Blatchford Moulded User manual

1
Moulded
Seating User Manual
blatchford.co.uk

32
Page
Introduction 4
Pre-use Checks 4
Fitting the Moulded Seat Insert into the Host Wheelchair 5
(including Multi Adjustable interface instructions)
Adjusting the Headrest 6
Adjusting the Footrest 6
Removable Liners 7
Pressure Padding Inserts 7
Cleaning Instructions 7
Maintenance by Carer 8
Maintenance by Seating Specialist 8
Posture Belt & Posture Harness - User Instructions 9
Moulded Trays - User Instructions 10
Moulded Sandals and Footstraps - User Instructions 11
AEL Mounting Kit - User Instructions 12
Transportation in a Motor Vehicle 13
Important Reminders 14
Further Information 14
Notes 15
Manufacturer’s Label 15
Moulded Seating User Manual

54
Fitting the Moulded Seat Insert into the Host Wheelchair
Introduction
The Moulded Seat Insert (MSI) is a custom-made device and it should only be used by the
person it was made for.
This user manual gives important safety information, advice about making basic adjustments to
the Moulded Seat Insert and user care instructions. The manual also gives important information
about maintenance and adjustments that must be carried out by the Wheelchair Service or
Blatchford Clinical Services.
Pre-use Checks
Before using the Moulded Seat Insert please check the following:
•The two retaining straps should be securely fastened as described under ‘Fitting the
Moulded Seat Insert into Host Wheelchair’ on the next page. These checks must be
carried out every time the equipment is dismantled and assembled.
•All user support items (such as postural straps and harnesses) should be
securely fastened.
• IftheMouldedSeatInsertisttedwiththeBlatchfordClinicalServicestilting
mechanism, check that the front and rear bars on the Moulded Seat Insert are
positioned into the locators on the wheelchair and that all four locking plates are
securely fastened.
If you are not sure about how to do any of these things please contact your
Wheelchair Service.
Removing the Seating System from the Interface
1. Undoordisconnectandbackrestxings.
2. Pull “D” ring (g.6, located under the front of the seat)rmly
and lean the Seating System forward.
3. Taking care, lift the Seating System upward and clear from
the wheelchair.
Attaching the Seating System
to the Interface
1. Taking care when lifting, position the
seat onto the interface and locate the
front hook onto the front bar (g.5).
2. Allow the seat to tilt backwards and
 down,pressingitrmlyintoplace.
A click will be heard as the locks engage.
3. Check that the pins have fully located by pulling the seat forward, (a small amount of
movement is normal). However, the seat should not lift forward.
4. Repeat stages 1 to 4 if the seat lifts from the interface.
Fitting the Interface to the Wheelchair (Applies to folding wheelchairs only)
1. Ensure that the wheelchair is fully open.
2. Check that the latches are in the open position (g.1).
3. Position the interface hooks, ensuring that on each side one hook is behind and one hook
is in front of the clamps (g.2 and g.3).
4. Slide the latch clamps so that the tongue is over the top of hooks (g.4).
5. Check that the interface is correctly located by attempting to lift it out (a small amount of
movement is normal).
6. To remove the interface, slide the latches back and lift the interface upward.
g. 1
g. 2g. 3
g. 4
g. 6
g. 5
Components:
AInterface
BLatch Clamps
CSeating Attachment
BAIS - Blatchford Adaptive
Interface System
A B C

