Blanco BDW4510X User manual

Dishwasher
Instruction
InstructionInstruction
Instruction Manual
Manual Manual
Manual
BDW4510X

CONTENTS
•Technicalspecifications……………………………………………………..
4
•ConformitywiththestandardsandTestdata……………………………..
4
SafetyinformationandRecommendations…………………………………..5
•Recycling.......……………………….........................................................
5
•Safetyinformation……………………………………………………………
5
•Recommendations…...………………………………………………………
8
•Itemsnotsuitablefordishwashing…………………………………………
9
Installing the machine …………………………………………………………..9
•Positioningthemachine……………………………………………………..
9
•Waterconnections…………………...............................................................
10
•Waterinlethose….…………………………………………………………..
11
•Wateroutlethose…..………………..............................................................
12
•Electricalconnection…………………………………………………………
13
•Fittingthemachineundercounter………………………………………….
14
•Priortousingthemachine…………………………………………………. 16
Preparing the machine for use………………………………………………… 16
•Detergentusage……………………........................................................16
•Fillingthedetergentcompartment…………………………………………. 16
•Combineddetergent….………………………………………………………16
•Fillingwithrinseaidandmakingthesetting………………………………. 17
1

Loadingyour dishwasher.……………………………………………………. 19
•Topbasket…………………………………………………………………...19
•Lowerbasket………………………………………………………………...20
•Alternativebasketloads…………………………………………………...22
Programmedescriptions .……………………………………………………..24
•Programmeitems…………………………………………………………..24
Selection of Program and Starting of the Machine.......……………........26
•Selection of Program and Starting of the Machine ……………………. 29
•Programmefollow-up………………………………………………………30
•Adding Additional Functions to the Program …………………………… 31
•Changing a programme /Changingaprogrammewithresetting……...32
•Settings Menu ...................….……………………………………………...33
Maintenanceand Cleaning ........................................................................36
•Filters..………………………………………………………………………36
•Sprayarms…………………………………………………………………. 37
•Hosefilter……………………………………………………………………37
Failure codesand whattodo incaseof failure ………………………… 38
Practicaland useful information…….........................................................40
2
Getting familiarwithyour machine ……………………………………………
25

3
7. Rating plate
2. Upper basket with racks 8. Control Panel
3. Upper spray arm 9. Detergent and rinse-aid dispenser
4. Lower basket
5. Lower spray arm 10.
6. Filters
Upper basket track latch
1. Worktop
12
Turbo Drying Unit: Thissystemprovides better drying performance for your dishes.
1 2 3
7
8
9
10
11
5
6
4
11. Upper Cutlery Basket
Ceiling Spray Arm: It provides
better washing for the dishes at
upper basket.
13

4
Capacity 15place settings
Height 850 mm
Height (without worktop) 820 mm
Width 598mm
Depth 598 mm
Net Weight 62 kg
Electricity input 220-240 V, 50 Hz
Total Power 2200 W
Heating Power 2000 W
Pump Power 100 W
Drain Pump Power 30 W
Water supply pressure 0.03 MPa (0,3 bar)-1 MPa (10 bar)
Current 10 A
Technical specifications
Producer company has its right to amend design and technical
specifications reserved.The machine's service life is 10 years
(the duration required to keep spare parts for the machine to
fulfil its usage functions).
ConformitywiththestandardsandTestdata/ECDeclaration
of Conformity
All stages related to the machine are executed in accordance
with the safety rules provided in all relevant directives of the
European Community. 2004/108/EC, 2006/95/EC,IEC 436/DIN
44990,AS/NZS 2007.1/2:2005
Important Note for User:For softcopy of this user manual,
please contact following address:
"[email protected]”.In your e-mail, please
provide the model name and serial number (20 digits) which
you can find on the appliance door.

