Blanco BRSR60X Installation guide

Instructions for the Use and Care and Installation of
BRSR60X
Range Hood

Dear Customer
You will nd that the modern look of your Blanco rangehood blends in perfectly with
your kitchen décor. It is easy to use and performs to a high standard.
Blanco also makes a range of products that will enhance your kitchen – such as cooktops,
ovens, dishwashers, microwaves, sinks and taps. There are models to complement your
new Blanco rangehood. Blanco now has a range of laundry products to choose from.
Of course, we make every eort to ensure that our products meet all your requirements,
and our Customer Relations Department is at your disposal, to answer all your questions
and to listen to all your suggestions.
Please complete the warranty section of this manual and keep your receipt as proof of
purchase. Retain all documents relating to the purchase of Blanco product.
Blanco is committed to providing increasingly ecient products that are easy to use,
respect the environment and are attractive and reliable.
BLANCO
- 2 -

72 127
46
34
72
26 34
51.2
27.2 41.4
460
A
C
B
P
O
I
L
min 0 - max 76
min 32 - max 75
min 0 - max 32
598.5
199
279
190
Fig.1
- 3 -

A
D
E E
E
E
A
B
C
Fig.2 Fig.3
Fig.4
- 4 -

1
2 3
A
B
C
B
B
D
BD
B
4
Fig.5
- 5 -

A
A
B
C
B
Fig.6
- 6 -

C
ABC
A
1
A 2
C 1
C 2
C 4
C 3
AB
Fig.7
Fig.8 Fig.9
- 7 -

· General Warnings:
· The appliance is not intended for use by young children or infirm persons without supervision.
· Young children should be supervised to ensure that they do not play with the appliance.
· If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
· There shall be adequate ventilation of the room when the rangehood is used at the same time as appliances
burning gas or other fuels.
· Ensure that the range rangehood is cleaned frequently.
· There is a risk of fire if cleaning is not carried out in accordance with the instructions.
· Do not flambé under the range rangehood.
· Warnings for Installation:
· The exhaust air must not be discharged into a flue that is used for exhausting fumes from appliances burning
gas or other fuels.
· The minimum distance from the hob surface and the lowest part of the range rangehood must not beless than
60cm. If the instructions for the hob specify a greater distance, please consider this.
· The regulations concerning the discharge of exhaust air have to be fulfilled.
· Exercise care when the rangehood is installed in an area where a gas burner is operating. Depending on the size
of the room, the rangehood may draw from the room air that is necessary for proper combustion of the burner.
All Blanco rangehoods are used for indoor application only.
GENERAL
Carefully read the following important information regarding installation safety and maintenance. Keep this
information booklet accessible for further reference.The appliance has been designed for use inthe ducting version
(air exhaust to the outside), filtering recirculating version (air circulation on the inside).
INSTALLATION INSTRUCTIONS
Before connecting the rangehood to the electricity network:
· Refer to the data plate (positioned inside the appliance) to ascertain that the voltage and power correspond to
the network and the socket is suitable. If in doubt ask a qualied electrician.
· If the power supply cable is damaged, it must be replaced with another cable of the same specication.
· Assembly and electrical connections must be carried out by a qualied tradesperson / electrician.
This product may be installed in 2 dierent ways:
Type A installation (g. 4)
· Installing the rangehood to the lower part of the wall cabinet.
Type B installation (g. 5)
· Installing the rangehood between two wall cabinets
· Installing the rangehood to the lower part of the wall cabinet (g. 4A)
This type of appliance must be positioned underneath the cabinet; before installation the front panel of the
rangehood must be aligned with the cabinet and xed in place by tightening the 4 screws D (suited to the type of
cabinet) in the corresponding holes E (g. 4) (please refer to the measurements indicated in g. 1).
· Installing the rangehood between two wall cabinets (g.5B)
The following procedures must be performed before the rangehood is installed:1. Lift the 4 side tabs on the
rangehood as indicated in gure 5.1.2. Take the screw guides B out of the pack supplied and position them in
corresponding two holes (perside) on the rangehood, as indicated in gure 5.2.3. Fix the guides B using the screws
supplied C, as indicated in gure 5.3. Make the holes in the side panel of the cabinet, according to the measurements
indicated in g. 1 and taking the thickness of the front panel into account so that the rangehood remains at the
same level as the cabinets at the side. Fix the rangehood to the cabinet by inserting the screws D (suited to the
type of cabinet) into the holes corresponding to the guides B, as indicated in gure 5.4.
Fitting the spacers.
To ll in any space remaining between the rangehood and the wall, simply position spacer and x in place with
the 3 screws L as indicated in gure 1
· If the rangehood is set up as a ducting version (air exhaust to the outside) the lever D must be positioned as
indicated in gure 9A.
· If the rangehood is set up as a ltering recirculating version (air circulation on the inside) the lever D must be
positioned as indicated in gure 9B.
- 8 -

