Blomberg TKF 8451 A 50 User manual

TKF 8451 A 50
TKF 8451 G 50
TKF 8451 AG 50
TKF 8451 SGC 50
TKF 8451 RGC 50
Dryer
Kuivaaja

2960310441_EN/011111.1525
This appliance’s packaging material is recyclable. Help recycle it and protect the environment
by dropping it off in the municipal receptacles provided for this purpose. Your appliance
also contains a great amount of recyclable material. It is marked with this label to indicate
the used appliances that should not be mixed with other waste. This way, the appliance
recycling organised by your manufacturer will be done under the best possible conditions,
in compliance with European Directive 2002/96/EC on Waste Electrical and Electronic
Equipment. Contact your town hall or your retailer for the used appliance collection points
closest to your home. We thank you doing your part to protect the environment.
Please read this user manual first!
Dear Customer,
We hope that you get the best results from the product which has been manufactured
in state-of-the-art plants and passed through a strict quality control procedure.
Therefore, please read the entire user manual carefully before using the product and
keep it as a reference for future use. In case of transferring the product to someone
else, give the manual as well.
The user manual will help you use your product in a fast
and safe way.
• Read the user manual before installing and starting your product.
• Always follow the safety instructions.
• Keep this user manual within easy reach for future reference.
• Read also the other documents supplied with the product.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
Read the instructions.
CImportant information or useful hints about usage.
AWarning for hazardous situations with regard to life and property.
BWarning for electric shock.
Warning for fire hazard.
Warning for hot surfaces.

3EN
1 Important safety instructions
This section contains safety instructions
that will help protect from risk of personal
injury or property damage. Failure to
follow these instructions shall void any
warranty.
General safety
• Never place the product on a carpet-
covered floor; otherwise, lack of
airflow beneath the machine will
cause electrical parts to overheat.
This will cause problems with your
product.
• Do not operate the product if the
power cable / plug is damaged. Call
the Authorized Service Agent.
• Do not make any changes on the
plug supplied with the product. If it is
not compatible with the socket, have
a qualified electrician change the
socket with a suitable one.
• Never touch the plug with wet hands!
Never unplug by pulling on the cable,
always pull out by grabbing the plug.
• Connect the product to a grounded
outlet protected by a fuse of suitable
capacity as stated in the technical
specifications table.
• Power cable of this product is
equipped with a conductor and
a grounding plug that allows for
grounding the product. This plug
must be inserted into a socket
which is installed and grounded in
accordance with the local laws and
regulations. Grounding installation
decreases the risk of electric shock
by opening a path with low resistance
for the electricity flow in case of a
malfunction or failure. Do not neglect
to have the grounding installation
made by a qualified electrician.
If you have any suspect about
the grounding installation, have it
checked by a qualified electrician or
the Authorized Service Agent. Our
company shall not be liable for any
damages that will arise when the
product is used without grounding in
accordance with the local regulations.
• The product should not be plugged
in during installation, maintenance,
cleaning and repair works.
• Always have the installation and
repairing procedures carried out
by the Authorized Service Agent.
Manufacturer shall not be held
liable for damages that may arise
from procedures carried out by
unauthorized persons.
• Do not use electrical devices in the
product.
• Do not connect the air exit of the
product to the chimney holes which
are used for the exhaust fumes of the
devices operating with gas or other
types of fuel.
• You must provide enough ventilation
in order to prevent gases exiting from
devices operating with other types of
fuels including the naked flame from
accumulating in the room due to the
back fire effect.
• Items cleaned or washed with
gasoil/fuel oil, dry-laundry solvents
and other combustible or explosive
materials as well as the items that are
contaminated or spotted with such
materials should not be dried in the
product since they emit flammable or
explosive vapor.
• Do not dry the laundry cleaned with
industrial chemicals in the dryer.
• Underwear that contains metal
reinforcements should not be dried in
the dryer. Dryer can get damaged if
metal reinforcements come loose and