76
RemovableLiners(wheretted)
All Moulded Seat Inserts come complete with one foam lining permanently
attached to the plastic shell. In some cases the MSI may be supplied with
extra, removable, liner(s).
The additional liner(s) can be taken out to allow extra room within the
MSI (for example to allow for thick clothing or growth).
To remove a liner:
• Removetheterrytowelcoveriftted(seethenotesonhow
to do this as part of the cleaning instructions on page 6).
• Usingbothhands,carefullypullthesecondlinerawayfromtherst
liner around the edges to release the velcro that holds them together.
• Guidetheseatrestraintsthroughtheslotsintheliner(seeg.9)
•The liner can now be completely removed.
•Reverse the process to replace.
PressurePaddingInserts(wheretted)
The MSI may have extra padding to reduce the chance of pressure sores. This extra padding will
needtobetakenothelinerthathasbeentakenoutandfastenedbackontothepermanent
liner.
The padding is attached with Velcro - to remove the pad:
•Carefully pull the pad around the edges to release the velcro.
• Pushthepadrmlyintotherecessedareaonthepermanentlinertorefastenthevelcro.
•Reverse the process to restore the original arrangement.
If the user’s skin becomes marked in the area that is in contact with the pressure pad, get
in touch with the Wheelchair Service immediately as the foam may need replacing.
Cleaning Instructions
Plastic Shell
A damp cloth can be used to remove dirt from the plastic outer shell of the MSI.
Foam Lining
To clean the foam lining of the seat, carefully wipe the surface of the foam with a damp cloth
Mild detergent may be used on heavier soiled areas - wipe over again with a clean damp cloth to
remove any cleaner used. Make sure the foam liners are dry before re-using the seat.
Dartex Fabric
If there is a foam section in your seat that is covered with Dartex material wipe a soapy cloth over
any soiled areas. Allow to dry before re-use.
Terry Towelling
IftheMSIhasapaddedcoverinTerryTowellingmaterialitcanbetakenoandwashed:
Adjusting the Headrest
The headrest can be moved both up and down and front to back. The angle of the support
canalsobesettogetthebestposition.(g.7showshowtomaketheadjustmentstothe
height and the front to back position).
•To adjust the height of the head support, turn the
locking knob (A) anticlockwise. Alter the height of the
headrest to suit the user and retighten the knob.
•To adjust the head support in or out turn the locking
knob (B) anticlockwise. Alter the position of the
headrest to suit the user and retighten the knob.
To adjust the angle of the headrest (C) please consult
your Wheelchair Service.
NOTE: The head support must be in place during the
transportation of the user in the MSI.
AdjustingtheFootrest(g.8)(iftted)
To adjust the height of the footrest:
•Undo the locking knob(s) at the back of the footrest (A)
•Move the footrest to the correct height and re-tighten
the locking knob(s).
To remove the footrest for storage:
•Loosen the locking knob (B) and pull the footrest away
from the seat.
•Reverse the process to re-attach.
Make sure that locking knobs are properly
re-tightened.
g. 7
g. 8
g. 9
A
B
C
A
B

98
• Thesidesofthecoverareelasticatedsoitcanbepulledovertheedgesoftheseattotakeito.
•Carefully pass the straps and buckles through the slots in the cover.
•Pull the cover away from the seat carefully – make sure it is not caught on the seat or wheelchair.
•The cover can now be hand or machined washed (no more than 30˚C).
•Do not tumble dry or use bleach (bleach will damage the material and tumble drying may
cause it to shrink).
Reversetheprocesstoretthecovers.Make sure that:
•The covers are completely dry.
•The straps are passed through the correct slots in the cover.
• Thecoveristtedevenlytotheseattopreventanycreasesasthesecouldcauselocalised
skin marking and discomfort.
Maintenance by Carer
The following checks should be carried out by the carer on a continuous basis to make
sure that the Moulded Seat Insert is both safe and comfortable:
•Check there is no damage to the retaining straps and that the buckles are working properly.
•Check there is no damage to any postural straps and harnesses and that the buckles on
these are working properly.
•Check that all adjustable parts of the seat operated by the carer, as previously described,
adjust freely and are not damaged.
•Check there is no damage to the foam lining resulting in raised or sharp surfaces.
If the user should suer any form of marking on the skin or if they appear to be in
discomfort this should be reported to the Wheelchair Service immediately.
Maintenance by Seating Specialist
The following checks are important and must only be carried out by the Wheelchair
Service or by Blatchford Clinical Services:
The Wheelchair Service should decide how often these checks should be made taking
into account the needs of the user and the intended usage level of the seat. In order to
ensure continuing safety of the MSI, it is recommended that the interval between these
checks is no longer than 24 months.
•Checks to make sure that the user’s shape is still accommodated properly by the shape of
the Moulded Seat Insert.
•Checks to make sure that the Moulded Seat Insert is not too tight for the user as a result of
growth or weight gain.
•Checks to make sure that there is no structural damage to the plastic shell or metal
framework and that all securing bolts are still in place.
• Checksontheconditionofanypressurerelievinginserts(wheretted).
•Checks to make sure that all locking knobs on the brackets are in place and working properly.
•Checks to make sure that all straps are undamaged and buckles are working properly.
Posture Belt & Posture Harness - User Instructions
Using a harness:
• Dothebottomstrapsuprstensuringtheharness
is away from the user’s neck.
• Do the top straps up by clicking the male buckle into the
attached female buckle of the harness.
• Adjust the top straps by pulling the ‘D’ loop forward
and down whilst holding the shoulder of the user in
the desired position.
For Belts & Harnesses, always make sure that:
• Straps are not twisted.
• Buckles are adjusted so that when they are fastened together there is no slack in the strap.
• Buckles are fully locked together.
• Each end of the belt or harness is still securely attached to the seating system or wheelchair.
• Buckles or webbing do not show signs of excessive wear –
if you are concerned about the condition of any items contact the wheelchair service.
Cleaning
These items should be wiped clean using a damp cloth using only a mild detergent.
(PLEASE DO NOT use bleach or products containing bleach).
A soft brush can be used to remove heavier soiling.
Safety Instructions
Blatchford posture belts and harnesses are designed to provide postural support and are
intendedtobeusedaspartofaspecialisedseatingsystem.Thebeltorharnessshouldbetted
totheseatandadjustedatthetimeofdelivery.ReplacementsmustonlybettedbyBlatchford
or a Wheelchair Service representative.
Important Safety Warnings
POSTURAL HARNESSES AND BELTS ARE NOT DESIGNED TO BE USED AS
SAFETY DEVICES AND MUST NOT BE USED AS VEHICLE RESTRAINTS FOR USE IN
TRANSPORTATION.
A suitable, separate, 3-point passenger seat belt (fastened into the vehicle) must be used
to secure the seated occupant during travel in order to provide protection in the event of an
accident. The seatbelt should have both pelvic and upper body sections, with the upper section
fastened into the vehicle at the upper level. This should be in accordance with Medical Device
Report –
Guidelines for transporting children in special seats.
ALWAYS CHECK THAT THE BELT IS A SNUG FIT. CHEST BELTS SHOULD ALWAYS BE
FASTENED AROUND THE OCCUPANT’S BODY AND UNDER THE ARMS. IT IS NOT
INTENDED THAT THE ARMS SHOULD BE INCLUDED WITHIN THE BELT.
If the hip belt is incorrectly adjusted there is a risk of the wheelchair occupant slipping down in
their seat and could result in occupant’s upper body and neck coming into contact with the belt.
If you are unsure about any of these instructions or if you are worried about the
adjustment of the belt contact your Wheelchair Service.