5
SAFETYINFORMATIONANDRECOMMENDATIONS
Recycling
• Certain components and the packaging of your machine
have been produced from recyclable materials.
• Plastic parts are marked with international abbreviations:
(>PE< , >PS< , >POM<, >PP<, )
• Cardboard parts have been produced from recycled paper
and they should be disposed of into waste paper collection
containers for recycling.
• Such materials are not suitable for being disposed of into
garbage bins. They should be delivered to recycling centres
instead.
• Contact relevant centres in order to obtain information on
methods and points of disposal.
Safety Information
When you take delivery of your machine
• Check for any damage to your machine or to its packaging.
Never start a machine damaged in any way, make sure to
contact an authorised service.
• Unwrap the packaging materials as indicated and dispose
of them in accordance with the rules.
The points to pay attention during machine installation
•Choose a suitable, safe and level place to install your
machine.
• Carry out the installation and connection of your machine by
following the instructions.
•This machine should be installed and repaired by an
authorised service only.
• Only original spare parts should be used with the machine.
• Before installing, be sure that the machine is unplugged.

6
• Check whether the indoor electrical fuse system is connected
according to the regulations.
• All electrical connections must match the values indicated
on the rating plate.
• Pay special attention and be sure that the machine does not
stand on the electricity supply cable.
• Never use an extension cord or a multiple socket for making
a connection. The plug should be comfortably accessible
after the machine has been installed.
• After installing the machine to a suitable place, run it unloaded
for the first time.
In daily use
• This machine is for household use; do not use it for any
other purpose. Commercial usage of the dishwasher will void
the guarantee.
• Do not get up, sit or place a load on the open door of the
dishwasher, it may fall over.
• Never put into the detergent and rinse aid dispensers of
your machine anything other than those detergents and rinse
aids which are produced specifically for dishwashers. Our
company will not be responsible for any damage that might
occur in your machine otherwise.
• The water in the machine's washing section is no drinking
water do not drink it.
• Due to danger of explosion, do not put into the machine’s
washing section any chemical dissolving agents such as
solvents.
• Check whether plastic items are heat-resistant before
washing them in the machine.
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or

7
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.Cleaning
and user maintenance shall not be made by children without
supervision.
• Do not put into your machine those items which are not
suitable for dishwashing. Also, do not fill any basket above its
capacity.Our company will not be responsible for any scratch
or rust to form on the inner frame of your machine due to
basket movements otherwise.
• Especially because hot water may flow out, the machine
door should not be opened under any circumstances while
the machine is in operation. In any case, a safety devices
ensures that the machine stops if the door is opened.
• Do not leave your dishwasher’s door open. Failure to do so
may lead to accidents.
• Place knives and other sharp-ended objects in the cutlery
basket in blade-down position.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
•This appliance is not intended for use by persons (including -
children) with reduced physical,sensory or mental capabilities,
or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• If EnergySave option is selected as "Yes", The door will be
opened at the end of the program. Do not force to close the
door to avoid harm auto door mechanism during 1 minutes.
The door must be open during 30 minutes to get effective
drying.( in models with auto door opening system )
Warning: Do not stand in front of the door after the signal
sounds belonging auto-open.

8
For your children’s safety
• After removing the machine’s packaging, make sure that the
packaging material is out of reach of children.
• Young Children should be supervised to ensure they do not
• Keep your children away from detergents and rinse aids.
•Keep children away from the machine while it is open
because there may still be residues of cleaning substances
inside the machine.
• Be sure that your old machine does not pose any threat to
your children. Children are known to have gotten themselves
locked in old machines. To forestall such a situation, break
your machine's door lock and tear off the electrical cables.
In case of malfunctioning
• Any malfunction in the machine should be repaired definitely
by qualified persons. Any repair work performed by anyone
other than the authorised service personnel will cause your
machine to be left outside the scope of warranty.
• Prior to any repair work on the machine, be sure that the
machine is cut off from the mains.Switch off the fuse or unplug
the machine.Do not pull by the cable when unplugging. Make
sure to turn off the water tap.
Recommendations
• For energy and water saving, remove coarse residues on
your dishes before placing the dishes into the machine. Start
your machine after having fully loaded it.
play with the appliance.
•WARNINGS: Some dishwasher detergents are strongly
alkaline. They can be extremely dangerous if swallowed. Avoid
contact with skin and eyes and keep children away from the
dishwasher when the door is open. Check the detergent
receptacle is empty after completion of the wash cycle.