4EN
break off during drying.
• Never attempt to repair the product
yourself. Do not perform any
repair or replacement procedures
on the product even if you know
or have the ability to perform the
required procedure unless it is
clearly suggested in the operating
instructions or the published service
manual. Otherwise, you will be
putting your life and others' lives in
danger.
• For failures that you cannot remedy
by applying the procedures in safety
instructions, turn off and unplug
the product and call the Authorized
Service Agent.
• Do not reach into the machine when
the drum is spinning.
• Do not use extension cords, multi-
plugs or adaptors to connect the
dryer to power supply in order to
decrease the risk of fire and electric
shock.
• Never wash the product by spreading
or pouring water onto it! There is the
risk of electric shock!
The final step of the drying
programme, namely the cool-down
step is performed without applying
heat to ensure that the laundry items
are kept at a temperature that will
not damage them. If you open the
loading door before the cool-down
step completes, hot vapour will come
out.
ANever stop the dryer before the
programme completes. If you must
do this, remove all laundry quickly
and lay them out to a suitable place
to dissipate the heat.
• Always clean the lint filter before or
after each loading. Never operate the
dryer without the lint filter installed.
• Clean inside and exhaust duct of the
product regularly. Do not allow fibre,
dust and dirt accumulation around
the exhaust exit and at adjacent
areas.
• Power cable plug must be within easy
reach after installation.
• Do not dry unwashed items in the
dryer.
• Items soiled with cooking oils,
acetone, alcohol, fuel oil, kerosene,
stain removers, turpentine, paraffin
and paraffin removers must be
washed in hot water with plenty of
detergent before being dried in the
dryer.
• Garments or pillows bolstered with
rubber foam (latex foam), shower
bonnets, water resistant textiles,
materials with rubber reinforcement
and rubber foam pads should not be
dried in the dryer.
• Do not use fabric softeners and
anti-static products unless they are
recommended by the manufacturers
of the relevant product.
• Use softeners, anti-static products
and etc. in accordance with the
instructions of their manufacturers.
• Do not install the product behind a
door with a lock, sliding door or a
hinged door which can strike the
product.
• Do not install or leave the dryer in
places where it will be exposed to
outdoor conditions.
• Your product can be operated at
temperatures between +5°C and
+35°C. If the operating conditions fall
outside of this range, operation of the
product will be adversely affected and
it can get damaged.
• Do not tamper with the controls.
• Unplug the product when it is not in
use.
• Remove the loading door of

5EN
the drying compartment before
decommissioning or disposing of the
product.
• Check all garments before loading
and make sure that there is no any
lighters, coins, metal pieces, needles,
and etc. in their pockets or on them.
• Make sure that the pets do not enter
into the product. Check the drum of
the product before using it.
• Make sure that original spare parts
and accessories are used during
maintenance works.
• Do not lean on the loading door when
it is open. The product may tip over.
• When your machine is not in use
or when you unload the laundry
after completion of drying process,
turn the machine off with the On/
Off button. In cases where the On/
Off button is in On position (while
the machine is energized), keep the
loading door closed.
Intended use
• This product has been designed for
domestic use. It should not be used
for other purposes.
• Product must only be used for
drying of textiles that are marked
accordingly.
• Dry only those articles in your product
that are stated in this manual.
• This product is not intended to be
used by persons with physical,
sensory or mental disorders or
unlearned or inexperienced people
(including children) unless they are
attended by a person who will be
responsible for their safety or who will
instruct them accordingly for use of
the product.
Children's safety
• Electrical products are dangerous for
the children. Keep children away from
the product when it is operating. Do
not let them tamper with the product.
• Do not allow children sit/climb on or
enter in the product.
• Do not forget to close the loading
door when leaving the room where
the product is located.
• Packaging materials are dangerous
to children. Keep the packaging
materials out of reach of children or
dispose them by classifying according
to waste directives.

