Blue Star Super Cooler SC300F User manual

User’s Manual
Super Cooler
ModelsSC300F SC375F SC500F SC650F SC1000F
SC300F-B SC375F-B SC500F-B SC650F-B SC1000F-B

Revised Edition - November 2021
No part of this publication may be reproduced in any manner whatsoever
without permission in writing from Vice President, Commercial Refrigeration Business,
Blue Star Limited.
While due care has been taken to avoid errors or misinterpretation,
Blue Star Limited is neither liable nor responsible for consequence of
any action taken on the basis of this publication.
All contents applicable as on date of publication.
Published by
Blue Star Limited,
Vatika Atrium, 6th Floor, Sector-53,
Golf Course Road, Gurugram 122 002, India.
For restricted circulation only. Not for sale.
Super Cooler

3
User’s Manual
3
User’s Manual
Table of Contents
Letter from the Vice President ..................................................................................................... 4
Safety Note ................................................................................................................................5
Caution.......................................................................................................................................7
Product Features ........................................................................................................................8
Installation............................................................................................................................... 9
Maintenance ............................................................................................................................12
General User Information.........................................................................................................13
Troubleshooting .......................................................................................................................14
Warranty ..................................................................................................................................16
Warranty Obligation for Customer ...........................................................................................18
.................................................................................................................19
24x7 Customer Care .................................................................................................................21
E-Waste Management........................................................................................Back Page Inner

4
Dear Customer,
Congratulations on the purchase of your new Blue Star Super Cooler, just one of the many world-class products that
we market. This superior product has been engineered for convenient and optimum performance. It has been tested
in the factory under actual operating conditions to ensure you years of satisfactory and trouble-free performance.
help you get the best of your Blue Star Super Cooler. Please spare some time to go through this manual carefully.
In the unlikely event of your running into a problem, kindly check the Troubleshooting Chart to diagnose the possible
I do hope that you will enjoy using your Blue Star Super Cooler.
Letter from the Vice President
With warm regards,
Super Cooler
M Srinivas Reddy
Vice President,
Commercial Refrigeration Business

5
User’s Manual
Safety Note
1. Do not modify the power cord length or sharing of outlet with other appliances and don't replace
the manufacturer.
2.
3. Do not switch ON/OFF the Super Cooler with wet hands. It may cause electric shock.
4. Use only dedicated power socket for supply to Super Cooler. Do not use an extension cord; otherwise
it will cause overloading and intermittent tripping of other appliances or household lights.
5. Never splash water on your Super Cooler. It may cause short circuit.
6. In the event of an electric short circuit, grounding (earthing) reduces the risk of electric shock by
providing an escape wire for the electric current. In order to prevent possible electric shock, this
on whether the appliance is properly grounded. Improper use of the grounding plug can result in
an electric shock.
7.
straight out from the outlet.
8. When moving your appliance away from the wall, be careful not to roll over the power cord or
Never unplug your Super Cooler by pulling on the power cord. Always grip rmly and pull it
damage it in any way.
9. Unplug the power cord from outlet for cleaning or other requirements. Never touch it with wet
hands because you can get an electric shock or be hurt.
10. Never damage, process, pull out, or twist the power cord, because damage of power cord may
Do not place the lit candle within the Super Cooler to deodorize. It may cause explosion or re.
11.
12.
13. When any strange smell or smoke is detected from the Super Cooler, disconnect the power plug
14. The Super Cooler should be so positioned that the supply plug is accessible for quick disconnection
when accident happens.
cosmetics near or in the Super Cooler. It may cause explosion or re.

6
15. The range of operating voltage is 187-242V. In order to avoid damaging the electrical performance
of the compressor, please equip it with a voltage stabiliser of power not less than 500W, to protect
the Cooler when the voltage is lower than 187V or higher than 242V.
16. Individual single-phase socket must be used. It should be reliably connected to a grounding wire.
The grounding wire should not be connected to a water pipe or a gas pipe.
17. Strong base, strong acid, organic solvent and corrosive goods or those that easily pollute food are
prohibited to be stored in the showcase; otherwise, it can cause corrosion or accident.
18. Don’t raise the showcase or the shell of the electric parts, as it will cause the decline in insulation
and cause corrosion.
19.
examine the circuit whether it is ok before reuse.
Caution:To ensure safety, the power plug must be pulled out before cleaning.
When transporting and installing the appliance, care should be taken to ensure that no parts of
the refrigerating circuits are damaged. Refrigerant squirting out of the pipes could ignite or cause
an eye injury. If a leak is detected, avoid any naked ames or potential sources of ignition and air the
room in which appliance is standing for several minutes.
Super Cooler

