BLACK DECKER BEBLV230 User manual

www.blackanddecker.com.au
www.blackanddecker.co.nz
12
3
5
7
8
10
11
6
1
4
4
2
9
12
BEBLV230

23
A
12
B
13
14
C
D
35
E
6 6a 5a 5 3

23
10a
10
G
11
11a
F
H
I
J
1

45
3
13
14
5
K
MN
O
L
12
P

45
Intended use
Your BLACK+DECKERTM BEBLV230 blower vacs have been
designed for leaf clearing. These appliances are intended for
consumer and outdoor use only.
General appliance safety
warnings
Warning! When using mains
powered/cordless
appliances, basic safety precautions,
including the following, should always be
followed to reduce the risk of re, electric
shock, personal injury and material
damage.
uRead all of this manual carefully before
using the appliance, be familiar with
the controls and the proper use of the
appliance.
uThe intended use is described in this
manual. The use of any accessory
or attachment or the performance
of any operation with this appliance
other than those recommended in this
instruction manual may present a risk
of personal injury.
7
811a
7
8
9
Q R
S
7
14
T

6
ENGLISH (Original instructions)
The term "appliance" in all of the warn-
ings listed below refers to your mains
operated (corded) appliance or battery
operated (cordless) appliance.
Save all warnings and instructions for
future reference.
Save all warnings and instructions for
future reference.
Using your appliance
uAlways take care when using the
appliance.
uKeep work area clean and well
lit. Cluttered or dark areas invite
accidents.
uOnly use the appliance in daylight or
good articial light.
uDo not operate your appliance in
explosive atmospheres, such as in the
presence of ammable liquids, gases
or dust.
uNever allow children or people
unfamiliar with the instructions to use
the appliance, local regulations may
restrict the age of the operator.
uDo not allow children or animals to
come near the work area or touch the
appliance supply cord.
uKeep children, bystanders and animals
away while operating an appliance.
Distractions can cause you to lose
control.
uThe appliance is not to be used as a
toy.
uDo not immerse the appliance in water.
uDo not open body casing. There are
no user serviceable parts inside.
Personal safety
uStay alert, watch what you are doing
and use common sense when
operating an appliance. Do not use an
appliance while you are tired or under
the inuence of drugs, alcohol or
medication. A moment of inattention
while operating an appliance may
result in serious personal injury.
uWhere required, use personal
protective equipment.
Protective equipment such as eye
protection, dust mask, non-skid safety
shoes, hard hat, or hearing protection
used for appropriate conditions will
reduce personal injuries.
uPrevent unintentional starting. Make
sure that the switch is in the off
position before connecting to a power
source and/or battery pack, picking up
or carrying the appliance.
Carrying appliances with your nger
on the switch or energising appliances
that have the switch on invites
accidents.
uDo not overreach. Keep proper footing
and balance at all times. This enables
better control of the appliance in
unexpected situations.
uDress properly. Do not wear loose
clothing or jewellery. Keep your hair,
clothing and gloves away from moving
parts. Loose clothes, jewellery or long
hair can be caught in moving parts.

7
ENGLISH
(Original instructions)
Appliance use and care
uBefore use, check the appliance for
damaged or defective parts.
Check for breakage of parts, damage
to switches and any other conditions
that may affect its operation.
uDo not use the appliance if the switch
does not turn it on and off. Any
appliance that cannot be controlled
with the switch is dangerous and must
be repaired.
uDisconnect the plug from the power
source and/or the battery pack from
the appliance before making any
adjustments, changing accessories,
or storing appliances. Such preventive
safety measures reduce the risk of
starting the appliance accidentally.
uWhere applicable, keep cutting tools
sharp and clean. Properly maintained
cutting tools with sharp cutting edges
are less likely to bind and are easier to
control.
uDo not use the appliance if any part is
damaged or defective.
uHave any damaged or defective parts
repaired or replaced by an authorised
repair agent.
uNever attempt to remove or replace
any parts other than those specied in
this manual.
Electrical safety
uAppliance plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) appliance.
Unmodied plugs and matching outlets
will reduce risk of electric shock.
uDo not expose appliance to rain or wet
conditions. Water entering a appliance
will increase the risk of electric shock.
uDo not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the appliance. Keep cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase
the risk of electric shock.
uWhen operating an appliance
outdoors, use an extension cord
suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the
risk of electric shock.
uIf operating an appliance in a damp
location is unavoidable, use a Residual
Current Device (RCD) protected
supply. Use of an RCD reduces the
risk of electric shock.
After Use
uWhen not in use, the appliance should
be stored in a dry, well ventilated place
out of the reach of children.
uChildren should not have access to
stored appliances.
uWhen the appliance is stored or
transported in a vehicle it should be
placed in the boot or restrained to
prevent movement following sudden
changes in speed or direction.
Service
uHave your appliance serviced by a
qualied repair person using only
identical replacement parts.

