Project
Item No.
Quantity
Model KLT-20E - 20 gallon (76 litres) electric tri-leg tilting kettle
Model KLT-30E - 30 gallon (114 litres) electric tri-leg tilting kettle
Model KLT-40E - 40 gallon (151 litres) electric tri-leg tilting kettle
Model KLT-60E - 60 gallon (227 litres) electric four leg tilting kettle
Model KLT-80E - 80 gallon (303 litres) electric four leg tilting kettle
Model KLT-100E - 100 gallon (379 litres) electric four leg tilting kettle
CONSTRUCTION
304 stainless steel construction
2/3 jacketed with factory sealed distilled water enclosure
Hemispherical design on bottom of kettle for superior heat circulation
Drip proof stainless steel console
Welded 1-5/8” (41mm) diameter stainless steel frame and legs
Legs fitted with four hole adjustable flanged feet for securing to floor
Self-locking tilt mechanism with trunnions and outbore bearing con-
nected to the frame permit the kettle to tilt forward 90° for emptying
Stainless steel control housing
316 stainless steel liner on 20, 30 and 40 gallon models
OPERATION
Electrically self-generated closed steam system
Integrally mounted controls
Power switch
Thermostat
Cook indicator light
Pressure gauge
Safety valve
Low water light
Low water shut off
165-285°F (74-140°C) temperature range
STANDARD FEATURES
Manual control
Stainless steel faucet bracket
Standard voltage options
208 VAC, 3 phase, 60 Hz
240 VAC, 3 phase, 60 Hz
208 VAC, 1 phase, 60 Hz ( 20 & 30 gallon models only)
240 VAC, 1 phase, 60 Hz ( 20 & 30 gallon models only)
One year parts and labor warranty*
* For all international markets, contact your local distributor.
BLODGETT
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: [phone] • Phone: [phone] • Fax: [phone]
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Voltage options
220 VAC, 1 phase, 60 Hz (20, 30 & 40 gallon
only)
220 VAC, 3 phase, 60 Hz
380 VAC, 3 phase, 60 Hz
415 VAC, 3 phase, 60 Hz
480 VAC, 3 phase, 60 Hz
220/380 VAC, 3 phase, 4 wire
240/415 VAC, 3 phase, 4 wire
600 VAC, 3 phase, 60 hz
Power increase options
24 kW elements for 40, 60 & 80 gallon
33 kW elements for 60, 80 & 100 gallon
Faucets
Single pantry faucet with swing spout
Double pantry faucet with swing spout
Covers
One piece lift off stainless steel cover
Spring assist hinged stainless steel cover
Draw Off valves and accessories
2” (50mm) draw off valve
3” (76mm) draw off valve
2” (50mm) dairy valve
3” (76mm) dairy valve
Perforated strainer for draw off
Solid stainless steel disc for draw off valve
Etched markings
Gallons
Litres
Correctional package
316 stainless steel liner for 60, 80 & 100 gallon models
Tri-basket assembly
Graduated measuring strip
Pour strainer
Strainer hook
Pan support
KLT-E
Electric Tilting Kettle on Legs
KLT-E TRI-LEG TILTING KETTLE

BLODGETT
www.blodgett.com 44 Lakeside Avenue, Burlington, VT 05401 Toll Free: [phone] • Phone: [phone] • Fax: [phone]
KLT-E TRI-LEG TILTING KETTLE
SHORT FORM SPECIFICATIONS
Provide Blodgett model KLT-20E (20 gallon), KLT-30E (30 gallon), KLT-40E (40 gallon), KLT-60E (60 gallon), KLT-80E (80 gallon) or KLT-100E (100 gallon) electrically heated tilting ket-
tle on legs. The unit shall have a double wall interior to form a steam jacket around the lower 2/3 of the kettle. The jacket enclosure shall contain distilled water which is factory sealed.
