Blanco BFID45X User manual

Thank you for your choosing Blanco. You will find that the clean lines and
modern look of your Blanco appliance blends perfectly with your kitchen décor.
It is easy to use and performs to a high standard. Blanco is committed to
providing increasingly efficient products that are attractive, reliable, easy to use
and respect the environment.
Of course we make every effort to ensure that our products meet all your
requirements, and our Customer Relations department is at your disposal, to
answer your questions and to listen to all your suggestions (see back cover of
manual).
For important information such as instruction manuals and catalogues, please
visit our website blanco-australia.com/support/instruction_manuals or
blanco-australia.com/support/catalogues.
Please make sure you activate your product warranty by registering your
warranty online at blanco-australia.com/warranty/ and retain all documents
relating to the purchase of this product.
We value your opinion, so please let us know your thoughts about your new
appliance. Simply go to the relevant appliance page of our website
blanco-australia.com and click on "Write a Review".
If you want to know more about promotions, receive tips and tailor made
content or connect with us on social media, like BlancoAU on Facebook and
follow BlancoAU on Twitter.
We hope you’ll enjoy special moments with your new appliance and remember,
we’re only one click away!
blanco-australia.com
BlancoAU
BlancoAU
BFID45X
DISHWASHER USER MANUAL

Read this Manual
Dear Customer,
Please read this User Information carefully
and keep it to refer to at a later date.
Pass it on to any subsequent owner of the
appliance.
This manual contains sections of Safety
Instructions, Operating Instructions, Installation
Instructions and Troubleshooting Tips, etc.
Carefully read it before using the dishwasher
will help you to use and maintain the
dishwasher properly.
Before Calling for Service
To review the section on Troubleshooting Tips
will help you to solve some common problems
by yourself and not need to ask for the help of
professional technicians.
NOTE:
The manufacturer, following a policy of
constant development and up-dating of
the product, may make modifications
without giving prior notice.
1
1) Safety Information .............................1-2
2) Disposal ................................................2
3) Operation Instruction.........................3-4
Control Panel ..............................................3
Dishwasher Features ..................................4
4) Prior using for the first time .............4-7
Fill the Rinse Aid Dispenser......................4-5
Function of Detergent ..............................5-7
5) Loading the Dishwasher Baskets..8-11
6) Starting a washing programme ....12-13
Wash Cycle Table ......................................12
Turning on the Appliance............................12
Change the Programme.............................13
Forget to Add Dish ...............................13
7) Maintenance and cleaning.............14-16
8) Troubleshooting Tips.....................17-19
Error codes...........................................................17
Before calling for service.....................................18-19
Technical information ................................19
WARNING !
When using your dishwasher, follow the basic precautions including the following:
WARNING! HYDROGEN GAS IS EXPLOSIVE
Under certain conditions, Hydrogen gas may be produced in a hot-water system that has not been
used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot-water system has not
been used for such a period, before using the dishwasher turn on all hot-water faucets and let the
water flow from each for several minutes. This will release some accumulated hydrogen gas. As the
gas is flammable, do not smoke or use an open flame this time.
WARNING! PROPER USE
Do not abuse, sit on, or stand on the door or dish basket of the dishwasher.
Do not touch the heating element during or immediately after using.
Do not operate your dishwasher unless all enclosure panels are properly in place. Open the door
very carefully if the dishwasher is operating. There is a risk of water squirting out.
Do not place any heavy objects or stand on the door when it is open. The appliance could tip
forward.
When loading items to be washed:
Locate sharp items so that they are not likely to damage the door seal;
Warning: Knives and other utensils with sharp points must be loaded in the basket with their
points down or placed in a horizontal position.
When using your dishwasher, you should prevent plastic items from contacting with heating
element.
Check that the detergent receptacle is empty after completion of the wash cycle.
Do not wash plastic items unless they are marked dishwasher safe or the equivalent. For plastic
items not so marked, check the manufacturer's recommendations.
Use only detergent and rinse additives designed for an automatic dishwasher. Never use soap,
laundry detergent, or hand washing detergent in your dishwasher.
Other means for disconnection from the supply must be incorporated in the fixed wiring with at
least 3mm contact separation in all poles.
Keep children away from detergent and rinse aid, keep children away from the open door of the
dishwasher , there could still be some detergent left inside.
These instructions can also be obtained from BLANCO website.
To protect against the risk of electrical shock, do not immerse the
unit, cord or plug in water or other liquid.
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge unless they have been given supervision
or instruction concerning use of the appliance by a person responsible
for their safety. Children should be supervised to ensure that they
do not play with the appliance.
1. Safety Information
9) Installation Instruction .................20-24

Program
( 3sec)
Alt
Control Panel
3. Operation Instruction
3
2
READ AND FOLLOW THIS SAFETYINFORMATION CAREFULLY
SAVE THESE INSTRUCTIONS
Dishwasher detergents are strongly alkaline. They can be extremely dangerous if swallowed.
Avoid contact with skin and eyes, and keep children away from the dishwasher when the door is
open.
The door should not be left in the open position since this could present a tripping hazard.
If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a
similarly qualified person in order to avoid a hazard.
Please dispose of packing materials properly.
During installation, the power supply cable must not be excessively or dangerously bent or flattened.
Do not tamper with controls.
The appliance is to be connected to the water mains using new hose sets, and the old hose-sets
should not be reused.
Make sure that the carpet must not obstruct the openings at the bottom base.
Use the dishwasher only for its intended function.
The dishwasher is intended for indoor use only.
The dishwasher is not designed for commercial use. This appliance is intended to be used in
household and similar applications such as:
2 Disposal
Packaging material could be dangerous for children!
For disposing of package and the appliance please go to a recycling centre. Cut off the power
supply cable and make the door closing device unusable.
Cardboard packaging is manufactured from recycled paper and should be disposed in the waste
paper collection for recycling.
