Blackview Tab 12 Series User manual

Scan QR Code to get support
USER MANUAL
Enjoy Smart Life
Tab 12 Series

Email: [e-mail]
Customer Service
Package Contents
Charger x 1 Type C Charging Cable x 1Tab 12 Tablet x 1
Card Pin x 1User Manual x 1
Enjoy Smart Life
Tab12 Series
[e-mail]
1

Product Overview
Charger/Type-C
[e-mail]
2

Specifications
Model
Color
Dimension
Weight
OS
Display
CPU
RAM & ROM
Max TF Card Capacity
Front Camera
Rear Camera
Face Unlock
Battery Capacity
Wi-Fi version & spec
GSM spec
LTE spec
Dual 4G LTE
Slots
Twilight Blue &
Lunar Silver & Space Gray
Tab 12
238.5*157.45*7.4mm
430g
Doke OS_P 2.0, Android 11
10.1 inches, 1200*1920, FHD+ & IPS
UNISOC SC9863A
4GB & 64GB
1TB
5MP
13MP
Supported
6580mAh
802.11a/b/g/n/ac(2.4GHz/5GHz)
850/900/1800/1900 (B2/B3/B5/B8)
FDD:B1/B3/B7/B8/B20/B40
Supported
2 SIM or 1 SIM & 1 SD
[e-mail]
3

1. Press the card pin into the side hole and then the card tray pops up
and pull out it.
2. Take out the card slot and place the Nano card or Nano card and TF card
with the metal side facing down. Make sure the bevel angle is aligned
with the bevel angle of the card slot and placed in the corresponding card slot.
3. With the pad facing up, insert the card holder into the pad in the
direction of the arrow.
FAQ
To make sure your pad be able to call, put the SIM card in the following order.
SIM 1
SIM 2
SIM 1
SIM 1 SIM 1
SIM 2
How to insert the card
[e-mail]
4

FAQ
Language switching settings
[e-mail]
Main menu--settings-system setting-- lauguage and input method
Language and input method--language--language adding
Select the language you need,the system will automatically
jump back to the language interface
Select the icon after the language bar and drag it to the
first one.
5

1. In Power off state
Press the Power button and volume + 10 seconds to enter Boot mode,
Press volume down to enter recoverty mode, opt Wipe data/Factory
mode, use volume key to choose and power key to confirm.
2. In power-on state
Click: Settings-System-Reset options-Erase all data
Factory Restore Setting
FAQ
[e-mail]
6

* Reboot your tablet after charging for more than 30 minutes.
* Press the power button to check if the tablet is in the sleep mode.
* Press and hold the power button and volume+ button for 10s to reboot it.
The table doesn't power on.
* Make sure the USB cable is properly plugged into the charging port.
* Try another compatible USB cable and adapter.
The tablet doesn't charge.
* Uninstall the App with the error message, then download and install again.
Error message occusrs during the operation.
Make sure the Wifi in your tablet is ON.
Instead of Charge only, choose Media device(MPT) or PTP when connecting
the tablet to the computer.
Try another USB cable.
Try another USB port on the computer.
* Make sure the tablet is powered on.
*
*
*
*
*
*
*
*
The tablet cann't be detected by the computer.
Make sure you input the correct password when connecting the Wifi
Restart the router
Make sure there is no filter setting or device connection limitation in the
setting of the router
Forget the current Wifi,reset the router and connect the WIFI again.
The tablet cann't connect to the wifi.
FAQ
[e-mail]
7

FAQ
* Delete the Apps that you don't use.
* Clear the cache of the Apps regularly.
* Install a memory card to expand the storage.
The storage space of the tablet is not enough.
Check if the screen is dusty or greasy. If yes, please gently wipe the screen
with a cloth to clean it.
The screen is unresponsive
* Please go to Setting-Display-Font Size to adjust the text size.
The font size is too small to read.
Yes, but an extra OTG cable is required. You can connect the mouse or a USB
drive through the cable then.
Can the tablet support OTG function?
[e-mail]
8
*
*

FAQ
How to contact Blackview After-Sale-Service?
Send E-mail to: [e-mail]
If you prefer on Amazon, find your order and click Ask a Question
We offer 2 year warranty and 30 day worry-free return warranty, if there is
any issue
with your tablet, please don’t hesitate to contact us, we will reply within 24
hours and resolve it 100%.
Warranty
[e-mail]
9
