Black & Decker MTSA2 User manual

MTSA2

2
A

3
B

4
C

5
ENGLISH
(Original instructions)
Intended use
Your Black & Decker multi-purpose tool has been
designed for a wide range of DIY applications.
Using the sander head (MTSA2), this tool is
intended for sanding wood, metal, plastics and
painted surfaces.
This tool is intended for consumer use only.
Safety instructions
General power tool safety warnings
@Warning! Read all safety warnings
and all instructions. Failure to follow
the warnings and instructions listed
below may result in electric shock, re
and/or serious injury.
@Warning! Read all safety warnings
and all instructions provide with your
power tool (MT143, MT350, MT108
or MT18) before using this accessory.
Failure to follow the warnings and in-
structions may result in electric shock,
re and/or serious injury.
Save all warnings and instructions for future
reference. The term “power tool” in the warnings
refers to your mains operated (corded) power tool
or battery operated (cordless) power tool.
@Warning! Additional safety warnings
for sanders
u Hold power tool by insulated gripping sur-
faces when performing an operation where
the cutting accessory may contact hidden
wiring. Cutting accessory contacting a “live”
wire may make exposed metal parts of the
power tool “live” and could give the operator an
electric shock
u Use clamps or another practical way to se-
cure and support the workpiece to a stable
platform. Holding the work by hand or against
your body leaves it unstable and may lead to
loss of control.

6
ENGLISH
(Original instructions)
@Warning! Contact with or inhalation
of dusts arising from sanding applica-
tions may endanger the health of the
operator and possible bystanders.
Wear a dust mask specically
designed for protection against dust
and fumes and ensure that persons
within or entering the work area are
also protected.
u Thoroughly remove all dust after sanding.
u Take special care when sanding paint which
is possibly lead based or when sanding some
woods and metal which may produce toxic
dust:
t Do not let children or pregnant women enter
the work area.
t Do not eat, drink or smoke in the work area.
t Dispose of dust particles and any other
debris safely.
u The intended use is described in this instruc-
tion manual. The use of any accessory or
attachment or performance of any operation
with this tool other than those recommended
in this instruction manual may present a risk of
personal injury and/or damage to property.
Features (g. A)
Tool shown is MT143. Other tools are available for
use with this tool head.
This tool includes some or all of the following
features.
10. Sander head
11. Sanding base
Assembly
Warning! Before assembly, remove the battery
from the tool.
Fitting and removing sanding sheets
(g. A)
The sanding head uses pre-cut sanding sheets.
u Lock the tool by setting the forward/reverse
slider (2) to the centre position.
u Before tting a new sheet, remove the two
additional diamond tips (12).
u To t a sanding sheet, line it up with the sand-
ing base (11) as shown.
u Press the sheet rmly and evenly onto the
sanding base, making sure that the holes in the
sheet coincide with the holes in the base.
u To remove the sheet, pull it off the sanding
pad.
Warning! Never use the sanding head without a
sanding sheet or accessory in place.

7
ENGLISH
(Original instructions)
Replacing the diamond sanding tip (g. B)
Sanding sheets are supplied with two replacement
diamond tips. The diamond tip can be reversed
when worn. When both sides are worn, replace the
diamond tip.
u Lock the tool by setting the forward/reverse
slider (2) to the centre position.
u To reverse the tip, remove it, turn it 180° and
press it back onto the base.
u To replace the tip, pull the old tip off the base
and press a new one onto the base.
Warning! When removing the tip from the pad, be
careful not to pull the pad off the sanding base.
Fitting and removing the dust extraction
adaptor (g. C)
u Line up the dust extraction adaptor (13) with
the sanding head (10) as shown.
u Press the adaptor rmly and evenly in to the
sanding base.
u Connect a vacuum cleaner to the dust extrac-
tion adaptor.
u To remove, pull the dust extraction adaptor (13)
out of the sanding head (10).
Use
Warning! Let the tool work at its own pace. Do not
overload.
Sanding
Note: Ensure the forward reverse slider (2) is not
in the locked position.
u To switch the tool on, press the variable speed
switch (1). The tool speed depends on how far
you press the switch.
u To switch the tool off, release the variable
speed switch.
Hints for optimum use
Sanding
u Do not exert too much pressure on the tool.
u Regularly check the condition of the sanding
sheet. Replace when necessary.
u When sanding new layers of paint before ap-
plying another layer, use extra ne grit.
u On very uneven surfaces, or when removing
layers of paint, start with a coarse grit. On
other surfaces, start with a medium grit. In
both cases, gradually change to a ne grit for a
smooth nish.
u Consult your retailer for more information on
available accessories for sanding, polishing,
stripping and scrubbing.