6EN
2 Installation
Refer to the nearest Authorized Service
Agent for installation of the product.
To make the product ready for use,
make sure that the electricity and water
drainage system are appropriate before
calling the Authorized Service Agent. If
they are not, call a qualified technician
and plumber to have any necessary
arrangements carried out.
C Preparation of the product's
location as well as the electrical and
waste water installations is under
customer's responsibility.
BInstallation and electrical connections
of the product must be carried out
by the Authorized Service Agent.
Manufacturer shall not be held
liable for damages that may arise
from procedures carried out by
unauthorized persons.
A Prior to installation, visually check if
the product has any defects on it. If
so, do not have it installed. Damaged
products cause risks for your safety.
A
Let your dryer wait for 12 hours
before starting to use it.
Appropriate installation
location
• Install the product on a stable and
level surface.
• Dryer is heavy. Do not move it by
yourself.
• Operate your product in a well
ventilated, dust-free environment.
• Do not block the air ducts in front of
and under the product with materials
such as long pile rugs, wooden
blocks and bands.
• Do not install the product behind a
door with a lock, sliding door or a
hinged door which can strike the
product.
• Once the product is installed, it
should stay at the same place where
its connections have been made.
When installing the product, make
sure that the rear wall of it does
not touch anywhere (tap, socket,
etc.). Also pay attention to select an
installation location which you will not
be required to change afterwards.
• Place the product at least 1.5
cm away from the edges of other
furniture.
BDo not place the product on the
power cable.
Removing the transportation
safety assembly
A
Remove the transportation safety
assembly before using the product for
the first time.
1. Open the loading door.
2. There is a nylon bag inside the drum
that contains a piece of styrofoam.
Hold it from its section marked with
XX XX.
3. Pull the nylon towards yourself and
remove the transportation safety
assembly.
A
Make sure that no part of the
transportation safety assembly
remains inside the drum.
Under counter installation
• This product can be installed under a
counter if the height of the counter is
sufficient.

7EN
A
While using undercounter dryer, it
should never be operated without
undercounter installation part.
Dryer Depth 60 cm 54 cm
Stock
number of
under-bench
installation
part
2979600100 2973600100
• Leave at least 3 cm of space around
the sides and the rear wall of the
product when installing it under a
counter or in a cupboard.
Mounting over a washing
machine
• A fixing device should be used
between the two machines
when installing the dryer above a
washing machine. The fixing device
(2977200100 white/2977200400
grey) must be installed by the
Authorized Service Agent.
• Total weight of the washing machine
and the dryer -with full load- when
they are placed on top of each other
reaches to approx. 180 kilograms.
Place the products on a solid floor
that has sufficient load carrying
capacity!
Connecting to the drain
In products equipped with condenser
unit, water accumulates in the water tank
during the drying cycle. You should drain
accumulated water after each drying
cycle.
You can directly drain accumulated water
through the water drain hose supplied
with the product instead of periodically
draining the water collected in the water
tank.
Connecting the water drain hose
1. Pull hose in the product by hand in
order to disconnect it from where it is
connected. Do not use any tools to
remove the hose.
2. Connect one end of the drain hose
supplied separately with the product
to the connection point from where
you removed the hose of the product
in previous step.
3. Connect the other end of the drain
hose directly to the wastewater drain
or to the washbasin.
A
Hose must be fixed in every type
of connection. Your house will be
flooded if the hose comes loose
during water discharge.
CWater drain hose should be attached

8EN
to a height of maximum 80 cm.
CMake sure that the water drain hose
is not stepped on and it is not folded
between the drain and the machine.
Adjusting the feet
In order to ensure that the product
operates more silently and vibration-free,
it must stand level and balanced on its
feet. Balance the machine by adjusting
the feet.
Turn the feet to left or right until the
machine stands level and firmly.
CNever remove the adjustable feet
from their housings.
Electrical connection
Connect the product to a grounded outlet
protected by a fuse complying with the
values in the "Technical specifications"
table. Our company shall not be liable
for any damages that will arise when the
product is used without grounding in
accordance with the local regulations.
• Connection must comply with
national regulations.
• Power cable plug must be within easy
reach after installation.
• The voltage and allowed fuse or
breaker protection are specified in
the “Technical specifications” section.
If the current value of the fuse or
breaker in the house is less than 10
Amps, have a qualified electrician
install a 10 Amp fuse.
• The specified voltage must be equal
to your mains voltage.
• Do not make connections via
extension cables or multi-plugs.
• The main fuse and switches must
have a contact distance of minimum
3 mm.
BDamaged power cable must be
replaced by the Authorized Service
Agent.
BIf the product is faulty, it must not be
operated unless it is repaired! There is
the risk of electric shock!
First use
Before starting to use the product, make
sure that all preparations are made in
accordance with the instructions in
sections "Important safety instructions"
and "Installation".
Disposing of packaging
material
Packaging materials are dangerous to
children. Keep packaging materials in
a safe place away from reach of the
children.
Packaging materials of the product are
manufactured from recyclable materials.
Dispose of them properly and sort
in accordance with recycled waste
instructions. Do not dispose of them with
normal domestic waste.
Transportation of the product
1. Unplug the product before
transporting it.
2. Remove the water drain (if any) and
chimney connections.
3. Drain the water in the product
completely.
AWe recommend carrying the product
in upright position. If it is not possible
to carry the machine in the upright
position, we recommend carrying
it by tilting towards the right side
when looked from the front. After the
product is moved to its new place,
you should wait for 12 hours before
starting it.