7
User’s Manual
Caution
1. Before use, Super Cooler must be properly installed and located as per the installation instructions.
2.
After your Super Cooler is in operation, do not touch the cold surface in the Super Cooler compartment,
particularly when your hands are damp or wet. Skin could adhere to these extremely cold surfaces.
3. Wait for 10 minutes or longer when reconnecting the plug. (It may cause the operation of the Super
Cooler to fail.)
5. Do not install the Super Cooler in a wet place or a place which water or rain splashes. (Deterioration
of insulation of electric parts may cause electric leakage.)
6. Unpack all packages before using the showcase. Don’t bend it over more than 60°, while moving it.
7. The showcase should be installed in an environment with good ventilation, cool and dry, without
corrosive gas. It should not be installed close to heat sources or directly under the sunlight. There
should be space of more than 10cm between the wall and the back of the showcase. When installing,
the universal wheels should be padded well to ensure that the showcase is levelled and stable, to
avoid vibration and too much noise.
8. During initial operation, the cooler should run empty for about one hour before storing food in it.
9. To save energy, the door should not be frequently opened or left open for a long time.
10. The surface and the inside of the showcase should be dry and clean. Long term moisture will cause
the showcase to rust slowly. (There will be some stains on the surface.)
11. Periodical cleaning is suggested. Generally, 30-45 days interval is best. When cleaning, it is best to
wipe the inside and the surface of the showcase using soft cloth with neutral soap or detergent.

Product Features
8
UV-protected galvanised sheets for interior and exterior
Adjustable plastic-coated wire mesh shelves
Eco-friendly refrigerant (R134a)
Uniform cooling
Clear product visibility with dual glass
Self-closing door
High-density PUF insulation.
Super Cooler

9
User’s Manual
Installation
Failure To Comply With The Instructions May Result In High- Energy Consumption,
Poor Performance Of The Unit And Void Warranty.
Installation Instructions
After unpacking, check the cabinet for any damage caused during transportation.
Always ensure that your merchandiser is installed on a stable surface/oor and is properly levelled.
There are 2 adjustable feet at the front, under the chassis. Please, adjust until the unit levels and
check using a spirit level, if available.
Do not place the cooler:
• In direct sunlight or near heat sources (radiators, stoves & other heating equipment)
• Outdoors, without proper protection from rain, moisture and other atmospheric elements
• In weather conditions for which it is not certied
• In extreme environmental conditions (i.E. Extensive exposure to saline humidity, areas with potential
water accumulation)
• On a surface angled by more than 5°
• Under a roof mounted ventilation system and near to air streams.
IMPROPER LEVELLING MIGHT RESULT TO CABIN DEFORMATION AFFECTING PERFORMANCE.
Mains connection: if the mains cord supplied is not long enough, do not use an extension lead and do
not replace it. Ask an authorized electrician to replace the cord with a longer one.
The Super Cooler must stand upright for at least 1 hour after transportation and prior to start up.
This gives the oil time to run back to the compressor after transit and installation. If the cabinet has
to be excessively tilted during delivery or installation, allow 3 hours before operation.
Allow a minimum gap of 100mm at the top, aprox 100mm at the rear (use rear spacer supplied
with the unit) and 50mm at the sides of the cooler for proper ventilation. Do not place anything on
top of the unit.

10
Relocation of the unit inside the outlet
• Empty the cooler and unplug the unit from mains supply.
• Fully extract the levelling feet.
• Move the unit to the desired location in cooperation with another person
Never reposition the unit when loaded with products.
3.2 Adjusting the shelf (not applicable to units with plastic inner liner)
To adjust the shelf rst unload it, lift it and unclip the shelf clips (4). Place the clips in the desired position
and reposition the shelf. Make sure that the horizontal metal rods at the bottom of the shelf are between
the front and back shelf clips.
3.3 Connection to the main supply
Connect the unit to power supply as mentioned in 2.3 (technical specication) on a min 10A fused &
grounded socket.
Do not connect the merchandiser to:
 A non grounded wall socket or power line
 Improper supply voltage and frequency
 Power supply that does not comply with the safety regulations of the appliance or with current
legislation on electrical installations
NEVER REPOSITION A SHELF WHEN LOADED WITH PRODUCTS.
Super Cooler

