Blomberg FNT 9683 N User manual

FNT 9683 N - FNT 9683 XN - FNT 9685 N - FNT 9685 XN
Refrigerator
User Manual
Køleskab
Brugervejledning
Kylskåp
Bruksanvisning
Kjøleskap
Bruksanvisning
58 4612 0000/AC
1/2
EN / DA / SV / NO

Please read this user manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and
checked under the most meticulous quality control procedures, will provide you
an effective service.
Therefore, read this entire user manual carefully before using the product and
keep it as a reference. If you handover the product to someone else, give the user
manual as well.
The user manual will help you use the product in a fast and safe way.
• Read the manual before installing and operating the product.
• Make sure you read the safety instructions.
• Keep the manual in an easily accessible place as you may need it later.
• Read the other documents given with the product.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.
A
A
A
C
SUPPLIER’S NAME MODEL IDENTIFIER (*)
INFORMATION
C
The model information as stored in the product data base
can be reached by entering following website and searching
for your model identifier (*) found on energy label.
https://eprel.ec.europa.eu/

EN
4
1 Your cooler/freezer 4
2 Important Safety Warnings 5
Intended use .....................................5
General safety ..................................5
For products with a water dispenser;.8
Child safety........................................8
Compliance with WEEE Directive and
Disposing of the Waste Product: .......8
Package information..........................9
HC warning .......................................9
Things to be done for energy saving ..9
3 Installation 10
Points to be paid attention to when the
relocation of the cooler/freezer.........10
Before you start the cooler/freezer, ..10
Electrical connection........................10
Disposing of the packaging .............11
Disposing of your old cooler/freezer.11
Placing and Installation ....................11
Adjusting the legs ............................12
Changing the door opening direction12
Door Open Warning.........................12
4 Preparation 13
5 Using your cooler/freezer 14
Icematic and ice storage container ..16
Dual cooling system: .......................17
Freezing fresh food ..........................17
Recommendations for preservation of
frozen food ......................................18
Freezing of Foodstuff .......................18
Defrosting........................................19
Placing the food ..............................19
Deep-freeze information ..................19
6 Maintenance and cleaning 20
Protection of plastic surfaces ..........20
7 Troubleshooting 21
CONTENTS

EN
5
C Figures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
1Your cooler/freezer
1. Control Panel
2. Flap (Fast-Freeze compartment)
3. Ice cube tray & Ice bank
4. Drawers
5. Adjustable front feet
1
3
4
5
2

EN
6
2Important Safety Warnings
Please review the following
information. Failure to observe
this information may cause
injuries or material damage.
Otherwise, all warranty and
reliability commitments will
become invalid.
The service life of your product
is 10 years. During this period,
original spare parts will be
available to operate the product
properly.
Intended use
A
WARNING:
Keep ventilation
openings, in the appliance
enclosure or in the built-
instructure, clear of
obstruction.
WARNING:
Do not use mechanical
devices or other means
to accelerate the
defrostingprocess, other
than those recommended
by the manufacturer.
WARNING:
Do not damage the
refrigerant circuit.
WARNING:
Do not use electrical
appliances inside the food
storage compartments
of the appliance, unless
they are of the type
recommended by the
manufacturer.
This appliance is intended to be
used in household and similar
applications such as
– staff kitchen areas in shops,
offices and other working
environments;
– farm houses and by clients
in hotels, motels and other
residential type environments;
– bed and breakfast type
environments;
– catering and similar non-retail
applications.
General safety
• When you want to dispose/
scrap the product, we
recommend you to consult the
authorized service in order to
learn the required information
and authorized bodies.
• Consult your authorized service
for all your questions and
problems related to the cooler/
freezer. Do not intervene or
let someone intervene to the
cooler/freezer without notifying
the authorised services.
• For products with a freezer
compartment; Do not eat
cone ice cream and ice
cubes immediately after you
take them out of the freezer
compartment! (This may cause
frostbite in your mouth.)
• For products with a freezer
compartment; Do not put
bottled and canned liquid
beverages in the freezer

