waste. Make this product
available for separate collection.
zSeparate collection of used products and packaging allows materials to be recycled and used again.
Re-use of recycled materials helps prevent
environmental pollution and reduces the demand for
raw materials.
Local regulations may provide for separate collection of
electrical products from the household, at municipal waste
sites or by the retailer when you purchase a new product.
Black & Decker provides a facility for the collection and
recycling of Black & Decker products once they have reached
the end of their working life. To take advantage of this service
please return your product to any authorised repair agent who
will collect them on our behalf.
You can check the location of your nearest authorised repair
agent by contacting your local Black & Decker ofce at the
address indicated in this manual.Alternatively, a list of
authorised Black & Decker repair agents and full details of our
after-sales service and contacts are available on the Internet
at: www.2helpU.com
Technical data
KA89E
Type 1
Input voltage VAC 230
Power input W 750
Belt speed m/min 120 - 250
Sanding base mm 75 x 533
Weight kg 3.7
Level of sound pressure according to EN 60745:
Sound pressure (LpA) 88 dB(A), uncertainty (K) 3 dB(A)
Sound power (LWA) 99 dB(A), uncertainty (K) 3 dB(A)
Vibrationtotal values(triaxvectorsum)accordingto EN 60745:
Vibration emission value (ah) 5.3 m/s2, uncertainty (K) 1.5 m/s2

9
ENGLISH
EC declaration of conformity
MACHINERY DIRECTIVE
%
KA89E
Black & Decker declares that these products described under
"technical data" are in compliance with:
2006/42/EC, EN 60745-1, EN 60745-2-4
For more information, please contact Black & Decker at the
following address or refer to the back of the manual.
The undersigned is responsible for compilation of the technical
le and makes this declaration on behalf of Black & Decker.
_Kevin Hewitt
Vice-President Global Engineering
Black & Decker Europe, 210 Bath Road, Slough,
Berkshire, SL1 3YD
United Kingdom
30/03/2010
Guarantee
Black & Decker is condent of the quality of its products and
offers an outstanding guarantee. This guarantee statement is
in addition to and in no way prejudices your statutory rights.
The guarantee is valid within the territories of the Member
States of the European Union and the European Free Trade
Area.
If a Black & Decker product becomes defective due to faulty
materials, workmanship or lack of conformity, within24 months
from the date of purchase, Black & Decker guarantees to
replace defective parts, repair products subjected to fair wear
and tear or replace such products to ensure minimum
inconvenience to the customer unless:
uThe product has been used for trade, professional or hire
purposes;
u The product has been subjected to misuse or neglect;
uThe product has sustained damage through foreign
objects, substances or accidents;
uRepairs have been attempted by persons other than
authorised repair agents or Black & Decker service staff.
To claim on the guarantee, you will need to submit proof of
purchase to the seller or an authorised repair agent. You can
check the location of your nearest authorised repair agent by
contacting your local Black & Decker ofce at the address
indicated in this manual.Alternatively, a list of authorised
Black & Decker repair agents and full details of our after-sales
service and contacts are available on the Internet at:
www.2helpU.com
Please visit our website www.blackanddecker.co.uk to
register your new Black & Decker product and to be kept up to
date on new products and special offers. Further information
on the Black & Decker brand and our range of products is
available at www.blackanddecker.co.uk

10
DEUTSCH
Bestimmungsgemäße Verwendung
Ihr Black & Decker Schleifer wurde zum Schleifen von Holz,
Metall, Kunststoff und lackierten Oberächen entwickelt.
Dieses Gerät ist nicht für den gewerblichen Einsatz vorgesehen.
Sicherheitshinweise
Allgemeine Warnhinweise zur Sicherheit von
Elektrowerkzeugen
@Achtung! Lesen Sie sämtliche Sicherheits- warnhinweise und sonstigen Anweisungen.
Die Nichteinhaltung der nachstehend aufgeführten
Warnhinweise und sonstigenAnweisungen kann
einen elektrischen Schlag, Brand und/oder schwere
Verletzungen verursachen.
Bewahren Sie alle Warnhinweise und sonstigen
Anweisungen zur künftigen Bezugnahme auf.
Der nachfolgend verwendete Begriff "Gerät" bezieht sich auf
netzbetriebene Geräte (mit Netzkabel) und auf akkubetriebene
Geräte (ohne Netzkabel).