9EN
Disposing of the old product
Dispose of the old product in an
environmentally friendly manner.
Refer to your local dealer or solid waste
collection centre in your area to learn how
to dispose of your product.
For children's safety, cut the power
cable and break the locking mechanism
of the loading door so that it will be
nonfunctional before disposing of the
product.
Warnings about sounds
C
It is normal to hear metallic noise from
the compressor sometimes during
operation.
C
Water collected during operation is
pumped to water tank. It is normal
to hear pumping noise during this
process.

10 EN
EN 2
Height (adjustable) 84,6 cm
Width 59,5 cm
Depth 59,8 cm
Capacity (max.) 8 kg
Net weight (plastic front door usage) 52 kg
Net weight (glass front door usage) 54,5 kg
Voltage
See type labelRated power input
Model code
Type label is located behind the loading door.
Technical specifications

11 EN
3 Preparations for drying
Things to be done for energy
saving
Following information will help you use
the product in an ecological and energy-
efficient manner.
• Operate the product at a capacity
suitable for the program you have
selected and pay attention not to
overload.
• Spin your laundry at the highest
speed possible when washing them.
Thus, the drying time is shortened
and energy consumption is reduced.
• Dry the same type of laundry
together.
• Follow the instructions in the user
manual for programme selection.
• Leave sufficient clearance at the
front and rear side of the dryer for
air circulation. Do not block the
ventilation grills at the front side of the
product.
• Do not open the loading door of
the machine during drying unless
necessary. If you must certainly open
the loading door, do not to keep it
open for a long time.
• Do not add new (wet) laundry during
drying.
• Lint and fibres released from the
laundry to the air during the drying
cycle are collected in the Lint Filter.
Clean the lint filter before or after each
drying cycle.
• Clean the filter drawer regularly either
when the Filter Drawer Cleaning
warning symbol appears or after
every 5 drying cycles
• Ventilate the room, where the dryer is
located, well during drying.
• For models with lamp, keep the door
closed if the On/Off button is pressed
(if the machine is energized) when
machine is not in use.
Laundry suitable for drying in
the machine
C Always obey the instructions given
on the garment tags. Dry only the
laundry having a label stating that
they are suitable for drying in a dryer
and make sure that you select the
appropriate programme.
A B C
l mn
o p q
D
Laundry unsuitable for drying
in the machine
• Laundry and items stated below are
not suitable for drying in a dryer:
• Laundry items with metal
attachments such as metal buttons,
metal reinforcements or belt buckles.
• Woolen or silk garments, nylon
stockings, delicate embroidered
fabrics and sleeping bags.
• Garments made of delicate and
valuable fabrics.
• Tulle curtains.
• Items made of hermetic fibres such
as pillows and quilts.
• Very wet laundry items.
• Unwashed dirty laundry items.
• Laundry items containing rubber
foam or rubber.

12 EN
Items cleaned, washed or spotted
with gasoil/fuel oil, dry-laundry
solvents, industrial chemicals or other
combustible or explosive materials
should not be dried in the dryer.
Items soiled with cooking oils,
acetone, alcohol, fuel oil, kerosene,
stain removers, turpentine, paraffin
and paraffin removers must be
washed in hot water with plenty of
detergent before being dried in the
dryer.
Preparing laundry for drying
• Check all garments before loading
and make sure that there is no any
lighters, coins, metal pieces, needles,
and etc. in their pockets or on them.
• Laundry may be tangled after
washing. Separate the laundry items
before placing them into the dryer.
• Sort the laundry according to their
types and thicknesses. Dry the same
type of laundry together. For instance,
thin kitchen towel and table cloths get
dry earlier than the thick bath towels.
CLaundry must be spun at the highest
spin speed that the washing machine
allows on basis of the fabric type.
Correct load capacity
Follow the instructions in the “Programme
selection and consumption table”. Do not
load more than the capacity values stated
in the table.
C
It is not recommended to load the
dryer with laundry exceeding the
level indicated in the figure. Drying
performance will degrade when the
machine is overloaded. Furthermore,
dryer and the laundry can get
damaged.
Following weights are given as examples.
Home articles Approximate
weights (g)
Cotton quit covers
(double) 1500
Cotton quit covers
(single) 1000
Bed sheets (double) 500
Bed sheets (single) 350
Large tablecloths 700
Small tablecloths 250
Tea napkins 100
Bath towels 700
Hand towels 350
Garments Approximate
weights (g)
Blouses 150
Cotton shirts 300
Shirts 200
Cotton dresses 500
Dresses 350
Jeans 700
Handkerchiefs (10
pieces) 100
T-Shirts 125

