2 | 3
Big bass
in any case. Contents
04 | 13 Velocity Speakers
14 | 15 Velocity Amplifiers
16 | 19 TH Speakers
20 | 27 THA-PnP Amplifiers
28 | 31 GT Speakers
32 | 3 3 GTA Amplifiers
34 | 37 EM Speakers
38 | 3 9 EMA Amplifiers
40 | 41 Logo explanation
42 | 4 9 Everything at a glance | Technical Specifications
50 | 51 Car Navigation | Car Radio
The bass makes
the music; you’ll really feel
it. The Blaupunkt sound systems
put rich sound into any vehicle. All
the components are matched with one
another – designed to deliver maximum
performance. The amplifiers operate
like turbo chargers, the subwoofers
like racing engines, and you are the
sound pilot sitting in the cock-
pit. So, just sit back and
enjoy bass power at
its best.

Perfect sound quality has a name: Velocity. The sub-
woofer, component and coaxial systems with the
triangular emblem guarantee music enjoyment of the
highest quality. Made for anyone who is unwilling to
compromise and always looking for perfection. If you
want a concert stage on wheels, the Velocity speaker
systems will get you where you want to go.
Optimal flexibility – all Velocity subwoofers have an impedance of
2 x 2 ohms to offer a wide range of connection configurations.
4000W
300
mm
91
Optimized to highest power handling capacity and maximum
sound quality
Solid aluminum die-cast baskets for all VPw and VPc systems
2 x 2-ohm voice coils in all subwoofers
3-ohm impedance in all coaxial and component systems –
coaxes up to 30 % more power out of the amp
Separate steep frequency crossovers for all VPc, Vc and
Vx systems
Voice coils
wired in parallel
= 1 ohm
Voice coils
wired in series
= 4 ohms
One voice coil
per amplifier
= 2 x 2 ohms
Sound that will let you take off –
the Velocity speakers.
4 | 5
That’s a 12 on the Richter scale – this subwoofer not
only gets any vehicle rocking, it also makes the deep
bass sound a thing that all your senses will enjoy.
VPw 1200 Pro

Vw 800 Vw 1000
6 | 7
Something for everyone – the Velocity
subwoofers in the Vantage Series are
available in four different sizes from
200 mm to 380 mm in diameter. All of
them have been optimized for use in
sealed or bass-reflex enclosures.
Vw Vantage
subwoofers
Vw 1200 Vw 1500

Cutting the corners off the box –
the Vb 1000 subwoofer.
1600W
2 x 250
mm
94
The protective rods of the
subwoofers and the logo can
be illuminated.
8 | 9
Enclosed subwoofers in a new dimension – the Velocity
Vb subwoofers are proof positive of the fact that a box
doesn’t always have to have four corners.
Vb 1000

A legend in their own time – experts rate VPc tweeters among
the best in the world.
Heavy metal – the complex
frequency crossover in
the VPc systems is built into
a solid aluminum enclosure.
Nice to look at and impossible
to destroy.
VPc component system tweeter
Acoustically optimized dispersing lens
For per fect radiation behavior
Highly damping Tetron fabric cone
For silk y smooth high-frequency reproduction
No ferrofluid used in the air gap
For perfect microdynamics
Dual symmetrical
neodymium magnet system
For ultrahigh sensitivity and minimal
total harmonic distortion
Pole piece borehole
For avoiding compression effects
Coupling volume filled with insulation
For deep resonance frequency
Rotary mount chassis
For optimal orientation to the listening location
480
165
mm
67
92
10 | 11
The reference of sound: High-end reproduction is
the result of years of experience, best materials and
excellent workmanship. Velocity Pro makes all your
sound dreams come true. All of the components of
these speakers were optimized to create a unique
listening experience.
VPc 662 Pro

