Pico Lumina RGB+W
Ref. 7730024 Pico Lumina 8 RGB+W
Ref. 7730026 Pico Lumina 11 RGB+W
Ref. 7730025 Pico Lumina 8 RGB+Marine
Ref. 7730027 Pico Lumina 11 RGB+Marine
BLAU
Ref. Model Power Lumen LED
7730024 Pico Lumina 8 RGB+W 8w 982 7 White + 7 RGB
7730026 Pico Lumina 11 RGB+W 11w 1471 14 White + 7 RGB
7730025 Pico Lumina 8 RGB+Marine 8w 528 7 Marine + 7 RGB
7730027 Pico Lumina 11 RGB+Marine 11w 726 14 Marine + 7 RGB

Pico Lumina RGB+W
Pico Lumina 8 and 11 RGB+ are luminaires for small aquarium with a RGB+ LED system.
Before installing and using these luminaires, we recommend read and understand these instruc!ons.to
Characteris!cs:
- Energy saving.
- RGB+W LED system (RGB LEDs and an exclusive channel of white LEDs)
- 4 independently adjustable channels.
- Flexible and adjustable support.
- Secondary lenses to avoid light dispersion.
- Epoxy resin layer for protec!on of circuits and LEDs (IPX7)
- selec!on llows the use of a !mer clock.Last memory a
Composi!on of the set:
- Luminaire Pico Lumina with controller.RGB+W
- Transformer.
Installa!on:
- Place it on the upper edge of the aquarium glass with the adjustable clamp
- Keep the controller and transformer away from water and splashes
- Not suitable for outdoor use.
ATTENTION: At the moment of shaping the flexible arm, it needs to be only hold by the flexible part avoiding
bending it by the area of the luminaire.
Color Adjustment:
- With the connected to the network and turned off, press the power bu$ on, all channels (Blue, Red, Greenlight
and White) will be turned on.
- With the bu$ ons [+] and [-] select the desired intensity of the white channel, the rest of the channels (Blue, Red
and Green) are shown but they cannot be adjusted.
- If you press the [Ch] bu$ on, only the blue channel will remain on, with the [+] and [-] bu$ ons you can
select the intensity of this channel.
- If you press the [Ch] bu$ on again, the red channel will light up and you can adjust it with the [+] and [-] bu$ ons,
the blue channel is displayed with the intensity selected in the previous step but it cannot be adjusted.
- If you press the [Ch] bu$ on again, the green channel will light up and you can adjust it with the [+] and [-]
bu$ ons, the blue and red channels are shown with the previous selec!ons.
- If you finally press the [Ch] bu$ on again, it will return to the ini!al posi!on, all channels are displayed.
- The controller memorizes the last selec!on so you can use a !mer to turn the luminaire on and off.
RECYCLING:
Do not throw this controller into normal bin container, it must be taken to a special spot for the treatment of
residues.
WARRANTY:
This product has a 2 year warranty for any factory defect.
The warranty does not cover:
- The damages caused for wrong installa!on.
- The damages caused by inadequate or improper use.
- The damages caused by natural wearing.
