bluemango BMH-HG25 User manual

Distributed by
PRINTED IN KOREA
P/N :
INSTRUCTION MANUAL
- Before attempting to connect or operate this product, please read these instructions carefully and
save this manual for future use.
- The design and specifications are subject to be changed without prior notice to improve product’s quality.
GLOBAL SHUTTER
FULL HD MEGA PIXEL IP ZOOM CAMERA

The lightning flash with an arrowhead symbol
within an equilateral triangle is intended to alert
the user to the presence of uninsulated
dangerous voltage within the product's enclosure
that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying
the product.
REGULATORY INFORMATION : FCC Part 15 WARNING -
Do not install this equipment in a confined
space such as a bookcase or similar unit.
Disposal of your old appliance
1.
When this crossed-out wheeled bin symbol
is attached to a product it means the product
is covered by the European Directive
2002/96/EC
2.
All electrical and electronic products should
be disposed of separately from the municipal
waste stream via designated collection facilities
appointed by the government or the local
authorities
3. The correct disposal of your old appliance
will help prevent potential negative conse-
quences for the environment and human
health
4.
For more detailed information about disposal
of your old appliance, please contact your
city office, waste disposal service or the shop
where you purchased the product.
To disconnect power from the mains, pull out the main
cord plug. When installing the product, ensure that the
plug
is easily accessible.
WARNING - Wiring methods shall be in accordance with
the National Electric Code, ANSI/NFPA 70.
WARNING - To reduce a risk of fire or electric shock, do
not expose this product to rain or moisture.
CAUTION - This installation should be made by a qualified
service personrel and should conform to all local codes.
CAUTION - To avoid electrocal shock, do not open the
cabinet. Refer servicing to qualified personnel only.
CAUTION -
The apparatus should not be exposed to
water (dripping or splashing) and no objects filled with
liquids, such as vases, should be placed on the apparatus.
WARNING - This is a class A product. In a domestic
environment this product may cause radio interference
in which case the user may be required to take adequate
measures.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION :
FCC WARING - This equipment may generate or use
radio frequency energy. Changes or modifications to
this equipment may cause harmful interference unless
the modifications are expressly approved in the instruction
manual. The user could lose the authority to operate this
equipment if an unauthorized change or modification is made.
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference
to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference
in which case the user will be required to correct the
interference at his own expense.
- A suitable conduit entries, knock-outs or glands shall
be provided in the cable entries of this product in the
end use.
-Holes in metal, through which insulated wires pass,
shall have smooth well rounded surfaces or shall
be provided with brushings.
03

1. Read these instructions - All these safety and operating
instructions should be read before the product is operated.
2. Keep these instructions - The safety, operating and user
instructions should be retained for future reference.
3. Heed all warnings - All warnings on the product and in
the operating instructions should be adhered to.
5. Do not use this apparatus near water - For example :
near a bath tub, wash bowl, kitchen sink, laundry tub,
in a wet basement, near a swimming pool, etc.
6. Clean only with dry cloth - Unplug this product from
the wall outlet before cleaning. Do not use liquid cleaners.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions. -
Slots and openings in the cabinet are provided for
ventilation, to ensure reliable operation of the product,
and to protect it from overheating. The openings should
never be blocked by placing the product on a bed, sofa,
rug or other similar surface. This product should not
be placed in a built-in installation such as a bookcase
or rack unless proper ventilation is provided and the
manufacturer’s instructions have been adhered to.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
4.
Follow all instructions - All operating and user instructions
should be followed.
9.
Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
10.
Only use attachments/accessories specified by the
manufacturer.
12. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
04 05
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS
11. Unplug this apparatus during lightning storms or
when unused for long periods of time.

