1. GETTING STARTED
What’s In The Box?
 •1xSnowBank™ProfessionalLEDFixture
 •ThisLovelyUserManual
Getting It Out Of The Box
CongratulationsonpurchasingoneofthecoolestLEDxtures
anywhere! Now that you’re the proud owner of a SnowBank™ (or
hopefully,MORE!),youshouldcarefullyunpacktheboxandcheckthe
contents to ensure that all parts are present and in good condition. If
anything looks as if it has been damaged in transit, notify the shipper
immediately and keep the packing material for inspection. Again,
pleasesavethecartonandallpackingmaterials.Ifaxturemustbe
returnedtothefactory,itisimportantthatthexturebereturnedin
the original factory box and packing.
Powering Up!
Allxturesmustbepowereddirectlyoffaswitchedcircuitandcannot
be run off a rheostat (variable resistor) or dimmer circuit, even
if the rheostat or dimmer channel is used solely for a 0% to
100% switch.
AC Voltage Switch -Notallxtureshaveavoltageselectswitch,so
pleaseverifythatthextureyoureceiveissuitableforyourlocal
powersupply.Seethelabelonthextureorrefertothexture’s
specicationschartformoreinformation.Axture’slistedcurrent
rating is its average current draw under normal conditions. Check
thextureordevicecarefullytomakesurethatifavoltageselection
switch exists that it is set to the correct line voltage you will use.
Warning! Verify that the voltage select switch on your unit
matches the line voltage applied. Damage to your xture may
result if the line voltage applied does not match the voltage
indicated on the voltage selector switch. All xtures must be
connected to circuits with a suitable Ground (Earthing).
Getting A Hold Of Us
If something is wrong, just give us a call or send an email.
We’ll be happy to help, honest.
Blizzard Lighting
W220N1531JerichoCt.SteE
Waukesha, WI 53186 USA
www.blizzardlighting.com
414-395-8365

Page 4
SnowBank User Manual Rev. A Copyright (c) 2012 Blizzard Lighting, LLC
SAFETY INSTRUCTIONS
•PleasekeepthisUserGuideforfutureuse.Ifyouselltheunittosomeone
else, be sure that they also receive this User Guide.
•ALWAYSmakesurethatyouareconnectingtothepropervoltage,andthat
the line voltage you are connecting to is not higher than that stated on the
decalorrearpanelofthexture.
•Thisproductisintendedforindooruseonly.
•Topreventriskofreorshock,donotexposexturetorainormoisture.
•Makesuretherearenoammablematerialsclosetotheunitwhileoperating.
•Theunitmustbeinstalledinalocationwithadequateventilation,atleast
20in (50cm) from adjacent surfaces. Be sure that no ventilation slots are
blocked.
•ALWAYSdisconnectfromthepowersourcebeforeservicingorreplacingfuse
and be sure to replace with same fuse size and type.
•ALWAYSsecurextureusingasafetychain.NEVERcarrythexturebyits
cord. Use its carrying handles.
•DONOToperateatambienttemperatureshigherthan104°F(40°C).
•Intheeventofaseriousoperatingproblem,stopusingtheunitimmediately.
NEVERtrytorepairtheunitbyyourself.Repairscarriedoutbyunskilledpeople
can lead to damage or malfunction. Please contact the nearest authorized
technical assistance center. Always use the same type spare parts.
•NEVERconnectthedevicetoadimmerpack.
•Makesurethepowercordisnevercrimpedordamaged.
•Neverdisconnectthepowercordbypullingortuggingonthecord.
•Avoiddirecteyeexposuretothelightsourcewhileitison.
Caution! There are no user serviceable parts inside the unit. Do not
open the housing or attempt any repairs yourself. In the unlikely event
yourunitmayrequireservice,pleasecontactBlizzardLightingat
[email protected].