13 EN
Loading the laundry
1. Open the loading door.
2. Place the laundry in the machine
without compressing.
3. Push the loading door to close.
AEnsure that no items are caught in
the door.

14 EN
1
9 6
78
2 3 45
Spin speed / Timer programs*
Operation symbol
Pause symbol
Water Tank warning symbol
Filter cleaning warning symbol
Filter Drawer Cleaning warning symbol
Remaining Time indicator**
Child-proof Lock warning symbol
Time Delay mode
Loading door open warning symbol
Anti-creasing mode
Audio Warning Level / Cancel Audio Warning
Dryness Level
Anti-creasing is activated
* Spin speed is used to show the remaining time more accurately. It does not
affect the performance of your machine.
** Time that appears on display indicates the remaining time until the end of the
programme and changes according to the dampness level of the laundry.
4 Selecting a Programme and Operating Your Machine
Control panel
1. Washing Machine Spin Speed / Timer
Programme Selection button
2. Display
3. Start / Pause / Cancel button
4. Programme Selection knob
5. On / Off button
6. Anti-creasing button
7. Dryness Level button
8. Cancel Audio Warning button
9. Time Delay buttons

15 EN
Preparing the machine
1. Plug in the machine.
2. Place the laundry in the machine.
3. Press the On / Off button.
C Pressing the On / Off button does
not necessarily mean that the
programme has started. Press Start
/ Pause / Cancel button to start the
programme.
Programme selection
1. Decide the appropriate programme
from the table below which includes
drying levels.
2. Select the desired programme with
the Programme Selection knob.
Extra Dry
Only the cotton laundry
is dried at normal
temperature. Thick and
multi layered laundry
(towels, linens, jeans and
etc.) are dried in a way that
they do not require ironing
before being placed in the
wardrobe.
Cupboard
Dry
Normal laundry
(tablecloths, underwear
and etc.) are dried in a way
that they do not require
ironing before being placed
in the wardrobe.
Iron Dry
Normal laundry (shirts,
dresses and etc.) are dried
ready to be ironed.
CFor further programme details,
see “Programme selection and
consumption table”.
Main programmes
Depending on the fabric type, the
following main programmes are available:
• Cottons
Dry durable laundry with this programme.
Dries at normal temperature. It is
recommended to use for your cotton
items (bed sheets, quilt covers, towels,
bathrobes, etc.).
• Synthetics
Dry less durable laundry with this
programme. Recommended for
synthetics.
Additional programmes
For special cases, following additional
programmes are available in the machine.
C
Additional programs may differ
according to the features of your
machine.
• Bedding
Dry only fibre quilts with machine-dryable
label. Make sure you are loading the quilt
in the correct way to avoid damages on
the machine and the quilt. Take out the
quilt cover before loading the quilt in the
machine. Fold the quilt in two before
loading.
- Do not load more than 1 double-size
fibre quilt (200x200 cm). Do not dry items
containing cotton such as quilts, pillows
Timer
programs
Cottons Synthetics Bedding Ventilation Anti
Creasing Iron
Dry
Extra
Dry
Cupboard
dry
Dryness
Level
Buzzer/
cancel
On/Off Start
pause
Shirt 30' Child-proof
lock
Jeans Shirt Reset 3''
Viscose Lingerie
Sport Spin Mixed Wool
Refresh
Wool Drying
Rack
Timer
Delay