• Filter version
This model is supplied with a carbon lter tted (for recirculating installation). Remove if the rangehood is ducted.
Vapours and odours ltered through the hood re-enters the room through the vents (g 7). When changing the
active carbon lters centre them and rotate 90 degrees until they click into place. To perform this operation, rst
remove the grill C (g 3).
• Ducted version
If you wish to duct the rangehood, rst remove the press-t lid A located above the bodywork, as indicated in (g
6). Take ange B and connect it to the air outlet hole (g. 6). When installed in this way the appliance expels fumes
outside, either through a perimeter wall or through existing ducting. A exible, non-ammable air exhaust hose
C must be purchased (this hose must comply with all current legislation) and connected to ange B, which is only
supplied for the extractor version (g. 6). Remove the carbon lter.
USE AND MAINTENANCE
• It is recommended to operate the appliance prior to cooking.
• It is recommended to leave the appliance in operation for 15 minutes after cooking to help eliminate cooking
vapors and odours.
• It is important to properly maintain the rangehood and the carbon lters to ensure proper function of the
rangehood.
•The anti-grease lters capture the grease particles suspended in the air, and are therefore subject to clogging
according to the frequency of the use of the appliance. In order to prevent re hazard, it is recommended to clean
the lter every 2 months (as a minimum) by carrying out the following instructions:
- Remove the lters from the rangehood and wash them in a solution of water and neutral liquid detergent,leaving
to soak.
- Rinse thoroughly with warm water and leave to dry.
- The lters may also be washed in the dishwasher. The aluminium panels may alter in colour after several washes.
This is normal and the lter panels will not need to be replaced.
• The active carbon lters purify the air that is recirculated into the environment. The lters are not washable
nor reusable and must be replaced every four months (as a minimum). The saturation of the active carbon lter
depends on the frequency of use of the appliance, by the type of cooking and the regularity of cleaning the anti-
grease lters.
• Clean the fan and other surfaces of the rangehood regularly using a cloth moistened with denatured alcohol or
non abrasive liquid detergent.
• The lighting is designed for use during cooking and not for prolonged general illumination of the environment.
Prolonged use of the light notably reduces the duration of the bulb and is generally not recommended.
Replacing the globe.
• Open the anti-grease lter as shown in (g 3).
• Un-screw the globe.
• Replace the globe.
• Re-install the anti-grease lter.
Globe: Tubular E14 (40Watts 240volts).
Controls: (Fig.8) SLIDER the key symbols are explained below:
A = Light switch
A1 = O position.
A2 = On position.
B = Filter saturation warning indicator.
C = Speed control
C1 = O position.
C2 = Speed 1
C3 = Speed 2
C4 = Speed 3
THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR EVENTUAL DAMAGES CAUSED BY BREACHING
THE ABOVE WARNINGS.
- 9 -