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product.
For more detailed information about recycling of this product, please contact your local city office
and your household waste disposal service
IMPORTANT!
To get the best performance from your dishwasher, read all
operating instructions before using it for the first time.
Dispose of the dishwasher packaging material correctly.
All packaging materials can be recycled.
Plastic parts are marked with the standard international abbreviations:
(e.g. PS for polystyrene, padding material)
This appliance is identified according to the European guideline
2002/96/EC on waste electrical and electronic equipment -WEEE. The
guideline specifies the framework for an EU-wide valid return and re-use of
old appliances.
WARNING!
123
11
7
58
9
10
4
6
1 2D :
3
Digital display: To display the running time remaining, error
codes and delay time.
elay button The START DELAY will allow you to delay the
start time of any cycle automatically up to 24hours.
twice to add the "Dry+" function, three times cancels both."
4 Dry+ indicator: An increased temperature will improve the drying
process during the final rinse stage .
5 6
Program indicator light When you select a washing programme ,
the corresponding light will display.
Power switch: To turn the dishwasher on and off.
Washing light: To come on when the dishwasher is washing.
11
Program select button/Child lock button: Press the button to select
the program. The "child lock"will be available when you press the
button 3 seconds ,and "LO" flashes 6 times on digital displays.
Drying light: To come on when the dishwasher is drying.
7 8 9 3 in 1 indicator: The indicator lights up when the additional
function has been selected.
10
Rinse aid refill indicator: The indicator lights up when dispenser
needs to be refilled.
- staff kitchen areas in shops, offices and other working environments;ÿÿ
- farm houses;
- by clients in hotels, motels and other residential type environments;ÿÿ
- bed and breakfast type environments.
Alternative Function button: This can be used to add or remove the "3 in 1" and "Dry+" functions. Press once to add the "3 in 1",

1
2
3
22
1133
1
2
3
4
5
6
MAX
1
2
3
4
5
6
MAX
To open the dispenser, turn the cap to the "open" (left) arrow and lift it out.
Pour the rinse aid into the dispenser, be careful not to overfill.
Replace the cap by inserting it aligned with "open" arrow and turning it to the "closed" (right)
arrow.
The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes
that can leave spots and streaks. It also improves drying by allowing water to sheet off the dishes.
Your dishwashers are designed to use liquid rinse aids. The rinse aid dispenser is located inside the
door next to the detergent dispenser.
To fill the dispenser, open the cap and pour the rinse aid into the dispenser until the level indicator
turns completely black. The volume of the rinse aid container is about 140ml.
Be careful not to overfill the dispenser, because this could cause over sudsing. Wipe away any spills
with a damp cloth. Don't forget to replace the cap before you close dishwasher door.
Attention!
Clean up any rinse aid split during filling with an absorbent cloth to avoid excess foaming during the
next wash.
Adjusting Rinse Aid Dispenser
NOTE: Increase the dose if there are drops of water or lime spots on the dishes after washing.
Reduce it if there are sticky whitish streaks on the dishes or a bluish film on glassware or knife
blades.
The rinse aid dispenser has four or six settings. Always start
With the dispenser set on "4" If spots and poor drying are
Problems, increase theamount of rinseaid dispensed
by removing thedispenser lid androtating the dial to "5”.
If the dishesstill are notdrying properly or are spotted,
adjust the dialto the nexthigher number until your dishes
are spot-free. The dose is factory set inposition 5.
Adjust lever
(Rinse)
RINSE AID DISPENSER
4 Prior Using for the First Time
Dishwasher Features
Before using your dishwasher for the first time:
A. Fill the rinse aid dispenser
B. Fill the detergent dispenser
5
4
A. Fill the Rinse Aid Dispenser
Function of Rinse Aid
Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, spot and streak
free drying.
Attention!
Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser with any other
substances (e.g. dishwasher cleaning agent, liquid detergent). This would damage the appliance.
When to Refill the Rinse Aid Dispenser
You can judge the amount of rinse-aid by the colour of the optical level indicator "D" located next to
the cap. When the rinse-aid container is full, the whole indicator will be dark .As the rinse aid
diminishes, the size of the dark dot decreases. You should never let the rinse aid get below 1 / 4 full.
As the rinse aid diminishes, the size of the
black dot on the rinse aid level indicator
changes, as illustrated below.
Full
3 / 4 full
1 / 2 full
1 / 4 full - Should refill to eliminate spotting
Empty
D (Rinse-Aid indicator)
B. Fill the Detergent Dispenser
Detergents with its chemical ingredients are necessary to remove dirt, crush dirt and transport it out
of the dishwasher. Most of commercial quality detergents are suitable for this purpose.
Front View
1 Upper Basket
2 Spray Arms
3 Lower Basket
4 Filters
5 Detergent Dispenser
6 Rinse Aid Dispenser
7 Cutlery basket
1
2
3
4
56
7

7
6
Concentrated Detergent
Based on their chemical composition, dishwasher can be split in two basic types:
conventional, alkaline detergents with caustic components
low alkaline concentrated detergents with natural enzymes
The use of "normal" washing programme in conjunction with concentrated detergents reduces
pollution and is good for your dishes; these washing programmes are specially matched to the dirt-
dissolving properties of the enzymes of the concentrated detergent. For this reason"normal"
washing programme in which concentrated detergents are used can achieve the same results that
can otherwise only be achieved using"intensive" programme.
Detergent Tablets
Detergent tablets of different brands dissolve at different speeds. For this reason some detergent
cannot dissolve and develop their full cleaning power during short programmes. Therefore please
use long programmes when using detergent tablets, to ensure the complete removal of detergent
residuals.
Detergent Dispenser
The dispenser must be refilled before the start of each washing cycle following the instructions
provided in the Wash Cycle Table.