8
ENGLISH (Original instructions)
This will ensure that the safety of the
appliance is maintained.
Additional Safety instructions
for blow vacs
The intended use is described in
this manual. The use of any accessory
or attachment or performance of any
operation with this appliance other than
those recommended in this instruction
manual can present a risk of personal
injury and/or damage to property.
uTo protect your feet and legs while
operating the appliance, always wear
heavy duty footwear and long trousers.
uDo not use in vacuum mode without
the vacuum tubes and collection bag in
place.
uAlways switch off your product, allow
the fan to stop and remove the plug
from the socket when:
uChanging from blower to vacuum.
uThe supply cable has become
damaged or entangled.
uYou leave your product unattended.
uClearing a blockage.
uChecking, adjusting, cleaning or
working on your product.
uIf the appliance starts to vibrate
abnormally.
uDo not place the inlet or outlet of
the vacuum near eyes or ears when
operating.
uNever blow debris in the
direction of bystanders.
uDo not use in the rain or leave
outdoors while it is raining.
uDo not cross gravel paths or roads
whilst your product is switched on
during blow/vac mode.
uWalk, never run.
uDo not place your unit down on gravel
while it is switched on.
uAlways be sure of your footing,
particularly on slopes.
uDo not overreach and keep your
balance at all times.
uDo not pick up matter that may be
contaminated with ammable or
combustible liquids such as gasoline,
or use in areas where they might be
present.
uDo not place any objects into the
openings. Never use if the openings
are blocked - keep free of hair, lint,
dust and anything that may reduce the
airow.
Warning! Always use your product in the
manner outlined in this manual.
Your product is designed to be used in an
upright mode and if it is used in any other
way it may result in injury. Never run your
product whilst lying on it’s side or upside
down.
uThe operator or user is responsible for
accidents or hazards occurring to other
people or their property.
uDo not carry the appliance by the
cable.
uAlways direct the cable to the rear
away from the appliance.
Warning! If a cord becomes damaged
during use, disconnect the supply cord
from the mains supply immediately.

9
ENGLISH
(Original instructions)
Always check that the power supply
corresponds to the voltage on the rating
plate.
uIf the supply cord is damaged, it must
be replaced by the manufacturer or
an authorised BLACK+DECKER
Service Centre in order to avoid a
hazard.
uElectric safety can be further improved
by using a highsensitivity 30 mA
Residual Current Device (RCD).
Using an extension cable
Always use an approved extension
cable suitable for the power input of this
tool (see technical data). The extension
cable must be suitable for outdoor use
and marked accordingly. Up to 30 m of
1.5 mm² HO5V V-F extension cable can
be used without loss of product perfor-
mance. Before use, inspect the extension
cable for signs of damage, wear and age-
ing. Replace the extension cable if dam-
aged or defective. When using a cable
reel, always unwind the cable completely.
Residual risks
Additional residual risks may arise when
using the tool which may not be included
in the enclosed safety warnings.
These risks can arise from misuse, pro-
longed use etc. Even with the application
of the relevant safety regulations and the
implementation of safety devices, certain
residual risks can not be avoided. These
include:
Do not touch the supply cord before
disconnecting the supply.
uDo not use solvents or cleaning uids
to clean your product. Use a blunt
scraper to remove grass and dirt.
uCheck the collection bag frequently for
wear or deterioration.
uReplacement fans are available from a
BLACK+DECKER service agent. Use
on BLACK+DECKER recommended
spare parts and accessories.
uKeep all nuts bolts and screws tight to
make sure that the appliance is in a
safe working condition.
Safety of others
uThis appliance can be used by children
aged from 8 years and above and
persons with reduced physical,
sensory or mental capabilities or lack
of experience and knowledge if they
have been given supervision or
instruction concerning use of the
appliance in a safe way and
understand the hazards involved.
Children shall not play with the
appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
uChildren should be supervised to
ensure that they do not play with the
appliance.
Electrical safety
This appliance is double
insulated; therefore no earth wire
is required.