Blanco Contact Information.
NEW SOUTH WALES
Head Oce, Sales & Marketing Oce
104 Vanessa Street
Kingsgrove NSW 2208
Telephone: [phone]
Facsimile: 02 9503 2810
NSW Showroom*
40 Ebley Street
Bondi Junction NSW 2022
Telephone: [phone]
Facsimile: 02 9386 1671
Agent and Sales Oce.
Hi –Performance Marketing
7 Coleman Street
Mascot NSW 2020
Telephone: [phone]
Facsimile: 02 90048739
Service and Spare Parts
All General Whitegoods Service
Telephone: [phone]
Facsimile: 02 9756 1091
AUSTRALIAN CAPITAL TERRITORY
Service and Spare Parts
Detlevs Appliance & Electrical Care
1/88 Sheppard Street
Hume
ACT 2905
Telephone: [phone]
Facsimile: 02 6260 1035
VICTORIA
State Oce and Showroom*
35 Centre Road
Scoresby VIC 3179
Telephone: [phone]
Facsimile: 03 8756 7907
Service and Spare Parts
Advantage Appliances
Telephone: [phone]
Facsimile: 03 9874 6917
QUEENSLAND
State Oce and Showroom*
148 Robinson Road - East
Geebung
QLD 4034
Telephone: [phone]
Facsimile: 07 3265 6933
Endeavour Appliances
Telephone: [phone]
Facsimile: 07 3852 2465
Platinum Appliance Service
Telephone: [phone]
Facsimile: 07 3862 1114
Roshad (Gold Coast)
Telephone [phone]
Facsimile 07 5535 7407
SOUTH AUSTRALIA & NORTHERN TERRITORY
Agent and Sales Oce
S C Lighting & Electrical Supplies
47 North Terrace
Hackney SA 5069
Telephone: [phone]
Facsimile: 08 8362 4591
Service and Spare Parts
Prestige Appliance Repair Centre
Telephone: [phone]
Facsimile: 08 8352 3044
WESTERN AUSTRALIA
1 Alvan Street
SUBIACO WA 6008
Telephone: [phone]
Service and Spare Parts
Metropolitan Appliance Repairs
Telephone: [phone]
Facsimile: 08 9317 1296
TASMANIA
Agent and Sales Oce
Mark Pearce Agencies
23 Tranmere Road
Howrah TAS 7018
Tel/Fax: [phone]
Service and Spare Parts
Electrical Equipment Service (Launceston)
Telephone: [phone]
Facsimile: 03 6339 4588
Baldocks Appliance Service (Hobart)
Telephone: [phone]
Facsimile: 03 6234 8134
BLANCO CUSTOMER SERVICE
1300 739 033
Website: www.meaappliances.com.au
* Showrooms open six days a week
- 10 -

1. Subject to the “Statement of Standard Warranty
Conditions” this product is covered by the following
Warranty.
TWO (2)YEARSWARRANTY from date of purchase,
covering all parts and labour.
2. The appliance is warranted under normal single
family domestic installation and use, as set out in the
instruction manual, against manufacturing defects for
the Warranty periods shown above.
3. Should service be required under thisWarranty, the
purchaser should contact an approved BLANCO Ser-
vice Provider during their normal business hours.
4. At no time does BLANCO/MEA have liability for
any freight or transportation costs or for any damage
during transit or for any consequence of failure of this
appliance outside of the normal service area, unless
such limitation of liability is prohibited by statute.
5. This Warranty excludes replacement of parts re-
quired due to normal wear and tear including light
globes.
6. This Warranty only applies, provided the appliance
has been used in accordance with the manufacturer’s
instructions and provided an accident, misuse, neglect
or abuse has not damaged the appliance.
7. None of the above Warranties purport to exclude,
restrict or modify either the application or the exercise
of a right conferred by any applicable Statute.
8. Please complete the details below, which should
be retained for future reference along with your proof
of purchase:
Date of Purchase: ……………………………..
Model No: ……………………………………….
Serial No: ………………………………………..
1. The Warranty only applies provided that the appli-
ance has been used in accordance with the manufac-
turer’s instructions and provided that the appliance
has not been damaged by an accident, misuse, neglect
or abuse of any person other than the manufacturer
or BLANCO/Major Electrical Appliances (“MEA”) or
from faulty installation, mis-adjustment or tampering
by unauthorised persons.
2. When a service inspection reveals the alleged fault
or faults are caused by incorrect operation, contrary to
the instruction manual, and otherwise the appliance
is in good order and working condition, the purchaser
shall be liable for a service fee charged by BLANCO/
MEA or one of its’Service Providers.
3. If the appliance is used in Commercial Applications
or for Rental purposes, a separate warranty of Twelve
(12) months covering all parts with Three (3) months
on the labour will apply.
4. Subject to the provisions of any applicable statute
this Warranty applies to the original retail purchaser
only and is not transferable.
5. Subject to the provisions of any applicable stat-
ute, at no time does BLANCO/MEA have liability
for freight, transport or travel costs outside normal
service areas.
6. None of the above Warranties purport to exclude,
restrict or modify either the application or the exercise
of a right conferred by any applicable statute.
7. Subject to any Warranties implied by statute, at no
time will BLANCO/MEA or its’ Service Providers be
liable for any economic loss consequent upon the
failure of the appliance.
8. This Warranty is only valid for major appliances im-
ported and distributed by BLANCO/MEA, purchased
and used in Australia.
MEA0702
BLANCO COOKING PRODUCT WARRANTY STATEMENT OF STANDARD
WARRANTY CONDITIONS
- 11 -

3LIK0525
Printed on recycled paper