1. Sicherheit am Arbeitsplatz
a. Halten Sie Ihren Arbeitsbereich sauber und gut
ausgeleuchtet. Unordnung und dunkleArbeitsbereiche
fordern Unfälle geradezu heraus.
b. Arbeiten Sie mit Geräten nicht in explosionsgefährdeter
Umgebung, in der sich brennbare Flüssigkeiten, Gase
oderStäubebenden. Geräte erzeugen Funken, die den
Staub oder die Dämpfe entzünden können.
c. Halten Sie Kinder und andere Personen während der
Benutzung eines Geräts fern. Bei Ablenkung können Sie
die Kontrolle verlieren.
2. Elektrische Sicherheit
a. DerAnschlussstecker des Geräts muß in die Steckdose
passen. Der Stecker darf in keiner Weise verändert
werden. Verwenden Sie keineAdapterstecker
gemeinsam mit schutzgeerdeten Geräten.
Unveränderte Stecker und passende Steckdosen
verringern das Risiko eines elektrischen Schlages.
b. Vermeiden Sie Körperkontakt mit geerdeten
OberächenvonRohren,Heizungen,Herdenund
Kühlschränken. Es besteht ein erhöhtes Risiko eines
elektrischen Schlags, wenn Ihr Körper geerdet ist.
c. Halten Sie Geräte von Regen und Nässe fern.
Das Eindringen von Wasser in ein Gerät erhöht das Risiko
eines elektrischen Schlages.
d. Mißbrauchen Sie nicht das Kabel. Verwenden Sie das
Kabel niemals zum Tragen, Ziehen oder Trennen des
Gerätes vom Netz. Halten Sie das Kabel fern von
Hitze, Öl, scharfen Kanten oder sich bewegenden
Teilen. Beschädigte oder verwickelte Kabel erhöhen das
Risiko eines elektrischen Schlages.
e. WennSiemiteinemGerätimFreienarbeiten,verwenden
Sie nur Verlängerungskabel, die auch für den
Außenbereich zugelassen sind. Die Verwendung eines
für den Außenbereich geeigneten Verlängerungskabels
verringert das Risiko eines elektrischen Schlages.
f. FallsderBetriebdesElektrowerkzeugsineiner feuchten
Umgebung unvermeidbar ist, verwenden Sie einen mit
einem Fehlerstromschutzschalter (FI-Schutzschalter)
abgesicherten Stromkreis. Durch die Verwendung eines
FI-Schutzschalters wird das Risiko eines Stromschlags
verringert.
3. Sicherheit von Personen
a. Seien Sie aufmerksam, achten Sie darauf, was Sie tun,
und gehen Sie vernünftig mit einem Gerät um.
Benutzen Sie das Gerät nicht, wenn Sie müde sind
oderunterdemEinußvonDrogen,Alkoholoder
Medikamenten stehen. Ein Moment der Unachtsamkeit
beim Gebrauch von Geräten kann zu ernsthaften
Verletzungen führen.
b. Tragen Sie persönliche Schutzausrüstung. Tragen Sie
immer eine Schutzbrille. Das Tragen persönlicher
Schutzausrüstung, wie Staubmaske, rutschfeste
Sicherheitsschuhe, Schutzhelm oder Gehörschutz, je
nachArt und Einsatz des Elektrowerkzeuges, verringert
das Risiko von Verletzungen.
c. Vermeiden Sie eine unbeabsichtigte Inbetriebnahme.
Vergewissern Sie sich, dass der Schalter auf derAus-
Stellung steht, bevor Sie den Stecker in die Steckdose
stecken und/oder dasAkkupaket im Werkzeug stecken,
das Werkzeug aufnehmen oder tragen. Wenn Sie beim
Tragen desElektrowerkzeugsdenFingeramSchalterhaben
oder das Werkzeug eingeschaltet an die Stromversorgung
anschließen, kann dies zu Unfällen führen.
d. Entfernen Sie Einstell- oder Schraubenschlüssel,
bevor Sie das Gerät einschalten. Ein Schlüssel, der sich
in einem sich drehenden Teil bendet, kann zu
Verletzungen führen.
e. Nicht zu weit nach vorne strecken! Achten Sie auf
einen sicheren Stand, um in jeder Arbeitsposition das
Gleichgewicht zu halten. Dadurch können Sie das Gerät
in unerwarteten Situationen besser unter Kontrolle halten.
f. Tragen Sie geeignete Kleidung. Tragen Sie keine weite
Kleidung oder Schmuck. Halten Sie Haare, Kleidung
und Handschuhe fern von sich bewegenden Teilen.
Lockere Kleidung, Schmuck oder lange Haare können von
sich bewegenden Teilen erfaßt werden.
g. Falls Staubabsaug- und -auffangvorrichtungen
vorhanden sind, vergewissern Sie sich, daß diese
angeschlossen sind und richtig verwendet werden.