EN
7
compartment. Otherwise,
these may burst.
• Do not touch frozen food by
hand; they may stick to your
hand.
• Unplug your cooler/freezer
before cleaning or defrosting.
• Vapor and vaporized cleaning
materials should never be
used in cleaning and defrosting
processes of your cooler/
freezer. In such cases, the
vapor may get in contact with
the electrical parts and cause
short circuit or electric shock.
• Never use the parts on your
cooler/freezer such as the door
as a means of support or step.
• Do not use electrical devices
inside the cooler/freezer.
• Do not damage the parts,
where the refrigerant is
circulating, with drilling or
cutting tools. The refrigerant
that might blow out when the
gas channels of the evaporator,
pipe extensions or surface
coatings are punctured causes
skin irritations and eye injuries.
• Do not cover or block the
ventilation holes on your cooler/
freezer with any material.
• Electrical devices must be
repaired by only authorised
persons. Repairs performed by
incompetent persons create a
risk for the user.
• In case of any failure or during
a maintenance or repair
work, disconnect your cooler/
freezer’s mains supply by either
turning off the relevant fuse or
unplugging your appliance.
• Do not pull by the cable when
pulling off the plug.
• Place the beverage with higher
proofs tightly closed and
vertically.
• Never store spray cans
containing flammable and
explosive substances in the
cooler/freezer.
• Do not use mechanical devices
or other means to accelerate
the defrosting process, other
than those recommended by
the manufacturer.
• This product is not intended
to be used by persons with
physical, sensory or mental
disorders or unlearned or
inexperienced people (including
children) unless they are
attended by a person who
will be responsible for their
safety or who will instruct them
accordingly for use of the
product
• Do not operate a damaged
cooler/freezer. Consult with the
service agent if you have any
concerns.
• Electrical safety of your cooler/
freezer shall be guaranteed
only if the earth system in
your house complies with
standards.
• Exposing the product to
rain, snow, sun and wind is
dangerous with respect to
electrical safety.

EN
8
• Contact authorized service
when there is a power cable
damage to avoid danger.
• Never plug the cooler/freezer
into the wall outlet during
installation. Otherwise, risk of
death or serious injury may
arise.
• This cooler/freezer is intended
for only storing food items. It
must not be used for any other
purpose.
• Label of technical specifications
is located on the left wall inside
the cooler/freezer.
• Never connect your cooler/
freezer to electricity-saving
systems; they may damage the
cooler/freezer.
• If there is a blue light on the
cooler/freezer, do not look at
the blue light with optical tools.
• For manually controlled cooler/
freezers, wait for at least 5
minutes to start the cooler/
freezer after power failure.
• This operation manual should
be handed in to the new owner
of the product when it is given
to others.
• Avoid causing damage on
power cable when transporting
the cooler/freezer. Bending
cable may cause fire. Never
place heavy objects on power
cable.
• Do not touch the plug with
wet hands when plugging the
product.
• Do not plug the cooler/freezer if
the wall outlet is loose.
• Water should not be sprayed
on inner or outer parts of the
product for safety purposes.
• Do not spray substances
containing inflammable gases
such as propane gas near the
cooler/freezer to avoid fire and
explosion risk.
• Never place containers filled
with water on top of the
cooler/freezer; in the event
of spillages, this may cause
electric shock or fire.
• Do not overload the cooler/
freezer with food. If overloaded,
the food items may fall down
and hurt you and damage
cooler/freezer when you open
the door.
• Never place objects on top of
the cooler/freezer; otherwise,
these objects may fall down
when you open or close the
cooler/freezer's door.
• As they require a precise
storage temperature, vaccines,
heat-sensitive medicine and
scientific materials and etc.
should not be kept in the
cooler/freezer.