9
Items not suitable for dishwashing:
• Cigarette ashes, candle leftovers, polish, paint, chemical
substances, iron-alloy materials;
• Forks, spoons and knives with wooden or bone, or ivory or
nacre-coated handles; glued items,items soiled with abrasive,
acidic or base chemicals.
• Plastic items that are not heat-resistant, copper or tin-coated
containers.
• Aluminium and silver objects (they may discolour, become
dull).
•Certain delicate glass types, porcelains with ornamental
printed patterns as they fade even after the first wash; certain
crystal items as they lose their transparency over time,
adhered cutlery that is not heat-resistant, lead crystal glasses,
cutting boards, items manufactured with synthetic fibre;
• Absorbent items as sponges or kitchen rags are not suitable
for dishwashing.
Warning:Take care to buy dishwasher-proof sets in your
future purchases.
INSTALLING THE MACHINE
Positioning the machine
When determining the place to put your machine on, take
care to choose a place where you can easily load and unload
your dishes.
• Place such hollow items as bowls, glasses and pots into the
machine in such a way that they will face down.
• You are recommended not to load into your machine any
dishes different or more than indicated.
• Use the pre-wash programme only whenever necessary.

10
Position the machine close to a water tap or drain. You
need to site your machine, taking into consideration that its
connections will not be altered once they are made.
Do not grip the machine by its door or panel in order to move
it.
Take care to leave a certain clearance from all sides of the
machine so that you can comfortably move it back and forth
during cleaning.
Make sure that the water inlet and outlet hoses do not get
squeezed while positioning the machine. Also, make sure
that the machine does not stand on the electrical cable.
Adjust the machine’s adjustable feet so that it can stand level
and balanced. Proper positioning of the machine ensures
problem-free opening and closing of its door.
If the door of you machine does not close properly, check if
the machine is stable on the floor it stands; if not, adjust the
adjustable feet and ensure its stable position.
Water connection
Be sure that the indoor plumbing is suitable for installing a
dishwasher. Also, we recommend that you fit a filter at the
entrance of your place or apartment so as to avoid any damage
to your machine because of any contamination (sand, clay,
rust etc.) that might be occasionally carried in through the
mains water supply or the indoor plumbing, and to forestall
such complaints as yellowing and formation of deposits after
washing.
Do not put your machine in any location where there is the
probability for the room temperature to fall below 0°C.
Before positioning, take the machine out of its packaging by
following the warnings located on the package.

11
Water inlet hose
Do not use the water inlet hose of your
old machine,if any. Use the new water inlet
hose supplied with your machine instead.
If you are going to connect a new or long
- unused water inlet hose to your machine
,run water through it for a while before
making the connection. Connect the water
inlet hose directly to the water inlet tap.
The pressure supplied by the tap should
be at a minimum of 0.03 Mpa and and at a
maximum of 1 Mpa.If the water pressure is
above 1 Mpa,a pressure-relief valve should
be fitted inbetween.
After the connections are made, the tap should be turned on
fully and checked for water tightness.For the safety of your
machine, make sure to always turn off the water inlet tap after
each wash programme is finished.
NOTE: Aquastop water spout is used
in some models. In case of using
Aquastop, a dangerous tension exists.
Do not cut Aquastop water spout. Do
not let it get folded or twisted.

12
Water outlet hose
The water drain hose can be connected
either directly to the water drain hole
or to the sink outlet spigot. Using a
special bent pipe (if available), the
water can be drained directly into the
sink via hooking the bent pipe over
the edge of the sink. This connection
should be at a minimum of 50 cm and
at a maximum of 110 cm from the floor
plane.
Warning: When a drain hose longer than 4 m is used, the
dishes might remain dirty. In that case, our company will not
accept responsibility.