06 07
CONTENTS FEATURES
Features
WHITE BALANCE ..........................................
IMAGE ..........................................................
INTELLIGENCE ............................................
SPECIAL FUNCTION ....................................
DISPLAY ....................................................
SPECIFICATION ...........................................
DRAWING ...................................................
TROUBLESHOOTING ...................................
25P
26P
28P
30P
32P
34P
37P
38P
FEATURES......................................................
PACKAGE COMPONENTS ...............................
SYSTEM CONFIGURATION..............................
PART NAMES AND FUNCTIONS .....................
CONNECTIONS .............................................
EXTERNAL DEVICE CONNECTIONS................
MENU OPERATION .......................................
NETWORK ...................................................
MAIN MENU .................................................
FOCUS .........................................................
TRIGGER ......................................................
EXPOSURE ...................................................
7P
8P
9P
10P
12P
13P
14P
15P
17P
18P
19P
22P
• 1/1.8" Sony Global Shutter CMOS Image Sensor
• Full HD Resolution
1920x1080p / 60fps(50fps), 1920x1080p / 30fps(25fps)
1280x720p / 60fps(50fps), 1280x720p / 30fps(25fps)
• DAY&NIGHT(ICR)
• DNR(Digital Noise Reduction, 2D+3D)
• DSS(Digital Slow Shutter)
• Defog Function
• HLC(High Light Compensation)
• Privacy mask Function
• On Screen Display
• Network, HD-SDI, EX-SDI, CVBS video output
• 3x Optical Zoom(3.6mm~10mm) & 6x Digital Zoom
• AD Key port for wired remote controller
• Remote control via RS-485
• Supports External trigger input and Strobe output

08 09
PACKAGE COMPONENTS SYSTEM CONFIGURATION
[Optional Remote Controller]
· ·
··
·
·
·
Not used
Far / Right
Tele/ Up
Menu/ Set
Wide / Down
Near / Left
MANUAL
DC 12V CABLE SERVICE OUT
BNC CABLE
2P, 6P
Terminal Block RS485
RS485
RS485
DVR/NVR
Keyboard
TV Monitor
VIDEO
VIDEO
VIDEO
(HD-SDI, CVBS)
CAMERA

10 11
PART NAMES AND FUNCTIONSPART NAMES AND FUNCTIONS
【1】Camera installation bracket
The braket can be fixed at the top or bottom of the
camera.
【1】IEEE802.3af PoE/LAN
【2】HD-SDI Out
【3】IP RESET
【4】CVBS Out
【5】Power : DC12V
【6】Control Terminal
1. OPTO - I : Trigger Input
2. OPTO - G : Isolated Ground(Trigger/Strobe)
3. OPTO - O : Strobe Out
4. GND : Ground
5. RS-485(-)
6. RS-485(+)
【7】Power LED
【8】AD Key : OSD Control
【3】
【1】
【6】
【7】
【5】
【2】
【8】【4】
【1】

12 13
CONNECTIONS EXTERNAL DEVICE CONNECTIONS
Basic connection
The peripheral devices (DVR, monitor, lens, etc), DC adaptor
and cables are not supplied.
1. Connecting the monitor.
Make the video signal connection between the camera and the
monitor or DVR/NVR.
2. Use a commercially available DC12V adaptor.
Connect DC 12V power source to the DC 12V input terminal
or using 802.3af.PoE power with network connection.
3. Insert the plug of this power cord into a wall outlet.
The POWER indicator will light. Adjust the picture on the monitor
using the Brightness and Contrast controls etc.
Connect video output(BNC / LAN) to the monitor or PC or NVR.
RS-485 COMMUNICATION
Connect to an external controller
of RS-485 format.
Note : Use a relay unit if the voltage
or current of the connected
device
exceeds the ratings.
2
3
1
PIN Signal Name PIN Remark
Anode of opto coupler(*)
Cathode of opto coupler
Emitter of opto coupler Isolated ground
Open Collector of opto coupler
(*) Serial resistors 375Ω inside camera
※The recommanded termination circuitry is drawn below
- A current of 2.5mA is recommanded for the strobe output.
- For the trigger input a current of 10mA is recommanded.
Trigger Input
Trigger/Strobe Return
Strobe Out
I
O
G
<Camera><Application>
TRIGGER
IF
IC
VCC
VCC
23
41
2 3
41
R1
23
4 1
23
4 1
375ohm
R2
R1
STROBE
OPTD : External trigger input and stobe output.