EN
9
• If not to be used for a long
time, cooler/freezer should be
unplugged. A possible problem
in power cable may cause fire.
• Cooler/freezer may move if
adjustable legs are not properly
secured on the floor. Properly
securing adjustable legs on the
floor can prevent the cooler/
freezer to move.
• When carrying the cooler/
freezer, do not hold it from door
handle. Otherwise, it may be
snapped.
• When you have to place your
product next to another cooler/
freezer or freezer, the distance
between devices should be at
least 8cm. Otherwise, adjacent
side walls may be humidified.
• The product shall never be
used while the compartment
which is located at the top or
back of your product and in
which electronic boards are
available (electronic board box
cover) (1) is open.
1
1
For products with a water
dispenser;
Pressure of water mains should
be minimum 1 bar. Pressure
of water mains should be
maximum 8 bars.
• Use only potable water.
Child safety
• If the door has a lock, the key
should be kept away from
reach of children.
• Children must be supervised to
prevent them from tampering
with the product.
Compliance with WEEE
Directive and Disposing of
the Waste Product:
This product complies
with EU WEEE Directive
(2012/19/EU). This product
bears a classification
symbol for waste electrical
and electronic equipment
(WEEE).
This product has been manufactured
with high quality parts and materials
which can be reused and are suitable
for recycling. Therefore, do not dispose
the product with normal domestic
waste at the end of its service life. Take
it to a collection point for the recycling
of electrical and electronic equipment.
Please consult your local authorities
to learn the nearest collection point.
Help protect the environment and
natural resources by recycling used
products. For children’s safety, cut the

EN
10
power cable and break the locking
mechanism of the door, if any, so that it
will be non-functional before disposing
of the product.
Package information
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations. Do
not dispose of the packaging materials
together with the domestic or other
wastes. Take them to the packaging
material collection points designated
by the local authorities.
Do not forget...
Any recycled substance is an
indispensable matter for nature and our
national asset wealth.
If you want to contribute to the re-
evaluation of the packaging materials,
you can consult to your environmentalist
organizations or the municipalities
where you are located.
HC warning
If your product's cooling system
contains R600a:
This gas is flammable. Therefore, pay
attention to not damaging the cooling
system and piping during usage and
transportation. In the event of damage,
keep your product away from potential
fire sources that can cause the product
catch a fire and ventilate the room in
which the unit is placed.
Ignore this warning if your
product's cooling system contains
R134a.
Type of gas used in the product is
stated in the type label which is on the
left wall inside the refrigerator.
Never throw the product in fire for
disposal.
Things to be done for energy
saving
• Do not leave the doors of your
refrigerator open for a long time.
• Do not put hot food or drinks in your
refrigerator.
• Do not overload your refrigerator so
that the air circulation inside of it is not
prevented.
• Do not install your refrigerator
under direct sunlight or near heat
emitting appliances such as ovens,
dishwashers or radiators. Keep your
refrigerator at least 30cm away from
heat emitting sources and at least
5cm from electrical ovens.
• Pay attention to keep your food in
closed containers.
• For products with a freezer
compartment; You can store
maximum amount of food items in
the freezer when you remove the
shelf or drawer of the freezer. Energy
consumption value stated for your
refrigerator has been determined
by removing freezer shelf or drawer
and under maximum load. There
is no harm to use a shelf or drawer
according to the shapes and size of
food to be frozen.
• Thawing frozen food in fridge
compartment will both provide energy
saving and preserve the food quality.

