Blaupunkt Car Multimedia User manual

Car Multimedia
2005/2006
www.blaupunkt.com
The advantage in your car.

It’s not whether you win
or lose, it’s how you play
the game. As long as
you’re one of the winners.
Each new win raises
the bar: for you as well as for
us. We are well aware of this, not only
because we have come out winning the
tests conducted by trade magazines time and
again, but because we are also an official spon-
sor of the German Touring Car Masters. And we
always use the experience we gain in our pioneer-
ing technological advances to make you a winner,
too. Take radio reception in CD quality, for example.
Traffic congestion avoidance thanks to proactive
navigation. Travel entertainment and sound
experience customised to meet your specific
needs. Our drive for perfection is reflec-
ted in all Blaupunkt’s products.
And that makes everyone
a winner.
2/3
Introduction

1932 – the first
car radio. 1957 – the first tran-
sistor radio. 1969 – the first stereo radio.
1974 – ARI. 1982 – the first turn-by-turn route
guidance system. 1983 – the first CD player. 1988 –
the first RDS radio. 1989 – the first European naviga-
tion system. 1991 – TIM: Traffic Information Memory.
1994 – DSA: Digital Signal Adaptation. 1996 – the first
fully digital radio. 1997 – the first TMC radio. Digital
Radio/DMB. 1998 – traffic telematics. 1999 – the first pro-
active, dynamic navigation system. 2001 – the first digital
radio with MP3 and MMC. The first MP3 unit with 1 GB. The
first WAP-enabled off-board navigation system incl.
sound and telephone. 2002 – the TwinCeiver. 2003 –
digital recording function. 2004 – the first dynamic,
proactive navigation system with “optimal
route” and CD sound at the same time.
Ultra-flat speakers with front
neodymium magnets.
You’ll find
out what your advantage in
the car is when you take a look
towards the bottom of this page. From
the very first car radio to the first radio-
based navigation system with the “optimal
route” function, we can look back proudly on a
long list of innovative accomplishments. And
if you now take a look to the right, you’ll see
the innovations you have to look forward to.
Whether it’s sound or entertainment, radio
or a navigation system, mobile com-
munications or information: with
Blaupunkt, you’ll always be
right out in front.
Product Guide
Navigation
24|86 TravelPilot DX-V
16|86 TravelPilot E
17|86 TravelPilot E
25|32|87 Chicago IVDN-7003
25|33|87 Aspen IVDN-7003
In Car Entertainment
32|87 Chicago IVDM-7003
33|87 Aspen IVDM-7003
34|86 DVD ME4
35|88 TV Tuner and Signal Controller
36|88 Monitors
MP3 Tuners
08|18|82 Bremen MP74
09|29|82 Seattle MP74
28|82 Los Angeles MP74
09|19|82 Acapulco MP54
10|82 Calgary MP35
10|83 Barcelona MP35
11|83 London MP35
11|83 Kingston MP35
12|83 Madrid MP35
12|83 San Diego MP35
44|84 Essen MP35
44|84 Brighton MP35
CD Tuners
13|84 Vancouver CD35
13|84 Bristol CD35
45|84 Kiel CD35
45|85 Malaga CD35
Cassette Tuners
45|85 Ravenna C32
Digital Radios
20|26|85 Woodstock DAB 54
Sound
48|56|62|89 Velocity-Series
50|89 Amplifiers
58|89 Subwoofers
64|90 Speakers
57|62 OD-Series
59|90 Subwoofers
66|90 Speakers
49|57|63 TH-Series
52|89 Amplifiers
60|90 Subwoofers
68|91 Speakers
49|53|57|63 GT-Series
53|89 Amplifiers
61|90 Subwoofers
69|91 Speakers
70– 71 Antennas and Accessories
72– 81 Technology
82– 91 Product Overview

User Guide
Fun | 6 – 13
More fun with mobile entertainment
MP3 and CD Tuners
Bremen MP74
Seattle MP74
Acapulco MP54
Calgary MP35
Barcelona MP35
London MP35
Kingston MP35
Madrid MP35
San Diego MP35
Vancouver CD35
Bristol CD35
In Car Entertainment | 30 – 41
More enjoyment with multimedia
Navigation
Chicago IVDN-7003
Aspen IVDN-7003
Multimedia
Chicago IVDM-7003
Aspen IVDM-7003
DVD
DVD ME4
TV Tuner and Signal Controller
IVTV-03, IVSC-5502, IVSC-3302,
IVSC-1102
Monitors
IVMS-5802, IVMS-6502, IVMR-7002,
IVMR-9002, IVMR-1042, IVMR-1542
Performance | 14 – 21
More fascination with technology and design
Navigation
TravelPilot E
TravelPilot E
MP3 Tuners, Digital Radios
Bremen MP74
Acapulco MP54
Woodstock DAB 54
Basic | 42 – 45
More features at the entry level
MP3, CD and Cassette Tuners
Essen MP35
Brighton MP35
Kiel CD35
Malaga CD35
Ravenna C32
Business | 22 – 29
More convenience with mobile communications
Navigation
TravelPilot DX-V
Chicago IVDN-7003
Aspen IVDN-7003
Digital Radios, MP3 Tuners
Woodstock DAB 54
Los Angeles MP74
Seattle MP74
Sound | 46 – 69
More enthusiasm for great sound
Amplifiers | Subwoofers | Speakers
Velocity-Series
OD-Series
TH-Series
GT-Series
4/5
Contents