Generally, only one tablespoon of detergent is needed for a normal wash load. Also, more heavily
lsoiled items need more detergent. Always add the detergent just before starting dishwasher,
otherwise it could get damp and will not dissolve properly. .
Amount of Detergent to Use
2
1
NOTE:
If the lid is closed: press release button. The lid springs open.
Always add the detergent just before starting each wash cycle. Only use branded detergent aid
for dishwasher.
WARNING!
Dishwasher detergent is corrosive! Take care to keep it out of reach of children
Use only detergent specifically made for use in dishwashers. Keep your detergent fresh and dry.
1122
Fill the dispenser
Fill the detergent dispenser with detergent.
The marking indicates the dosing levels , as
illustrated on the right:
The place of main wash cycle detergent placed,
MIN means approximately 20g of detergent.
The place of pre-wash cycle detergent placed ,
approximately 5g of detergent.
""
2
1
Please observe the manufacturer's dosing and storage recommendations as stated on the
detergent packaging.
Close the lid and press until it locks in place.
If the dishes are heavily soiled, place an additional detergent dose in the pre-wash detergent
chamber. This detergent will take effect during the pre-wash phase.
NOTE:
You find information about the amount of detergent for the single programme on the last page.
Please be aware that according to the level soiling and the specific hardness of water, differences
are possible.
Please observe the manufacturer's recommendations on the detergent packaging.
Use of "3 in 1" Detergent Tablets
General Advice
1. Before using these products you should first check that the water hard-ness in your supply is
compatible with the use of these products as the detergent manufacturers instructions (on the
product packaging).
2. These products should be strictly used according to the detergent manufacturers instructions.
3. If you encounter problems when using "3 in 1" products for the first time then please contact the
detergent manufacturers care line (the telephone number is given on the product packaging).
These products are detergents with integrated and combined detergent/rinse aid functions.
1
2
3
4
5
6
MAX
2
1
To select "3in1" function:
To cancel "3in1" function:
To cancle the 3in1 washing cycle by pressing the button or follow the "change the
programme" instructions.
If you decide to switch to the use of a standard detergent system we advise that you:
1. Refill the rinse aid compartments.
2. Switch the water hardness setting to the highest possible position and run for three normal cycles
without load.
3. Readjust the water hardness setting again according to the conditions for your region (For more
information please refer to your instruction manual).
1. lose the door and select the 3in1 washing cycle by pressing the function alternative button until
the "3in1"indicator lights.
2. The 3in1 washing cycle will be available.
function alternative
C

1
2
2
Loading the Lower Basket
It is recommend that you place large items which are most difficult to clean in to the lower basket:
pots, pans, lids, serving dishes and bowls, as shown in the figure below.
It is preferable to place serving dishes and lids on the side of the baskets in order to avoid blocking
the rotation of the top spray arm.
Pots, serving bowls, etc. must always be placed top down.
Deep pots should be slanted to allow water to flow out.
The bottom basket features fold down tine rows so that larger or more pots and pans can be loaded.
Adjusting the Upper Basket
If required, the height of the upper basket can be adjusted in order to create more space for large
utensils either in the upper basket or lower basket. The height of the upper basket can be adjusted
by adjusting which rollers are placed on the rails. (see diagrams). Long items, serving cutlery, salad
servers or knives should be placed on the shelf so that they do not obstruct the rotation of the spray
arms. The shelf can be folded back or removed when not be required for use.
5 Loading the Dishwasher Baskets
For best performance of the dishwasher, follow these loading guidelines. Features and appearance
of baskets and Cutlery tray may vary from your model.
Attention before or after Loading the Dishwasher Baskets
1. Scrape off any large amounts of leftover food. It is not necessary to rinse the dishes under
running water. Place objects in the dishwasher in the following way:
A. Items such as cups, glasses, pots/pans, etc. are stood upside down.
B. Curve items, or those with recesses, should be at a slant so that water can run off.
C. They are stacked securely and can not tip over.
D. They do not prevent the spray arms from rotating while washing takes place.
2. Very small items should not be washed in the dishwasher as they could easily fall out of the
Baskets.
3. Do not pull out the lower and upper baskets at the same time when loading the baskets;
The combined weight can cause the dishwasher to topple forward.
Removing the Dishes
To prevent water dripping from the upper basket into the lower basket, we recommend that you
empty the lower basket first and then the upper basket.
Loading the Upper Basket
The upper basket is designed to hold more
delicate and lighter dishware such as
glasses, coffee and tea cup and
saucers, as well as plates,
small bowls and shallow
pans (as long as they are
not too dirty). Position the
dishes and cookware so
that they do not get
moved by the spray of water.
Upper and Lower basket Folding racks
Folding racks consisting of two parts
that are located on the upper and lower
basket of your machine are designed in
order to let you place big items easier
as pots, pans, etc. If more room is needed
for larger items, the sections can be
folded down. When smaller items are being
cleaned, they can be straightened up.
9
8
Lower Basket
12
Lower basket
Type Item
Dessert plate
G
H
I
Dinner plate
Soup plate
Dessert plate
Upper Basket
Lower Basket
1
Upper Basket
Upper basket
Type Item
Cup
Glass
Saucer
A
B
C
C1
C9
B1
B9
A1
A9
A
B
C
H9H1
G9G2
I9I2
G1I1

11
10
For washing in the dishwasher the following cutlery/dishes
Are not suitable
Cutlery with wooden, horn china or
mother-of-pearl handles
Plastic items that are not heat resistant
Older cutlery with glued parts that is not
temperature resistant
Bonded cutlery items or dishes
Pewter or copper items
Lead crystal glass
Steel items subject to rusting
Wooden platters
Items made from synthetic fibre
WARNING!
