MODELS WTS (HOT WATER)
User’s Manual
-
The WTS (HOT WATER THERAPY) series has been "treating" hot water systems from harmful infections, bacteria and viruses with ultraviolet radiation
technology for decades. Even at low doses, UV radiation provides protection against chlorine-resistant pathogens such as Cryptosporidium and Giardia.
Models are engineered to sterilize the supply water with instantaneous deactivation of contaminant loads and deodorizing results.
CONTENTS
The following symbols are used to indicate and classify the precautions in this
manual and on the product safety label. Failure to observe could result in personal
injury or damage to property.
1.1 Warnings for your safety
1.2 Marking label
1.3 Technical specifications of the product
This symbol is used to identify the risk of electric shock.
1.4 Web APP Connection (options)
1.5 Device and component design
This symbol is used to identify the need to wear protective gloves.
1.6 Reactor maintenance instructions
1.7 Laboratory certifications
This symbol is used to identify security alerts.
1.8 Warranty conditions
1.9 Returns of Goods
This symbol is used to identify ultraviolet light hazards.
2.1 Responsibilities and commitments of manufacturer and distributor
2.2 Certifications
This symbol is used to identify parts that should not be disposed of in the
trash.
This symbol indicates that the lamp contains mercury.
1.1 Warnings for your safety
The appliance must be operated safely, in accordance with the manufacturer's instructions and exclusively for the intended use. Improper handling may cause damage to
the equipment and possible injury to the user. Do not store explosive substances, such as aerosol products containing flammable propellant. If the power cord is damaged,
it must be replaced by the manufacturer, service representative or similarly qualified persons to avoid danger.
For protection against injury, read and follow all safety instructions as indicated:
•DO NOT EXPOSE YOURSELF TO REFLECTIVE germicidal UV rays, they can be harmful to your eyes.
•All personnel should be alerted to the potential hazards listed on safety labels.
•This equipment is intended for indoor use.
•Do not use this unit for any purpose other than its intended use as described in this manual.
•If the insulation cable or plug is damaged, broken do not use the unit.
•Do not operate the unit if any damage is visible or suspected.
•Do not touch the lamps when the unit is in operation.
•Save these instructions and do not remove the safety and warning labels from the unit.

ERGON LOGITECH LTD - ΚΑRATASOU 6ΑSINDOS - PC 57400 - GREECE T [phone] / https://www.ergonlogitech.com / e-mail:[e-mail]
We recommend the use of safety gloves when performing this work. The construction and operation of each piece of equipment is strictly tested at the factory. Confirm that
the features match the order specifications. Please be reminded that our constant search for technological improvements means that changes to the equipment described in
this manual may be applied without prior notice. Remove the shipping box and carefully inspect the unit, report all damage immediately. Do not operate if there is visible or
suspected damage.
1.2 Marking label
The marking plate is located at the back. It contains the main technical data for the
equipment and identifies the MODEL and SERIAL NUMBER, which is vital information for
any queries to the manufacturer.
European Directive on waste electrical and electronic equipment.
The International (WEEE) Directive specifies that, at the end of the life cycle of an
appliance, its components and consumables should be sent separately to be recycled or
reused.
ADDRESS
BRAND NAME
MODELS
PRODUCT CODE
SERIAL NUMBER
YEARS
VOLTAGE FREQUENCY
INPUT POWER
1.3 Product technical specifications
MODEL
WTS (HOT WATER)
WTS (HOT WATER)
WTS (HOT WATER)
Product code
WTSHT40 / 00185
WTSHT80 / 00185
WTSHT160 / 00185
Power Supply
220-240 V / 50 Hz
220-240 V / 50 Hz
220-240 V / 50 Hz
Input power
55 W / 0.3 A
110W / 0.5 A
170W / 0.6 A
Max. Power Consumption (W)
55
110
165
Flow rate (lt/h)
800
1.000
10.000
Rated flow at dose
30 mJ/cm2@ 95% UVT
40 mJ/cm2@ 95% UVT
50 mJ/cm2@ 95% UVT
UV Chamber Dimensions (mm)
(400 x 42)
(400 x 42) Χ 2
(400 x 42) Χ 3
Ambient water temperature
(+4°C +55°C)
(+4°C +55°C)
(+4°C +55°C)
Inlet & Outlet pipe connections
1’’
1’’
1’’
Dimensions / Width,Depth,Height / (mm)
360 x 640 x 174
560 x 640 x 174
760 x 640 x 174
Power per lamp (W)
40
40 Χ 2
40 Χ 3
Ultraviolet output per lamp(W)
12
12
12
Service life (H)
9.000
9.000
9.000
Number of lamps
1
2
3
Weight (kg)
12
15
17
Operating pressure (bar)
6
6
6
UV Chamber Material
Copper pipe
Copper pipe
Copper pipe
External finish
HPD paint
HPD paint
HPD paint
UV lamp
Low pressure
Low pressure
Low pressure
Quartz sleeve
Pure quartz (F200)
Pure quartz (F200)
Pure quartz (F200)
Temperature sensor
OPTIONS TS180P
OPTIONS TS180P
OPTIONS TS180P
UV sensor
OPTIONS TS1200P
OPTIONS TS1200P
OPTIONS TS1200P
Cabinet material
Stainless steel 304
Stainless steel 304
Stainless steel 304
Αpprovals
CE marked
CE marked
CE marked
All specifications are approximate and subject to change without notice. It is the operator's responsibility to determine and validate the suitability of the
equipment for use in the system or process.
1.4 Web APP WiFi Connection (options)
Each external device power panel includes a 433 MHz RF transponder. The system allows users to
remotely power on or off the connected devices via the EWeLink application from anywhere in the world.
The wireless device switch transmits data to a cloud platform via the WiFi router, which allows users to
remotely control all connected devices via the eWeLink APP.