EN
11
3Installation
BThe manufacturer will not be liable
for any event caused by disregarding
the information supplied in this user
manual.
Points to be paid attention
to when the relocation of the
cooler/freezer
1. Your cooler/freezer should be
unplugged.Before transportation
of your cooler/freezer, it should be
emptied and cleaned.
2. Before it is re-packaged, shelves,
accessories, crisper, etc. inside
your cooler/freezer should be fixed
with adhesive tape and secured
against impacts. Package should
be bound with a thick tape and the
transportation rules on the package
should be strictly observed.
3. Original packaging and foam
materials should be kept for future
transportations or moving.
Before you start the cooler/
freezer,
Check the following before you start
to use your cooler/freezer:
1. Attach 2plastic wedges as illustrated
below. Plastic wedges are intended
to keep the distance which will
ensure the air circulation between
your cooler/freezer and the wall.
(The picture is drawn up as a
representation and it is not identical
with your product.)
2. Clean the interior of the cooler/
freezer as recommended in the
“Maintenance and cleaning” section.
3. Connect the plug of the cooler/
freezer to the wall socket. When the
fridge door is opened, fridge internal
lamp will turn on.
4. When the compressor starts to
operate, a sound will be heard. The
liquid and gases sealed within the
refrigeration system may also give rise
to noise, even if the compressor is
not running and this is quite normal.
5. Front edges of the cooler/freezer
may feel warm. This is normal. These
areas are designed to be warm to
avoid condensation.
Electrical connection
Connect your product to a grounded
socket which is being protected by a
fuse with the appropriate capacity.
Important:
The connection must be in compliance
with national regulations.
• The power plug must be easily
accessible after installation.
• Electrical safety of your cooler/freezer
shall be guaranteed only if the earth
system in your house complies with
standards.

EN
12
• The voltage stated on the label
located at left inner side of your
product should be equal to your
network voltage.
• Extension cables and multi plugs
must not be used for connection.
BA damaged power cable must be
replaced by a qualified electrician.
BFaulty product must not be operated
before it is repaired! There is the risk
of electric shock!
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or dispose of them by
classifying them in accordance with the
waste instructions stated by your local
authorities. Do not throw away with
regular house waste, throw away on
packaging pick up spots designated by
the local authorities.
The packing of your cooler/freezer is
produced from recyclable materials.
Disposing of your old cooler/
freezer
Dispose of your old cooler/freezer
without giving any harm to the
environment.
• You may consult your authorized
dealer or waste collection center of
your municipality about the disposal
of your cooler/freezer.
Before disposing of your cooler/
freezer, cut out the electric plug and, if
there are any locks on the door, make
them inoperable in order to protect
children against any danger.
Placing and Installation
AIf the entrance door of the room
where the cooler/freezer will be installed
is not wide enough for the cooler/
freezer to pass through, then carefully
remove the doors of your cooler/freezer
and pass it sideways through the door.
1. Install your cooler/freezer to a place
that allows ease of use.
2. Keep your cooler/freezer away from
heat sources, humid places and
direct sunlight.
3. There must be appropriate air
ventilation around your cooler/
freezer in order to achieve an efficient
operation. If the cooler/freezer is to be
placed in a recess in the wall, there
must be at least 5 cm distance with
the ceiling and at least 5 cm with the
wall. Do not place your product on
the materials such as rug or carpet.
4. Place your cooler/freezer on an even
floor surface to prevent jolts.
WARNING:
Do not locate extension
sockets or charging transformers/
power supplies or Lithium-Iron battery
operated products adjacent to the
compressor as they could overheat.

EN
13
Adjusting the legs
If your cooler/freezer is unbalanced;
You can balance your cooler/freezer
by turning its front legs as illustrated
in the figure. The corner where the leg
exists is lowered when you turn in the
direction of black arrow and raised
when you turn in the opposite direction.
Taking help from someone to slightly
lift the cooler/freezer will facilitate this
process.
Changing the door opening
direction
Door opening direction of your
refrigerator can be changed according
to the place you are using it. If this is
necessary, please call your nearest
Authorized Service.
Door Open Warning
*May not be available in all models
An audio warning signal will be given
when the door of your product is left
open for at least 1 minute. This warning
will be muted when the door is closed
or any of the display buttons (if any) are
pressed.

