BLACK DECKER PV1820LAVC User manual

www.blackanddecker.co.uk PV1820LAVC
Operating instructions in the back

2
ENGLISH (Original instructions)
3
ENGLISH
(Original instructions)
Intended use
Your Black & Decker Dustbuster® handheld vacuum cleaner
has been designed for vacuum cleaning purposes. This
appliance is intended for household use only.
Read all of this manual carefully before operating
the appliance.
Safety instructions
@Warning! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions listed below may result in electric shock,
re and/or serious injury.
@Warning! When using battery-powered appliances, basic safety precautions, including the following,
should always be followed to reduce the risk of re,
leaking batteries, personal injury and material dam-
age.
uRead all of this manual carefully before using the appli-
ance.
uThe intended use is described in this manual. The use of
any accessory or attachment or the performance of any
operation with this appliance other than those recom-
mended in this instruction manual may present a risk of
personal injury.
uRetain this manual for future reference.
Using your appliance
uDo not use the appliance to pick up liquids or any materi-
als that could catch re.
uDo not use the appliance near water.
uDo not immerse the appliance in water.
uNever pull the charger lead to disconnect the charger from
the socket. Keep the charger lead away from heat, oil and
sharp edges.
uThis appliance is not intended for use by persons (includ-
ing children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concern-
ing the use of the appliance by a person responsible for
their safety.
uChildren should be supervised to ensure that they do not
play with the appliance.
Inspection and repairs
uBefore use, check the appliance for damaged or defective
parts. Check for breakage of parts, damage to switches
and any other conditions that may affect its operation.
uDo not use the appliance if any part is damaged or defec-
tive.
uHave any damaged or defective parts repaired or replaced
by an authorized repair agent.
uRegularly check the charger lead for damage. Replace the
charger if the lead is damaged or defective.
uNever attempt to remove or replace any parts other than
those specied in this manual.
Additional safety instructions
After use
uUnplug the charger before cleaning the charger or charg-
ing base.
uWhen not in use, the appliance should be stored in a dry
place.
uChildren should not have access to stored appliances.
Residual risks.
Additional residual risks may arise when using the tool which
may not be included in the enclosed safety warnings. These
risks can arise from misuse, prolonged use etc.
Even with the application of the relevant safety regulations
and the implementation of safety devices, certain residual
risks can not be avoided. These include:
uInjuries caused by touching any rotating/moving parts.
uInjuries caused when changing any parts, blades or ac-
cessories.
uInjuries caused by prolonged use of a tool. When using
any tool for prolonged periods ensure you take regular
breaks.
uImpairment of hearing.
uHealth hazards caused by breathing dust developed when
using your tool (example:- working with wood, especially
oak, beech and MDF.)
Batteries and chargers
Batteries
uNever attempt to open for any reason.
uDo not expose the battery to water.
uDo not expose the battery to heat.
uDo not store in locations where the temperature may
exceed 40°C.
uCharge only at ambient temperatures between 10°C and
40°C.
uCharge only using the charger provided with the appli-
ance. Using the wrong charger could result in an electric
shock or overheating of the battery.
uWhen disposing of batteries, follow the instructions given
in the section "Protecting the environment".
uDo not damage/deform the battery pack either by puncture
or impact, as this may create a risk of injury and re.