Do not let any item extend through bottom
Are of limited suitability
Some types of glasses can become
dull after a large number of washes
Silver and aluminium parts have a
tendency to discolour during washing
Glazed patterns may fade if machine
washed frequently
NOTE: Do not put in items that are dirty with cigarette ash, candle wax, lacquer or paint. If you buy
new dishes please make sure that they are suitable for dishwashers.
NOTE: Please do not overload your dishwasher. The maximum that can be washed at one time is
the equivalent of 9 place settings.This is important for good results and for reasonable energy
consumption.
Before loading the dishes, you should:
Scrape off any large amounts of leftover food
Soften remnants of burnt food in pans
Loading Cutlery and Dishes
When Loading the Dishes and Cutlery, Please Note:
Dishes and cutlery must not impede the rotation of the spray arms.
Load hollow items such as cups, glasses, pans etc. with the opening downwards so that water cannot
collect in the container or a deep base.
Dishes and items of cutlery must not lie inside one another, or cover each other
To avoid damage to glasses, they must not touch
Load large items which are most difficult to clean into the lower basket
The upper basket is designed to hold more delicate and lighter dishware such as glasses, coffee and
tea cups
Long bladed knives stored in an upright position are a potential hazard!
Long and/or sharp items of cutlery such as carving knives must be positioned horizontally in the upper
basket
Attention!
Damage to Glassware and other Dishes
Possible causes:
Type of glass or manufacturing process. Chemical composition of detergent.
Water temperature and duration of dishwasher programme.
Suggested remedy:
Use glassware or porcelain dishes that have been marked dishwasher-proof by the manufacturer.
Use a mild detergent that is described as kind to dishes. If necessary, seek further information from
detergent manufacturers.
Select a programme with a low temperature.
To prevent damage, take glass and cutlery out of the dishwasher as soon as possible after the
programme has ended.
Cutlery tray
Arrange the cutlery in the tray as shown. Cutlery should be placed to ensure that water
runs off freely.
At the End of the Wash
When the working cycle has finished, the buzzer of the dishwasher will ring for 6 times, then stop.
Turn off the appliance using the ON/OFF button, shut off the water supply and open the door of the
dishwasher. Wait a few minutes before unloading the dishwasher to avoid handling the dishes and
utensils while they are still hot and more susceptible to breakage. They will also dry better.
Door side
Cutlery basket
Door side
Cutlery basket
Type Item
Tea spoons
Dessert spoons
Soup spoons
Forks
Knives
1
2
3
4
5
12345

4/22g
(Or 3 in 1)
4/22g
(Or 3 in 1)
NOTE: If all the lights begin to glimmer, that indicates the machine is out of order, please turn off the
main power and water supply before calling a service.
Forget to Add Dish
A forgotten dish can be added any time before the detergent cup opens.
1 Open the door a little to stop the washing.
2 After the spray arms stop working, you can open the door completely.
3 Add forgotten dishes.
4 Close the door, the dishwasher will work after ten seconds.
WARNING!
It is dangerous to open the door when washing, because the hot water may scald you.
Switch Off the Dishwasher
The digital display appears "---” and the buzzer rings 6 times, only in this case the programme
has ended.
1.Switch off the dishwasher by pressing the ON/OFF button.
2.Turn off the water tap!
Open the door carefully. Hot steam may escape when the door is opened!
Hot dishes are sensitive to knocks. The dishes should therefore be allowed to cool down around
15 minutes before removing from the appliance.
Open the dishwasher's door, leave it ajar and wait a few minutes before removing the dishes. In
this way they will be cooler and the drying will be improved.
Unloading the dishwasher
It is normal that the dishwasher is wet inside.
Empty the lower basket first and then the upper one. This will avoid water dripping from the upper
basket onto the dishes in the lower one.
Change the Programme.
Premise: A cycle that is underway can only be modified if it has only been running for a short time.
Otherwise, the detergent may have already been released, and the appliance may have already
drained the wash water. If this is the case, the detergent dispenser must be refilled (see the section
entitled " Fill in the Detergent " ).
Open the door. Press current programme button more than three seconds to cancel the programme,
then you can change the programme to the desired cycle setting (see the section entitled "Starting a
wash cycle. . . " ). Then, close the door.
NOTE: If you open the door when washing, the machine pauses and warning alarm rings, the display
appears E1. When you close the door, the machine will keep on working after 10 seconds.
The 6 programme lights show the state of the dishwasher:
a) All program lights off --> stand by
b) One of the program lights on --> cycle running
c) One of the program lights blinking --> pause
6. Starting a Washing Programme
Wash cycle table
Program Cycle Selection
Information
Description
of Cycle
Detergent
Pre/main
Running
Time
(min)
Energy
(kWh)
Water
(L)
Intensive
Heavy
For the heaviest soiled loads,
such as pots, pans, casserole
dishes and dishes that have
been sitting with dried food
on them for a while.
For normally soiled loads,
such as pots, plates, glasses
and lightly soiled pans.
standard daily cycle.
Rapid
Soak
A shorter wash for lightly
soiled loads that do not
need drying.
To rinse dishes that you
plan to wash later that day
1. The dishwasher must be connected to the power source (220-240V / 50 Hz) via the power plug
and cable. The Water must be connected and set to full pressure.
Turning on the Appliance
AS/NZS 2007.1:This programme is the test cycle. The information for comparability test
in accordance with AS/NZS.2007.1, as follows:
- Capacity: 9 settings
- Position of Upper basket: Low position
- Rinse aid setting:5 or 4 for four setting dispenser)
Pre-wash(40 )
Main wash(55 )
Rinse1
Rinse2
Hot rinse(65 )
Drying
Main wash(60 )
Rinse 1
Rinse 2
Hot rinse(65 )
Drying
Main wash(44 )
Rinse
Hot rinse(46 )
Drying
Main wash(40 )
Hot rinse(50 )
Pre-wash
15g
137
122
110
43
8
0.56
15.0
11.5
9.4
6.0
3.3
Normal
(AS/NZS 2007.1)
13
12
NOTE:
For heavy soiled loads,
such as pots, plates, glasses
and lightly soiled pans.
standard daily cycle.