10
ENGLISH (Original instructions)
uInjuries caused by touching any
rotating/ moving parts.
uInjuries caused when changing any
parts, blades or accessories.
uInjuries caused by prolonged use
of a tool. When using any tool for
prolonged periods ensure you take
regular breaks.
uImpairment of hearing.
uHealth hazards caused by breathing
dust developed when using your tool
(example:- working with wood,
especially oak, beech and MDF.).
Vibration
The declared vibration emission values
stated in the technical data and the
declaration of conformity have been
measured in accordance with a standard
test method provided by EN50636 and
may be used for comparing one tool with
another. The declared vibration emission
value may also be used in a preliminary
assessment of exposure.
Warning! The vibration emission value
during actual use of the power tool can
differ from the declared value depending
on the ways in which the tool is used.
The vibration level may increase above
the level stated.
When assessing vibration exposure to
determine safety measures required by
2002/44/EC to protect persons regularly
using power tools in employment, an
estimation of vibration exposure should
consider, the actual conditions of use and
the way the tool is used, including tak-
ing account of all parts of the operating
cycle such as the times when the tool is
switched off and when it is running idle in
addition to the trigger time.
Labels on Appliance
The following pictograms, along with the
date code, are shown on the tool.
Warning! Read the manual
prior to operation.
Wear safety glasses or goggles
when operating this appliance.
Wear suitable ear protection
when operating this appliance.
Do not expose the tool to rain or
high humidity or leave outdoors
while it is raining.
Switch off: remove plug from
mains before cleaning or mainte-
nance.
Disconnect the mains plug if
the cord becomes damaged or
entangled.
Beware of ying objects.
Keep bystanders away.
Directive 2000/14/EC guaran-
teed sound power.
Features
This appliance includes some or all of the following features.
1. On/Off switch - speed control
2. Front handle
3. Back handle
4. Power head
5. Upper vacuum tube
6. Lower vacuum tube
7. Upper blower tube
8. Lower blower tube
9. Concentrator

11
ENGLISH
(Original instructions)
uUnclip the the catch (10a) on the back pack collection bag
(g I).
uUnfold the opening of the back pack collection pack (g J).
uOpen the back pack collection pack (g K) and proceed to
empty its contents.
uTo seal the collection bag, hold the exible bars together
and roll 2-3 times (g L).
uLatch the retaining clip (10a) as shown in gure M.
Warning! Never remove the collection bag without rst turning
off and unplugging the appliance.
Note: If the suction decreases and the bag is not full, the
vacuum tube is probably clogged with debris. Turn off and
unplug the vacuum and clear the tube before continuing.
uWhen task is complete, rotate the assembled vacuum
tube anticlockwise to release the bayonet fixing. Insert the
rod (14) into the fan guard release (13) and push upwards
to release the assembled vacuum tube. Remove the
assembled vacuum tube from the powerhead as shown in
figure N.
uReplace the fan guard assembly as shown in figure O.
uRotate the fan guard assembly clockwise as shown in
gure P.
Blower mode (g. Q, R, S, T)
uAssemble the upper blow tube (7), the lower blow tube (8)
and the optional concentrator (9) as shown in figure Q.
uPush the assembled blow tube onto the vacuum outlet
(11a) until the lock engages tightly with the blow tube as
shown in figure R.
Warning! Never operate in Blow mode without the blow tube
firmly in place.
uHold the blow tube approximately 180 mm above the
ground, switch on the appliance and using a sweeping
motion from side to side, advance slowly keeping the
accumulated debris/leaves in front of you (fig. S).
uOnce you have blown the debris/leaves into a pile, you
can remove the blow tube assembly by inserting the rod
(14) into the aperture on the vacuum head and pushing
down to release the lock as shown in figure T.
uNow you can convert to vacuum mode and collect the
debris.
Troubleshooting
Problem Possible solution
Failure to operate
Check the connection to the power supply
Check the fuse in the plug, if blown, replace
(UK only).
Check that the blow/vacuum tube assembly is
correctly tted to the powerhead.
If the fuse continues to blow - immediately
disconnect from the mains power supply and
consult your local BLACK+DECKER
authorisedrepair agent.
10. Collection bag
11. Bag connector
Using your product
Warning! When using as a blower or vacuum, always wear
safety glasses. If using in dusty conditions, wear a lter mask
as well.
Warning! Switch off your product, allow the fan to stop and
remove the plug from the socket before carrying out any
adjustment, servicing or maintenance.
Assembly
Warning! Before assembly, make sure that the
appliance is switched off and unplugged.
Warning! Always wear protective gloves when
working with your blow vac.
Vacuum tube assembly (g. A)
The vacuum tubes must be assembled together before use.
Warning! Do not operate the appliance with the vacuum
tubes separated.
uTo ease assembly, apply a soapy water solution to the
joint area.
uAlign the notches (5a) and the recesses (6a) on the upper
(5) and lower (6) vacuum tubes.
uPush the lower vacuum tube (6) firmly onto the upper
vacuum tube (5) until they click into place.
Warning! Do not separate the tubes once assembled.
Vacuum mode (g. B, C, D, E, F, G, H, I, J, K, L, M)
uRotate the fan guard assembly anti-clockwise as (g. B).
uInsert the rod (14) (supplied) into the fan guard release
(13) and push upward to release the fan guard assembly
(12) as shown in figure C.
uDrop the fan guard assembly (12) forward as shown in
figure D.
uInsert the assembled vacuum tube (5) into the available
recess in the power head (4) as shown in figure E.
uRotate the assembled vacuum tube clockwise so that the
bayonet fixing locks into place as shown in figure E.
uInsert the collection bag connector (11) onto the power
head receptacle (11a) as shown in figure F.
uPlace the straps from the collection bag (10) over your
shoulders (fig. G) this will support the additional weight as
the back pack collection bag fills.
uPosition the vacuum tube slightly above the debris/leaves.
Switch on the appliance by pushing the On/Off switch (1)
upwards (fig.H insert) and use a sweeping motion; the
debris/leaves will be sucked up the tube, and thrown into
the collection bag (10) (fig. H).
uAs the bag lls, the power of the suction will decrease,
switch off the appliance and unplug from the mains power
supply.

