Blodgett KTT-10DS User manual

Project
Item No.
Quantity
Model KTT-6DS - 6 gallon (23 litres) direct steam tilting kettle
Model KTT-10DS - 10 gallon (38 litres) direct steam tilting kettle
Model KTT-12DS - 12 gallon (45 litres) direct steam tilting kettle
Model KTT-20DS - 20 gallon (76 litres) direct steam tilting kettle
CONSTRUCTION
Water resistant construction
304 stainless steel construction
316 stainless steel interior cooking surface for added corrosion
resistance
2/3 jacketed
Hemispherical design on bottom of kettle for superior heat circulation
Tilt mechanism permits kettle to tilt forward 90° to empty
Tubular stainless steel legs containing steam control valve and con-
densate return pipes
STANDARD FEATURES
Reversible operating handle with heat proof knob
Steam control valve mounted in leg
One year parts and labor warranty*
* For all international markets, contact your local distributor.
BLODGETT
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: [phone] • Phone: [phone] • Fax: [phone]
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Etched markings
Gallons
Litres
18” (46 mm) high stainless steel stand with sliding
shelf
One piece stainless steel lift off cover
Stainless steel perforated basket
Steam control assembly consisting of line strainer,
check valve, steam trap and safety valve
Pour strainer
Kettle table
KTT-DS
Direct Steam Table Top Tilting Kettle
KTT-DS TABLE TOP TILTING KETTLE

BLODGETT
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: [phone] • Phone: [phone] • Fax: [phone]
KTT-DS TABLE TOP TILTING KETTLE
SHORT FORM SPECIFICATIONS
Provide Blodgett model KTT-6DS (6 gallon), KTT-10DS (10 gallon), KTT-12DS (12 gallon) or KTT-20DS (20 gallon) direct steam counter tilting kettle. The unit shall have a double wall
interior to form a steam jacket around the lower 2/3 of the kettle. The bottom of the kettle shall be of hemispherical design for superior heat circulation. Steam control valve mounted in
leg. The tubular stainless steel mounting legs shall have the steam supply and condensate return pipes completely concealed within the leg memebers. The sealed stainless steel tilt
mechanism bearings shall permit the kettle to tilt forward 90° for complete emptying. A removeable operating handle with heat proof knob shall be mounted on the left or right. Unit shall
have a single support leg with nylon insert. Construction shall be all welded satin finish 304 stainless steel with a 316 stainless steel liner. Unit shall be ASME code stamped and National
Board registered. Provide options and accessories as indicated.
Printed in U.S.A. NOTE: FOR COMMERCIAL USE ONLY
NOTE: The company reserves the right to make substitutions of components without prior notice.
APPROVAL/STAMP
P/N S00004 Rev D (12/06)
PIPING REQUIREMENTS:
Steam Supply 1/2” IPS
Condensate Return 1/2” IPS
STEAM PRESSURE:
Minimum 5 PSI (34 kPa)
Maximum 50 PSI (345 kPa)
Pressure reducing valve required if incoming steam pressure
exceeds the kettle rating.
SHIPPING INFORMATION:
Approx. Weight:
KTT-6DS 75 lbs. (34 kg)
KTT-10DS 90 lbs. (41 kg)
KTT-12DS 100 lbs. (45 kg)
KTT-20DS 125 lbs. (57 kg)
MODEL A B C D E F G H J K L M N O P Q
KTT-6DS 12[305] 14.5[368] 19.5[495] 13.75[349] 5[127] 7.5[191] 15.1[384] 8.5[216] 12.25[311] 10.4[264] 30.25[768] 4[102] 4.38[111] 34.1[867] 0[0] 15.75[400]
KTT-10DS 16[406] 15[381] 18.5[470] 13.75[349] 7[178] 7.75[197] 19.1[486] 9[229] 16.25[413] 8.88[225] 32.25[819] 2.38[60] 4.88[124] 33.1[841] 0[0] 15.75[400]
KTT-12DS 16[406] 17[432] 20.5[521] 13.75[349] 7[178] 7.75[197] 19.1[486] 9[229] 16.25[413] 10.88[276] 39.5[1003] 2.38[60] 4.88[124] 33.1[841] 0[0] 15.75[400]
KTT-20DS 21[533] 18[457] 26.5[673] 23.5[597] 1.5[38] 6.25[159] 24.1[613] 15.25[387] 15.75[400] 10.5[267] 40.5[1029] 7.5[191] 11.12[283] 42.4[1076] 1.5[38] 26[660]
