Blanco BRS60X Installation guide

Instructions for the Use and Care and Installation of
BRS60X Single Motor
BRS60W
BRS90X
BRS602X Twin Motor
BRS602W
BRS902X
BRS902W
BRSH60X Single Motor
BRSH90X
BRST60X Single Motor
BRST90X
Slide Out Rangehood

Dear Customer,
Thank you for buying a BLANCO rangehood.
Before we continue telling you about this rangehood, we cordially invite you to become
part of the Blanco family by subscribing online.
Please visit our website where you can easily subscribe and request such things as‘
invitations to future cooking classes’and gourmet recipes.
Go to www.blanco-australia.com and fill in the subscription details.
You will find that the clean lines and modern look of your Blanco rangehood blends in
perfectly with your kitchen décor. It is easy to use and performs to a high standard.
Blanco also makes a range of products that will enhance your kitchen such as cooktops,
ovens, dishwashers and microwaves, sinks and taps. There are models to complement
your new Blanco rangehood.
Of course, we make every effort to ensure that our products meet all your requirements,
and our Customer Relations department is at your disposal, to answer all your questions
and to listen to all your suggestions.
Please complete the warranty card and keep your receipt as proof of purchase. Retain all
documents relating to the purchase of this product.
Blanco is committed to providing increasingly efficient products that are easy to use, and
are not just beautiful, smart.
BLANCO
- 3 -


































 





- 4 -















 
 
 
 
 







- 5 -

GENERAL
Carefully read the following important information regarding installation safety and maintenance. Keep this
information booklet accessible for further consultations. The appliance has been designed for use in the duct-
ing version (air exhaust to the outside), ltering version (air circulation on the inside) or with external motor.
SAFETY PRECAUTION
1. Take care when the rangehood is operating simultaneously with an open replace or burner that depend on
the air in the environment and are supplied by other than electrical energy, as the rangehood removes the air
from the environment which a burner or replace need for combustion. The negative pressure in the environ-
ment must not exceed 4Pa (4x10-5 bar). Provide adequate ventilation in the environment for a safe operation
of the rangehood. Follow the local laws applicable for external air evacuation.
Before connecting the model to the electricity network:
Inspect the data plate (positioned inside the appliance) to ascertain that the voltage and power correspond to
the network and the socket is suitable. If in doubt ask a qualied electrician.
General Warnings.
· The appliance is not intended for use by young children or inrm persons without supervision.
· Young children should be supervised to ensure that they do not play with the appliance.
· If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly quali-
ed person in order to avoid a hazard.
· There shall be adequate ventilation of the room when the range hood is used at the same time as appliances
burning gas or other fuels.
· Ensure that the range hood is cleaned frequently.
· There is a risk of re if cleaning is not carried out in accordance with the instructions.
· Do not ambé under the range hood.
Warnings for Installation:
· The exhaust air must not be discharged into a ue which is used for exhausting fumes from appliances burn-
ing gas or other fuels.
· The minimum distance between the support surfaces of the cooking pots on the cooker top and the lowest
part of the rangehood must be at least 65 cm.
· The regulations concerning the discharge of exhaust air have to be fullled.
Other Information:
This appliance conforms to the European Directive EC/2002/96,Waste Electrical and Electronic Equipment (WEEE).
By making sure that this appliance is disposed of in a suitable manner, the user is helping to prevent potential
damage to the environment or to public health.
The symbol on the product or on the packaging label on the carton indicates that the appliance should not
be treated as domestic waste, but should be delivered to a suitable electric and electronic appliance recycling
collection point. Follow local guidelines when disposing of waste. For more information on the treatment,
re-use and recycling of this product, please contact your local authority or domestic waste collection service.
INSTALLATION INSTRUCTIONS
• Electric Connection
The appliance has been manufactured as a class II, therefore no earth cable is necessary. The connection to the
mains is carried out as follows:
BROWN = L line
BLUE = N neutral
If not provided, connect a plug for the electrical load indicated on the description label. Where a plug is pro-
vided, the rangehood must be installed in order that the plug is easily accessible. An omnipolar switch with
a minimum opening of 3mm between contacts, in line with the electrical load and local standards, must be
placed between the appliance and the network in the case of direct connection to the electrical network.
• The minimum distance between the support surfaces of the cooking pots on the cooker top and the lowest
part of the rangehood must be at least 65 cm. If a connection tube composed of two parts is used, the upper
- 6 -

part must be placed outside the lower part. Do not connect the rangehood exhaust to the same conductor
used to circulate hot air or for evacuating fumes from other appliances generated by other than an electrical
source. In the case of assembly of the appliance in the exhausting version prepare the hole for evacuation of
the air.
Warning: Failure to install the screws or xing device in accordance with these instructions
may result in electrical hazards (see technical data if supplied).
Installation
The following instruction should be followed to carry out the correct installation of the rangehood .
1) Mounting of the rangehood on the lower side of the cupboard.
2) Selection of the version (extraction or ltration)
Mounting the rangehood on the lower side of the cupboard. This appliance must be tted to a cupboard or
other suitable support. For xing use 4 screws suitable for the cupboard, using the hole in Fig.1. When mount-
ing align the front of the rangehood to the door of the cupboard and regulate the Lwall spacer through the
screws marked P(Fig. 2). The rear of the appliance must then align with the cupboard.
Extraction through an outside wall
The appliance expels the fumes through an outside wall or a duct. It is necessary to buy a telescopic pipe in
accordance with the standards in use and connect it to ange B(Fig.3-4).
Recirculation
To transform the rangehood from the extraction version to the re circulating one ask your supplier for an acti-
vated carbon lter. The activated carbon lter cleans the air of the room. This lter is not washable or re-usable
and must be substituted at least every 4 months. Saturation of the activated carbon depends on how often the
appliance is used, the type of kitchen and how regularly the grease lter is cleaned. The lter must be tted to
the motor in the centre of the fan grille by twisting it by 90 degrees until it is gripped securely. Remove the grill
(G) g. 2 to carry out this operation. The clean air is returned into the room through a connecting tube passing
inside the cupboard and connected to the ring B(Fig.1).
- 7 -

