Blanco BOSE652X User manual

1
Instruction Manual for
Electric Ovens
BOSE652X

2
Dear Customer,
Thank you for buying a BLANCO oven.
Before we continue telling you about this oven, we cordially invite you to
become part of the Blanco family by subscribing online. Please visit our
website where you can easily register for product/cooking demonstrations, and
request Blanco’s gourmet recipes. Go to www.blanco-australia.com and fill in
the subscription details in the contact us/showrooms section.
You will find that the clean lines and modern look of your Blanco oven blends in
perfectly with your kitchen décor. It is easy to use and performs to a high
standard.
Blanco also makes a range of products that will enhance your kitchen such as
cooktops, rangehoods, dishwashers, microwaves, sinks and taps. There are
models to complement your new Blanco oven.
Of course, we make every effort to ensure that our products meet all your
requirements, and our Customer Relations department is at your disposal, to
answer all your questions and to listen to all your suggestions.
Please complete the warranty card and keep your receipt as proof of purchase.
Retain all documents relating to the purchase of this product.
Blanco is committed to providing increasingly efficient products that are easy to
use.

3
Table of Contents
Safety Instructions 4
Warnings 4
Use 4
Maintenance and cleaning 5
Installation of your Oven 6
Electrical Installation 8
Oven Racks 9
Accessories 10
Oven Presentation 11
Cooking Functions 15
Instructions for Use 16
Oven Door Removal 18
Replacement of the Oven Light 20
Guidance Temperature and Time Temperature for Cooking 21
Cooking Recipes 23

4
Safety Instructions
Important
-When you receive the appliance, unpack it or have it unpacked immediately.
Give it an overall inspection. Make note of any concerns or reservations on the delivery slip and make sure
to keep a copy of this form. Keep this user guide with your appliance.
If the appliance is ever sold or transferred to another person, ensure that the new owner receives the user
guide. Please become familiar with these recommendations before installing and using your oven. They
were written for your safety and the safety of others.
WARNING
-The Appliance is not intended for use by persons (including Children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervised
instruction concerning use of the appliance by a responsible person for their safety.
-Cleaning and maintenance operations must not be carried out by children without supervision.
-Children must be supervised to prevent them from playing with the appliance.
WARNING
-During use the appliance becomes hot. Care should be taken to avoid touching heating elements inside
the oven.
-Accessible parts will become hot when in use. To avoid burns and scalds, young children should be kept
away.
Use
-Before using your oven for the first time, heat it while empty for approximately 15 minutes.
You should ensure you heat each element in the oven before use. Make sure that the room is sufficiently ventilated.
You may notice a particular odour, or a small release of smoke. All of this is normal.
Your appliance is intended for standard household use. Do not use it for commercial or industrial purposes or for
any other purpose than that for which it was designed.
This oven was designed for use by private individuals in their homes. It is intended solely for cooking foodstuffs.
This oven does not contain any asbestos-based components.
-Do not modify or attempt to modify any of the characteristics of this appliance. This would be dangerous to your
safety.
-Never pull your appliance by the door handle.
-When placing dishes inside or removing them from the oven, do not place your hands close to the upper heating
elements and use heat-protective kitchen gloves.
-At the end of cooking, do not pick up oven or grill items (grid) with your bare hands.
-Never place aluminium foil directly in contact with the floor of the oven, as accumulated heat may cause
deterioration of the enamel.
-Do not place heavy weights on the open oven door, and make sure that children are able neither to climb nor sit
on it.
-Do not use your oven as a larder or to store any items after use.
-After using your oven, make sure that all the controls are in their stop position.
-In addition to the accessories supplied with your oven, only use dishes capable of withstanding high temperatures.

5
Maintenance and cleaning
-Do not use a steam cleaner.
-For any cleaning operation inside the oven cavity, the oven must be switched off.
-Before unclipping the door, allow the appliance to cool.
-Before removing the back, ensure that the appliance is powered down. After cleaning, the back should be
replaced.
-Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven glass door since they can scratch
the surface, which may result in shattering of the glass.
-To clean both the electronic programmer window and the oven door, use a soft cloth.
-Do not use cleaning products, abrasive creams, or scouring sponges.
WARNING
-Make sure the appliance is disconnected from the power before replacing the lamp in order to avoid the
risk of electric shock.
-Change the lamp only when the appliance has cooled down. To unscrew the view port and the light, use a
rubber glove, which will make disassembly easier.
WARNING
-Installation should only be performed by qualified installers and technicians.
WARNING
-If the electrical supply is restricted, means of all-pole disconnection must be accessible and
incorporated in the fixed wiring in accordance with the wiring rules.
-If the power cable is damaged, it should be replaced by the manufacturer, its after-sales service
department or by a similarly qualified person in order to avoid danger.
PACKAGING
-This appliance’s packing materials are recyclable. Recycle them by depositing them in local authority
containers provided for this purpose.
-Your appliance also contains many recyclable materials. It is therefore marked with this logo to indicate
that used appliances must not be mixed with other waste.