11
User’s Manual
3.4 Operation instructions
 Do not plug the cooler into a multiple outlet strip or use extension cables.
 If the supply cord is damaged, it must be replaced by the manufacturer, its service provider or
similarly qualied person.
 Route the power cables in such a way that they are protected from damage and they do not pose a
risk of tripping.
The unit is now ready to operate.
Do not apply load, such as packs of products while loading the unit, on the front glass.
Energy saving tips:
For energy saving and for better performance:
• Load the unit at night for better cooling by day.
• Store your back-up stock in a cool and/or dark place so that when reloaded, the unit will need much
less time to cool them down.
• Wipe moisture o the products before you place them in the unit.
• Avoid opening the door for long periods of time.
• After one year, the uorescent tubes emit 30% less light. Call a service technician to replace the
uorescent tubes or starters if installed with new ones if you wish to have stronger lighting.
Not following the instructions might cause high-energy consumption and poor performance.
This unit contains live components. Service tasks should be carried out by trained personnel only.

12
Maintenance
Before proceeding to do any cleaning or maintenance, unplug the cooler.
Care & Cleaning
• It is important to clean the Super Cooler twice a year. In order to avoid mould formation, odours,
etc. Product compartments must also be thoroughly cleaned. The interior of the unit should be
cleaned with a mildly soapy cloth and the glass surface using a window-cleaning agent.
• Never use a water hose or high-pressure jet to clean the cooler.
• Do not remove the safety devices (grates, guards, groundings, etc.).
• Keep the cooler in a stable position during cleaning, do not step on or lean over the cooler.
• Do not clean with sharp objects, ammable or corrosive liquids or sprays.
• If one or more of the bottles break while in the appliance and liquid spills inside the cabinet or the
space surrounding the appliance gets wet, unplug the cooler before you clean the liquid around
and inside the cooler. Remember to take all necessary actions to protect yourselves from broken
glass (use protective gloves when cleaning).
• Cleaning and user maintenance shall not be made by children without supervision.
Super Cooler

13
User’s Manual
General User Information
Operation
The evaporator fan inside the unit should be in continuous operation.
Energy saving tips:
To minimise power consumption and improve performance, do the following:
Since cooling consumes less power when the ambient temperature is lower, load the Super Cooler
at night for ready use of chilled drinks in the morning.
Store back-up stock in a cool and/or dark place so that the Super Cooler will need less time to
cool them down.

Avoid opening the door frequently or leaving it open for long.

14
Troubleshooting
Before proceeding to do any cleaning or maintenance, unplug the cooler.
If the cooler is not performing or not working, please check the following before calling for professional
service:
FAULT POSSIBLE REASONS HANDLING
1. The unit does not work. a) Power cord not plugged in.
b) No power coming through the socket.
a) Plug it.
b) Check for fuse / Mains MCB.
2. a) The unit has recently been reloaded
with warm products. It takes 12-19
hours to cool them down.
b) The unit is placed near strong air
streams or heat sources.
c) The unit is loaded in such a way
that the air-circulation in the
interior is getting blocked.
d) The door does not seal properly
e) No air is circulating in the
condenser area at all times
f) Leakage on the cooling system.
g) Controller/ Thermostat not
functioning properly.
a) Preferably, reload the unit before
night closing.
b) Relocate the unit according to the
instructions.
c) Load the unit according to
standards you have been
provided with by the company.
d) Repair the doors for proper closing
(This type of repair should be
performed by a technician).
e) Possible fan motor failure.
Replace motor (This type of
repair should be performed by a
technician).
e) Repair the leakage (This type
of repair should be performed
by a technician).
e) Contact the service provider
The unit does not cool enough.
The products are warm.
Super Cooler

15
User’s Manual
Symptoms Possible Causes Suggested Remedy
3. The unit sometimes makes noise. a) For this particular super cooler,
a powerful mechanism is
needed and consequently a
certain amount of
noise cannot be avoided.
b) Intense metallic noise.
c) Inclined or curved oor.
a) Super Coolers are of
dynamic type, according to the
specications that the company
is oering.
b) Contact the service provider.
c) Level the unit properly by adjusting its
feet. Placing a spirit level on the top of
the unit will assist you in leveling it.
4. There is water on the oor. a) The drainage hose for condensate
water is out of the tray.
b) There is a leakage in the tray.
c) The drainage hole for the
condensate water is blocked.
d) Excessive humid environment.
a) Contactthe serviceprovider.
b) Contact the service provider.
c) Unblock the drainage hole.
c) Certain days with excessive levels
of humidity, overow of the tray
could occur.
5. The lights don’t work.
a) The light switch(If available) is turned o
a) The light (uorescent tubes/LED tube/
LEDStrip) is out of order.
a) Turn on the light switch.
b) Contact the service provider.
6. Condensation on Glass. b) Very high humid atmosphere.
b) Certain days with excessive levels
of humidity, condensation could
occur.
7. Smoke or burning smell comes
out from the unit
a) Burning of electrical cable, etc. a) Unplug the unit from the wall
socket immediately and contact
the service provider.
If after all the above-mentioned checks the problem with your unit remains, contact the customer service
department.