14 15
MENU OPERATION NETWORK
This camera utilizes an on-screen user MENU. To set items
on the menu, use the remote controller.
Tele(Up) button : Zoom in, Tele (Moves the cursor
upwards. Use this button to select an item or
adjust the parameters.)
Wide(Down) button : Zoom out, Wide (Moves the
cursor downwards. Use
this button to select an
item or adjust the parameters.)
Far(Right) button : Adjust focus in Manual Mode
(Moves the cursor to the right. Use this button to
select or adjust the parameters of the selected
item. The parameter changes each time this
button is pressed.)
Near(Left) button : Adjust focus in Manual Mode
Moves the cursor to the left. Use this button to
select or adjust the parameters of the selected
item. The parameter changes each time this
button is pressed.)
Set button : Executes selections and displays a
submenu for an item with the mark.
· ·
··
·
·
·
Not used
Far / Right
Tele/ Up
Menu/ Set
Wide / Down
Near / Left
Setting IP address
Using NVTManagement enables to set network settings.
1. Excute NVTManagement.
• Double click NVTManagement.exe
3. Access the camera using web browser.
2. Setting IP address
• Click NVT Scan button to find IP cameras than select the camera.
• Input IP address, net mask, gateway and name server address than click
Apply button.
• If you have any network information about your network, please ask to
your network administrator.
Login
Setting
※ Please contact your vendor for the Login IP&Password.

16 17
MAIN MENUNETWORK
MENU
FOCUS
TRIGGER
EXPOSURE
WHITE BAL
INTELLIGENCE
SPECIAL FUNC
DISPLAY
[EXIT] [SAVE] [DFLT]
Camera menu is subject to be changed without prior notice to upgrade and quality increase and we may use
slip sheet for the change.
Please check the camera version and the slip sheet if the camera menu and this manual menu is not matched.
MAIN MENU
Functions can be setup using “Menu Key Command”
of Visca protocol.
The menu consists of the “Main Menu” and “Sub Menu”.
The main menu is displayed where 8 camera functions
can be selected.
To the push of each main menu selection, the sub-menu
is displayed
If you want save the menu, select [SAVE]
If you want not save the menu, select [EXIT]
(After select , Power off → on)
If you want default the menu, select [DFLT]
4. Camera setting
4. 1 Go to setting menu as below.
4. 3 Go to Camera Control section.
Click Enter button to call OSD menu.
Adjust camera setting using OSD menu.
For more information, please refer the following OSD setting manual.
4. 2 Click Video Source.
* COMM Aux IP board default RS 232 settings are 115200bps & Visca.

18 19
TRIGGERFOCUS
TRIGGER
※This ‘TRIGGER’ menu should set the ‘MODE’ of the ‘EXPOSURE’ menu to ‘MANUAL’
◈ Trigger Mode : Select trigger mode ► FreeRun / ExtTrig
▷FreeRun : Continuous image output mode
▷ExtTrig : External trigger synchronous image output mode
◈ TrigIn Polari : Trigger Input Polarity ► OFF / ON
◈ StrOut Polari : Strobe Output Polarity ► OFF / ON
◈ ExtTrig Delay : External Trigger Delay ► 0 ~ 255 steps ▷1step = 1ms
◈Strobe Delay : Strobe Output Delay
► 1 ~ 29 steps : FreeRun Mode (@ 30fps) ▷1step = 1ms
► 0 ~ 255 steps : Trigger Mode ▷1step = 1ms
◈Strobe Width : Strobe Output Width
► 1 ~ 33 steps : FreeRun Mode (@ 30fps) ▷1step = 1ms
► 1 ~ 255 steps : Trigger Mode ▷1step = 1ms
◈AF MODE : Select auto focus mode
► AUTO, MANUAL
◈SCANNING : Select focus scan range
► HALF, FULL
◈ONE SHOT : Select readjust focus
► ON : Pressing the [SET] button more than 3 seconds activates the One-push Auto Focus.
◈SYNC TDN : Select the One-shot AF when the switch TDN
► OFF, ON
◈LENS RESET : Lens origin calibrated automatically
► ON : Pressing the [SET] button more than 3 seconds activates the Lens initialization.
◈REFOCUS : select the refocus interval time
► OFF, ON↲
▷ INTERVAL TIME : 1day ~ 10days
FOCUS
MENU
FOCUS
TRIGGER
EXPOSURE
WHITE BAL
INTELLIGENCE
SPECIAL FUNC
DISPLAY
[EXIT] [SAVE] [DFLT]
FOCUS
AF MODE
SCANNING
ONE SHOT
SYNC TDN
LENS RESET
REFOCUS
[BACK] [SAVE] [DFLT]
AUTO
HALF
ON
ON
ON
OFF
MENU
FOCUS
TRIGGER
EXPOSURE
WHITE BAL
INTELLIGENCE
SPECIAL FUNC
DISPLAY
[EXIT] [SAVE] [DFLT]
TRIGGER
Trigger Mode
TrigIn Polari
StrOut Polari
ExtTrig Delay
Strobe Delay
Strobe Width
[BACK] [SAVE] [DFLT]
---
---
OFF
---
0
1