EN
14
4Preparation
• For a freestanding appliance; ‘this
refrigerating appliance is not intended
to be used as a built-in appliance’ .
• Your cooler/freezer should be
installed at least 30 cm away from
heat sources such as hobs, ovens,
central heater and stoves and at least
5 cm away from electrical ovens and
should not be located under direct
sunlight.
• The ambient temperature of the room
where you install your cooler/freezer
should at least be -15°C. Operating
your cooler/freezer under cooler
conditions is not recommended with
regard to its efficiency.
• Please make sure that the interior
of your cooler/freezer is cleaned
thoroughly.
• If two cooler/freezers are to be
installed side by side, there should be
at least 2 cm distance between them.
• When you operate your cooler/freezer
for the first time, please observe the
following instructions during the initial
six hours.
• The door should not be opened
frequently.
• It must be operated empty without
any food in it.
• Do not unplug your cooler/freezer.
If a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for the
problems” section.
• Original packaging and foam
materials should be kept for future
transportations or moving.
• Due to temperature change as a
result of opening/closing the product
door during operation, condensation
on the door/body shelves and the
glass containers is normal.
• Since hot and humid air will not
directly penetrate into your product
when the doors are not opened,
your product will optimize itself in
conditions sufficient to protect your
food. Functions and components
such as compressor, fan, heater,
defrost, lighting, display and so on
will operate according to the needs
to consume minimum energy under
these circumstances.

EN
15
5Using your cooler/freezer
2
1
4
3
8
11
12
7
6
5
9
10
Indicator Panel
1. Quick Freeze Function:
Quick Freeze indicator turns on when
the Quick Freeze function is on. Press
QuickFreeze button again to cancel this
function. QuickFreeze indicator will turn
off and normal settings will be resumed.
QuickFreeze function will be cancelled
automatically 50 hours later if you do not
cancel it manually. If you want to freeze
plenty amount of fresh food, press
QuickFreeze button before you place
the food into the freezer compartment.
If you press the QuickFreeze button
repeatedly with short intervals, the
electronic circuit protection will be
activated and the compressor will not
start up immediately.
2. Quick Freeze Indicator
This icon flashes in an animated
style when the QuickFreeze function is
active.

EN
16
3. Freezer Set Function:
This function allows you to make
the freezer compartment temperature
setting. Press this button to set the
temperature of the freezer compartment
to -18, -20, -22 and -24 respectively.
4. Freezer Compartment
Temperature Setting Indicator
Indicates the temperature set for the
Freezer Compartment.
5. Eco-Fuzzy (Special Economic
Usage) Function:
Press Eco-Fuzzy button to activate the
Eco Fuzzy Function. Cooler/freezer
will
start operating in the most economic
mode at least 6 hours later if the door
is not opened and any buton is not
pressed.The
economic usage indicator will turn
on when the function is active. Press
Eco Fuzzy button again to activate the
Eco-Fuzzy function.
6. Eco-Fuzzy (Special Economic
Usage) Indicator:
This icon lights up when the Eco-
Fuzzy Function is active.
7. High Temperature/Error Warning
Indicator:
This light comes on during high
temperature failures and error warnings.
8. Economic Usage Indicator:
Economic Usage Indicator turns on
when the Freezer Compartment is set
to -18°C. It turns off when the qfreeze
function is on.
9.Energy Saving Function
Energy saving icon will light up and
energy saving function will be activated
automatically after 1 minute. If energy
saving function is active, all icons on
the display other than energy saving
icon will turn off. When the energy
saving function is active, if any button
is pressed or the door is opened,
Energy saving function will be exited for
a minute and the icons on display will
return to normal.
10.Energy Saving Indicator
This icon lights up when the Energy
Saving Function is selected
11.Key Lock Mode
Press Key Lock button concurrently
for 3 seconds. Key lock icon will light
up and key lock mode will be activated.
Buttons will not function if the Key Lock
mode is active.
Press Key Lock button
concurrently for 3 seconds again. Key
lock icon will turn off and the key lock
mode will be exited.
12.Key Lock Indicator
This icon light up when the Key Lock
mode is activated.

EN
17
Icematic and ice storage
container
*May not be available in all models
Using the Icematic
Fill the Icematic with water and place
it into its seat. Your ice will be ready
approximately in two hours. Do not
remove the Icematic from its seating to
take ice.
Turn the knobs on the ice reservoirs
clockwise by 90 degrees.
Ice cubes in the reservoirs will fall
down into the ice storage container
below.
You may take out the ice storage
container and serve the ice cubes.
If you wish, you may keep the ice
cubes in the ice storage container.
Ice storage container
Ice storage container is only intended
for accumulating the ice cubes. Do not
put water in it. Otherwise, it will break.