2
ENGLISH (Original instructions)
3
ENGLISH
(Original instructions)
uDo not charge damaged batteries.
uUnder extreme conditions, battery leakage may occur.
When you notice liquid on the batteries carefully wipe the
liquid off using a cloth. Avoid skin contact.
uIn case of skin or eye contact, follow the instructions
below.
Warning! The battery uid may cause personal injury or
damage to property. In case of skin contact, immediately rinse
with water. If redness, pain or irritation occurs seek medical
attention. In case of eye contact, rinse immediately with clean
water and seek medical attention.
Chargers
Your charger has been designed for a specic voltage. Always
check that the mains voltage corresponds to the voltage on
the rating plate.
Warning! Never attempt to replace the charger unit with a
regular mains plug.
uUse your Black & Decker charger only to charge the
battery in the appliance with which it was supplied. Other
batteries could burst, causing personal injury and damage.
uNever attempt to charge nonrechargeable batteries.
uIf the supply cord is damaged, it must be replaced by the
manufacturer or an authorised Black & Decker Service
Centre in order to avoid a hazard.
uDo not expose the charger to water.
uDo not open the charger.
uDo not probe the charger.
uThe appliance/battery must be placed in a well ventilated
area when charging.
Electrical safety
Symbols on the charger
Read all of this manual carefully before using the
appliance.
#This tool is double insulated; therefore no earth wire is required. Always check that the power supply
corresponds to the voltage on the rating plate.
wShort circuit proof safety isolating transformer. The mains supply is electrically separated from the
transformer output.
xThe charger automatically shuts off if the ambient temperature becomes too high. As a consequence
the charger will be inoperable. The charging base
must be disconnected from the mains supply and
taken to an authorised service centre for repair.
$The charging base is intended for indoor use only.
Maintenance
Your Black & Decker cordless appliance has been designed
to operate over a long period of time with a minimum of main-
tenance. Continuous satisfactory operation depends upon
proper tool care and regular cleaning.
Warning! Before performing any maintenance on cordless
appliances:
uRun the battery down completely if it is integral and then
switch off.
uUnplug the charger before cleaning it. Your charger does
not require any maintenance apart from regular cleaning.
uRegularly clean the ventilation slots in your appliance/
charger using a soft brush or dry cloth.
uRegularly clean the motor housing using a damp cloth. Do
not use any abrasive or solvent-based cleaner.
Protecting the environment
ZSeparate collection. This product must not be disposed of with normal household waste.
Should you nd one day that your Black & Decker product
needs replacement, or if it is of no further use to you, do not
dispose of it with household waste. Make this product avail-
able for separate collection.
zSeparate collection of used products and packaging allows materials to be recycled and used again.
Re-use of recycled materials helps prevent environ-
mental pollution and reduces the demand for raw
materials.
Local regulations may provide for separate collection of elec-
trical products from the household, at municipal waste sites or
by the retailer when you purchase a new product.
Black & Decker provides a facility for the collection and
recycling of Black & Decker products once they have reached
the end of their working life. To take advantage of this service
please return your product to any authorised repair agent who
will collect them on our behalf.
You can check the location of your nearest authorised repair
agent by contacting your local Black & Decker ofce at
the address indicated in this manual. Alternatively, a list of
authorised Black & Decker repair agents and full details of our
after-sales service and contacts are available on the Internet
at: www.2helpU.com

4
ENGLISH (Original instructions)
5
ENGLISH
(Original instructions)
Guarantee
Black & Decker is condent of the quality of its products and
offers an outstanding guarantee. This guarantee statement is
in addition to and in no way prejudices your statutory rights.
The guarantee is valid within the territories of the Member
States of the European Union and the European Free Trade
Area.
If a Black & Decker product becomes defective due to faulty
materials, workmanship or lack of conformity, within 24
months from the date of purchase, Black & Decker guarantees
to replace defective parts, repair products subjected to fair
wear and tear or replace such products to ensure minimum
inconvenience to the customer unless:
uThe product has been used for trade, professional or hire
purposes;
uThe product has been subjected to misuse or neglect;
uThe product has sustained damage through foreign
objects, substances or accidents;
uRepairs have been attempted by persons other than
authorised repair agents or Black & Decker service staff.
To claim on the guarantee, you will need to submit proof of
purchase to the seller or an authorised repair agent. You can
check the location of your nearest authorised repair agent
by contacting your local Black & Decker ofce at the address
indicated in this manual. Alternatively, a list of authorised
Black & Decker repair agents and full details of our after-
sales service and contacts are available on the Internet at:
www.2helpU.com
Please visit our website www.blackanddecker.co.uk to register
your new Black & Decker product and to be kept up to date
on new products and special offers. Further information on the
Black & Decker brand and our range of products is available
at www.blackanddecker.co.uk
Do not forget to register your product!
www.blackanddecker.co.uk/productregistration Register your
product online at www.blackanddecker.co.uk/productreg-
istration or send your name, surname and product code to
Black & Decker in your country.
Australia
Black & Decker (Australia) Pty. Ltd. Tel. [phone]
20 Fletcher Road, Mooroolbark, Fax [phone]
Victoria, 3138
New Zealand
Black & Decker Tel. [phone]
5 Te Apunga Place Fax [phone]
Mt Wellington
Auckland 1060
United Kingdom
Black & Decker Tel. [phone]
210 Bath Road Fax [phone]
Slough, Berkshire SL1 3YD

