BC-14E AND BC-142E
Single or Double
Combination-Oven/Steamer
Project
Item No.
Quantity
All data is shown per oven section, unless otherwise indicated.
Refer to operator manual specification chart for listed model names.
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Legs
4" (101.6mm) adjustable legs
6" (152.4mm) adjustable legs
6" (152.4mm) seismic legs
25" (635mm) adjustable legs
Voltage options
480VAC 3 phase
380/220VAC 3 phase
415/240VAC 3 phase
400/230VAC 3 phase
Floor stand with rack supports
Stand Mount Casters
Semi-Automatic Deliming pump that installs directly
to the back of the unit with delivery hose and delim-
ing container
Programmable digital controls with cook and hold
and Vario Steam®
Locking control panel
Locking door hasp
Tamper proof screws
Additional stainless steel wire shelves
Core temperature probe with digital readout
Stainless steel back panel
Chicken roasting rack
Hot water/filtered water connection kit
Extended warranty
EXTERIOR CONSTRUCTION
Stainless steel top, front, sides and right hand door hinge
Single pane tempered viewing window
Door mounted condensate trough
Well protected control panel
Side mount, easily adjustable door hinges
Roll out control panel exposes most serviceable parts
Modular controls allow for field upgrade to digital controls
INTERIOR CONSTRUCTION
Fully welded stainless steel frame
Fully insulated cooking chamber
Fixed drain bottom center of cavity
Filterless grease slinging convection fan
Easily removable stainless steel side rails
OPERATION
Standard control with four function selection switch for steam, hot air, com-
bined steam/hot air, cool down, Vario Steam® and steam on demand feature
Solid state rotary dial thermostat - range 150-500°F (66-260°C)
Motor driven 120 minute timer shuts down at elapsed time
Two speed fan
Magnetic door interlock switch shuts off oven when door is opened
Open vented system. Condenses steam and drains away by-products of the
cooking process, eliminates flavor transfer
Self contained, self-flushing steam generator separate from cooking compart-
ment for instant steam recovery when switching modes
Deliming light flashes when steam generator requires deliming
Deliming container with manual pump for storing and dispensing deliming solu-
tion. (See automatic deliming option)
CAPACITY
Fourteen 12" x 20" x 2-1/2" deep pans at 3-1/4" spacing
Seven 18" x 26" deep pans at 3-1/4" spacing
STANDARD FEATURES
Five (5) stainless steel wire shelves per section (capacity for 7)
Deliming bottle and pump assembly
Pressure spray bottle for oven cleaning
Hose and spray assembly for interior cleaning
Stacking kit and casters for double stack ovens
Two speed fan
Water pressure regulator (1 per section)
Drain kit assembly
Start-up inspection service by factory authorized service agent
One year parts and labor oven warranty*
* For all international markets, contact your local distributor.
BC-14E AND BC-142E

BLODGETT COMBI
www.blodgett.com
44 Lakeside Avenue, Burlington, VT 05401 • Phone: [phone] • Fax: [phone]
BC-14E AND BC-142E
SHORT FORM SPECIFICATIONS: Provide Blodgett Combi model BC-14E single or double, electric combination-oven/steamer. Unit shall have the ability to cook with pressureless
steam, hot air, or combination of steam and hot air. Mechanical mode switch shall allow the operator to choose four modes, steam, hot air, combi or cool down mode. Timer to be 120
minute motor driven. Temperature control to be solid state with rotary knob. Unit shall include two speed fan, steam on demand feature, deliming indicator light and Vario Steam® fea-
ture. The interior shall have the capability of being hosed down for cleaning. Door gaskets shall be easily removable for replacement and cleaning. Unit shall be open vented for waist air
quenching. Steam generator shall be separate from the cooking compartment in order to provide the fastest possible steam recovery. Steam generator shall flush automatically to cut
down on mineral build up. A start-up inspection service will be performed by our factory authorized agent at no cost to the operator.
POWER SUPPLY (per section):
60 Hz Domestic
208VAC 18.0KW 1 phase (87 amp) or 3 phase (50 amp)
240VAC 19.6KW 1 phase (82 amp) or 3 phase (43 amp)
480VAC 18.0KW 3 phase (22 amp)
50 Hz International
380/220VAC 16.5KW 3 phase (25 amp)
415/240VAC 19.6KW 3 phase (27 amp)
400/230VAC 18.0KW 3 phase (26 amp)
WATER SUPPLY (per section):
TDS: < 100 ppm Hardness: 80-120 ppm pH: 7.0 - 8.0
Chlorides: < 30 ppm 40(min)-50(max) PSI 122°F (50°C) avg. drain temp.
2" drain connection 3/4" hose cold water (Hot or filtered water
optional, order part #R9604)
SHIPPING INFORMATION:
Approx. Weight:
Single section 680 lbs. (309 kg)
Double section 1370 lbs. (619 kg)
Stand w/guides 141 lbs. (64 kg)
Crate sizes (per section):
53" H x 45" W x 42" D (1346.2 x 1143 x 1066.8mm)
Printed in U.S.A. NOTE: FOR COMMERCIAL USE ONLY
NOTE: The company reserves the right to make substitutions of
components without prior notice
P/N R9640 Rev K (5/06)
DIMENSIONS:
Floor space: 34-5/8" D x 40-1/8" (879.4 x 1019mm)
Unit Height: 33" (838mm) per section
Additional Height:
4" adjustable legs 4-7/8" - 6" (123.8-152.4mm)
6" adjustable legs 6-7/8" - 8" (174.6-203.2mm)
6" adjustable seismic legs 6-5/8" - 8" (168.3-203.2mm)
25" adjustable legs 25-1/4" - 26-3/8" (641.4-670mm)
Low profile caster 4" (101.6mm)
Stand w/rack supports 22-1/2" - 23-5/8" (571.5-600.1mm)
Stand w/rack supports on casters 22-5/8" (574.7mm)
OVEN CLEARANCES:
Right Side 1" (26mm)
Rear 6" (152.4mm)
Left Side (with casters) 4" (101.6mm)
Left Side (without casters) 12" (304.9mm)
MINIMUM ENTRY CLEARANCE:
Uncrated 33" (838mm)
Crated 42" (1066.8mm)
