Blomberg TSM1750u User manual

Fully Integrated Larder Fridge
User Manual
TSM1750u

Please read this manual first!
Dear Customer,
We hope that your product, which has been produced in a 1st-class
manufacturing facility and checked under the most meticulous quality control
procedures, will provide you with years of good service.
For this, we recommend you to carefully read the entire manual of your product
before using it and keep it at hand for future reference.
This manual
•Will help you use your appliance quickly and safely.
•Read the manual before installing and operating your product.
•Follow the instructions, especially those for safety.
•Keep the manual in an easily accessible place as you may need it later.
•Besides, read also the other documents provided with your product.
Please note that this manual may be valid for other models as well.
Symbols and their descriptions
This instruction manual contains the following symbols:
CImportant information or useful usage tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.

EN
2
1 Your Refrigerator 3
For models with water dispenser .......6
Electrical Requirements .....................6
Warning! This Appliance Must Be
Earthed .............................................7
Energy Saving Tips............................8
Compliance with WEEE Directive and
Disposing of the Waste Product: .......8
Compliance with RoHS Directive: ......9
Package information..........................9
3Installation 10
Points to be considered when re-
transporting your refrigerator ...........10
Before operating your refrigerator ....10
Electric connection ..........................10
Disposing of the packaging .............11
Disposing of your old refrigerator .....11
Placing and Installation ....................11
Important.........................................12
Installation Instructions ....................12
Changing the illumination lamp .......13
Placing the refrigerator under the
counter and adjusting the legs.........14
Reversing The Doors .......................15
Installation Instructions - Detailed Step
By Step ...........................................17
4 Before operating 23
5 Using your refrigerator 24
Temperature setting button..............24
Defrosting........................................24
6 Maintenance and cleaning 25
Protection of plastic surfaces ..........25
7 Do's and Don'ts 26
8 Guarantee Details 28
CONTENTS

EN
3
1Your Refrigerator
2
1
1
1
3
4
6
7
5
8
9
1. Body shelves
2. Bulb thermostate box
3. Sliding crisper cover
4. Food storage cabin
5. Adjustable front legs
6. Egg compartment
7. Door shelf
8. Bottle shelf
9. Bottle holder
CThe figures in this manual are schematic, and they may not be in exact
accordance with your product. If the product you purchased does not have the
related parts, then they are valid are for other models.
Congratulations on your choice of a BLOMBERG quality Appliance which has
been designed to give you service for many years.

EN
4
2 Warnings
•DO NOT connect
your appliance to the
electricity supply until
all packing and transit
protectors have been
removed.
•Leave to stand for at
least 4 hours before
switching on to allow
compressor oil to settle if
transported horizontally.
•If you are discarding an
old refrigerator with a
lock or latch fitted to the
door, disable the lock/
latch, ensure that it is
left in a safe condition to
prevent the entrapment
of young children.
•This appliance must only
be used for its intended
purpose i.e the storing of
edible foodstuff.
•Do not dispose of the
appliance on a fire.
At BLOMBERG, the
care and protection of
our environment is an
ongoing commitment.
This appliance which
is among the latest
range introduced is
particularly environment
friendly. Your appliance
contains non CFC /
HFC natural substances
in the cooling system
(Called R600a) and in
the insulation (Called
cyclopentane) which are
potentially flammable
if exposed to fire.
Therefore, take care
not to damage, the
cooling circuit / pipes
of the appliance in
transportation and in
use. In case of damage
do not expose the
appliance to fire or
potential ignition source
and immediately ventilate
the room where the
appliance is situated.
•We suggest you contact
your local authority for
disposal information and
facilities available.
•To obtain the best
possible performance
and trouble free
operation from your
appliance it is very
important to carefully
read these instructions.

EN
5
•On delivery, check to
make sure that the
product is not damaged
and that all the parts
and accessories are in
perfect condition.
•Ensure that the
plug remains readily
accessible. Do not use
multiple adapter or
extension cable.
•Failure to observe
these instructions may
invalidate your right to
free service during the
guarantee period.
•Keep ventilation
openings, in the
appliance enclosure or
in the built-in structure,
clear of obstruction.
•Do not use mechanical
devices or other means
to accelerate the
defrosting process,
other than those
recommended by the
manufacturer.
•Do not damage the
refrigerant circuit.
•Do not use electrical
appliances inside
the food storage
compartments of the
appliance, unless
they are of the type
recommended by the
manufacturer.
•We suggest you keep
these instructions in
a safe place for easy
reference.
•This appliance can
be used by children
aged from 8 years and
above and persons
with reduced physical,
sensory or mental
capabilities or lack
of experience and
knowledge if they have
been given supervision
or instruction concerning
use of the appliance
in a safe way and
understand the hazards
involved.
•Children should be
supervised to ensure
FITTED WITH
BS 1362 13A FUSE ALWAYS
FIT BS 1362 REPLACEMENT
CARTRIDGE FUSE
GREEN &
YELLOW
OR
GREEN
N
BLUE
OR
BLACK
L
BROWN
OR
RED
22mm.
6mm.
6mm.
6mm. 32mm.
12mm.
FUSE
CORD GRIP