4
ENGLISH (Original instructions)
5
ENGLISH
(Original instructions)

PB 6
LED paterns Sollution
Battery hot Allow to cool before continuing.
LED Patern : charging Sollution
Battery fault Ensure correct charger is being used. Retry
charging procedure. If fault continues, return unit
to an authorised Black & Decker service centre.
Charger fault
Troubleshooting
PV1820LAVC
(H1)
Voltage Vdc
18
Battery Typ.
Li-Ion
Weight kg
1.38
Charger
SO 1 OQB2300040
Input voltage Vac
100-240
Output voltage Vdc
23
Current mA
400
Approximate charge time h
4
Weight
kg 0.21
Technical data

9
7
ENGLISH (Original instructions)
9
ENGLISH
(Original instructions)
Features
This tool includes some or all of the following features.
1. On/off switch
2. Nozzle rotate button
3. Charging indicator
4. Nozzle
5. Bowl release button
6. Integrated crevice tool
7. Brush tool
8. Dust bowl door
9. Dust bowl door release
10. Removable dust bowl
11. Charging base
12. Right angle brush tool
13. Hose
14. Hose connector
15. Crevice tool
Wall Mounting
The product can be attached to a wall to provide a convenient
storage and charging point for the appliance.
When xing to a wall, make sure that the xing method is
suitable for the wall type and is appropriate to the weight of
the appliance.
uMark the location of the screw holes (within reach of an
electrical outlet for chargeing the vac while it is on the wall
bracket).
Replacing the lters
The lters should be replaced every 6 to 9 months and when-
ever worn or damaged.
Replacement lters are available from your Black & Decker
dealer (cat. no. VF90):
Fitting the accessories (g D)
The appliance is supplied with the following accessories:
uA right angle brush tool (12) for upholstery
uAn extension hose (13)
uA hose connector (14)
uA crevice tool (15) for deep openings
To t an accessory, proceed as follows:
uFit the hose connector (14) onto the nose of the appliance
and attach one end of the hose (13) to the connector.
uAttach the right-angled brush tool (12) or the crevice tool
(15) to the other end of the hose.
uWhen not in use, the accessories can be stored in the
storage bag (Provided).
Battery
ZIf you want to dispose of the product yourself, the battery must be removed as described below and
disposed of in accordance with local regulations.
uRun the battery down completely.
uRemove the dust bowl.
uRemove the two screws and lift off the housing.
uDetach all lead connections from the battery pack.
uRemove battery pack and place in suitable packaging to
ensure that the terminals cannot be short-circuited.
uTake the battery to your service agent or to a local recy-
cling station.
Once removed, the battery cannot be retted.

10
10
ENGLISH (Original instructions)
8
ENGLISH
(Original instructions)
Features
15
12
13
14

97
Wash
6
2
1
543
Dry thoroughly

810
Re-assemble after cleaning the lter or continue to wash.
Clean lter
3 4 5
1 2

11 5
Brush
Emptying
1 2
In order to keep the suction force optimised,
the lters must be cleared regularly during use.

612
Use
Crevice tool
1 2
12 3
1 2

13 3
LED paterns
Battery low
Battery empty
On
On
Battery hot

414
Charging
LED paterns
Battery fault
Battery hot
Charger fault
The appliance can be left connected to the charger and may
become warm during use.

15 3
Charging
1
23
4
Remove tag
Off
The light will go out when charging is complete.

2
N734693 REV-0 05/2019
Operating Instructions