20 21
TRIGGERTRIGGER
Timing Chart : FreeRun Mode
VD
Frame2 Exposure Time
Frame1 Data
Strobe Out Polari(OFF)
Strobe Delay Strobe Width
Strobe Out Polari(ON)
Strobe Delay Strobe Width
<FreeRun Mode>
TrigIn Polari(OFF)
TrigIn Polari(ON)
Ext.Trig Delay Frame Exposure Start Frame Data
Strobe Out Polari(OFF)
Strobe Delay Strobe Width
Strobe Out Polari(ON)
Strobe Delay Strobe Width
<Ext.Trig Mode>
Timing Chart : Ext. Trig Mode

22 23
EXPOSUREEXPOSURE
◈SHUT SPEED : Can be set in SHUT.P or MANUAL
► SHUT.P / MANUAL
▷Manual Shutter Speed
* 30 / 25 fps mode
: 1/30(25), 1/60(50), 1/120(100), 1/180(150), 1/240(200), 1/300(250),
1/500, 1/1000, 1/2000, 1/5000, 1/10000 sec
◈ DSS : Select maximum DSS(Digital Slow Shutter)
* 30 / 25 fps mode
► OFF / x2, x3, x4, x5, x6, x7, x8, x9, x10, x12, x15
◈FLICKERLESS : Select Flickerless mode
► OFF / ON (remove screen flicker)
◈BRIGHTNESS : Adjust brightness level
► 0(dark) ~ 20(bright) steps
◈BLC : Select BLC(Back Light compensation)
► BLC↲
▷POSITION : Adjust the window position
▷SIZE : Adjust the window size
※Can’t use MD&PM, HLC and BLC at the same time.
(When MD&PM, HLC On, BLC is Off. And when BLC is On, others is Off)
EXPOSURE
◈ LENS : Select LENS type
► DC / MANUAL
▷DC lens mode : Include IRIS
▷Manual lens mode : Except IRIS
◈MODE : Select AE type
► AUTO / SHUTTER.PRIORITY / MANUAL
◈AGC : Select Auto Gain Control
► OFF / ON
▷Manual Gain
Analog gain : 0dB, 2, 4, 6, 8, 10, 12, 14, 16, 18, 20, 22, 24, 26, 27dB
Digital gain : d3X,5,7,9,11,13,15,17,19,21,23,25,27,29,31,d33X
ISP gain : PG1
MENU
FOCUS
TRIGGER
EXPOSURE
WHITE BAL
INTELLIGENCE
SPECIAL FUNC
DISPLAY
[EXIT] [SAVE] [DFLT]
EXPOSURE
LENS
MODE
AGC
SHUT SPEED
DSS
FLICKERLESS
BRIGHTNESS
BLC
DAY&NIGHT
[BACK] [SAVE] [DFLT]
DC
AUTO
ON
---
OFF
OFF
OFF
AUTO
13