280
280
165
mm
130
mm
60
50
91
91
130 %
100 %
4-ohm speakers
3-ohm speakers
Amplifier power in %
12 | 13
No room in your car for separate tweeters and woo-
fers? No problem – the Velocity coaxial systems offer
everything for optimal sound quality that you would
otherwise only expect of component systems.
Vx 662
A separate, particularly compact 12 dB
frequency crossover provides for
precise separation between tweeters and
woofers in all the coaxial systems.
It’s all about the impedance. All the Velocity coaxial and
component systems have an impedance of 3 ohms. The
advantage: You can get up to 30 % more power out of
your amplifier compared to conventional 4-ohm systems.
And don’t worry – there won’t be any problems, even if
the system is connected directly to the car radio!
Superior sound, elegance and acoustics that will
blow you away: The best thing about the components
systems in the Vc Series is not their black carbon look.
They also shine with a multitude of other elaborate
details. And anyone who thinks that top-quality sound
has to cost a lot will be pleasantly surprised by this
series.
Vc 542

3000W
850
1
High-Level
Input
The direct line – the Velocity
amplifiers are also equipped
with Blaupunkt’s unique
“Direct Aux input”. Which means
that you can connect such
portable devices as MP3 players,
iPods or navigation systems
to the audio systems you have
without an Aux input.
Perfect sound doesn’t come
from nothing – a look into
the interior of the VPA amplifier
shows you where brilliance
begins.
Would you care for a second
helping of power? The “link
function” lets you have it,
connecting two VPA 1500 Pro
amplifiers to create one
powerhouse. The result:
up to 5000 watts at 1 ohm!
14 | 15
This giant will drive any subwoofer to its limits. Thanks
to its uncompromising 1-ohm stability, it delivers up
to 1.5 kW of continuous power or 3 kW of maximum
power. And if that’s not enough, you can also connect
two of these amps to virtually quadruple your power.
Listening to music is good, feeling it is a lot better. The
ideal pre-requisites are provided by amplifiers with
great power reserves that don’t give up even when
the going gets tough. The amplifiers in the Velocity
series are able to meet even the most demanding
requirements. With no compromises. Excellent sound
and top-rate workmanship were combined to create a
unique work of art with a rich feature package.
Uncompromising design for highest sound quality
VPA 1500 Pro 1-ohm stable, all other output stages
2-ohm stable
Cable remote control for BassBoost included with all
VPA 2140 Pro and VPA 150 0 Pro
Direct Aux-In (except VPA 1500 Pro)
High-level input for VA 275 and VA 475
The Velocity-Pro amplifiers are available in three diffe-
rent versions: 1-channel, 2/1-channel and 4/3/2-chan-
nel systems. The Velocity-Vantage amplifiers come in
two different versions: 2/1-channel and 4/3/2-channel
systems.
Technical specifications, see Page 44.
VPA 1500 Pro
Power that knows no limits:
the Velocity amplifiers.
First-class sound doesn’t have to be expensive – the VA
amplifiers offer outstanding performance and a unique
range of features at an affordable price. Coupled with
elegant looks in titanium silver and stylish black.
VA 475

16 | 17
240
6
165
mm
Great sound with no trouble: The drive concept of the
TH Series impressively displays how compact high-
quality vehicle speaker systems can be today. Don’t
waste any more time on thinking about how your
factory-installed speakers can be replaced by a better
system. And certainly don’t worry about the installat-
ion – because the TH Series fits just about anywhere.
Extremely flat design – easiest installation
Low-resonance membranes made of injected polypropylene
(IPP) in an elegant “black brushed metal look”
Rear-ventilated voice coils for optimized heat dissipation and
higher electrical power handling
Woofer magnets integrated in the steel basket for optimum
stability (Integrated Magnet System)
Designer covers with metal application included
Two particularly compact active subwoofers and a passive
version for the spare-wheel well
Top-rate sound made so
simple – the TH Series.
Elegant and extremely easy to install – the THc 662
pursues this philosophy right to the end. Whether it’s
the low installation depth of the woofer of just 46 mm,
the compact tweeter with its swivel mounting or the
extremely small 12 dB frequency crossover – every-
thing is optimized for the best sound with the smallest
footprint.
THc 662
Perfect climate:
The many vents in the
basket do not only ensure
optimal cooling for the
voice coil, they also
prevent any compression
effects.
Flat intelligence:
The special geometry of
the low-resonance mem-
brane made of injected
polypropylene (IPP) makes
for the particularly flat
design of all the TH speakers.