13
Electrical connection
The earthed plug of your machine should be connected to
an earthed outlet supplied by suitable voltage and current. If
there is no earthing installation, have a competent electrician
carry out an earthing installation. In case of usage without
earthing installed, our company will not be responsible for
any loss of usage that might occur.
The indoor fuse current value should be 10-16 A.
Your machine is set according to 220-240 V. If the mains
voltage in your location is 110 V, connect a transformer of
110/220 V and 3000 W inbetween. The machine should not
be plugged in during positioning.
Always use the coated plug supplied with your machine.
Running in low voltage will cause a decline in washing quality.
The machine’s electrical cable should be replaced by an
authorised service or an authorised electrician only. Failure
to do so may lead to accidents.
For safety purposes, always make sure to disconnect the
plug when a wash programme is finished.
In order not to cause an electric shock, do not unplug when
your hands are wet.
When disconnecting your machine from the mains supply,
always pull from the plug. Never pull the cord itself.

14
Fitting the machine undercounter
If you wish to fit your machine undercounter, check whether
you have sufficient space under your countertop and whether
the wiring-plumbing is suitable to do so.1If you decide that
the space under the countertop is suitable for fitting your
machine, remove the worktop as shown in the illustration. 2
Warning:The stand part which we will settle our machine
under it by removing its worktop has to be stable in such a
way not to allow balance disorder.
To remove the worktop, remove the screws that hold the
worktop which are located at the rear of the machine; then
push the front panel 1 cm from the front side towards the rear
and lift it.

15
Adjust the machine feet according to the slope of the floor.3
Fit your machine by pushing it undercounter without letting
the hoses get crushed or bent.4
Warning: After removal of worktop, the machine should be
placed in such a closed place of which dimensions are shown
at fig.
H
WithoutInsulation
AllProductFor2ndBasket For3rdBasket
Height 820mm 830mm 835mm
WithInsulation
Product

Prior to using the machine for the first time
•Check whether the electricity and supply water specifications match the values indicated by the
installation instructions for the machine.
•Remove all packaging materials inside the machine.
•Fill the rinse aid compartment.
16
Detergent usage
Use a detergent specifically designed for use in domestic dishwashers.
You can find powder,gel,and tablet detergents in the market that have been designed for
household dishwashers.
Detergent should be put into the compartment prior to starting the machine. Keep your
detergents in cool, dry places out of reach of your children.
Do not fill detergent into the detergent compartment more than required; otherwise it may cause
scratches on your glasses as well as lead to a poorly dissolved detergent.
Should you need more information concerning the detergent you will use, contact detergent
manufacturers directly.
Filling the detergent compartment
Push the latch to open the detergent container as shown in the
image. 1Detergent pod has level lines inside. It is possible to
measure the right
detergent amount using
these lines. Detergent
pod can take totally 40
cm3detergent.
Open the dishwasher
detergent and pour into
the larger compartment b25 cm3if your dishes are
heavily soiled or 15 cm3if they are less soiled.2If your
dishes have been kept dirty for a very long time, if there
are dried food wastes on them, and if you have overly
loaded the dishwasher, pour a5 cm3detergent into the pre-wash compartment and start your
machine.
You may have to add more detergent into your machine, depending on the degree of soil and
on the water hardness level in your area.
Combined detergent
Detergent manufacturers also produce combined detergents called “2 in 1”, “3 in 1” or “5 in 1”
etc.
“2 in 1” detergents contain detergent + salt or rinse aid. When using “2 in 1” detergents make
sure to check the specifications of the tablet.
Other tablet detergents contain detergent + rinse aid + salt + varlous extra functions.
Generally, combined detergents produce sufficient results under certain usage conditions only.
Such detergents contain rinse aid and/or salt in preset amounts
PREPARING THE MACHINE FOR USE