WHITE BALANCE
◈AWB : Select WHITE BALANCE mode
► AUTO / ONE PUSH↲/ MANUAL / INDOOR / OUTDOOR
▷AUTO : Automatically adjusts color according to the available lighting.
▷ONE PUSH : It is a fixed white balance mode that may be automatically
readjusted only by pressing ONE PUSH
▷MANUAL↲: Color can be corrected when the user increases or decreases
“RED GAIN” or “BLUE GAIN”.
▷INDOOR : Set color temperature to be Indoor light (3700°K)
▷OUTDOOR : Set color temperature to be Outdoor light (5100°K)
◈ RED GAIN : Adjust R gain value ► 0 ~ 20 steps
◈ BLUE GAIN : Adjust B gain value ► 0 ~ 20 steps
◈ CHROMA : Adjust CHROMA gain value ► 0 ~ 20 steps
◈ HUE : Adjust HUE gain value ► 0 ~ 20 steps
MENU
FOCUS
TRIGGER
EXPOSURE
WHITE BAL
INTELLIGENCE
SPECIAL FUNC
DISPLAY
[EXIT] [SAVE] [DFLT]
WHITE BAL
MODE
RED GAIN
BLUE GAIN
CHROMA
HUE
[BACK] [SAVE] [DFLT]
AUTO
---
---
14
10
24 25
WHITE BALANCE
EXPOSURE
◈DAY&NIGHT : Select Day&Night
► MODE : AUTO↲/ DAY / NIGHT↲
▷AUTO
► DELAY : 0 ~ 255 sec
► THRS : 0 ~ 10
Day↔Night switching level in Auto Mode.
Switching in lower lux with higher threshold level.
► GAP : LOW, MID-LOW, MIDDLE, MID-HIGH, HIGH
Margin between Day→Night switching level and Night→Day
switching level.
► BURST : OFF / ON
▷NIGHT
► BURST : OFF / ON

26 27
IMAGE IMAGE
◈MIRROR : Select a flip mode
► OFF / H / V / H&V
▷ H : You can flip the picture horizontally on the screen
▷V : You can flip the picture vertically on the screen
▷ H&V : You can flip the picture horizontally & vertically on the screen
◈SHARPNESS : Adjust sharpness level
► 0 ~ 10 steps
◈ ACE : Select Digital WDR (Wide Dynamic Range)
► OFF / MANUAL↲▷ LEVEL : 0 ~ 11 steps
◈DEFOG : Carry out defog function
► OFF / MANUAL↲
▷LEVEL : 0 ~ 11 steps
◈ Freeze : Select real or still mode
► OFF / ON
◈GAMMA : Select GAMMA
► 0.45 / 0.55 / 0.65 / 0.75
◈E.ZOOM
► OFF / ON↲
▷ LIMIT : Max x1.0 ~ x6.0
▷ POSITION : Select maximum digital zoom magnification.
◈HLC : Select High Light Compensation.
When extremely bright light is projected to the camera masking is used on
the portion to prevent partial saturation on the monitor.
▷MODE : OFF / ON ▷ LEVEL : 0 ~ 20 steps
▷POSITION : Adjust the window position ▷ SIZE : Adjust the window size
※Can’t use MD&PM, HLC and BLC at the same time.
(When MD&PM, HLC On, BLC is Off. And when BLC is On, others is Off)
◈DNR : Select Digital Noise Reduction
► OFF / 2D / 3D / 2D+3D
▷LEVEL : AUTO / LOW / MIDDLE/ HIGH
MENU
FOCUS
TRIGGER
EXPOSURE
WHITE BAL
INTELLIGENCE
SPECIAL FUNC
DISPLAY
[EXIT] [SAVE] [DFLT]
HLC
DNR
MIRROR
SHARPNESS
ACE
DEFOG
FREEZE
GAMMA
E.ZOOM
[BACK] [SAVE] [DFLT]
5
OFF
OFF
OFF
0.55
OFF
2D+3D
OFF

28 29
INTELLIGENCE INTELLIGENCE
◈MOTION : When there is movement of the subject in the screen, there will be an motion detection
► OFF / ON↲
▷ AREA# : Setting 4 areas(1~4) of motion detection
▷ MODE : OFF / ON (Limit and define areas of motion detection)
▷ AREA DISPLAY : OFF / ON (Event areas of motion detection)
▷POSITION : Adjust the Area position
▷ SIZE : Adjust the Area size
▷MOTION VIEW : Show the detection event
▷ SENSITIVITY : Adjust sensitivity of MD (0 ~ 35 steps)
More sensitive to setting to high step with sensitivity
▷ INTERVAL TIME : Select the alarm interval time of Motion Detection Out (0 ~ 255sec)
▷DWELL TIME : Select the duration time of Motion Detection Out about changing MD mode
(0 ~ 255sec)
◈ DIS : Select Digital Image Stabilizer mode
► OFF / ON
INTELLIGENCE
◈PRIVACY : Hide an area you want to hide on the screen
► OFF / ON↲
▷ MASK# : Select mask area number (1 ~ 8)
▷ MODE : Mask enable or disable (OFF / ON)
▷POSITION : Adjust the mask position
▷ SIZE : Adjust the mask size
▷ COLOR : Select mask color (0 ~ 14)
MENU
FOCUS
TRIGGER
EXPOSURE
WHITE BAL
INTELLIGENCE
SPECIAL FUNC
DISPLAY
[EXIT] [SAVE] [DFLT]
INTELLIGENCE
PRIVACY
MOTION
DIS
[BACK] [SAVE] [DFLT]
OFF
OFF
OFF