6/7
Fun
Fun – Are you in the
market for an attrac-
tive, new passenger
in your vehicle?
Good music
demands good sound. And
that always goes hand-in-hand
with the best possible reception.
Brilliant sound and rich volume.
Perfectly matched components. And
that means technology that is – and
stays – state-of-the-art. And then
there’s individual sound con-
figuration. And it’s all
Blaupunkt.

8Fun
MP3 and CD Tuners.
Bremen MP74
The TwinCeiver Bremen MP74, a digital twin receiver with
a Digital Directional Antenna (DDA), is clearly the top choice
for individualists with the most exacting demands on sound
and tuner performance. It is equipped with a four-channel,
self-adjusting equalizer with a total of 108 bands and delivers
richly detailed, differentiated, well-balanced sound. It is also
possible to adjust all 108 bands on your PC – to reflect your
own personal tastes and to accommodate the conditions in
your specific vehicle interior. Experience listening pleasure in
a new dimension.
connectivity
Vario
Colour

9
Fun
Seattle MP74
The Seattle MP74 with the Digital DigiCeiver is equipped with
a DEQmaxEX equalizer with a self-adjusting function that
enables it to determine perfect sound all on its own. Thanks to
the digital, self-adjusting parametric 5-band equalizer, you’ll
enjoy differentiated range of sound that can be individually
adjusted to accommodate the vehicle acoustics. You can also
choose from three key variocolor illuminations; green, red and
amber, which make the Seattle look perfect in your dashboard.
Acapulco MP54
The Acapulco MP54 with an MP3-enabled CD drive and
DEQmaxEX, a digital, fully parametric, self-adjusting 5-band
equalizer, is state-of-the-art in terms of technology as well as
looks. Real sound freaks can now use the PC connection to
adjust all the sound parameters on their PCs and the
VarioColour display is a delight to the eyes. You can select
exactly the display colour you want from more than 4,000
shades.
connectivity
connectivity
Vario
Colour

10 Fun
MP3 and CD Tuners.
Nowadays, it’s hard to imagine in-vehicle sound without MP3
sound files. The advantages are obvious: not only is there a
diverse range of storage media, you’ve got a choice of different
playback devices as well. The most important argument in
favour of this technology, however, is the compression stand-
ard used for music files, based on the MPEG1 standard –
which gives you hours of music listening enjoyment. And a new
interface also makes it possible to connect an iPod, the mobile
MP3 player from Apple®. The unique VarioColour feature also
offers a great deal of flexibility in looks: 4,096 different shades
of colour enable you to match up the radio perfectly to virtu-
ally any vehicle dashboard.
Calgary MP35
Barcelona MP35
Aux- in
Aux- in
4-Channel
Preamp-out
4 x45 W
4-Channel
Preamp-out
Equalizer

11
Fun
London MP35
Kingston MP35
4-Channel
Preamp-out
4-Channel
Preamp-out
Vario
Colour
Speech
output
Vario
Colour
Sub out

12 Fun
Madrid MP35
Equalizer
Remote
Control
4 x45 W
Aux- in
4-Channel
Preamp-out
San Diego MP35
4-Channel
Preamp-out
MP3 Tuners.

13
Fun
Vancouver CD35
Aux- in
Sound
Presets
Bristol CD35
CD tuners from Blaupunkt exhibit convincing technology
with their high-quality, shock and shake-proof CD drives, easy
operation and high functionality. The Sound Preset feature, for
example, lets you set the ideal frequency response for different
types of music (rock, pop and classical) at the touch of a
button. The convenient 4-channel preamp out provides reli-
able control for external amplifiers and different connection
options make it possible to add to your music system.
4-Channel
Preamp-out
Aux- in
Sound
Presets
4-Channel
Preamp-out
CD Tuners.