We recommend you open the door slightly 50mm to assist in drying of the dishes
after every wash.
3. Press the On/Off button once to turn the dishwasher on. Press the Program Select button to select
a wash cycle.
4. Close the door until a click is heard. The washing cycle should now start.
5 . When the washing cycle has finished, the dishwasher is turned off by pressing the On/Off button again.
1.10
1.00
0.48
0.01
2. Open the door and load the baskets. It is recommended to load the lower one first, then the upper
one. Check there is rinse aid and load in the detergent.ÿÿ
/
Rinse
Pre-wash
Hot rinse(70 )
Drying
60 0.69 6.0
For dishes that need to be
rinsed and dried only
4/22g
(Or 3 in 1)
4/22g

15
14
WARNING!
WARNING!
Filtering System The filter is used to avoid the big remnants and other sundries getting inside
the pump. When there is a lot of residue, the filter can become obstructed.
The filter systemconsists of acoarse filter, a flat
(Main filter) anda micro filter(fine filter).
1 Flat filter
Food and debriswill be trappedby a special jet
on the lowerspray arm.
2 Coarse filter
Big debris, suchas bone andglass that could clog the
drain will betrapped in thecoarse filter.
Toremove an itemcaught in thisfilter, gently squeeze
the taps onthe top of this filter andlift it out.
3 Micro filter
This filter holdssoil and food residue in thesump area
and prevents itfrom being redeposit on the dishes
during a cycle.
- Inspect thefilters for obstructions every time the
dishwasher has beenused.
- By unscrewingthe coarse filter, you can remove
the filter system.Remove any food remnants and
clean the filtersunder running water.
Step 1 Rotate the coarse
filter anti-clockwise and lift it up.
Step 2 lift the flat filter up.
7. Maintenance and cleaning
Filter assembly
For best performance and results, the filter assembly must be cleaned. The filter efficiently removes
food particles from the wash water, allowing it to be recirculated during the cycle. For this reason, it
is a good idea to remove the larger food particles trapped in the filter after each wash cycle by rinsing
the semicircular filter and cup under running water. To remove the filter assembly, pull on the cup
handle in the upward direction. The entire filter assembly should be cleaned once a week. To clean
the coarse filter and the micro filter, use a cleaning brush. Then, reassemble the filter parts as shown
in the figures above and reinsert the entire assembly in the dishwasher, positioning in its seat and
pressing downward. The dishwasher must never be used without the filters. Improper replacement
of the filter may reduce the performance level of the appliance and damage dishes and utensils.
Never run the dishwasher without the filters in place. When cleaning the filters, don't knock on them.
If the filters become deformed, they may affect the efficiency of the dishwasher.
Cleaning the Spray Arms
It is necessary to clean the spray arms regularly as hard
water chemicals will clog the spray arm jets and bearings.
To remove the spray arms, screw off the nut clockwise to
take out the washer on top of the spray arm and remove the
arm. Wash the arms in soapy and warm water and use a soft
brush to clean the jets. Replace them after rinsing thoroughly.
Caring for the Dishwasher
To clean the control panel, use a lightly dampened cloth then
dry thoroughly.
To clean the exterior, use a good appliance polish wax.
Never use sharp objects, scouring pads or harsh cleaners
on any part of the dishwasher.
Protect Against Freezing
If your dishwasher is left in an unheated place during the winter, ask a service technical to:
1.Cut off electrical power to the dishwasher.
2.Turn off the water supply and disconnect the water inlet pipe from the water valve.
3.Drain water from the inlet pipe and water valve. (Use a pan to catch the water)
4.Reconnect the water inlet pipe to the water valve.
5.Remove the filter in the tub and the bottom and use a sponge to use up water in sump
Cleaning the Door
To clean the edge around the door, you should use only a soft warm, damp rag. To prevent
penetration of water into the door lock and electrical components, do not use a spray cleaner of any
kind.
Also, never use abrasive cleaners or scouring pads on the outer surfaces because they will scratch
the finish. Some papers towels can also scratch or leave marks on the surface.
Never use a spray cleaner to clean the door panel for it could damage the door lock and electrical
components. It is not allowed to use the abrasive agent or some paper towel because of the risk of
scratching or leaving spots on the stainless steel surface.
2
1
3
3
1 2
After cleaning, replace the
filters by following the
instructions in reverse.

17
16
How to Keep Your Dishwasher in Shape
After Every Wash
After every wash, turn off the water supply
to the appliance and leave the door slightly
ajar so that moisture and odors are not
trapped inside.
Remove the Plug
Before cleaning or performing
maintenance, always remove the plug from
the socket.
No Solvents or Abrasive Cleaning
To clean the exterior and rubber parts of
the dishwasher, do not use solvents or
abrasive cleaning products. Use only a
cloth and warm soapy water. To remove
spots or stains from the surface of the
interior, use a cloth dampened with water
and a little white vinegar, or a cleaning
product made specifically for dishwashers.
When You Go on holiday
When you go on holiday, it is
recommended that you run a wash cycle
with the dishwasher empty and then
remove the plug from the socket, turn off
the water supply and leave the door of the
appliance slightly ajar. This will help the
seals last longer and prevent odors from
forming in the appliance.
Moving the Appliance
If the appliance must be moved, try to keep
it in the vertical position. If absolutely
necessary, it can be positioned on its back.
Seals
One of the factors that cause odors to form
in the dishwasher is food that remains
trapped in the seals. Periodic cleaning with
a damp sponge will prevent this.
Attention:
The installation of the pipes
and electrical equipments
should be done by professionals.
Electrical Shock Hazard!
Disconnect electrical power before
installing dishwasher.
