Black Lion Audio PG-1 User manual

P-1
Professional Power Condioner
Thank you for purchasing the Black Lion Audio PG 1 ProfessionalPowerCondioner. The PG 1 is
a single rack unit line power monitor and condioner. This product was designed and
engineered by Black Lion Audio in Chicago, IL USA.
At Black Lion Audio, we believe in pung sound quality first. We strive to offer mindblowing
products at incredible prices. We are commied to connuously innovang in pursuit of the
perfect sound. We live and breathe gear and can’t imagine doing anything else. We hope you
enjoy this product and share in our passionfor all things audio.

IMPORTANT
Be sure to use a three prong AC cable that properly fits the power
source. Please use the correct fuse designated on the rear panel before
plugging in the power cord. Improper selection can result in damage to the
unit that will not be covered under the warranty.
Engineering Objecve: We wanted to build a world class power condioner worthy of use with
our classic studio gear. Many units on the market today do not strive forthe absolute minimum
of noise on the AC outputs. We included high grade Japanese power supply caps, high quality
film caps and generally the best construcon we could manage.
Since every studio’s objecve is a noise free signal chain, we feel it is important to start at the
source. Clean power equals clean sound. Also, with the costly investment in all of that cool

gear, protecon from harmful surges and degradaon in wiring is important.
We haveincluded separate outputs for both analog and digital equipment to prevent cross
contaminaon of noise.As true gearheads, we designed this to meet themostcrical
objecves. We hope you enjoy it.

Quick Start Guide
Once you have installed your PG 1 where you need it, plug it in to an appropriate power
source. If you are not sure your source is correct, consult with your local power company.
Plug in your equipment to the correct outlets on the PG 1.
Turn on the power.The digital and analog outlets are switched with a delay sequence. The
digital and analog outputs turn on with the power switch and turn off aer a six second delay.
The high current outputs turn on aer six seconds and turn offwith the power switch. This
allows any startup sequences to be finished before the high current devices are turned on.
The front panel outlets are not switched and operate simultaneously with the power switch.
Please refer to the detailed feature guide below for more informaon.
ON/OFF Switch: Oncethe PG 1 is plugged into a grounded 115VAC outlet, turning the
front panel POWER switch to the ON posion will sequenally power the components
plugged into therear panel outlets.
GROUND OK: When this is on, the PG 1 is plugged into a properly grounded power
source. If theLED is not on, unplugthe unit from the power source and correct the
fault.
Wiring Fault: This indicates the LINE and NEUTRAL wires in the source are reversed.
Unplugthe unit immediately and consult an electrician to fix thefault.
CleanPowerOn: This LED indicates that the PG 1 is providing clean, beauful AC power

to all connected components.
Abnormal Voltage: When this LED is ON, the PG 1 is warning about under/over voltage
(greater than 130VAC or less than 90VAC)
Protecon ON: When this LED is on, the PG 1’s power surge circuitry is funconing
correctly. If this LED is OFF,the circuit has malfunconed. If it is OFF,unplugthe unit
immediately.
Digital Filter (Switched) Outlets: These outlets have a special filter circuit that is
designed to reduce AC supply interference to your digital components (workstaon,
digital effects, etc.).They also isolate therest of your system from noise generated by
the digital components themselves.
Analog Audio Filter (Switched) Outlets: These outlets have a special filter circuit that
reduces audible noise in your analog components (mixers, dynamic effects, etc.)
High Current Filter (Timed) Outlets: These outlets have a special filter circuit designed to
handle high current components like power amplifiers or Acve Speakers.
Gold plated ground post: Provides a connecon point for any ungrounded components.
Thermal Circuit Breaker: protects the PG 1 from power overload.
Breaker Open: When this LED is on, the thermal circuit breaker has tripped due to an
overload. Before reseng the breaker, find thereasonforthe overload.
Ultra high Current AC Power Cable: integral high power, heavy duty AC cable to
maximize power transfer to high current components such as amplifiers.
Dimmer: This knob controls a flexible accessory light. Push on/offand turn clockwise
forbrightness.
12V XLR Lamp Socket: Provides 12VDC on PIN 2 to an accessory lamp.
Numerical Display: Three character LED displays the line voltage at thesource.
Unswitched Convenience Outlets: These are‘always on’ filtered power outlets.
Note: For best performance we recommend plugging analog components into theanalog
outlets and digital to digital. It will not harm any components if they are plugged into any other
outlet.
Specificaons:
Voltage: 115VAC 15A max
AC Mains Input: NEMA standard plug
Dimensions: 438mm (19”) x 44mm (1U) x 250mm D
Weight: 4.2+kg