Page 5
SnowBank User Manual Rev. A Copyright (c) 2012 Blizzard Lighting, LLC
2. MEET THE SNOWBANK™ LED BLINDER
MAIN FEATURES:
•Userselectable7or26DMXchannels
•Poweredby32Tri-ColorRGBLED’s
•Fullcolormixinginstandalone,master/slaveandDMXmodes
•Built-inautomatedprogramsviamaster/slave
•Built-insoundactivatedprogramsviamaster/slave
•EasytouseLEDdigitalcontrolpanel
•3-pinmaleinputand3-pinfemaleoutput
•Dualmountingyokeallowsexibilityinpositioning
•Heavyduty,blackaluminumhousing
OPTICAL:
•BeamAngle:45°
•400hzicker-freeLEDdrivers
•LightSource:32*3-wattTri-ColorLEDs,100,000hours
CONTROL:
•USITTDMX-512(26/7Channels)
•3-pinInput/Output
•LED4-buttoncontrolpanel
DMX Quick Reference (26-Channel Mode)
Channel Channel
1 Dimmer
2-25 Individual Pixel R/G/B Intensity
26 Strobe
DMX Quick Reference (7-Channel Mode)
Channel Channel
1 Dimmer
2 Global Red Intensity
3 Global Green Intensity
4 Global Blue Intensity
5 Built-in Programs
6 Speed
7 Strobe

Page 6
SnowBank User Manual Rev. A Copyright (c) 2012 Blizzard Lighting, LLC
Figure 1: The SnowBank™ Pin-Up Picture
High Power
Tri-ColorLEDs
Black Aluminum
Casing
Dual
Mounting Brackets
Figure 2: The Rear Connections
Microphone
LEDControlPanel
DMX In DMX Out
Locking
Knobs
AC Power In

Page 7
SnowBank User Manual Rev. A Copyright (c) 2012 Blizzard Lighting, LLC
3. SETUP
Fuse Replacement
CAUTION! The SnowBank™ utilizes a high-output switch-mode power
supply with an internal fuse. Under normal operating conditions, the
fuseshouldnotrequirereplacement.Thefuseiseldreplaceable,
howeveritisanadvancedproceduresuitedtoqualiedindividuals.
ShouldyourSnowBank™fuserequirereplacement,pleasecontact
Blizzard Lighting for instructions, or to return your unit for service.
Connecting A Bunch of SnowBank™ Fixtures
You will need a serial data link to run light shows using a DMX-512
controllerortorunshowsontwoormorexturessettosyncin
master/slave operating mode. The combined number of channels
requiredbyallthexturesonaserialdatalinkdeterminesthenumber
ofxturesthedatalinkcansupport.
Fixtures on a serial data link must be daisy chained in one single line.
Also,connectingmorethan32xturesononeserialdatalinkwithout
the use of a DMX optically-isolated splitter may result in deterioration
of the digital DMX signal.
The maximum recommended cable-run distance is 500 meters (1640
ft).Themaximumrecommendednumberofxturesonaserialdata
linkis32xtures.
Data/DMX Cabling
Tolinkxturestogetheryou’llneeddatacables.Youshouldusedata-
gradecablesthatcancarryahighqualitysignalandarelessproneto
electromagnetic interference.
Forinstance,Belden©9841meetsthespecicationsforEIARS-
485 applications. Standard microphone cables will “probably” be
OK, but note that they cannot transmit DMX data as reliably over
long distances. In any event, the cable should have the following
characteristics:
2-conductor twisted pair plus a shield
Maximum capacitance between conductors – 30 pF/ft.
Maximum capacitance between conductor & shield – 55 pF/ft.
Maximum resistance of 20 ohms / 1000 ft.
Nominal impedance 100 – 140 ohms