Failure to do so can result in death or
electrical shock.
Warning
8. Troubleshooting Tips
ERROR CODES
When some malfunctions happen, the appliance will display error codes to warn you.
WARNING!
If overflow occurs, turn off the main water supply before calling a service. If there is water in the base
pan because of an overfill or small leak, the water should be removed before restarting the
dishwasher.
Codes Meanings Possible Causes
Water drainage malfunction
E1
E2
E3
E4
E5
E6
E7
Door open
Water inlet
Water drainage
Temperature sensor
Overflow/leakage
Water leakage
Heating element
The door is opened when the
dishwasher is operating
Water inlet malfunction
Temperature sensor malfunction
Overflow occurs/Water leakage occurs
Water leakage occurs
Abnormal heating

19
18
Stained tub
interior
Detergent with
colorant was used Make sure that the detergent is the one without colorant.
Dishes and
flatware
not clean
Make sure that the action of the detergent dispenser
and spray arms are not blocked by large dishware.
Improper program
Improper basket
loading
Select a stronger programme.
Spots and
filming on
glasses and
flatware
1Extremely hard
water
2Low inlet
temperature
3Overloading the
dishwasher
4Improper loading
5Old or damp
powder detergent
6Empty rinse agent
dispenser
7Incorrect dosage
of detergent
To remove spots from glassware:
1Take out all metal utensils out of the dishwasher.
2Do not add detergent.
3Choose the longest cycle.
4Start the dishwasher and allow it to run for about
18 to 22 minutes, then it will be in the main wash.
5Open the door to pour 2 cups of white vinegar
into the bottom of the dishwasher.
6Close the door and let the dishwasher complete
the cycle. If the vinegar does not work: Repeat
as above, except use 1/4 cup (60 ml)of citric acid
crystals instead of vinegar.
Before Calling for Service
Reviewing the charts on the following pages may make you be free of calling for service.
Use only the special dishwasher detergent to avoid
suds.If this occurs, open the dishwasher and let suds
evaporate. Add 4 litres of cold water to the tub. Close
and latch the dishwasher, then start the "soak" wash
cycle to drain out the water... Repeat if necessary.
Problem
Dishwasher
doesn't run
Drain pump
doesn't stop
Noise
Suds in
the tub
Possible Causes What To Do
Spilled rinse agent
Always wipe up rinse agent spills immediately.
Fuse blown, or the
circuit breaker acted
Power supply is
not turned on
Water pressure
is low
Overflow
The system is designed to detect an overflow. When it
does, it shuts off the circulation pump and turns on the
drain pump.
Some audible
sounds are normal
Utensils are not
secure in the
baskets or
something small
has dropped into
the basket
Motor hums
Improper detergent
Dishwasher has not been used regularly. If you do not
use it often, remember to set it to fill and pump out
every week, which will help keep the seal moist.
To ensure everything is secured in the dishwasher.
Sound from detergent cup opening.
Check that the water supply is connected properly and
the water is turned on.
Make sure the dishwasher is turned on and the door is
closed securely. Make sure the power cord is properly
plugged into the wall socket.
Replace fuse or reset circuit breaker. Remove any other
appliances sharing the same circuit with the dishwasher.
Cloudiness
on glassware
Combination of soft
water and too much
detergent
Use less detergent if you have soft water and select a
shortest cycle to wash the glassware and to get them
clean.
Yellow or
brown film on
inside surfaces
White film
on inside
surface
The detergent
dispenser lid
cannot be clos
-ed properly
Detergent
left in
dispenser
cups
Steam
Black or
gray marks
on dishes
Water
standing on
the bottom
of the tub
Iron deposits in
water can cause an
overall film
Dishes block
detergent Cups
Using a solution of 1/2 cup of bleach and 3 cups of
warm water to remove the stains by hand.
WARNING
You have to wait for 20 minutes after a cycle to let the
heating elements cool down before cleaning interior;
otherwise, burns will happen.
To clean the interior, use a damp sponge with
dishwasher detergent and wear rubber gloves. Never
use any other cleaner than dishwasher detergent for the
risk of foaming or suds.
Hard water minerals
Clogged detergent
residue is blocking
the catch
Tea or coffee stains
A small amount of clean water around the outlet on
the tub bottom keeps the water seal lubricated.
Use a mild abrasive cleaner to eliminate those marks.
There is some steam coming through the vent by the
door latch during drying and water draining.
Re-loading the dishes properly.
Clean the detergent from the catch.
You have to call a water softener company for a special
filter.
This is normal
Aluminum utensils
have rubbed
against dishes
Normal phenomenon
Dishwasher
leaks
Dishwasher isn't
level Make sure the dishwasher is level.
Be careful not to overfill the rinse aid dispenser.
Spilled rinse aid could cause oversudsing and lead
to overflowing. Wipe away any spills with a damp cloth.
Overfill dispenser or
rinse aid spills
Technical information
WDH 448mm 558mm 815mm
Voltage connected load:
Water pressure:
See rating label
0.04--1.0MPa
Power supply: 220-240V / 50Hz
Capacity: 9 Place settings
Hot water connection:
Max 60

21
20
Notices
Water pipes and electrical devices
should be installed by professionals
Installation Instruction
The dimension of the
front ornamental plate
Before Installation
Dishwasher placement requirements: The back of dishwasher should
face to the wall. The dishwasher has inlet and outlet pipes which can be
connected from the right or left side.
The installation dimensions within a cabinet are below.
Cut off the power before
installing the dishwasher,
or electric shock may occur
Install the dishwasher into
the cabinet
450min
The
connectors
for power
cord and
inlet/outlet
hose
815-8 75
580min
815
448
90
52
558
145
657
95
Fully built in
446
19
390
658min 708max
2- 2 the hole with
10mm depth
66
4-4x42 wooden screws
Connecting the water inlet hose (for cold water)
Connection the cold water supply hose to a
threaded 3/4'' water tap and make sure that
it is fastened tightly in place.