18 | 19
240
200
mm
140
200
mm
71
THb 210 A
This is how small great performance can be: The THb 210 A
is particularly compact (only about 9 liters of net volume),
but still has all the power of a big, fat subwoofer. Saving
space is one of its specialties. No need for a separate
amplifier, because a powerful output stage is already
integrated into an extremely robust enclosure made of
die-cast aluminum. With automatic power-on and speaker
inputs, the THb 210 A is an ideal addition to any existing
original car audio system.
The electronics on the inside
of the THb 210 A with the
powerful 240 W amplifier gives
the right drive to the woofer.
THb 200 A
Flat, but packs a powerful punch: with only 71 mm of
installation height, the subwoofer is so compact that
it fits under the front seat in many different vehicles.
Still, the THb 200 A delivers its best sound performance
when it’s installed directly under the dashboard in the
front-seat passenger footwell.

20 | 21
1000W
An ideal couple – the THA 1250 PnP
(not included) fits perfectly into the
recess in the THs 6902.
THs 6902
Get your head “round” this! Now you can tuck your
subwoofer away in a space that is usually left unused
in many vehicles – in the spare-wheel well. And thanks
to the hole in the center of the subwoofer enclosure, it
doesn’t matter if you can’t remove the central bolt that
holds the spare wheel in place. With its two oval 6" x 9"
woofers, the THs 6902 delivers rich, full-bodied bass
sound from a flat bass-reflex box. Pairing this sub-
woofer up with the THA 1250 PnP amplifier makes for an
ideal combination: there’s a recess designed to accom-
modate the amp integrated right into the subwoofer
enclosure.
TH coaxial system sizes:
100 mm, 130 mm, 165 mm and 4" x6".
TH triaxial system sizes:
6" x 9".
TH component system sizes:
130 mm and 165 mm.
TH subwoofer sizes:
200 mm ultra-flat, 200 mm, 2 x6" x9".
Technical specifications, see Page 45.
It doesn’t get any easier than this:
out with the spare wheel – in with
the THs 6902 subwoofer!

22 | 23
Plug’n’Play for Rock’n’Roll –
the THA-PnP amplifiers.
More and more vehicles are now equipped with ra-
dios from the factory that can be upgraded with other
systems some time down the line. And then there
are leasing vehicles that you can’t alter, making ret-
rofitting with new sound systems virtually impossi-
ble. Now there’s a solution for more power – thanks
to Blaupunkt’s new THA Plug ’n’ Play amplifier series,
almost any vehicle can be fitted with powerful am-
plifiers without having to cut a single original cable.
The installation is child’s play in the truest sense of
the word and can usually be finished in less than
30 minutes. The only thing that can be faster is you
making your decision.
Plug ’n’ Play connection option
Ultra-compact
Minimal power consumption
Direct Aux-In (except THA 1250)
Cable remote control for BassBoost included
(THA 1250 and THA 555 only)
720
Plug ’n’Play
Connectivity
Ultra
compact
Our motto is: Save space. Thanks to their
extremely compact dimensions, the THAs
can be easily installed virtually anywhere.
Gone are the days when amplifiers almost
always had to be installed in the trunk
because of their size. Center console,
glove compartment, under the front seats
or behind the dashboard are the convenient
installation locations of the future.
THA 475 PnP
Simply strong – despite its particularly compact enclo-
sure, the THA 475 PnP is a real powerhouse. Intelligent
circuitry has made it possible to reduce its dimensions
by about 65 percent compared to conventional am-
plifiers in its class. And its innovative Plug ’n’ Play con-
nection technology makes installation incredibly easy.

24|25
Say goodbye to bulky tool kits: Up to now, anyone
wanting to install an amplifier needed a whole range
of different pliers, screwdrivers, special wrenches and
often even a soldering iron at the ready. Nowadays,
sometimes all you need are the mounting brackets to
remove the original radio. And thanks to the vehicle-
specific adapters, you don’t need to be an electronics
engineer.
Six steps
to more power:
Remove the radio. Plug the correct PnP adapter
into the radio.
Connect the original wiring
harness to the PnP adapter.
Connect the PnP extension
cord to the PnP adapter.
Connect the PnP extension
cord to the amplifier.
Mount the amplifier and return
the radio to its original position.
123 456