16 EN
and etc.
-Do not dry items other than quilts such
as carpets, rugs or mats. Permanent
damage may arise in your machine.
C
To obtain better results from your
dryer, your laundry must be washed
at suitable programmes and spun at
the recommended spin speeds in the
washing machine.
• Shirt
This programme dries the shirts more
sensitively and creases them less and
thus, helps to iron them more easily.
CThere may be a little moisture on the
shirts at the end of the programme.
We recommend you not to leave the
shirts in the dryer.
• Jeans
Use this programme to dry your jeans
that are spun at high speeds in the
washing machine.
• Mixed
Use this programme to dry non-
pigmenting synthetic and cotton laundry
items together.
• Sport
Use this programme to dry together the
synthetic and cotton laundry items and
the laundry items made of mixed fabrics.
• Wool refresh
Use this programme to ventilate and
soften the woolen laundry that can be
washed in the washing machine. Do not
use to dry the laundry completely. Take
out and ventilate the laundry immediately
after the programme is over.
• Shirt 30’
Use this programme to make 2 shirts
ready for ironing in 30 minutes.
• Lingerie
Use this programme to dry 100%
synthetic and synthetic blended satin
underwear (nightgown, brassiere,
underpants, pyjamas) that bear the
“machine-dryable” mark on its garment
tag.
CLevel of dryness may change
depending on the blend of the
garment, type of knitting and
dampness level.
CGarments that contain accessories
such as lace, tulle, gems, beads,
scales, wire and etc., and garments
with high silk content should not be
dried in the machine.
C Silk garments that contain cotton or
has a satin appearance may remain
wet when they are dried with this
programme.
• Viscose
Use this programme to dry viscon and
modal mixed laundry. Viscose-polyester,
viscose-cotton blended products can be
dried.
CLevel of dryness may change
depending on the blend of the
garment, type of knitting and
dampness level.
CIt is not recommended to dry
garments and evening gowns that
contain accessories such as lace,
tulle, gems, and etc..
• Ventilation
Only ventilation is performed for 10
minutes without blowing hot air. You can
air the clothes that have been kept at
closed environments for a long time and
deodourise unpleasant odours thanks to
this programme.
• Timer programmes
You can select one of the 10 min., 20
min., 30 min., 40 min., 50 min., 60 min.,
80 min., 100 min., 120 min., 140 min.
and 160 min. timer programmes to
achieve the desired final drying level at
low temperatures.

17 EN
CWith this programme, the machine
dries for the time selected regardless
of the dryness level.

18 EN
Programme selection and consumption table
* : Energy Label standard programme (EN 61121:2005)
All values given in the table have been fixed according to EN 61121:2005 Standard.
These values may deviate from the values in the table according to the laundry type,
laundry spin speed, environmental conditions and voltage fluctuations.
EN 2
Programs Capacity (kg) Spin speed in
Approximate
amount of
remaining
humidity
Drying time
(minutes)
Cottons / Coloreds
AExtra dry 8 1000 % 60 160
ACupboard dry 8 1000 % 60 145
AIron dry 8 1000 % 60 115
Shirt 30’ 0.5 1200 % 60 30
Shirt 1.5 1200 %50 40
Jeans 4 1200 %50 100
Bedding 2.5 1000 %40 120
Mixed 4 1000 %60 95
Sport 4 1000 %60 90
Viscose 1.5 600 %100 90
Lingerie 1 800 %40 40
Wool Refresh 1.5 600 %50 8
Synthetics
BCupboard dry 4 800 % 40 60
BIron dry 4 800 % 40 45
Energy consumption values
Programs Capacity (kg) Spin speed in
Approximate
amount of
remaining
humidity
Energy
consumption
value kWh
Cottons linen Ready to wear* 8 1000 % 60 1.92
Cottons Ready to iron 8 1000 % 60 1.50
Synthetics Ready to wear 4 800 % 40 0.75