Page 8
SnowBank User Manual Rev. A Copyright (c) 2012 Blizzard Lighting, LLC
Cable Connectors
Cables must have a male XLR connector on one end and a female XLR
connector on the other end. (Duh!)
CAUTION: Do not allow contact between the common and the
xture’schassisground.Groundingthecommoncancauseaground
loop,andyourxturemayperformerratically.Testcableswithan
ohm meter to verify correct polarity and to make sure the pins are not
grounded or shorted to the shield or each other.
3-Pin??? 5-Pin??? Huh?!?
If you use a controller with a 5 pin DMX output connector, you will need to use a 5 pin to 3 pin adapter.
They are widely available over the internet and from specialty retailers. If you’d like to build your own,
the chart below details a proper cable conversion:
Conductor 3-Pin Female
(Output)
5-Pin Male
(Input)
Ground/Shield Pin 1 Pin 1
DMX Data (-) Pin 2 Pin 2
DMX Data (+) Pin 3 Pin 3
Not Used. No Connection. No Connection.
Not Used. No Connection. No Connection.
Take It To The Next Level: Setting Up DMX Control
Step 1: Connect the male connector of the
DMX cable to the female connector (output)
on the controller.
Step 2: Connect the female connector of
theDMXcabletotherstxture’smale
connector (input). Note: It doesn’t matter
whichxtureaddressistherstone
connected. We recommend connecting the
xturesintermsoftheirproximitytothe
controller, rather than connecting the lowest
xturenumberrst,andsoon.
Step 3:Connectotherxturesinthechain
from output to input as above. Place a DMX
terminatorontheoutputofthenalxture
to ensure best communication.

Page 9
SnowBank User Manual Rev. A Copyright (c) 2012 Blizzard Lighting, LLC
Fixture Linking (Master/Slave Mode)
1. Connect the (male) 3 pin connector side of the
DMX cable to the output (female) 3 pin connector of
therstxture.
2. Connect the end of the cable coming from
therstxturewhichwillhavea(female)3pin
connectortotheinputconnectorofthenextxture
consisting of a (male) 3 pin connector. Then,
proceed to connect from the output as stated above
totheinputofthefollowingxtureandsoon.
A quick note: Often,
the setup for Master-
Slave and Standalone
operationrequiresthat
therstxtureinthe
chain be initialized for
this purpose via either
settings in the control
panel or DIP-switches.
Secondarily,thextures
that follow may also
requireaslavesetting.
Check the “Operating Adjustments” section in this manual for
completeinstructionsforthistypeofsetupandconguration.
Mounting & Rigging
ThisxturemaybemountedinanySAFEpositionprovidedthereis
enough room for ventilation.
It is important never to obstruct the fan or vents pathway. Mount the
xtureusingasuitable“C”or“O”typeclamp.Theclampshouldbe
ratedtoholdatleast10xthexture’sweighttoensurestructural
stability. Do not mount to surfaces with unknown strength, and ensure
properly“rated”riggingisusedwhenmountingxturesoverhead.
Adjusttheangleofthexturebylooseningbothknobsandtiltingthe
xture.Afterndingthedesiredposition,retightenbothknobs.
•Whenselectinginstallationlocation,takeintoconsiderationlamp
replacement access (if applicable) and routine maintenance.
•SafetycablesMUSTALWAYSbeused.
•Nevermountinplaceswherethexturewillbeexposedtorain,
high humidity, extreme temperature changes or restricted ventilation.

Page 10
SnowBank User Manual Rev. A Copyright (c) 2012 Blizzard Lighting, LLC
4. OPERATING ADJUSTMENTS
The Control Panel
All the goodies and different modes possible with the SnowBlind™
areaccessedbyusingthecontrolpanelonthesideofthexture.
Thereare4controlbuttonsbelowtheLEDdisplaywhichallowyouto
navigate through the various control panel menus.
<MODE>
Is used to navigate the various modes.
<SETUP>
Is used to enter into the selected mode setup.
<UP>
Scrolls through menu items and numbers in ascending order.
<DOWN>
Scrolls through menu items and numbers in descending order.
TheControlPanelLEDDisplayshowsthemenuitemslistedonthe
Control Panel Menu Structure on page 11. Use the <MODE>
button to navigate your choices. To edit a setting, push the <SETUP>
button, then use the <UP> and <DOWN> buttons again to scroll
through your options.
Mode Setup doWNup