16
Warranty
1. This Super Cooler is warranted, to the original purchaser, to be free from defects in material and
workmanship under normal use and service.
2.
defective within 12 months from the date of sale.
3. Free transportation of the equipment to the workshop for repairs is available during the Warranty
period if the appliance is used within the municipal limits of the city or town where the Blue Star
4. The defective parts must be sent to the Company, freight prepaid and insured, for the company’s
examination and satisfaction that they are defective. Return freight and insurance on such repaired/
replacement parts plus any excise duty and taxes/levies will be extra.
5. This Warranty will be valid only if the Super Cooler is operated on a power supply on a single phase
of 230V±10% AC.
6. This Warranty will be invalid if:
(a) Service/repairs on the equipment are carried out by any person other than the one authorised
by the Company.
(b) The equipment is let on hire.
(c) A defective voltage stabiliser is in use.
7. Any consequential damage or loss arising from any cause whatsoever, is excluded from this Warranty.
8. Failure/deterioration of any part/assembly arising, in the Company’s opinion, by reasons of shifting
to another location, accident, alteration, abuse/misuse, substitution of original part(s) with
are not covered under this Warranty.
1.
parts which may be provided under Warranty and such replacement parts shall not carry any fresh
Warranty.
2. Employees and/or authorised dealers of the Company have no authority to vary the terms of this
Warranty. No person is authorised to assume, in Company’s name or on Company’s behalf, any
other obligation or liability in respect of this appliance.
Super Cooler

17
User’s Manual
3. Any dispute whatsoever covering our Warranty terms, if not amicably settled, shall be referred to
mutually approved arbitrator, in Mumbai.
4. Warranty Registration: You can register your product warranty with Blue Star in either of two easy ways:
a. Visit www.bluestarindia.com/customer-service/online-warranty-register.aspx and follow
instructions therein.
b. Fill in the Warranty Certicate Cards in this manual and mail the lower card to the address
printed on the reverse.

1818
Warranty Obligation for Customer
Product Warranty Parts Covered Range(Parts not covered under
1 year of Warranty period)
Super Cooler
Models:
SC300F/SC300F-B
SC375F/SC375F-B
SC500F/SC500F-B
SC650F/SC650F-B
SC1000F/SC1000F-B
1 Year 1. Compressor
2. Condenser
Fan Motor
3. Evaporator Fan
Motor
4. Controller
300 to
1000
Litres
1. Thermostat
2. Condenser
3. Copper Pipe
4. Electrical Cable
5. Bimetal/plastic body/Li
6. Grilles
7. Other plastic parts/glass door
(All handles, hinges, locks,
rubber/glass/plastic parts and
lights)
Super Cooler

Customer’s Name: .........................................................................................................................................................................
Address : .......................................................................................................................................................................................
......................................................................................................................................................................................................
City ....................................... State ...................................... Pin..................................................................................................
Phone / Mobile No.: (O).............................................................. (R) .............................................................................................
Bill No................................................................. Date: .................................................................................................................
Model No. ............................................................. Serial No. ........................................................................................................
Dealer’s Name & Address
Super Cooler
Dealer’s Signature & Stamp
19
Customer’s Name: .........................................................................................................................................................................
Address : .......................................................................................................................................................................................
......................................................................................................................................................................................................
City ....................................... State ...................................... Pin..................................................................................................
Phone / Mobile No.: (O).............................................................. (R) .............................................................................................
Bill No................................................................. Date: .................................................................................................................
Model No. ............................................................. Serial No. ........................................................................................................
Cut and mail to Blue Star Ltd to the address on reverse.
Dealer’s Name & Address
Super Cooler
Dealer’s Signature & Stamp

Customer Copy

19

2020
Blue Star Limited,
CBO -
II Pokharan Road ,
Majiwada,
Thane - 400610
Pleas e
Post age
Stamp
CSG
Super Cooler