19 EN
Auxiliary functions
Audio Warning
The machine will give an audio warning
when the programme comes to an end.
If you do not want the machine give an
audio warning, press the Volume Level
button repeatedly until “x” appears on the
display. Use the same button to adjust
the volume level.
C You can activate this function either
before or after the programme starts.
Cancel
audio warning
Audio warning
level 1
Audio warning
level 2
Audio warning
level 3
Dryness level
Used to adjust the required dryness level.
More drying is performed compared
to the default settings when “+” sign
appears and less drying is performed
when “-” sign appears. Programme
duration can change depending on the
selection.
C You can activate this function only
before the programme has started.
Anti-creasing
You can use Anti-creasing function to
prevent laundry from creasing if you will
not take the laundry out after the program
has come to an end. This program
rotates the laundry in every 240 second
for 2 hours to prevent creasing.
Anti-creasing is activated but the
programme is still running in the first
display image below. Drying cycle is
completed and the Anti-creasing step has
started in the second display image.
C Press Anti-creasing button to activate
this function.
Changing the contrast
Adjust the display contrast in order to
make the symbols on the display appear
clearer. It may particularly be necessary to
change the contrast setting of the display
when the dryer is installed over a washing
machine.
Press and hold the Spin Speed / Timer
Programme button for 3 seconds.
When the contrast is changed, all
symbols on the display will appear for
3 seconds in order to indicate that the
process is complete.
C Perform the same procedure to revert
back to the previous contrast setting.
Warning symbols
CWarning symbols may differ
according to the model of your
machine.
Lint filter cleaning
When the programme is completed, a
warning symbol will appear to remind that
the filter needs to be cleaned.
CIf the Filter Cleaning symbol flashes
continuously, refer to “Troubleshooting”
section.
Water tank
When the programme is completed, a
warning symbol will appear to remind that
the water tank needs to be drained.
If the water tank becomes full while
the programme is running, the warning
EN 2
Programs Capacity (kg) Spin speed in
Approximate
amount of
remaining
humidity
Drying time
(minutes)
Cottons / Coloreds
AExtra dry 8 1000 % 60 160
ACupboard dry 8 1000 % 60 145
AIron dry 8 1000 % 60 115
Shirt 30’ 0.5 1200 % 60 30
Shirt 1.5 1200 %50 40
Jeans 4 1200 %50 100
Bedding 2.5 1000 %40 120
Mixed 4 1000 %60 95
Sport 4 1000 %60 90
Viscose 1.5 600 %100 90
Lingerie 1 800 %40 40
Wool Refresh 1.5 600 %50 8
Synthetics
BCupboard dry 4 800 % 40 60
BIron dry 4 800 % 40 45
Energy consumption values
Programs Capacity (kg) Spin speed in
Approximate
amount of
remaining
humidity
Energy
consumption
value kWh
Cottons linen Ready to wear* 8 1000 % 60 1.92
Cottons Ready to iron 8 1000 % 60 1.50
Synthetics Ready to wear 4 800 % 40 0.75

20 EN
symbol will start to flash and machine will
pause. Drain the water in the water tank
and press Start / Pause / Cancel button
to resume the programme. The warning
symbol turns off and the programme
resumes operating.
Cleaning of filter drawer
Warning symbol flashes with certain
intervals to remind that the filter drawer
needs to be cleaned.
Loading door open
This warning symbol appears when the
loading door of the dryer is open.
Time Delay
Time Delay function allows you to delay
the startup of the programme up to 24
hours.
1. Open the loading door and put the
laundry in.
2. Select the drying programme, spin
speed and, if required, the auxiliary
functions.
3. Press Time Delay buttons + and - to
set the desired time delay. The Time
Delay symbol will flash.
4. Press Start / Pause / Cancel button.
The Time Delay starts to count down.
The Time Delay symbol lights up.
Start symbol appears. The “:” in the
middle of the displayed delay time will
start flashing.
C Additional laundry may be loaded
/ taken out during the Time Delay
period. At the end of the Time Delay
countdown process, Time Delay
symbol disappears, drying process
starts and the programme duration
is displayed. The time on the display
is the total of normal drying time and
delay time.
Time Delay is activated by pressing the
Start / Pause / Cancel button in the
above display image.
Changing the delay time
If you want to change the time during
countdown:
1. Press Start / Pause / Cancel
button for 3 seconds to cancel the
programme. Repeat the Time Delay
procedure for the desired time.
2. Set the desired delay time with Time
Delay + and - buttons. The Time
Delay symbol will flash.
3. Press Start / Pause / Cancel button.
The Time Delay starts to count down.
The Time Delay symbol lights up.
Pause symbol disappears. Start
symbol appears.
4. The “:” in the middle of the displayed
delay time will start flashing.
Cancelling the Time Delay
If you want to cancel the Time Delay
countdown and start the programme
immediately:
1. Press Start / Pause / Cancel
button for 3 seconds to cancel the
programme.
2. Press Start / Pause / Cancel button
to start the programme you have
previously selected.