26 | 27
VW adapter BMW adapter Ford adapter
Volvo adapterSuzuki adapter
A connection for any car: There are 40 different adap-
ters to choose from, which means that you can easily
connect a THA PnP amplifier to factory-installed radios
in close to 1500 vehicle models built by European,
Asian and American manufacturers.
The THA-PnP amplifier is available in four different ver-
sions: 1-channel, 2/1-channel, 4/3/2-channel and 5/4/3-
channel systems.
Technical specifications, see Page 46.
Lots of power – low on “thirst”. In order to supply the
THA PnP amps with power through the original wires,
their power consumption has to be minimal. Thanks to
the enormous efficiency of the PnP amplifiers, almost
all of the input power is transformed into music –
and not into heat. Don’t worry: the PnPs won’t get the
wires smoking – but your ears might.
Efficiency
80 %
45 %
Conventional amplifier
THA PnP
Heat Music
The sound pipeline: Wherever
you install the amplifier –
in the rear of the vehicle or in
the trunk – you’ll always find
a connection cable in the right
length. Two different lengths
are available (2.5 m and 5.5 m).
THA 1250 PnP THA 275 PnPTHA 555 PnP

28| 29
Black is beautiful –
the GT Series.
Hardly another speaker series currently on the market
has been as successful over the past few years as the
GT Series made by Blaupunk t. Thanks to regular model
updates, these masters of sound have been able to
consistently provide optimized performance year after
year. As a result, the 2009 generation with its 17 dif-
ferent models and sizes is now more uncompromising
and elegant than ever before. The acoustic properties,
which have been enhanced yet again with new cones
and gold-plated connectors for maximum service life,
are unique, not only in this price segment.
Low-resonance membranes (Injected PP) in all GTx,
GTc and GTw speakers
Rear-ventilated voice coils for optimized heat dissipation
and higher electrical power handling
Gold-plated connectors
Designer covers included (except the GTx 352 Mystic Series)
260
74,5
GTx 693 Mystic Series
Black magic – the combination of black covers, cones
in the “black brushed metal look” and tweeter bridges
in “black chrome” give the GT Series a unique and par-
ticularly elegant appearance. Sound and workmanship
are also in a class of their own, and not only in this
price segment.
What glistens here really is gold
– the connector contacts on the
GT speakers have been covered
with a layer of the precious metal
to provide for optimal resistance
to corrosion.

30|31
240
900
850
56
126
300
mm
165
mm
250
mm
91
GTc 662 Mystic Series
GTw 1000 Mystic Series
Going separate ways for perfect sound harmony – the
component systems in the GT series make it possible
to separately install the tweeters at the acoustically
most suitable location. And if that is not enough, their
swivel mounting even allows you to tweak the posi-
tioning to provide for impeccable sound.
The ideal solution for individualists. The parameters of
the GTw subwoofer systems were chosen so that they
provide for impressive deep bass sound in sealed as
well as in bass-reflex enclosures.
GTb 1200 Mystic Series
DIY installation is not for you? The GTb 1200 Mystic Series
already comes complete with an optimally dimensioned
enclosure.
The sizes of the GT coaxial systems:
87 mm, 100 mm, 130 mm, 158 mm, 165 mm,
4"x 6"and 5"x 7".
The sizes of the GT triaxial systems
165 mm, 200 mm und 6"x 9".
The sizes of the GT component systems:
130 mm, 158 mm und 165 mm.
The sizes of the GT subwoofers:
250 mm, 300 mm, 300 mm tube and 300 mm box.
Technical specifications, see Pages 46 to 48.
Perfect connections –
the GTC1 set contains all the
wiring and cables you need
to connect the GTA amplifiers.
Power cords, speaker wiring
and the four-channel cinch
cable – it’s all there.

