PARTS LIST - SELF-GENERATING STEAM JACKETED TILTING KETTLE, MODEL: KTT-20E
PART NUMBER 10035R3 1 2006-10-26
PARTS LIST
SELF-GENERATING STEAM JACKETED TILTING KETTLE
MODEL: KTT-20E
October 26, 2006

PARTS LIST - SELF-GENERATING STEAM JACKETED TILTING KETTLE, MODEL: KTT-20E
PART NUMBER 10035R3 2 2006-10-26

PARTS LIST - SELF-GENERATING STEAM JACKETED TILTING KETTLE, MODEL: KTT-20E
PART NUMBER 10035R3 3 2006-10-26
ITEM Part # DESCRIPTION QUANTITY
1 40613 Relief Valve 50 PSI 1
* 41044 Down Tube 1
2 40548 Air Vent Assembly 1
3 40259 Phenolic Knob 1
4 42795 Handle 1
5 40352 Console Cover 1
6 40473 Console Cover Gasket 1
7 42948 Acorn Nut ½ - 13 NC 1
8 40930 Probe 1
9 40205 Thermostat Probe Fitting 1
10 41754 Inner Bearing 1
11 41803 Set Screw 3/8 - 16 x ½” 2
12 40372 Actuating Collar 1
13 41897 Hex Socket Set Screw 3/8 - 16 x ½” 1
* 43298 Spring Pin 1/4 x 2-1/4" LG 1
14 41307 Cam Collar 1
15 41753 Outer Bearing 1
16 40938 Interlock Switch 1

PARTS LIST - SELF-GENERATING STEAM JACKETED TILTING KETTLE, MODEL: KTT-20E
PART NUMBER 10035R3 4 2006-10-26
ITEM Part # DESCRIPTION QUANTITY
17 41619 Element Gasket 1
** 18 41367 Element Assembly, 208V, 12 kW 1
41368 Element Assembly, 220/380V, 12 kW 1
41369 Element Assembly, 240/415V, 12 kW 1
41370 Element Assembly, 480V, 12 kW 1
42221 Element Assembly, 600V, 12 kW 1
19 42886 Trunnion Box Cover 1
20 40840 Ground Lug 1
21 43294 Hex Bolt 5/16-18 x 3/4" 4
** 22 40943 Contactor (208, 240V) 2
40943 Contactor (380, 416, 480, 600V) 1
23 40707 Terminal Block End Section 1
24 40708 Terminal Block 3
25 42176 Component Mounting Plate 1
26 40928 Liquid Level Control 1
27 41474 Flanged Adjustable Feet 4
28 40134 External Ring 1
29 43297 Washer 2
30 40808 Spring 1
31 40138 “O” Ring 1
32 40803 Locking Pin 1
33 43322 Base Assembly 1
34 42113 Control Decal 1
35 41887 Thermostat 1

PARTS LIST - SELF-GENERATING STEAM JACKETED TILTING KETTLE, MODEL: KTT-20E
PART NUMBER 10035R3 5 2006-10-26
ITEM Part # DESCRIPTION QUANTITY
36 40994 Bezel 1
37 41006 Dial 1
38 40095 Bolt 1
39 41565 Bottom Cover 1
40 49053 Pilot Light 1
41 40953 Pilot Light 1
42 41883 Power Switch 1
43 40076 Screw 10-32 x 1/2 3
44 42692 Pressure Gauge 1
45 41609 Pressure Gauge Mounting Bracket 1
46 40415 Connector 1/4" C x 1/4" FP 1
* 47 41622 Copper Tube Pressure Gauge 1
* 48 40425 Pressure Gauge Kettle Fitting 1
* 49 43323 Bearing Retainer 2
** 50 40974 Transformer 380V 1
40974 Transformer 416V 1
40980 Transformer 480V 1
40985 Transformer 600V 1
** 51 43324 Fuse 600V 3A 380, 416, 480, 600V 1
43325 Fuse Holder 380, 416, 480, 600V 1
* 52 40682 Wire Harness 1
*
**