6
Installation of your oven
TALLATION OF YOUR OV
To install the oven into the kitchen a cut out should be made in accordance with the dimensions shown in below.
Please allow for 3/4mm of a difference in the dimensions provided below. Please measure the original product to
ensure that the cut out details are correct.
The apparatus is to be fastened to the top by means of the two screws provided in the kit through the holes made
on the oven uprights.
The cabinet in which the apparatus is installed shall be open on the back side to ensure a sufficient air circulation
and prevent overheating.
Leave a gap of at least 20 cm2 for air circulation if the oven is installed in a column; this is not necessary if the oven
is installed under the work top.
WARNING
As the apparatus is to be fitted in your kitchen furniture, make sure that all surfaces in contact with the
oven can resist a temperature of approx 90°C.
Overall
product
Dimensions
595 mm
Height
595 mm
Width
550 mm
Depth

7

8
Electrical Installation
BOSE652X is a 10 amp appliance.
WARNING This apparatus must be earthed.
The oven is only for domestic use.
The feed voltage and the absorbed power are as indicated on the data plate attached to the left-hand side upright,
which can be seen when the oven door is open.
Connecting must be carried out by qualified personnel and in accordance with the regulations currently in force.
The manufacturer cannot be held responsible for any damages to persons or objects caused by failure to observe
these instructions.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
The oven must be connected to the mains through a multiple circuit breaker with a contact-to-contact gap of at least
3 mm, making sure that the earth wire is not disconnected.
For connecting use a flexible cable of the H05V2V2-F 3x1,5 mm2 type remembering to make it long enough to
allow the oven to be removed from its housing unit when maintenance work is required.
To connect the cable to the oven, proceed as follows:
-Remove the lid by unfastening the three screws.
-Unfasten the two screws for the cable holder and feed the cable through the opening immediately below the cover.
-Remove about 12 cm of the outside insulation from the cable and shorten the two active wires (live and neutral) to
6 cm, leaving long the one to be connected to the main earth terminal on the terminal box; remove about 1 cm of
the main insulation from the three wires and connect them correctly to the terminal box, Remembering to respect
the polarities.
-Tighten the two screws of the cable holder and put the lid back on with the three screws.
2200W
2300 W
25 W
20 - 25 W
Electrical Specification
BOSE652X
- Absorbed power:
Grill element:
Fan forced element:
Lamp:
Hot air fan motor:
Cooling fan motor: 25 W
-Maximum absorbed power: (see data plate).
-Supply voltage: (see data plate)

9
Oven Racks
WARNING
Never use aluminum foil to cover the oven racks or to line the oven. It can
cause damage to the oven liner if heat is trapped under the foil.
WARNING
Make sure you do not force it to avoid damage to the enamel.
The oven has rack guides at five levels as per the below image.
Rack positions are numbered from the bottom rack guide (#1) to the top (#5).
Check cooking charts for best rack positions to use when cooking. Each level
guide consists of paired supports formed in the walls on each side of the oven
cavity. Always be sure to position the oven racks before turning on the oven.
Make sure that the racks are level once they are in position. The racks are
designed to stop when pulled forward to their limit.

10
Accessories
BOSE652X
Included accessories which are provided with this oven are as follows:
-2 x safety anti tip shelves
-1 x grill pan
-2 x telescopic runners
-1 x grill pan insert
-1 x grill handle

11
English
Oven Presentation
The oven control panel is made up of 2 knobs and one touch control timer display.
-1 knob for the temperature control
-1 knob for the oven functions
– Touch control timer display as per the below image. (Please note that the
display colour in the oven is red when lit and not white as shown in these images)
TIMER TOUCH CONTRO L
Setting the clock
Fig.1
“Auto” and “0:00” will start flashing when the unit is switched on for the first time. To set the clock,
press the central button for about 3 seconds. When appears, press “+” or “-“ to set the
correct time.
Wait until a beep tells you that the clock has been set (fig. 1).
To set the time at a later stage, press “+” and “-” together for 3 seconds and then adjust the clock
as described above.

12
Minute coun t e r
Fig. 2
As this minute counter does not control the oven, when it finishes counting the oven will continue
to work.
To set, press the central button for 3 seconds until the below symbol appears (fig. 2). Press “+”
and “-” to set the required time.
The minute counter beeps when it finishes counting. To disable it, press any button.
To cancel the minute counter press the ‘-‘ button until the timer displays 0:00
Cooking t i m e
Fig. 3
This is a semi-automatic cooking function. It can be used to set cooking times. This function
automatically switches the oven off after the duration is complete
Firstly your cooking mode and temperature should be set.
Press the central button for 3 seconds. Then press it again until “dur” appears (figure 3). Press “+”
and “-” to set the required cooking timer.
The oven will work in the set mode and at the set temperature until the end of cooking time
To cancel the cooking duration press the ‘-‘ button until the timer displays 0:00.