17
Points to consider when using this type of products:
•Always make sure to check the specifications of the product you will use or whether or not
it is a combined product.
•Check if the detergent used is appropriate for the hardness of mains water that machine is
appertaining to.
•Observe the instructions on packagings when using such products.
•If such detergents are in the form of tablets, never put them into the interior section or the
cutlery basket of the dishwasher. Always put the tablets into the detergent compartment in
the detergent dispenser.
•They produce good results for certain types of usage only. If you are using this type of
detergents, you need to contact the manufacturers and find out about the suitable
conditions of use.
•When the conditions of use of such products and the machine settings are appropriate,
they ensure savings in rinse aid consumption.
•Contact the detergent manufacturers if you are not obtaining good wash results (if your
dishes stay calcareous and wet) after having used 2 in 1 or 3 in 1 detergents. The scope of
warranty for your machine does not cover any complaints caused by the use of these types
of detergents.
Recommended usage: If you want to obtain better results while using combined detergents,
add rinse aid into your machine and adjust the rinse aid setting to the lowest position.
Solubility of the tablet detergents produced by different companies can vary
depending on the temperature and time. Therefore, it is not recommended to use such
detergents in short programs. It is more suitable to use powder detergents in such
programs.
Warning: Should any problem, which you have not encountered before, arise with the use of
this type of detergents, contact the detergent manufacturers directly.
When you give up using combined detergents
•Fill the rinse aid compartment.
•Make the suitable rinse aid setting.
Filling with rinse aid and making the setting
Rinse aid is used to prevent the stay of white water drops, lime
stains, white film strip-shaped stains that may form on the dishes, as
well as to increase the drying performance. Contrary to the popular
beliefs, it is used not only for obtaining shinier dishes but also for
obtaining sufficiently dried dishes. For this reason, care should be
taken that there is adequate amount of rinse aid in the rinse aid
compartment and only polishing material produced for use at
dishwashers should be used.
If the rinse aid lamp on the control panel becomes on fill the rinse aid
compartment with rinse.

To put rinse aid, remove the rinse aid compartment cap by turning it.1Fill the rinse aid
compartment with rinse aid until the rinse aid level indicator becomes dark;2refit the cap and
close it by turning it in a way that the nails will correspond to one another. By checking the rinse
aid level indicator on the detergent dispenser, you can understand whether or not your machine
needs rinse aid. A dark indicator b means that there is rinse aid in the compartment, while a
light indicator ashows that you need to fill the compartment with
rinse aid.
The rinse aid level adjuster can be set
to a position between 1 and 6. Factory
settingforrinseaidistheposition3.
You need to increase the degree of the
adjuster if water stains form on your
dishes after a wash, whereas you need
to decrease the degree if a blue stain
is left when wiped by hand.3
18
Warning: Use only those rinse aid materials which are allowed for use in the machine. As rinse
aid residues left as a result of overflowing will create extremely high amounts of foam and thus
reduce the washing performance, remove the excess amount of rinse aid by wiping it with a rag.

19
If you properly place your dishes into the machine, you will be using it in the best way in terms
of energy consumption, washing and drying performance.
There are two separate baskets for you to load your dishes into your machine. You can load into
the lower basket such round and deep items as pots with long handles, pot lids, plates, salad
plates, cutlery sets.
The upper basket has been designed for tea plates, dessert plates, salad bowls, cups and
glasses. When placing long-stem glasses and goblets, lean them against the basket edge, rack
or glass supporter wire and not against other items. Do not lean long glasses against one
another or they cannot remain steady and may receive damage.
It is more appropriate to locate the thin narrow parts into the middle sections of baskets.
You can place spoons among the other cutlery sets in order to prevent them from sticking to
one another. You are recommended to use the cutlery grid in order to obtain the best result.
To avoid any possible injuries, always place such long-handle and sharp-pointed dishes as
serving fork, bread knife etc. with their sharp points facing down or horizontally on the baskets.
Warning: Place your dishes into your machine in a way that they will not prevent the upper and
lower spray arms from spinning.
LOADING YOUR DISHWASHER
Top basket
Height Adjustable Rack
These racks are designed to increase the capacity of the
top basket. You can place your glasses and cups on the
racks. You can adjust the height of these racks. Thanks to
this feature, you can place different sizes of glasses under
these racks.
Thanks to height adjustment plastics mounted on the
basket, you can use your racks in 2different heights. In
addition, you can place long forks, knives and spoons on
these racks laterally, so that they do not block the
revolution of propeller.
2
1
Foldable racks on the upper basket are designed
in order to let you place big items easier such as
pots, pans, etc. If requested, each part can be
folded separately, or all of them can be folded
and larger spaces can be obtained. You can use
foldable racks by raising them upwards,or by folding
down.