32|33
Even really successful models can still be tweaked and
optimized. That’s why the new GTA amplifiers were
treated to a full power makeover. Both versions now
deliver more power under all kinds of conditions to
provide for greater sound enjoyment. What has stayed
the same, of course, are the outstanding workman-
ship and legendary reliability. The new amplifiers are
real GTAs, there’s no doubt about it – they’re built for
success!
2-ohm stable (4-ohm stable in bridged mode)
Variable high and low pass filters
Variable BassBoost for deeper bass reproduction
Enhanced performance
840
420
Everything you need for rich
sound – the connector panel
of the GTA 470 offers different
setting options for input
sensitivity, the crossover
frequency and BassBoost.
A real Blaupunkt – even in
the entry-level category.
The embossed aluminum
logo is the trademark and
guarantee for highest
reliability and quality at the
same time.
More powerful
than ever –
the GTA Series.
The dark side of power – with their elegant, black sur-
faces, the GTA Mystic Series amplifiers pack a real visu-
al punch. And anyone who has listened to them knows
that their sound performance compares in every way
to their stylish appearance.
A size smaller – the GTA 270 offers the same sound
features as its big brother, but just has two channels.
Technical specifications, see Page 48.
GTA 470 Mystic Series GTA 270 Mystic Series

34|35
Your start into the Blaupunkt
world of sound – the EM Series.
160
56
165
mm
If your budget is low, but your expectations are high,
it’s time to take a look at the new EM Series. Many of
the elements and ideas that have made the GT Series
so successful have been incorporated into this new
concept. Because the series concentrates on the most
popular sizes, these speakers deliver the right sound
for many vehicles. The small, active EMb 800 A sub-
woofer is the highlight of the series; it can be added
to the system quickly and inexpensively to provide a
richer bass foundation.
Low-resonance polypropylene cones
High power-handling capacity
Designer covers included with the coaxial and triaxial systems
EMx 663
Three ways to good sound – even in the entry-level
segment, the EMx 663 has been equipped with all the
prerequisites to afford lots of music quality. The only
cheap thing about this speaker is the price – with no
compromises made in terms of reliability or sound.

36|37
600
300
mm
91
150
200
mm
The small bass sensation – the compact EMb 800 A is
the ideal way to dramatically upgrade sound systems
that are a little weak on the bass in smaller vehicles.
Its active electronics deliver a lot of power to the wide-
excursion 200-mm chassis, which is built into a solid
bass-reflex enclosure.
The right settings make the critical
acoustic difference. Parameter level,
cut-off frequency and phase – only
when all three are infinitely variable
is it possible to perfectly integrate
an active subwoofer into an existing
speaker system. And that’s why
we have made no exception with the
EMb 800 A.
EMb 800 A
EMb 1200
30 – 27 – 35 – the EMb 1200 has the “ideal figure” for
a powerful bass blizzard. Its 30-cm woofer works in a
27-liter wood enclosure, supported by a bass-reflex
aperture tuned to 35 Hz. So that you not only hear the
music, you can feel it, too.
The tunnels for more pressure – both
EMb subwoofers are supported in the
deep bass range by precisely tuned bass-
reflex channels on the top side of the
enclosure. The generously dimensioned
cross sections minimize unwanted noise.
The EM coaxial system is available in the following sizes:
100 mm, 130 mm and 165 mm.
The EM triaxial system is available in the following sizes:
165 mm and 6"x 9".
The EM subwoofer is available in the following sizes:
200 mm and 300 mm.
Technical specifications, see Page 49.

38|39
Solid basis –
the EMA Series.
Are you looking for reliable amplifiers at particularly
affordable prices? In that case, the new EMA Series is
exactly the right choice. By concentrating on the most
important functions and ample power reserves, the
amplifiers prove once again that genuine Blaupunkt
quality is available in every price segment. Rich sound
and the legendary reliability are just as much a part of
the package as the high-quality appearance in elegant
titanium silver.
2-ohm stable (4-ohm stable in bridged mode)
Variable high and low-pass filters
Variable BassBoost for expanded bass reproduction
700
350
Everything you need for
good sound. Gain control,
high-pass and low-pass filters
and variable BassBoost –
the EMA amplifiers are equip-
ped with all the important
features.
EMA 460 EMA 260
The EMA amplifiers are convincing proof, visually as
well as technically, that cutting corners is absolutely
taboo, even in the entry-level segment. Solid heat
sinks with a brushed, anodized surface on the outside
along with well-engineered technology on the inside
guarantee long product service life with great sound
properties.
A half pint ? No way ! Compared to its bigger colleague,
the EMA 260 is equipped with only two channels and
half the total power, but has all the same features.
Technical specifications, see Page 49.