13
The end of cooking time
Fig. 4
The end of cooking time can also be set. This works as part of a programmed time.
Press the central button for 3 seconds. Press the central button twice consecutively and wait for
“End” to appear. Press “+” and “-” to set the required end of cooking time.
The oven will work in the set mode and at the set temperature until the end of cooking time.
Setting Programming automatic cooking
Fig. 5
Cooking function with set times.
Firstly your cooking mode and temperature should be set
Press the central button for 3 seconds. Then press it again until “dur” appears. Press “+” and
“-” to set the required cooking time. Wait 2 seconds for the setting to be memorised.
Press the central button again, “End” will appear (fig. 4). Press “+” and “-” to set the required
end of cooking time.
The oven will switch off and the word AUTO will appear in the display.
E.g.:
Current time: 12.30
Cooking time: 10 minutes
End of cooking time: 14.00
The oven will start cooking at 13.50 (14.00 less 00.10) at the set temperature and in the set
mode and will stop at 14.00
The oven will beep when it stops cooking. To disable it, press any button.

14
Adjusting beep vo l u m e
To adjust beep volume, press “+” and “-” together. Then press the central button and wait for
“ton1” (high volume) to flash. Press “-” to select “ton2” (medium volume) or “ton3” (low volume).
Press the central button to set the selected volume.

15
English
Cooking Functions
BOSE652X
This oven has 5 specific cooking functions as follows:
Symbol
Description
Light
Defrost
Fan forced
Full grill
Fan grill
Please note that the cooling fan will continue to run for some time even
when the oven has been turned to the off position.

16
EnglishEnglish
Instructions for Use
Fan forced cooking
For this type of cooking a fan positioned at the back allows the circulation
of hot air inside the oven, creating uniform heat. In this way cooking is more
rapid than conventional cooking. It is a suitable method for cooking dishes
on more than one shelf, especially when the food is of different types (fish,
meat etc.).
Grill Cooking
Use this function to grill or brown foods. Some ovens may be equipped with
an electric motor, spit and skewers for turning on the spit.
Place the shelf with the food to be cooked in the 1st or 2nd position from
the top. Pre-heat the oven for 5 minutes.
Temperature Regulation
Use the thermostat to set the temperature you require. The temperature
can be adjusted from 0 to 205’C which is max heat.

17
English
Oven Light Contr ol
In order to achieve the best results in terms of performance and energy
consumption, this function is automatically managed by the oven during its
functioning. If you want to turn it on at any time, just turn the function knob on
the control panel.

18
Oven Door Removal
WARNING
Make sure that:
-The oven is cool and power to the oven has been turned off before
removing the door. Failure to do so could result in electrical shock
or burns.
-The oven door is heavy and fragile. Use both hands to remove the
oven door. The door front is Glass. Handle carefully to avoid
breakage.
-Grasp only the sides of the oven door. Do not grasp the handle as
it may swing in your hand and cause damage or injury.
-Failure to grasp the oven door firmly and properly could result in
personal injury or product damage.
To remove the oven door (see Fig. 10):
1. Open the door completely.
2. Lift up the hinge bracket (1) into the slot (2) on both sides.
3. Hold the door firmly on both sides using both hands and close the door
as far as it will go.
4. Whilst holding the door with both hands, force the door closed a little
more and lift it out of the housing.
5. Place the door in a convenient location.

19
To replace the oven door (see Fig. 10):
1. Insert the upper arms (3) of both hinges into the upper slots (6) and the
lower arms (4) into the lower slots (7). The recesses (5) must hook on
the lips (8).
2. Move the hinge brackets (1) back down into position.
3. Close and open the door slowly to assure that it is correctly and
securely in place.

20
Replacement of the Oven Light
WARNING
Make sure that:
- The oven and lights are cool and power to the oven has been
turned off before replacing the light bulb(s). Failure to do so could
result in electrical shock or burns.
- The lenses must be in place when using the oven.
- The lenses serve to protect the light bulb from breaking.
- The lenses are made of glass. Handle carefully to avoid breakage.
Broken glass could cause an injury.
1. Turn off power at the main power supply (fuse or breaker box).
2. Remove the lens (1) by unscrewing it.
3. Remove the light bulb (2) from its socket (3).
4. Replace the bulb (2) with a new one. Avoid touching the bulb with
fingers, as oils from hands can damage the bulb when it becomes hot.
5. Use one with the same Volt and Watt (see Fig. 11).
6. Screw the lens (1) back on.
7. Turn power back on at the main power supply (fuse or breaker box).
