Blu Stream SP12AB-V2 User manual

SP12AB-V2 QUICK REFERENCE GUIDE
01
www.blustream.co.uk
Quick Reference Guide
SP12AB-V2
Our SP12-V2 4K HDMI 2.0 splitter distributes a single HDMI source to two simultaneousoutputs. The splitter
supports full HDMI 2.0 and HDCP 2.2 with video resolutions up to and including 4K @ 60Hz 4:4:4.
Introduction
Key Features:
• Features 1x HDMI input that is replicated to 2x HDMI outputs
• Supports full HDMI 2.0 4K UHD video including HDR (up to 4K @60Hz 4:4:4)
• HDCP 2.2 compliant
• Supports 3D signal display
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and
DTS-HD Master Audio transmission
• Advanced EDID management
Power Input Output 1 Output 2
2-way 4K HDMI 2.0 Splitter
Input
EDID
1
0
3 2 1 0
Update Output 1 Output 2 Coaxial
Audio Out
L/R
DC 5V
SP12AB-V2
Power Input Output 1 Output 2
2-way 4K HDMI 2.0 Splitter
Input
EDID
1
0
3 2 1 0
Update Output 1 Output 2 Coaxial
Audio Out
L/R
DC 5V
SP12AB-V2

SP12AB-V2 QUICK REFERENCE GUIDE
02
contact [e-mail] / [e-mail]
Panel Description
Front Panel:
Rear Panel:
The EDID configuration can be altered using the dip-switches located on the rear panel of the splitter.
Please see adjacent table for EDID settings.
Note: You must power-cycle the HDMI splitter aer changes have been made in order for the EDID settings to update.
Adjusting The EDID Settings
EDID Dip-switches
[DIP]=0000: HDMI 1080p@60Hz, Audio 2ch PCM
[DIP]=0001: HDMI 1080p@60Hz, Audio 5.1ch PCM/DTS/DOLBY
[DIP]=0010: HDMI 1080p@60Hz, Audio 7.1ch PCM/DTS/DOLBY/HD
[DIP]=0011: HDMI 1080i@60Hz, Audio 2ch PCM
[DIP]=0100: HDMI 1080i@60Hz, Audio 5.1ch PCM/DTS/DOLBY
[DIP]=0101: HDMI 1080i@60Hz, Audio 7.1ch PCM/DTS/DOLBY/HD
[DIP]=0110: HDMI 4K@60Hz 4:2:0+4K@30Hz 4:4:4, Audio 2ch PCM
[DIP]=0111: HDMI 4K@60Hz 4:2:0+4K@30Hz 4:4:4, Audio 5.1ch PCM/DTS/DOLBY
[DIP]=1000: HDMI 4K@60Hz 4:2:0+4K@30Hz 4:4:4, Audio 7.1ch PCM/DTS/DOLBY/HD
[DIP]=1001: HDMI 4K@60Hz 4:4:4, Audio 2ch PCM
[DIP]=1010: HDMI 4K@60Hz 4:4:4, Audio 5.1ch PCM/DTS/DOLBY
[DIP]=1011: HDMI 4K@60Hz 4:4:4, Audio 7.1ch PCM/DTS/DOLBY/HD
[DIP]=1100: DVI 1280x1024@60Hz, Audio None
[DIP]=1101: DVI 1920x1080@60Hz, Audio None
[DIP]=1110: DVI 1920x1200@60Hz, Audio None
[DIP]=1111: Soware Control EDID
EDID Dip-switches
Power LED - indicates if SP12AB-V2 is on or o
Input LED - indicates if HDMI input is active
Output LED - indicates if HDMI output is active
1
2
3
12
Micro USB connector used for firmware upgrade
EDID DIP switch - used to adjust HDMI input EDID settings
HDMI input - connect to HDMI source
HDMI outputs 1 and 2 - connect to HDMI displays
Coaxial digital audio output
Analog L/R audio output - 3.5mm stereo audio jack,
Supports 2 channel PCM only
Power port - use included 5V/1A DC power adaptor
4
5
8
9
4 65 8 9 10
6
710
3
7
Power Input Output 1 Output 2
2-way 4K HDMI 2.0 Splitter
Input
EDID
1
0
3 2 1 0
Update Output 1 Output 2 Coaxial
Audio Out
L/R
DC 5V
SP12AB-V2
Power Input Output 1 Output 2
2-way 4K HDMI 2.0 Splitter
Input
EDID
1
0
3 2 1 0
Update Output 1 Output 2 Coaxial
Audio Out
L/R
DC 5V
SP12AB-V2
Power Input Output 1 Output 2
2-way 4K HDMI 2.0 Splitter
Input
EDID
1
0
3 2 1 0
Update Output 1 Output 2 Coaxial
Audio Out
L/R
DC 5V
SP12AB-V2

SP12AB-V2 QUICK REFERENCE GUIDE
03
www.blustream.co.uk
Example Schematic SP12AB-V2
Stereo Audio HDMI
Input
EDID
1 0
3 2 1 0
Update Output 1 Output 2 Coaxial
Audio Out
L/R
DC 5V
SP12AB-V2
1 x 4K SOURCE
DISPLAY 1
4K
DISPLAY 2
4K

SP12AB-V2 QUICK REFERENCE GUIDE
04
contact [e-mail] / [e-mail]
Package Contents:
Specifications:
• 1x SP12AB-V2
• 1x 5V/1A DC power supply
• 1x Mounting kit
• 1x Quick reference guide
Video Input Connectors: 1x HDMI Type A, 19-pin, female
Video Output Connectors: 2x HDMI Type A, 19-pin, female
Audio Output Connectors: 1x RCA (SPDIF), 1x 3.5mm stereo jack (L/R)
EDID: 4-Pin DIP switch
Casing Dimensions (W x D x H): 159mm x 64mm x 22mm
Dimensions Inc. Connections (W x D x H): 159mm x 71mm x 22mm
Shipping Weight: 0.4kg
Operating Temperature: 32°F to 104°F (0°C to 40°C)
Storage Temperature : -4°F to 140°F (-20°C to 60°C)
Power Supply : 5V/1A DC
Audio Breakout
The splitter includes audio breakout from the selected HDMI input to associated analogue L/R audio and coaxial digital outputs.
Extracted audio will be concurrent with the corresponding HDMI video output. Note: Source input must be PCM 2ch audio for
analogue audio outputs to work. The splitter does not down-mix multi-channel audio signals.
Coaxial digital output - Output 1
Analogue fixed line level output 3.5mm stereo jack - Output 2
12
1
2
Power Input Output 1 Output 2
2-way 4K HDMI 2.0 Splitter
Input
EDID
1
0
3 2 1 0
Update Output 1 Output 2 Coaxial
Audio Out
L/R
DC 5V
SP12AB-V2
RevA4_QRG_SP12AB-V2_180420_Web Layout