30 31
SPECIAL FUNCTION SPECIAL FUNCTION
SPECIAL FUNC
◈LENS SHADING : Improve light fall-off observed towards the edges of an images.
◈DEFECT : Compensates for bad pixels that may occur.
◈ SYSTEM : Select NTSC(60/30fps) or PAL(50/25fps).
◈HD FORMAT : Select Digital output
(1080p 60/50/30/25fps, 720p 60/50/30/25fps)
◈EX-SDI : Select EX-SDI mode.
OFF (HD-SDI) / 270M V1.0 / 135M V2.0
◈Out Select : Select signal output
IP/SDI, IP/CVBS, SDI/IP, SDI/CVBS
※CVBS IP(SDI) mode change hotkeys are “Left-Left-Left-Right”
MENU
FOCUS
TRIGGER
EXPOSURE
WHITE BAL
INTELLIGENCE
SPECIAL FUNC
DISPLAY
[EXIT] [SAVE] [DFLT]
SPECIAL FUNC
LENS SHADING
DEFECT
SYSTEM
HD FORMAT
EX-SDI
Out Select
COMM
COMM IP
[BACK] [SAVE] [DFLT]
NTSC
1080p/30fps
OFF
IP/SDI
ON
OFF
◈COMM / COMM IP : Set up the camera ID, baud rate, protocol
▷ID : Select the camera ID
► 1 ~ 255
▷BAUD RATE : Select serial communication speed
► 2400 / 4800 / 9600 / 19200 / 38400 / 57600 / 115200bps
▷PROTOCOL : Select operating protocol
► VISCA / PELCO-D / PELCO-P

32 33
DISPLAY DISPLAY
※Character Table of Text edit Mode
i
◈ SET INIT MSG : modify initial message. (Text edit – max 40 characters)
◈LANGUAGE : Select language.
► English / Simplified Chinese / Traditional Chinese / Japanese
DISPLAY
◈DISP SEL : Select display item.
► OFF / ON↲
▷ID : OFF / ON ▷TITLE : OFF / ON
▷ZOOM RATIO : OFF / ON ▷ SYSTEM MSG : OFF / ON (MD Alarm and Wait message)
◈ SET TITLE : Select camera title menu (Text edit– max 40 characters)
◈INIT SEL : Select display initial message.
► OFF / ON↲
▷ID : OFF / ON ▷BAUDRATE : OFF / ON
▷PROTOCOL : OFF / ON ▷VERSION : OFF / ON
▷INIT MSG : OFF / ON
MENU
FOCUS
TRIGGER
EXPOSURE
WHITE BAL
INTELLIGENCE
SPECIAL FUNC
DISPLAY
[EXIT] [SAVE] [DFLT]
DISPLAY
DISP SEL
SET TITLE
INIT SEL
SET INIT MSG
LANGUAGE
[BACK] [SAVE] [DFLT]
ON
ON
ENGLISH