8
ENGLISH
(Original instructions)
Accessories
The performance of your tool depends on the
accessory used. Black & Decker and Piranha ac-
cessories are engineered to high quality standards
and designed to enhance the performance of your
tool. By using these accessories you will get the
very best from your tool.
Technical data
MTSA2
(14.4V) (H1)
MTSA2
(Max) (H1)
No-load speed min-1
0-7500 0-8500
Weight
kg 1.3 1.3
Level of sound pressure according to EN 60745:
Sound pressure (LpA) 76.4 dB(A), uncertainty (K) 3 dB(A)
Sound power (LWA) 87.4 dB(A), uncertainty (K) 3 dB(A)
Vibration total values (triax vector sum) according to EN 60745:
Sanding (ah) 4.5 m/s2, uncertainty (K) 1.5 m/s2
Guarantee
Black & Decker is condent of the quality of its
products and offers an outstanding guarantee. This
guarantee statement is in addition to and in no way
prejudices your statutory rights. The guarantee is
valid within the territories of the Member States of
the European Union and the European Free Trade
Area.
If a Black & Decker product becomes defective
due to faulty materials, workmanship or lack of
conformity, within 24 months from the date of
purchase, Black & Decker guarantees to replace
defective parts, repair products subjected to fair
wear and tear or replace such products to ensure
minimum inconvenience to the customer unless:
u The product has been used for trade, profes-
sional or hire purposes;
u The product has been subjected to misuse or
neglect;
u The product has sustained damage through
foreign objects, substances or accidents;
u Repairs have been attempted by persons
other than authorised repair agents or Black &
Decker service staff.

9
ENGLISH
(Original instructions)
To claim on the guarantee, you will need to submit
proof of purchase to the seller or an authorised
repair agent. You can check the location of your
nearest authorised repair agent by contacting
your local Black & Decker ofce at the address
indicated in this manual. Alternatively, a list of
authorised Black & Decker repair agents and full
details of our after-sales service and contacts are
available on the Internet at: www.2helpU.com
Please visit our website www.blackanddecker.
co.uk to register your new Black & Decker product
and to be kept up to date on new products and
special offers. Further information on the Black &
Decker brand and our range of products is avail-
able at www.blackanddecker.co.uk
EC declaration of conformity
MACHINERY DIRECTIVE
%
MTSA2
Black & Decker declares that these products
described under “technical data” are in compliance
with:
2006/42/EC, EN60745-1, EN60745-2-4
These products also comply with Directive
2004/108/EC and 2011/65/EU. For more informa-
tion, please contact Stanley Europe at the following
address or refer to the back of the manual.
The undersigned is responsible for compilation of
the technical le and makes this declaration on
behalf of Black & Decker.
_Kevin Hewitt
Vice-President Global Engineering
Black & Decker Europe, 210 Bath Road, Slough,
Berkshire, SL1 3YD
United Kingdom
13/07/2012

10
(Übersetzung der ursprünglichen Anweisungen)
DEUTSCH
Bestimmungsgemäße Verwendung
Das Black & Decker Multifunktionswerkzeug wurde
für zahlreiche Heimwerkerarbeiten entwickelt.
Mit dem Schleifkopf (MTSA2) ist das Gerät
zum Schleifen von Holz, Metall, Kunststoff und
gestrichenen Oberächen ausgelegt.
Dieses Gerät ist nicht für den gewerblichen Einsatz
bestimmt.
Sicherheitshinweise
Allgemeine Sicherheitswarnungen für das
Gerät
@Achtung! Lesen Sie sämtliche Sicher-
heitswarnungen und Anweisungen.
Die Nichteinhaltung der folgenden
Warnungen und Anweisungen kann
einen elektrischen Schlag, Brand
und/oder schwere Verletzungen
verursachen.
@Achtung! Lesen Sie vor Inbetrieb-
nahme sämtliche Sicherheitshinweise
und Anweisungen, die im Lieferum-
fang des Geräts (MT143, MT350,
MT108 oder MT18) enthalten sind.
Die Nichteinhaltung der nachstehend
aufgeführten Warnhinweise und
Anweisungen kann einen elektrischen
Schlag, Brand und/oder schwere
Verletzungen verursachen.
Bewahren Sie alle Sicherheitswarnungen und
Anweisungen gut auf. Der Begriff “Gerät” bezieht
sich auf netzbetriebene Geräte (mit Netzkabel) und
auf akkubetriebene Geräte (ohne Netzkabel).
@Achtung! Zusätzliche Sicherheit-
swarnungen für Schleifgeräte
u Halten Sie das Gerät an den isolierten
Griffächen fest, wenn Sie Arbeiten aus-
führen, bei denen verdeckte Kabel durch
Werkzeuge beschädigt werden könnten.
Der Kontakt mit stromführenden Leitungen
kann auch offenliegende Metallteile am Gerät
unter Strom setzen und zu einem Stromschlag
führen.