The bottom of the kettle shall be of hemispherical design for superior heat circulation. The console shall be drip proof, stainless steel clad and shall be supported on all welded, 1-5/8”
(42mm) diameter stainless steel frame and legs fitted with 4 hole adjustable flanged feet for securing to floor. The unit shall pivot on trunions connected to the tilt mechanism and the out-
bore bearing connected to the frame and shall permit the kettle to tilt forward a full 90° for complete emptying. The tilt mechanism shall be self locking for positive stop action. Construction
shall be of all welded satin finish 304 stainless steel. The controls shall be integrally mounted and shall include a power switch, thermostat with range of 165-285°F (74-140°C), a cook
indicator light, pressure gauge, safety valve, low water light and low water shut off. The elements shall be removable. Unit shall be ASME code stamped and National Board registered.
Provide options and accessories as indicated.
Printed in U.S.A. NOTE: FOR COMMERCIAL USE ONLY
NOTE: The company reserves the right to make substitutions of components without prior notice.
APPROVAL/STAMP
P/N S00015 Rev E (12/06)
POWER CONNECTION:
Refer to data plate.
MAXIMUM PRESSURE:
All models 50 PSI (345 kPa)
SHIPPING INFORMATION:
Approx. Weight:
KLT-20E 350 lbs. (159 kg)
KLT-30E 365 lbs. (166 kg)
KLT-40E 400 lbs. (181 kg)
KLT-60E 465 lbs. (211 kg)
KLT-80E 570 lbs. (259 kg)
KLT-100E 680 lbs. (308 kg)
MODEL A B C D E F G H J (2”) J (3”) K (2”) K (3”) L M
KLT-20E 21[533] 18[457] 38[965] 36[914] 15[381] 18[457] 14[356] 19.25[489] 14.75[375] 15.5[394] 18[457] 17.5[445] - 63.5[1613]
KLT-30E 24[610] 20[508] 38[965] 39[990] 16.5[419] 19[483] 12.38[314] 19.25[489] 16.75[425] 17.25[438] 16[406] 15.5[394] - 66.5[1689]
KLT-40E 26[660] 22.5[572] 38[965] 41[1041] 17.5[445] 23[584] 10254] 20.25[514] 17.5[445] 18.5[470] 13.5[343] 13[330] - 68.5[1740]
KLT-60E 29.5[749] 26[660] 42[1067] 44.5[1130] 19.13[486] 24[610] 11[280] 22.25[565] 19.5[495] 20.75[527] 14[356] 13.5[343] 10.5[267] 76[1930]
KLT-80E 33[838] 28[711] 45[1143] 48[1219] 20.88[530] 27[686] 12.6[321] 23.75[603] 20.25[514] 21.25[540] 15[381] 14.5[368] 12[305] 82.5[2096]
KLT-100E 35.5[902] 29.75[755] 48.75[1238] 49.5[1257] 22.25[565] 32[813] 14.5[368] 25.25[641] 20.25[514] 21.25[540] 18.75[476] 18.25[464] 14[356] 88.5[2248]
AVAILABLE kW
MODEL STD OPT
KLT-20E 12 N/A
KLT-30E 15 N/A
KLT-40E 18 24
KLT-60E 18 24, 33
KLT-80E 18 24, 33
KLT-100E 24 33
AMPS PER LINE
KW PHASE 208V 220V 240V 380V 415V 480V 600V
12 1 57.7 54.4 50.0 N/A N/A N/A N/A
3 33.3 31.5 28.9 18.2 16.7 14.4 11.6
15 1 72.1 68.2 62.5 N/A N/A N/A N/A
3 41.6 39.4 36.1 22.8 20.9 18.0 14.5
18 3 50.0 47.2 43.3 27.3 25.0 21.7 21.7
24 3 66.6 63.0 57.7 36.5 33.4 28.9 23.1
33 3 91.6 86.6 79.4 50.1 45.9 39.7 31.8