Installation
Exercise care when a rangehood is installed in an area where a gas burner is operating. Depending on the size
of the room, the rangehood may draw from the room air that is necessary for proper combustion of the burner.
All Blanco rangehoods are used for indoor application only.
Rangehoods may be installed in two ways:
1. Ducted to the atmosphere (outside).
2. Recirculating.
We recommend ducting to the atmosphere to ensure optimum performance. Recirculating the air back into
the room should only be used when outside extraction is not possible. To ensure maximum performance
when ducting it is important the ducting that carries the fumes away, be as short and as straight as possible.
When incorporating a rangehood in the design of a kitchen the following points need to be considered to
achieve the most benet from the rangehood.
1. Ducting from a rangehood carrying the exhaust air, should not exceed a length of three (3) metres.
2. For ducted installation we recommend using galvanised or similar metal type ue pipe. PVC pipe is not
recommended.
3. Ducting containing a 90° degree bend will encounter a loss in eciency of approximately 35%. Additional
90° degree bends can cause losses of up to 15% per bend.
4. Ducting size should always comply with the manufacturers specication.
5. We recommend carbon lters be used when re-circulating the air into the room. There will be some loss of
air movement when carbon lters are tted.
USE AND MAINTENANCE
•It is recommended to operate the appliance prior to cooking. It is recommended to leave the appliance in
operation for 15 minutes after cooking is terminated in order to completely eliminate cooking vapours and
odours. The proper function of the rangehood is conditioned by the regularity of the maintenance operations,
in particular, the active carbon lter.
• The aluminium lters capture the grease particles suspended in the air, and are therefore subject to clogging
according to the frequency of the use of the appliance.
In order to prevent re hazard, it is recommendable to clean the aluminium lter at a maximum of 2 months by
carrying out the following instructions:
-Remove the aluminium lters from the rangehood and wash them in a solution of water and neutral liquid
detergent, leaving to soak.
- Rinse thoroughly with warm water and leave to dry.
-The lters may also be washed in the dishwasher.
The aluminum panels may alter in colour after several washes.
This is not cause for customer complaint nor replacement of panels.
• The active carbon lters purify the air that is replaced in the environment. The carbon lters are not washable
nor re-useable and must be replaced at maximum every four months. The saturation of the active carbon lter
depends on the frequency of use of the appliance, by the type of cooking and the regularity of cleaning the
aluminium lters.
• Clean the fan and other surfaces of the rangehood regularly using a cloth moistened with a non abrasive
liquid detergent.
• The rangehood lighting is designed for use during cooking and not for prolonged general illumination of the
environment. Prolonged use of the lighting notably reduces the duration (life) of the bulb.
• To replace the halogen lamp. With a small blade, remove the metal surround holding the glass in place. The
lamp can be pulled outward from its socket.
• Replacing the halogen/incandescent lamps (Fig.5A):
Only use lamps of the same type and wattage installed on the device.
• Light replacement - halogen (Fig.5B)
12 volt 20 W Halogen.
Remove the glass retaining ring and glass.
Replace the globe with another of the same type.
Replace the glass and retaining ring.
- 8 -

• Commands (Fig.6):
Push-button A = On/off lights switch.
Push-button B = On/off cooker hood switch. The appliance switches on at speed level 1, If the cooker hood
is on depress the push-button for 2 sec. to switch off the cooker hood. If the cooker hood is at speed level 1 it
will not be necessary to depress the push-button to switch the cooker hood off. Decreases the motor speed.
Display C = Indicates the motor speed level selected and activates the timer.
Push-button D = Switches on the cooker hood. Increases the motor speed. Touching the key at 3rd speed, the
intensive function runs for 10’, then the appliance go back to work at the original speed. During this function
the display blinks.
Key E =The Timer times the functions on activation for 15 minutes, after which they are switched off. The Timer
is deactivated by re-pressing Key E.
When the Timer is activated the decimal point must flash on the display. The Timer cannot be activated if the
intensive speed is functioning.
The “clean air” function is activated by pressing key Efor 2 seconds when the appliance is switched off. This
switches the motor on for 10 minutes every hour at the first speed. During functioning a rotary movement of
the peripheral segments must be visualised on the display. When this time has passed the motor switches off
and the fixed letter“C” must be visualised on the display until the motor re-starts after 50 minutes for another
10 minutes and so on. Press any key apart from the light keys to return to normal functioning. Press key Eto
deactivate the function.
• Anti-grease/active charcoal filters saturation:
-When display item Cflashes, at a speed where it alternates with the letter F (e.g. 1and F), the anti-grease filters
must be washed.
-When display item Cflashes, at a speed where it alternates with the letter A (e.g. 1and A), the active carbon
filters must be replaced or washed depending on the type of filter.
After the clean filter has been positioned correctly, the electronic memory must be reset by pressing button A
for approximately 5 seconds, until the indication For Ashown on the display Cstops flashing.
• Commands slider (Fig.7) the key symbols are explained below:
A = Light switch
A1= Off key
A2= On key
C = Speed control
C1 = Off key
C2 = FIRST SPEED key
C3 = SECOND SPEED key
C4 = THIRD SPEED key.
- 9 -

- 10 -