1110
Moulded Trays - User Instructions
Moulded Trays are designed to provide a work or play surface together with support and
control in conjunction with any seating arrangement.
Using the tray
1. Ensure that the two vertical stems on the underside of the tray are securely
located in the wheelchair location points.
2. Tonetunethepositionofthetrayinrelationtotheuser,thelockingknobsonthe
underside of the tray must be loosened to allow the tray to be moved forwards or
backwards into the desired position. Re-tighten the locking knobs after adjustment.
Width adjustment
Tochangethewidthofthetrayttingstosuitanalternativewheelchair;
1. Turnthetrayoverandloosenthefourscrewsusingalargeatbladedscrewdriver
(do not remove the screws completely).
2. Slide the adjustment tubes out/in to the desired width, ensuring that they remain parallel.
3. Re-tighten the screws.
Cleaning
A damp, soapy cloth can be used to clean the tray surface.
Warnings
• ON NO ACCOUNT SHOULD ANY HOLES BE DRILLED INTO THE TRAY TOP.
• ENSURE ALL LOCKING KNOBS ARE SECURE BEFORE USE.
• THE TRAY MUST BE REMOVED BEFORE TRANSPORTATION.
Moulded Sandals & Footstraps - User Instructions
Moulded Sandals and Footstraps are designed to provide support and control in
conjunction with any seating arrangement.
Do:
• Ensure that straps are not twisted.
• Ensure that buckles are adjusted so that when they
are fastened, there is no slack in the strap.
Care
Check that buckles and straps do not show signs of excessive wear or fraying - if you are
concerned about the condition of any item refer to your seating technician at the clinic or through
your supplier as soon as possible.
Cleaning
These items can be wiped clean using a damp, soapy
cloth. A soft brush can be used to remove heavier soiling.
Warning
THIS DEVICE IS NOT DESIGNED FOR USE AS PART
OF A SAFETY RESTRAINT SYSTEM FOR TRAVEL IN A
VEHICLE.