If the water hoses are new or have not
been used for an extended period of time, let
the water run through to make sure that the
water is clear and free of impurities,
If this precaution is not taken, there is
a risk that the water inlet can get
blocked and the appliance could
be damaged.
Electrical connection
Make sure the socket is compatible
with the plug of the appliance.
The socket must have earthing wire, and be
rated to 230-240V/10A, otherwise damage to
the appliance may occur.
Do not run any other appliances from the
same power socket at the same time as the
dishwasher.
7
Drain hose hook
sink
Max:1000mm
Min:400mm
outlet hose
Min:40mm
Connecting the water outlet hose
Put the hose into a drainage pipe with a diameter of
more than 40mm or into the sink waste pipe,. The
outlet pipe must be straight, and the height of the end
of pipe should be less than 1000mm higher than the
base of the dishwasher.
Notice: The outlet pipe connector
should be tight.
8
Level Adjustment
Allowable slope under entire dishwasher is 2 degree. Adjust the height by
turning the feet to make sure the dishwasher is level.
Tension Adjustment of the Door Spring
After placing the panel on the dishwasher, open and close the door
to test the balance of the door (see whether the door can remain at
the same place. If not, turn the adjustment screw to adjust the
balance of the door.
+-
Adjust the back feet
Adjust the front feet
+ - + -
Fix the dishwasher to the cabinet using four ST4*26 self-
tapping wood screws. There are four holes on the inside edge
of the dishwasher. Open the door, place the screws in the
supplied hole plugs, and screw through into the cabinet.
1.Fixing the dishwasher with the cabinet by turning the screws.
2.Plug the four hole plugs into the holes in the sketch map.
Fixation of dishwasher
ST4 * 26
hole plug
Hexnut tools
CR-V 4mm
Notice:
The required height of the skirting board is determined by the height
of the ornamental plate and clearance when the door is opened.
Installation of skirting board
9
Referenced dimension
serial
number
1
2
3
4
5
6
ornamental
plate
708mm
698mm
688mm
678mm
668mm
658mm
skirting board
75mm
85mm
95mm
105mm
115mm
125mm
-
+
708max 658min
ornamental plate
125max
75min
skirting board
15
4
Fix the ornamental plate to the door
ST 4x42wooden screw
4x42wooden screw
①
②
ornamental plate (2~5KG)
The T-shaped plug
2-4x26wooden screw
Remove 2-ST 4x10 screw
The door of dishwasher
3
Tension Adjustment of the Door Spring
After placing the panel on the dishwasher, open and close the door
to test the balance of the door (see whether the door can remain at
the same place. If not, turn the adjustment screw to adjust the
balance of the door.
Hexnut tools
CR-V 4mm
-
+
4
1
2

23
22
Connecting the water inlet hose (for cold water)
Connection the cold water supply hose to a
threaded 3/4'' water tap and make sure that
it is fastened tightly in place.
If the water hoses are new or have not
been used for an extended period of time, let
the water run through to make sure that the
water is clear and free of impurities,
If this precaution is not taken, there is
a risk that the water inlet can get
blocked and the appliance could
be damaged.
Electrical connection
Make sure the socket is compatible
with the plug of the appliance.
The socket must have earthing wire, and be
rated to 230-240V/10A, otherwise damage to
the appliance may occur.
Do not run any other appliances from the
same power socket at the same time as the
dishwasher.
7
Drain hose hook
sink
Max:1000mm
Min:400mm
outlet hose
Min:40mm
Connecting the water outlet hose
Put the hose into a drainage pipe with a diameter of
more than 40mm or into the sink waste pipe,. The
outlet pipe must be straight, and the height of the end
of pipe should be less than 1000mm higher than the
base of the dishwasher.
Notice: The outlet pipe connector
should be tight.
8
Level Adjustment
Allowable slope under entire dishwasher is 2 degree. Adjust the height by
turning the feet to make sure the dishwasher is level.
+-
Adjust the back feet
Adjust the front feet
+ - + -
Notice:
The required height of the skirting board is of the
ornamental plate and clearance when the door is opened
.
Installation of skirting board
Referenced dimension
serial
number
1
2
3
4
5
6
ornamental
plate
708mm
698mm
688mm
678mm
668mm
658mm
skirting board
75mm
85mm
95mm
105mm
115mm
125mm
708max 658min
ornamental plate
125max
75min
skirting board
15

21
24
Installation Instruction
Connecting the water inlet hose (for cold water)
Connection the cold water supply hose to a
threaded 3/4'' water tap and make sure that
it is fastened tightly in place.
If the water hoses are new or have not
been used for an extended period of time, let
the water run through to make sure that the
water is clear and free of impurities,
If this precaution is not taken, there is
a risk that the water inlet can get
blocked and the appliance could
be damaged.
Electrical connection
Make sure the socket is compatible
with the plug of the appliance.
The socket must have earthing wire, and be
rated to 230-240V/10A, otherwise damage to
the appliance may occur.
Do not run any other appliances from the
same power socket at the same time as the
dishwasher.
7
Drain hose hook
sink
Max:1000mm
Min:400mm
outlet hose
Min:40mm
Connecting the water outlet hose
Put the hose into a drainage pipe with a diameter of
more than 40mm or into the sink waste pipe,. The
outlet pipe must be straight, and the height of the end
of pipe should be less than 1000mm higher than the
base of the dishwasher.
Notice: The outlet pipe connector
should be tight.
8
Level Adjustment
Allowable slope under entire dishwasher is 2 degree. Adjust the height by
turning the feet to make sure the dishwasher is level.
Tension Adjustment of the Door Spring
After placing the panel on the dishwasher, open and close the door
to test the balance of the door (see whether the door can remain at
the same place. If not, turn the adjustment screw to adjust the
balance of the door.