EN
18
How to Freeze Fresh Foods
• Foods to be frozen must be divided
into portions according to a size to
be consumed, and frozen in separate
packages. In this way, all the food
should be prevented from being re-
frozen by thawing.
• In order to protect the nutritional
value, the aroma and the color of
the foods as much as possible,
vegetables should be boiled for a
short period of time before freezing.
(Boiling is not necessary for foods
such as cucumber, parsley.) Cooking
time of the vegetables frozen in this
way is shortened by 1/3 than that of
the fresh vegetables.
• To extend the storage times of frozen
foods, boiled vegetables must first
be filtered and then hermetically
packaged as in the all types of foods.
• Foods should not be placed in
the freezer compartment without
package.
• The packaging material of the food
to be stored should be air-tight, thick
and durable and should not deform
with cold and humidity. Otherwise,
the food that is hardened by freezing
might pierce the package. Sealing
the package well is also important in
terms of securely storing the food.
The following packaging types are
suitable for use to freeze the food:
Polyethylene bag, aluminum foil,
plastic foil, vacuum bags and cold-
resistant storage containers with caps.
The use of the following types of
packaging is not recommended to
freeze the food;
Packaging paper, parchment paper,
cellophane (gelatin paper), garbage
bag, used bags and shopping bags.
• Hot foods should not be placed in the
freezer compartment without cooling.
• When placing unfrozen fresh foods in
the freezer compartment, please note
that it does not contact with frozen
foods. Cool-pack (PCM) can be
placed to the rack immediately below
the quick freezer rack for preventing
them from being getting warm.
• During the freezing time (24 hours) do
not place other food to the freezer.
• Place your foods to the freezing
shelves or racks by spreading them
so that they will not be cramped (it
is recommended that the packaging
does not come into contact with
each other).
• Frozen foods must be immediately
consumed in a short period of time
after defrosting and must never be
frozen again.
• Do not block the ventilation holes by
putting your frozen foods in front of
the ventilation holes located on the
back surface.
• We recommend you to attach a label
onto the package and write the name
of the foods in the package and the
freezing time.
Foods suitable for freezing:
• Fish and seafood, red and white
meat, poultry, vegetables, fruit,
herbaceous spices, dairy products
(such as cheese, butter and strained
yoghurt), pastries, ready or cooked
meals, potato dishes, souffle and
desserts.

EN
19
Foods not suitable for freezing:
• Yoghurt, sour milk, cream,
mayonnaise, leaved salad, red radish,
grapes, all fruits (such as apple, pears
and peaches).
• For foods to be frozen quickly and
thoroughly, the following specified
amounts per package should not be
exceeded.
-Fruits and vegetables, 0.5-1 kg
-Meat, 1-1.5 kg
• A small amount of foods (maximum
2 kg) can also be frozen without the
use of the quick freezing function.
To obtain the best result, apply the
following instructions:
1. Activate the quick freezing function
24 hours before placing your fresh
foods.
2. 24 hours after pressing the button,
firstly place your food that you want
to freeze to the third drawer from the
bottom with higher freezing capacity.
If you have food remained, place
them in front of the second drawer
from the bottom.
3. The quick freezing function will be
automatically inactivated after 50
hours.
4. Do not try to freeze a large quantity
of food at a time. Within 24 hours,
this product can freeze the maximum
food quantity specified as «Freezing
Capacity … kg/24 hours» on its type
label. It is not convenient to put more
unfrozen/fresh foods to the freezer
compartment than the quantity
specified on the label.
• You can review the Meat and Fish,
Vegetables and Fruits, Dairy Products
tables for placing and storing your
foods in the deep-freezer.
Recommendations for
Preservation of
Frozen Foods
• While purchasing your frozen foods,
make sure that they are frozen at
appropriate temperatures and their
packages are not broken.
• Put the packages on the freezer
compartment as soon as possible
after purchasing them.
• Make sure that the expiration
date indicated on the packaging
is not expired before consuming
the packaged ready meals that
you remove from the freezer
compartment.
Defrosting
The ice in the freezer compartments is
automatically thawed.
Deep Freezer Information
The EN 62552 standard requires
(according to specific measurement
conditions) that at least 4.5 kg of
food for each 100 liter of freezer
compartment volume can be frozen
at a room temperature of 25°C in 24
hours.
Defrosting the frozen foods
Depending on the food diversity and
the purpose of use, a selection can be
made between the following options for
defrosting:
• At room temperature (it is not very
suitable to defrost the food by leaving
it at room temperature for a long
time in terms of maintaining the food
quality)