EN
6
that they do not play with
the appliance.
For models with water
dispenser
•Pressure for cold water
inlet shall be maximum
90 psi (6.2 bar). If your
water pressure exceeds
80 psi (5.5 bar), use a
pressure limiting valve
in your mains system. If
you do not know how
to check your water
pressure, ask for the
help of a professional
plumber.
•If there is risk of water
hammer effect in your
installation, always
use a water hammer
prevention equipment in
your installation. Consult
Professional plumbers
is you are not sure
that there is no water
hammer effect in your
installation.
•Do not install on the
hot water inlet. Take
precautions against
of the risk of freezing
of the hoses. Water
temperature operating
interval shall be 33°F
(0.6°C) minimum and
100°F (38°C) maximum.
•Use drinking water only.
Electrical
Requirements
Before you insert the plug
into the wall socket make
sure that the voltage and
the frequency shown on
the rating plate inside the
appliance corresponds to
your electricity supply.
Rating label is on the left
hand side of inner liner.
We recommend that this
appliance be connected
to the mains supply via a
suitable switched
and fused socket. The
appliance must be
positioned so that the plug
is accessible.
Should the mains lead
of the appliance become
damaged or should it need
replacing at any time,
it must be replaced by a
special purpose made
mains lead which can
only be obtained from a
BLOMBERG Authorised
Service Agent.

EN
7
Warning! This
Appliance Must Be
Earthed
If the fitted moulded plug
is not suitable for your
socket, then the plug
should be cut off and an
appropriate plug fitted.
Destroy the old plug which
is cut off as a plug with
bared cord could cause
a shock hazard if inserted
into a socket elsewhere in
the house.
The moulded plug on this
appliance incorporates
a 13 A fuse. Should the
fuse need to be replaced
an ASTABEAB approved
BS 1362 fuse of the same
rating must be used. Do
not forget to refit the fuse
cover. In the event of losing
the fuse cover the plug
must not be used until a
replacement fuse cover
has been fitted. Colour
of the replacement fuse
cover must be the same
colour as that visible on
the pin face of the plug.
Fuse covers are available
from any good electrical
store.
Important! Fitting A
Different Plug
As the colours of the
wires in the mains lead
of this appliance may
not correspond with
the coloured markings
identifying the terminals
in your plug proceed as
follows: (See diagram).
1. Connect the green-
yellow or green (Earth)
wire to the terminal in the
plug marked ‘E’ or with
the symbol or coloured
green and yellow or
green.
2. Connect the blue
(Neutral) wire to the
terminal in the plug
marked ‘N’ or coloured
black.
3. Connect the brown
(Live) wire to the terminal
in the plug marked ‘L’ or
coloured red.
4. With alternative plugs
a 13 A fuse must be

EN
8
fitted either in the plug or
adaptor or in the main
fuse box. If in doubt
contact a qualified
electrician.
Energy Saving Tips
1. Ensure your appliance
is installed in a well
ventilated area.
2. Ensure the time
between buying chilled/
frozen food and placing
them in your appliance
is kept at minimum,
particularly in summer.
We recommend you use
a cool bag or a special
carrier bag to carry
perishable food.
3. Do not leave the door (s)
of your appliance open
longer than necessary
and ensure they are
closed properly after
each opening.
4. Defrost frozen food in
the fridge, so that frozen
food acts as an ice pack
to assist cooling in fridge.
Compliance with
WEEE Directive and
Disposing of the Waste
Product:
T h i s p r o d u c t
complies with EU
WEEE Directive
(2012/19/EU).
This product
bears a classification
symbol for waste electrical
and electronic equipment
(WEEE).This product has
been manufactured with
high quality parts and
materials which can be
reused and are suitable
for recycling. Do not
dispose of the waste
product with normal
domestic and other
wastes at the end of its
service life. Take it to the
collection center for the
recycling of electrical and
electronic equipment. Please
consult your local
authorities to learn about
these collection centers.

EN
9
Compliance with RoHS
Directive:
The product you have
purchased complies
with EU RoHS Directive
(2011/65/EU). It does
not contain harmful and
prohibited materials
specified in the Directive.
Package information
Packagingmaterialsofthe
product are manufactured
from recyclable materials
in accordance with our
National Environment
Regulations. Do not
dispose of the packaging
materials together with the
domestic or other wastes.
Takethemtothepackaging
material collection points
designated by the local
authorities.