12
ENGLISH (Original instructions)
Poor vacuum/high
pitched whine
Switch off - disconnect from the mains power
supply, debris should fall clear of the tube.
Remove and empty the collection bag.
Check that both the inlet and exit ports on the
vacuum tube are clear.
Remove any debris from the fan area.
If poor vacuuming continues - immediately
disconnect from the mains power supply and
consult your local BLACK+DECKER
authorised
repair agent
Maintenance
Your BLACK+DECKER appliance has been designed
to operate over a long period of time with a minimum of
maintenance.
Continuous satisfactory operation depends upon proper
appliance care and regular cleaning.
uKeep the appliance clean and dry.
uRemove any leaves stuck to the inside of the vacuum
tube.
uRegularly clean the ventilation slots with a clean, dry paint
brush.
uRegularly clean the collection bag and ensure that it is
clean and empty after each use.
uTo clean the appliance, use only mild soap and a damp
cloth. Never let any liquid get inside the tool and never
immerse any part of the tool into liquid. Do not use any
abrasive or solvent-based cleaner.
uSelf lubricating bearings are used in your product,
therefore lubrication is not required.
Protecting the environment
Separate collection. Products and batteries marked
with this symbol must not be disposed of with
normal household waste.
Products and batteries contain materials that can be
recovered or recycled reducing the demand for raw materials.
Please recycle electrical products and batteries according to
local provisions. Further information is available at
www.2helpU.com
Technical data
BEBLV230
Input voltage VAC 230
Power Input W 2300
Capacity L 55
Weight (blower) kg 3.6
Weight (vaccum) kg 4.4
Level of sound pressure according to EN 50636-2-100
Sound pressure level at the operator position: (LpA) 90.0 dB(A), uncertainty
(K) 1.2 dB(A)
Sound power level (LWA) 102.5 dB(A), uncertainty (K) 1.1 dB(A)
Vibration total values (triax vector sum) according to EN 50636-2-100
Vibration (ah) 2.5 m/s2, uncertainty (K) 1.5 m/s2
EC declaration of conformity
MACHINERY DIRECTIVE
OUTDOOR NOISE DIRECTIVE
%
BEBLV230 - Blower Vac
Black & Decker declares that these products described under
"technical data" are in compliance with:
2006/42/EC, EN60335-1:2012+A11:2014+A13:2017;
EN50636-2-100:2014
2000/14/EC, Blow Vac, Annex V
DEKRA Quality B.V., Utrechtseweg 310, 6802 ED Arnhem,
The Netherlands Notified Body ID No.: 0344
Level of accoustic power according to 2000/14/EC
(Article 13, Annex III):
Sound power level: LwA: 102,5 dB(A); K=1,1 dB(A)
The guarantee sound power level: LWA: 104 dB(A)
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact Black &
Decker at the following address or refer to the back of the
manual.

13
ENGLISH (Original instructions)
The undersigned is responsible for compilation of the techni-
cal le and makes this declaration on behalf of
Black & Decker.
R. Laverick
Director of Engineering
Black & Decker Europe, 270 Bath Road, Slough,
Berkshire, SL1 4DX
United Kingdom
16/10/2018
Australia & New Zealand
SSttanley Black & Decker
www.blackanddecker.com.au
www.blackanddecker.co.nz
Tel.[phone] (Aust) or Tel. [phone] (NZ)
810 Whitehorse Road Box Hill VIC 3128, Australia

N794694
08/2020