1312
Transportation in a Motor Vehicle
NOTE: • The MSI must not be used as a car safety seat.
•The MSI is designed to allow the user to be transported in a forward facing
position providing the MSI is secured in the host wheelchair in a vehicle designed
for the purpose (for example, in a suitably equipped minibus).
•Blatchford Special Seating products are interfaced using BAIS, which conforms
with ISO16840.
Transportation - Essential Safety Information. NOTE: this information should be passed on
to those people making transport arrangements (e.g. schools and other organisations).
Securing the user, the Moulded Seat Insert and the host wheelchair in a vehicle:
1. During travel the MSI must be securely fastened into its wheelchair as described earlier in
this manual.
2. Posture belts and postural harnesses supplied as part of the seating system are designed
 togiveposturalsupportonly.Wheretheseitemsarettedtheyshouldbeusedduring
travel but they must not be used as the only safety restraints.
3. The wheelchair itself must be fastened down in the vehicle – this must be in
accordance with the wheelchair manufacturer’s instructions. (The wheelchair
manufacturer should issue these instructions separately. In case of query contact the
Wheelchair Service).
4. A suitable, separate, passenger seat belt (fastened in to the vehicle) must be used
by the occupant during travel. In order to achieve occupant restraint and optimum
protection in a crash situation the seatbelt should have both pelvic and upper
body sections (for example a 3 point type with the upper section fastened into
the vehicle at the upper level) as a minimum standard.
Please ensure that the occupant restraint, both lap and diagonal, make good contact with
the occupant. Failiure to do so may cause injury in the event of an accident.
Using MSI accessories during travel:
The following information and advice should be considered - the accessories used and the
needs and circumstances of the user must be taken into account:
1. The MSI seat headrest should be used during travel.
2. Wheelchair mounted trays should always be taken o while travelling and these
should be stored securely in the vehicle.
3. Kneeblocks used in a vehicle could cause damage to the hips and knees in the
event of an accident but, without these in place, there could be risks to other
passengers. (As part of the initial assessment by the Wheelchair Service the best
practice for the particular user should be determined and the outcome of this
assessment passed on to the people making the transport arrangements).
4. Footstraps are not designed to be a part of a passenger restraint system but,
where these are tted, there may be advantages in these being in place during
travel. (Again these issues should be considered as part of the initial assessment
by the Wheelchair Service and recommendations made to the people making the
transport arrangements).
(Separate information sheets are issued with accessories and these should also be consulted).
AEL Mounting Kit - User Instructions
TheAELMountingKitismadeupofthecomponentsshownabove(gs.A, Band C). These
are not user adjustable components and therefore should not be altered in anyway by the
user or carers.
Aand Barescrewedtogetherwiththesuppliedttingsandattachedtothebackoftheseating
systembackrest(g.D)ortothebottomoftheseatingsystemseatbase(g.H).
Component Cisttedtoeitherthebackrestpostsortheseatrailtubesofthewheelchair.
Toattachtheseattothewheelchair,itisnecessarytopress(rmly)thehookpartontothetube
asshowning.Eand Fnexttothelocatinglatches(gC).
Once correctly located the latch can then be moved over the hook and hence preventing it from
beingremoved,asshowning.H. This should be completed for all locating latches.
The backrest or seat base is now securely attached to the wheelchair.
A
D
B
E
C
F G H

1514
Notes:
Please attach manufacturer’s label here.
Manufacturer’s Label:
Important Reminders
It is important that the carer is aware of and considers the following:
•The Moulded Seat Insert is a custom-made device to be used only by the person it was
made for.
•If the user has marking on the skin or becomes uncomfortable when in the seat, contact
the Wheelchair Service immediately.
• TheMSImustonlybeusedwiththewheelchairitwasmadefor.Ifadierentwheelchairis
going to be used contact the Wheelchair Service for help and advice.
•Maintenance and adjustments (other than those shown in this User Manual) should only be
carried out by Blatchford Clinical Services.
•No alterations should be made to the seat nor should other company’s components
 bettedwithouttheprioragreementofBlatchfordClinicalServices.
•The Moulded Seat Insert is not designed for use as a car safety seat.
Due care and attention must be taken at all times when using the Moulded Seat
Take particular care when negotiating slopes, dicult surfaces or other obstacles.
Further Information
Information about wheelchair tie-down and occupant restraint systems can be obtained from:
C N UNWIN LTD., Unwin House, The Horseshoe, Coat Road, Martock, Somerset, TA12
6EY. Tel: [phone] www.unwin-safety.com
If you have further questions about any of the following please contact the Wheelchair Service:
•availability of seating accessories.
• changingaMouldedSeatInserttotadierentwheelchair.
•use of the seating system in a motor vehicle.
•information on the crash testing of Moulded Seats.

16 9369190615
ChasABlatchford&SonsLtd.,11AtlasWay,AtlasNorth,Sheeld,S47QQ.
t:+44(0)1142637900f:+44(0)1142637901e:[email protected]
blatchford.co.uk