We just keep raising
the bar, for sound as well as
for navigation. And our claim to the
technical sophistication of our pro-
ducts is also reflected in their modern,
ergonomic design. Advances that we
prove time and again with Digital Radio,
MP3 playback or the TwinCeiver. With
Blaupunkt, you experience the best
ever Car Multimedia. With all
your senses.
Performance –
See it with your
own two ears.
14/15
Performance

16 Performance
Get to your destination quicker and more conveniently
than ever before.
Precise, reliable route guidance with traffic congestion ahead
avoidance is good. Individual navigation – with a setting option
to combine the quickest and the shortest route – is better.
And being able to listen to music at the same time – CD or
MP3 – means technology of the finest.
The TravelPilot E , the TravelPilot E ’s big
brother, is equipped to perfection in terms of technology as
well as looks. Enjoy MP3 sound or your favourite CD, while
you take advantage of the dynamic corridor function to get
wherever you’re going on the optimal route without a traffic
jam in sight. Thanks to house number interpolation, the
TravelPilot E not only finds the best way to the street
you’re looking for, it takes you directly to the front door. Just
insert the Europe navi CD to get you to virtually any desti-
nation in Europe. Precise navigation with optional speed signal
hook-up (easy to install). Easy installation in just three steps:
remove the old system – connect the new one and attach
the GPS antenna – slide the Travel-Pilot E right in.
You’re done!
Display illumination in
white
Key pad illumination in
white
Display illumination in
blue
Key pad illumination in
red
Display illumination in
white
Key pad illumination in
red
Start/Finish corridor
Shortest route
Quickest route
Optimal route

17
Performance
The TravelPilot E has been making it easy to go into the
navigation mode since 2004. Thanks to a new chip concept,
this navigation system is excellent value for money. The
TravelPilot E started off as the first radio-based naviga-
tion system with optimal route guidance (combination of quick-
est and shortest route) and a dynamic corridor function.
And while you are listening to your favourite CD, the Travel-
Pilot E gets you to your destination, quickly and reliably.
The TravelPilot E is also able to boast easy installation
in just three steps thanks to the optional speed signal hook-up.
Other CDs including Major Roads:
Benelux E 2005, Germany E 2005, France E 2005 (incl. Monaco), Great
Britain/Ireland E 2005, Italy E 2005 (incl. San Marino and Vatican City),
Austria/Switzerland E 2005 (incl. Liechtenstein), Poland (from summer 2005),
Czech Republic E 2005, Portugal/Spain E 2005 (incl. Andorra), Scandinavia E 2005
(incl. Denmark, Sweden, Norway and Finland)
Features based on the Germany CD:
• Detailed road network in Germany
• Major connecting roads in: France, Belgium, the Netherlands, Luxembourg, Italy,
Great Britain, Ireland, Austria, Switzerland, Portugal, Spain, Norway, Sweden,
Denmark, Finland, Andorra, Liechtenstein, San Marino, Vatican City and Monaco
• Dynamic navigation in Germany, Austria, Belgium, Denmark, France, Italy, the
Netherlands, Sweden, Switzerland and Spain
• Destination input in Germany via postal codes (complete coverage in Germany)
• More than 260,000 Points of Interest, such as airports, motorways, border cross-
ings, city centres and petrol stations right on up to fast-food restaurants and much
more
• Compatible with the TravelPilot E , TravelPilot E

18 Performance
The Blaupunkt Bremen MP74 is the first car radio to have made
it to “autohifi” magazine’s reference class, a prestigious award
given by Europe’s well respected Car hifi magazine. Thanks to
a self-adjusting equalizer (DSA Max) with 108 bands, which
can also be adjusted individually, you’ll experience optimal
sound at the touch of a button. And we even added an interface
(PC connection) to connect the car radio with a PC so that you
can display all the sound settings conveniently on a large screen
while you adjust them in real time. A TwinCeiver equipped with
two DSP-based receivers puts the finishing touch on perfect
radio reception. The TIM speech memory makes it possible to
store traffic messages lasting a total of four minutes, and, last
but not least, the high-resolution full-graphic display with
VarioColour makes for a fantastic all-round package.
Two of a kind.
Bremen MP74
connectivity
Vario
Colour

19
Performance
The automatic DEQmaxEX self-adjusting equalizer is the heart
of the Acapulco MP54 DigiCeiver. It can optimize the system’s
sound at the touch of a button. Or use the PC connection to
fine-tune the system’s sound performance on your computer
yourself. This car radio sports a very elegant look, featuring
a VarioColour display. Select your favourites from among
4,096 colours and 16 coloured night design shades.
Acapulco MP54
connectivity
Vario
Colour

20 Performance
Digital Radio – the future on board.
Woodstock DAB 54
The Woodstock DAB 54 digital radio features a professional
design with a high-resolution full-graphic display and sophisti-
cated technology. Interference-free listening pleasure in CD
quality is guaranteed by digital reception on the DigiCeiver. A
one-of-a-kind digital recorder lets you record your favourite
song on an SD/MMC card even when you’re already on the road.
And don’t fret if you missed the first few seconds – thanks to
Blaupunkt technology, your recording will be complete from
start to finish every time.