+-
Adjust the back feet
Adjust the front feet
+ - + -
Fix the dishwasher to the cabinet using four ST4*26 self-
tapping wood screws. There are four holes on the inside edge
of the dishwasher. Open the door, place the screws in the
supplied hole plugs, and screw through into the cabinet.
1.Fixing the dishwasher with the cabinet by turning the screws.
2.Plug the four hole plugs into the holes in the sketch map.
Fixation of dishwasher
ST4 * 26
hole plug
Hexnut tools
CR-V 4mm
Notice:
The required height of the skirting board is determined by the height
of the ornamental plate and clearance when the door is opened.
Installation of skirting board
9
Referenced dimension
serial
number
1
2
3
4
5
6
ornamental
plate
708mm
698mm
688mm
678mm
668mm
658mm
skirting board
75mm
85mm
95mm
105mm
115mm
125mm
-
+
708max 658min
ornamental plate
125max
75min
skirting board
15
4
Fix the dishwasher to the cabinet using four ST4*26 self-
tapping wood screws. There are four holes on the inside edge
of the dishwasher. Open the door, place the screws in the
supplied hole plugs, and screw through into the cabinet.
1.Fixing the dishwasher with the cabinet by turning the screws.
2.Plug the four hole plugs into the holes in the sketch map.
Fixation of dishwasher
ST4*26
hole plug
9
That the purchaser contact Blanco prior to any product repair.
That the purchaser carefully follows all instructions pro ided with the product and complies with all rele ant electrical & plumbing
regulations in their State when installing the product.
That the purchaser carefully follows the instructions pro ided in the owner’s handbook relating to the proper use and care of the
product and does not use the product for any purpose other than the DOMESTIC use for which it has been designed. If the
appliance is used in commercial applications or for rental purposes, Our Warranty is limited to a warranty of Twelve (12) months
co ering all parts with Three (3) months on any labour cost of ser ice or repair.
SERVICE AREA
The pro ision of ser ice under Our Warranty is limited by the boundary / territory area of the nearest ser ice centre. Tra elling cost incurred
for ser ice outside this area is not co ered by Our Warranty and ser ice will incur commercial cost to be paid by the customer regulated by
the number of kilometres tra elled beyond the ser ice area. These costs will be disclosed to you for acceptance by you prior to your claim
being processed.
Microwave ovens must be returned to your nearest Authorised Ser ice Centre for repair as they are a carry in ser iceable appliance.
WHAT IS COVERED: By Our Warranty
During the warranty period, Blanco or its authorised Ser ice Centre will at no extra charge, if your appliance is readily accessible without the
need of special equipment and subject to the terms and conditions of this warranty, repair or replace any parts which it considers defecti e.
WHAT IS NOT COVERED: By Our Warranty
Products installed damaged or incomplete or not in compliance with the rele ant electrical & plumbing regulations in their State.
Normal wear and tear e.g. cleaning, light globes, filters etc.
Failure resulting from power surges and electrical storms.
Insect or ermin infestation.
Unauthorised repairs or use of non genuine Blanco parts.
Any failure caused by the product not being used in accordance with the instruction and the installation manual pro ided with the product.
Misuse or abuse, including failure to properly maintain or ser ice.
The clearing of blockages in pumps and hoses.
Damage which occurs during deli ery or installation.
Claims to product surface coating due to liquid or solid spill-o ers, accidental damage or damage caused from cleaning products not
recommended by Blanco.
HOW TO CLAIM OUR WARRANTY
You will need to contact Blanco in Australia or New Zealand by using the contact details below.
IN AUSTRALIA
Blanco is distributed by Shriro Australia Pty Ltd
Locked Bag 5002, Kingsgrove, NSW, 2208 Phone:
1300 795 572 Fax: [phone]
Email: [email protected]
Web: http://www.blanco-australia.com/
IN NEW ZEALAND
Blanco is distributed by Monaco Corporation
(Member of Shriro Australia Pty Ltd)
PO Box 4399, Shortland St, Auckland, 1140
Phone: [phone] Fax: [phone]
Email: [e-mail]
Web: http://www.blanco.co.nz/
Note: Please complete the following details when you have unpacked the product and staple this card with the purchase
invoice or sales docket.
Model No<<<<<<<<<<<<<<<< Serial No<<<<<<<<<<<<<<<
Date of Purchase<<<<<<<<<<<..< Retailer<<<<<<<<<<<<<<<.<
AUSTRALIAN & NEW ZEALAND PRODUCT WARRANTY
STATEMENT OF STANDARD WARRANTY CONDITIONS
AUSTRALIAN CUSTOMERS
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund
for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to ha e the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
NEW ZEALAND CUSTOMERS
Nothing herein contained shall be construed in any way as excluding or limiting your rights under the Consumer Guarantee Act 1993.
OUR WARRANTY
This product is also co ered by the manufacturer's warranty set out in this document (Our Warranty).
Our Warranty is for a period of fourty eight (48) months from the date of purchase and for dishwasher & refrigeration appliances will
ha e an additional thirty six (36) months after the first twenty four (24) months on the wash motor for dishwashers & on the Sealed
System (PARTS only Compressor & condenser etc) for refrigeration appliances. The labour cost to replace these parts is the
responsibility of the customer.
This is in addition to (and does not exclude, restrict or modify) any rights or remedies to which you may already be entitled under the
Australian consumer Law or the New Zealand Consumer Guarantee Act 1993 relating to this product.
Our Warranty (which is subject to the conditions below) co ers rectification free of charge of any fault arising from defecti e materials or
components, or faulty workmanship. The product will be repaired or replaced at the option of Blanco, and all costs of installation, remo al,
cartage, freight tra elling expenses and insurance are to be paid by the customer.
Our Warranty is subject to the following conditions:
