CT4-V and CT5-V Blackwing
MODELS TRACK PREPARATION
The CT4-V Blackwing and CT5-V Blackwing have been built for track performance in sanctioned racing events. But before unleashing their
acceleration, cornering and braking capability, there are several key procedures and steps that must be taken in order to properly experience
their track dominance. For full details and information, see the CT4/5 Owner’s Manual.
Please note: It is the driver’s responsibility to obey all applicable traffic laws at all times. This supplement is for the purpose of racing enthusiasts for sanctioned racing events. Track
events or competitive driving may affect the vehicle warranty. See the warranty manual before using the vehicle for racing or other competitive driving.
1. ATTAIN THE RIGHT MILEAGE
NEW VEHICLE BREAK-IN
Models: CT4-V Blackwing and CT5-V Blackwing
All models have a required break-in period during the first 1,500 miles (2414 km) that can help with the life of their performance.
PART/DRIVING BEHAVIOR
TIME PERIOD
ACTION
Tires
First 200 miles (322 km)
Drive at moderate speeds and avoid hard cornering
Brake linings
First 200 miles (322 km)
Avoid making hard stops (recommended every time
brake linings are replaced)
Full-throttle starts and abrupt stops
First 1,500 miles (800 km)
Avoid full-throttle starts and abrupt stops
Exceeding 4000 rpm
First 500 miles (800 km)
Avoid exceeding 4000 rpm
Cruise control or driving at one constant
speed
First 1,500 miles (800 km)
Avoid cruise control or driving at one constant
speed
Letting the engine labor or lugging the
engine
First 1,500 miles (800 km)
Avoid letting the engine labor or lugging the engine.
With a manual transmission, shift to the next lower gear
(this rule applies at all times, not just during the break-in
period)
Vehicle Speed
First 1,500 miles (800 km)
Do not drive above 80mph
Track or competitive driving
First 1,500 miles (2414 km)
Do not participate in track events, sport driving schools
or similar activities
Engine oil maintenance
First 1,500 miles (2414 km)
Check engine oil with every refueling and add if
necessary (oil and fuel consumption may be higher than
normal during the first 1,500 miles)
Please note: It is recommended that the first oil change occur at 500
miles.
For full details and information, see the vehicle’s Owner’s Manual.

2. SEASON THE BRAKES
BRAKE BURNISH PROCEDURE
Models: CT4-V Blackwing, CT5-V Blackwing
1. From a stop, accelerate as rapidly as possible without activating traction control to a speed of 60mph.
2. Using the G-Force Gauge in the HUD display, use enough pedal force to completely stop the vehicle in four to five seconds. If ABS activates,
braking is too hard.
3. Repeat the first two steps 20 consecutive times, this should take about five minutes.
4. After completing the 20 stops, cool the brakes by driving for 5mi at 60mph.
Please note: During the burnishing procedure, the brake pads will smoke and produce an odor. The braking force and pedal travel may increase. After the procedure is complete, the
brake pads may appear white at the rotor contact.
CONTINUED
BRAKE COOLING PREPARATION
Model: CT4-V Blackwing, CT5-V Blackwing
Prior to any track event, high speed driving event, or competitive driving, complete the following:
1. Ensure all the brake cooling parts are correctly secured and installed.
2. Inspect and replace and deflectors that have damage.
3. Inspect for blockage in the front brake cooling duct prior to every event.
4. Remove front tire deflector (if equipped).
If improved brake cooling is desired on Blackwings with cast-iron brakes (JGH) install the ball joint protector front shield, remove both upper
and lower rear rotor shields, and install the rear lower control arm cooling deflectors per the instruction in the brake cooling kit.
For full details on how to install, see the Owner’s Manual (pages 194-195).

3. ADJUST THE FOUR CORNERS AND VEHICLE COMPONENTS
TIRE PRESSURE AND WHEEL ALIGNMENT
Tire pressure specifications are listed in psi (kPa). Limit the vehicle weight to a maximum of the driver and one passenger, with no additional
cargo.
MODEL
AXLE
ROAD COURSE
COLD STARTING
PRESSURES2
ROAD COURSE
TARGET HOT
PRESSURES2
DRAG STRIP
COLD STARTING
PRESSURES
SUSTAINED
HIGH-SPEED
COLD STARTING
PRESSURES
CT5-V Blackwing
Front
28 psi
35-38 psi
N/A
41 psi
Rear
28 psi
35-38 psi
N/A
42 psi
CT4-V Blackwing
Front
30 psi
35-38 psi
N/A
44 psi
Rear
28 psi
(190 kPa)
37-39 psi
(255-270 kPa)
26 psi
(180 kPa)
44 psi
1Do not use summer-only tires in winter conditions, as it would adversely affect vehicle safety, performance and durability. Use only GM-approved tire and wheel
combinations. Unapproved combinations may change the vehicle’s performance characteristics. For important tire and wheel information, go to https://my.chevrolet.
com/learnAbout/chevrolettires or see your dealer for details.
2Value will vary based on driving style, track, temperature and weather conditions.
Please note: The CT4-V Blackwing and CT5-V Blackwing are equipped with high performance summer-only tires. These tires have a special tread and compound that are optimized for
maximum dry and wet road performance. This special tread and compound will have decreased performance in cold climates, and on ice and snow. It is recommended that winter tires
be installed on the vehicle if frequent driving at temperatures below approximately 40°F (5° C) or on ice- or snow-covered roads is expected.
D
WHEEL ALIGNMENT
Wheel alignment settings should be set as follows for optimized road course usage.
MODEL
AXLE
CASTER (NOT
ADJUSTABLE)
CAMBER
TOTAL TOE
STEERING WHEEL
ANGLE
THRUST ANGLE
LEFT
RIGHT
LEFT
RIGHT
(LEFT + RIGHT)
(LEFT –RIGHT/2)
CT5-V Blackwing
Track
Alignment
Settings
Front
7.9°
7.9°
-2.5° ±
0.15°
-2.5° ±
0.15°
0.1° ±
0.05°
0.0° ±
3.5°
—
Rear
—
—
-1.5° ±
0.15°
-1.5° ±
0.15°
0.1° ±
0.05°
—
0.0° ±
0.1°
CT5-V Track
Alignment
Settings
Front
6.9°
6.9°
-2.0° ±
0.15°
-2.0° ±
0.15°
0.1° ±
0.05°
0.0° ±
3.5°
—
Rear
—
—
-1.7° ±
0.15°
-1.7° ±
0.15°
0.1° ±
0.05°
—
0.0° ±
0.1°
CT4-V Blackwing
Track
Alignment
Settings
Front
6.9°
6.9°
-2.4° ±
0.15°
-2.4° ±
0.15°
0.1° ±
0.05°
0.0° ±
3.5°
—
Rear
—
—
-1.8° ±
0.15°
-1.8° ±
0.15°
0.1° ±
0.05°
—
0.0° ±
0.1°
CT4-V Track
Alignment
Settings
Front
6.9°
6.9°
-2.0° ±
0.15°
-2.0° ±
0.15°
0.2° ±
0.05°
0.0° ±
3.5°
—
Rear
—
—
-1.7° ±
0.15°
-1.7° ±
0.15°
0.2° ±
0.05°
—
0.0° ±
0.1°
.
CONTINUED

4. CHECK YOUR FLUIDS
Models: CT4-V Blackwing, CT5-V Blackwing
Be sure to follow all service procedures before driving your Blackwing on the track or competitively.
FLUID/LUBRICANT
TO DO
WHEN
Engine Oil
CT4-V Blackwing:
dexos1Gen3 5w-30
CT5-V Blackwing
dexosR 0w-40
(Currently only Mobil 1 Supercar)
Check the oil level and keep it at or near
the upper mark that shows the proper
operating range on the engine oil dipstick.
Often (before, during and after every
track event or competitive driving
session)
Please note: If you use the vehicle for racing or
other competitive driving, the engine may use
more oil than it would with normal use. Low oil
levels can damage the engine. Be sure to check the
oil level often during racing or other competitive
driving and keep the level at or near the upper
mark that shows the proper operating range on the
engine oil dipstick.
Automatic Transmission Fluid –
CT4V-Blackwing and CT5-V
Blackwing (DEXRON® ULV
Automatic
Transmission Fluid)
Change after track usage.
Every 15 hours
DOT-4 Brake Fluid
For track events or competitive driving, it is
recommended that the brake fluid be
replaced with a high-performance brake
fluid that has a dry boiling point greater than
>310° C (590° F). After conversion to the
high-performance brake fluid, follow the
brake fluid service recommendations
outlined by the fluid manufacturer. Do not
use silicone or DOT-5 brake fluids.
Before every track event or competitive
driving session
Rear Differential Fluid
CT5-V Blackwing
SAE 75W-85
API GL5
AC Delco 19418501
Change after 1,500 miles prior to first track
event.
Change every 24 track hours
Please note: Chevrolet recommends the use of TOP TIERTM Detergent Gasoline to keep the engine cleaner and reduce engine deposits. Visit www.toptiergas.com for a list of TOP TIER
Detergent Gasoline marketers. Use premium unleaded gasoline meeting ASTM specification D4814 with a posted octane rating of 93. If unavailable, unleaded gasoline with a posted
octane rating of 91 may be used but with reduced performance and fuel economy.
CONTINUED

5. ADJUST THE SUSPENSION
Models: CT4-V Blackwing.
Track Prep –Camber
To achieve the maximum camer setting for track use, follow this procedure prior to the final track alignment.
1. Remove the Upper Radiator Baffle and both front tower shock braces
2. Remove strut rebound top
3. Using a punch, tap out the strut top mount alignment pins. Use compressed air or other method to ensure no debris
remains between top mount and upper spring seat
4. Loosen the final strut top mount fastener. Do not completely remove this fastener
5. Reposition the suspension/strut assembly so that the strut top mount is located as close to the center of the vehicle as
possible (inboard)
6. With the suspension located as far inboard as possible, retitghten the loose fastener and torque it to 194 in-lbs
7. With the car on the ground, reinstall the strut rebound stop and torque it to 212 in-lbs
8. With the car on the ground, reinstall the Upper Radiator Baffle and both front shock tower braces. Torque the fasteners as
follows:
a. Front tower brace mounting bolts to 194 in-lbs
b. Front strut top mount nuts to 194 in-lbs
9. Complete setting the track alignment per the track specifications
CONTINUED

6. CUSTOMIZE YOUR PERFORMANCE
DRIVER MODE SELECTOR
Models: CT4-V Blackwing and CT5-V Blackwing
When maximum vehicle handling is desired for track use or competitive driving, Track Mode should be selected using the Driver Mode
Selector switch. When in Track Mode, the accelerator pedal is adjusted to give maximum control during the highest level of spirited driving. If
the vehicle is equipped with Magnetic Ride Control™, it will be set to optimum level for vehicle responsiveness. If the vehicle is equipped with
Active Exhaust, the exhaust valves will be open.
CUSTOM LAUNCH CONTROL
Models: V-Series Blackwings. Custom Launch Control allows the Launch RPM, Slip Target (5%-15%) and Surface Type parameters for Launch
Control to be modified.
To adjust Launch RPM:
•The vehicle must be in Track Mode
•Performance Traction Management (PTM) Mode must be enabled
•The steering wheel must be straight and the driver door closed
•The transmission must be in a gear other than R (Reverse). It will work in P (Park) or N (Neutral)
•The parking brake must not be engaged
Using the steering wheel 5-way controller, scroll to “Options” on the Driver Information Center menu to select your Surface, Launch RPM and
desired Slip Target. For full details and information, see Owner’s Manual.
LINE LOCK
Models: V-Series Blackwings.
Line Lock allows for locking the front brakes independently of the rear brakes. This allows the rear tires to spin when the throttle is applied.
To enter Line Lock, all of these conditions must be met:
•The vehicle must be in Track Mode
•Performance Traction Management (PTM) Mode must be enabled
•The steering wheel must be straight and the driver door closed
•The vehicle must be in D (Drive) for automatic transmission or 1st (First) gear for manual transmission • The parking brake must not
be engaged
•The vehicle must be stopped on level ground and the accelerator pedal must not be applied
Using the buttons on the right side of the steering wheel, scroll to “Launch Control” on the Driver Information Center menu to select an
Automatic or Custom launch. From there:
•Select Line Lock, then press the brake pedal firmly to move the bar graph to 100%
•Release the brake pedal. There are 15 seconds to complete the burnout and exit
•To release the brakes and roll out, press the tachometer symbol and SEL at the same time
For full details, see the Owner’s Manual.