ERGON LOGITECH LTD - ΚΑRATASOU 6ΑSINDOS - PC 57400 - GREECE T [phone] / https://www.ergonlogitech.com / e-mail:[e-mail]
You can set schedules for the appliances, with countdown or scheduled on and off, water temperature control in your tank and, therefore, can help customers
maintain an easy and seamless use. The iOS version of the app can be downloaded on the AppStore while the Android version can be downloaded on Google Play.
Press "+" for operation following the message in the app.
After activation, the device will enter the quick pairing mode (Touch) first use
mode. The device will close the quick pairing (Touch) mode if the Wi-Fi
connection is not successful within 3 minutes.
If you want to enter this mode, press and hold the manual button for about 5
seconds until the Wi-Fi LED changes to a cycle of two short and one long flash
and release.
1.5 Design of device and connection components
The WTS (HOT WATER THERAPY) devices have been designed in such a way that they can be installed in places with minimal space and with easy and direct adaptation
to tanks and hot water systems.
1
Electrical connections lamp, circulator
2
Ultraviolet lamp
3
Stainless steel cabinet
4
Copper reactor body
5
Circulator disconnect switch
6
Circulator
7
Reactor drain point
8
Water return to the reactor from the tank
9
Reactor water feed to the tank
10
Outer door of the hermarium
11
Wall support point
12
Door hinge
13
Power supply panel /Web APP Connection
1.6 Reactor maintenance instructions
A
Lamp disconnection record
Β
Electrical supply connector
C
Sealing connector
D
Fixed lamp rack
E
Water inlet in the reactor to the tank
F
UV lamp
The drawing above shows the components that make up the UV reactor. To replace the lamp,
the water must be drained from the device at point (K).
G
Copper reactor body
L
Water return to the reactor from the tank
Then we need to rotate the rack (A) counterclockwise and watch that it will detach from the
fixed rack (E).
K
Water discharge point from the reactor
Pull back the fitting, pulling the bulb and the rubber link (C). Disconnect the power supply connector (B) from the lamp and remove the lamp from the reactor. Reinstall the
new lamp in the reactor and fit the rubber sealing connector (C) to the fixed connector (D). Connect the power connector (B) to the lamp and screw the rack (A) clockwise to
the fixed connector (D) until it terminates. Turn on the supply and check for any leaks between the rack (A+D). If there is no leakage you can turn on the device.
CAUTION: To replace the lamp, disconnect the device from the power supply
and depressurize the water pressure. Gloves must be worn throughout the replacement process.

ERGON LOGITECH LTD - ΚΑRATASOU 6ΑSINDOS - PC 57400 - GREECE T [phone] / https://www.ergonlogitech.com / e-mail:[e-mail]
1.7 Laboratory Certifications
CERTIFICATE OF ANALYSIS / Issuing date of certificate: 9/8/2022
REPORTING MICROBIOLOGICAL RESULTS: Our company will not share microbial analysis for its clients' installations as every one of their results are confidential. The following analysis
come from an independent agent that provides the infectious load (contamination) for the devices' microbial certification/ ISO 17025 NO. 909-3 LABORATORY QLAB.
Λεωφ. Κων/νου Καραμανλή 122, Διαβατά, Θεσσαλονίκη, 57008
Konstantinou Karamanli Avenue 122, Diavata, Thessaloniki, 57008
Τ: 2310 784 712 , F: 2310 784 713 Email: [email protected],Web: www.q-lab.gr

ERGON LOGITECH LTD - ΚΑRATASOU 6ΑSINDOS - PC 57400 - GREECE T [phone] / https://www.ergonlogitech.com / e-mail:[e-mail]
1.8 Warranty Conditions
The guarantee is valid only in case of possession of the purchase document. The two (2) year warranty covers, based on proper operation of the device, the electrical
equipment management board. Maintenance, with compatible consumables and by an authorized service is a prerequisite.
Warranty is void for damage caused by failure to follow the instructions accompanying the product at the time of purchase. Failure to comply with periodic inspections,
maintenance, repairs or replacement of parts from normal wear and tear. Use of incompatible spare parts or consumables. Compatibility is ensured only by using products
purchased or recommended by our company. Damage caused by modification of device/system without prior consent of the company. Improper use of the product, drop.
Modifications or repairs by unauthorized personnel.
1.9 Returns of Goods
To return defective materials, you must request a return authorization by sending an email to the store where you purchased the device or by calling their phone number.
Only authorized products will be accepted, otherwise they will be rejected and returned to the sender..
2.1 Responsibilities and commitments of the manufacturer and the distributor
The company assumes no responsibility for any damage to persons or property due to failure to follow the instructions or use of the technology without the prescribed safety
provisions. We recommend that you carefully read all instructions or consult our engineering department. The manufacturer agrees with the purchaser to furnish, upon
request, circuit diagrams, parts lists, instructions for calibrating lamps and other information useful in repairing parts that the manufacturer deems repairable. The company
reserves the right to make changes without notice.
2.2 Certifications
European Community Certifications: EU LVD 2014/35/EU with the following Standards IEC EN 60335 -1 IEC EN 60335 -2 IEC EN 60529 IEC EN 60417.
Microbial certification / ISO 17025 NO. 909-3 LABORATORY QLAB for the devices' microbial certification/ ISO 17025 NO. 909-3 LABORATORY QLAB.