EN
20
• In the refrigerator
• In the electrical oven (in models with
or without fan)
• In the microwave oven
CAUTION:
• Never put acidic beverages in glass
bottles and cans into your freezer due
to the risk of explosion.
• If there is moisture and abnormal
swelling in the packaging of frozen
foods, it is likely that they were
previously stored in an improper
storage condition and their contents
deteriorated. Do not consume these
foods without checking.
• Since some spices in cooked
meals may change their taste when
exposed to long-term storage
conditions, your frozen foods should
be less seasoned or the desired
spices should be added to the foods
after the thawing process.
Recommended Temperature Settings
Freezer
compartment setting
Remarks
-20 °C This is the default recommended temperature setting.
-21,-22,-23 or -24 oC These settings are recommended when the ambient
temperature is higher than 30°C or when you think the
refrigerator is not cool enough due to frequent opening
and closing of the door.
Quick Freezing Use when you want to freeze your food in a short time.
It is recommended to be applied to preserve the
quality of your fresh food. You do not need to use the
quick freezing function when putting your frozen food.
You do not need to use the quick freezing function to
freeze a small amount of fresh food, up to 2 kg per
day.

EN
21
Meat and Fish Preparation
Longest
storage
time
(month)
M e a t
products
Veal
Steak By cutting them 2 cm thick and placing foil between them or wrapping
tightly with stretch
6 – 8
Roast By packing the pieces of meat in a refrigerator bag or wrapping them
tightly with stretch
6 – 8
Cubes In small pieces 6 – 8
Schnitzel,
chops
By placing foil between cut slices or wrapping individually with stretch 6 – 8
Mutton
Chops By placing foil between meat pieces or wrapping individually with
stretch
4 - 8
Roast By packing the pieces of meat in a refrigerator bag or wrapping them
tightly with stretch
4 - 8
Cubes By packing the shredded meats in a refrigerator bag or wrapping them
tightly with stretch
4 - 8
Beef
Roast By packing the pieces of meat in a refrigerator bag or wrapping them
tightly with stretch
8-12
Steak By cutting them 2 cm thick and placing foil between them or wrapping
tightly with stretch
8-12
Cubes In small pieces 8-12
Boiled meat By packaging in small pieces in a refrigerator bag 8-12
Mince Without seasoning, in flat bags 1 - 3
Offal (piece) In pieces 1 - 3
Fermented sausage -
Salami
It should be packaged even if it has casing. 1-2
Jambon By placing foil between cut slices 2-3
Poultry
a n d
hunting
animals
Chicken and Turkey By wrapping in foil 4 – 6
Goose By wrapping in foil (portions should not exceed 2.5 kg) 4 – 6
Duck By wrapping in foil (portions should not exceed 2.5 kg) 4-6
Deer, Rabbit, Roe Deer By wrapping in foil (portions should not exceed 2.5 kg, and their bones
should be separated)
6 – 8
Fish
a n d
seafood
Freshwater fish (Trout,
Carp, Crane, Catfish)
After thoroughly cleaning the inside and scales, it should be washed
and dried, and the tail and head parts should be cut when necessary.
2
Lean fish (Sea bass,
Turbot, Sole)
4-6
Fatty fish (Bonito,
Mackerel, Bluefish, Red
Mullet, Anchovy)
2 - 4
Shellfish Cleaned and in bags 4 - 6
Caviar In its packaging, in an aluminum or plastic container 2 - 3