34 35
SPECIFICATION SPECIFICATION
HLC
DNR
Mirror
Sharpness
ACE
Defog
Freeze
Gamma
E.Zoom
Privacy Mask
Motion Detection
Defect DET
System
HD Format
Communication
Disp Sel (Off / On)
Set Title
Init Sel (Off / On)
Set Init Msg
Language
Power Source
Power Consumption
Power Input
Video Output
Off / On
Off / 2D / 3D / 2D+3D (Auto/Low/Middle/High)
Off / H / V / H&V
0 ~ 20 steps
Off / Manual (0 ~ 11 steps)
Off / Manual (0 ~ 11 steps)
Off / On
0.45 / 0.55 / 0.65 / 0.75
Off / On (x1 ~ x6)
Off / On (8 positions)
Off / On (4 positions)
One push
NTSC / PAL
1080p/60(50)fps, 1080p/30(25)fps, 720p/60(50)fps, 720p/30(25)fps
ID : 1 ~ 255
Baud Rate : 2400 / 4800 / 9600 / 19200 / 38400 / 57600 / 115200
Protocol : Pelco-P / Pelco-D / VISCA
ID / Title / Zoom Ratio / System Message
Text Edit
ID / Baud Rate / Protocol / Version / Init. Message
Text Edit
English / Chinese / Japanese
DC12V±10% / 802.3af PoE
700mA
Connector
Connector
Image Sensor
Total Pixels
Recording pixels
Scanning system
Shutter Mode
Resolution
Min. illumination
Video Output
1/1.8" Sony Global Shutter CMOS Sensor
2,064(H) x 1,554(V) = 3.21M Pixels
1,920(H) x 1,080(V) = 2.07M Pixels
Progressive Scan
Global Shutter
Digital : 1080p/60(50), 1080p/30(25)fps, 720p/60(50)fps, 720p/30(25)fps
Analog : 700TVL
Color(1/30s) : 0.3 lux , BW(1/30s) : 0.02 lux
Color DSS(1/7.5s) : 0.075 lux , BW DSS(1/7.5s) : 0.005lux
HD : HD-SDI, EX-SDI / SD : CVBS (optional) / IP : H.265, H.264, MJPEG
Polarity / Delay
Polarity / Width / Delay
X3 Day & Night Motorized Lens
Optical x3, Digital x6 Zoom
f = 3.6mm ~ 10mm
F1.5 (wide) ~ F2.8 (tele)
Auto / Day / Night
0 ~ 20 steps
Auto / Manual ( 1/30(1/25) ~ 1/10,000 sec )
Off / x2/ x3/ x4/ x5 / x6/ x7/ x8/ x9/ x10/ x12/ x15
Off / On
Off / On
Off / On
Auto / One Push / Manual / Indoor / Outdoor
Trigger Input
Strobe Out
Lens Type
Zoom Ratio
Focal Length
Aperture Ratio
Angle of View (D, H, V)
Day & Night
Brightness
Shutter Speed
Digital Slow Shutter(DSS)
Gain Control(AGC)
Flickerless
BLC
White Balance
Wide
Tele
93.1º
41.6º
85.2º
36.6º
54.7º
21.1º

36 37
SPECIFICATION
DRAWING
* Design and specifications are subject to change without notice.
NETWORK
Ethernet
Video Compression Format
Resolution
Streaming Capability
IP
Protocol
ONVIF
Webpage Language
RJ-45 (10/100BASE-T)
H.265, H.264, MJPEG
1080p, 720p, 1024x576, 640x360, D1, 4CIF, VGA
Triple streaming
IPv4, IPv6
TCP, IP, HTTP, DHCP, FTP, DNS, DDNS, NTP, ICMP, SNMP, SMTPE, UPnP,
RTP, RTSP, ONVIF
Support
Korean, English
Operating Temperature
Storage Temperature
External Dimension
Weight
-10℃ ~ +50℃ (Humidity : 0%RH ~ 90%RH)
-20℃ ~ +60℃ (Humidity : 0%RH ~ 90%RH)
59.2(W) x 62.2(H) x 143.8(D) mm
410g
59.2
58.2
62.2
110
143.8
14
Ø5.00
1/4"-20UNC-2B
49 14

38 39
TROUBLESHOOTING
• Nothing appears on the screen.
-Please check the power connection.
-Please check the video signal line connection.
• The video image is not clear.
-Please clean the lens with a clean cloth or brush.
-Please adjust that the screen is not exposed directly to a bright light.
-Please move the camera if necessary.
• The screen is dark.
-Please adjust the contrast feature of the monitor.
-If you have an intermediate device, set the 75 Ω /Hi-Z properly, and check the terminals.
-Please adjust the brightness level.
• The MOTION DETECTION function is not working
-Please check if “MOTION DETECTION” mode is turned on.
-Please check if the MD Sensitivity is too high.
-Please check the setting of the MD AREA.
• The WDR function is not working
-Please check if the WDR Level is too low.
-Please check if the AE Mode is set to MANUAL. The WDR doesn’t work in MANUAL, Shutter priority
Exposure mode.
• Colors are not quite right.
-Please check if the camera is facing directly into sunlight or fluorescent light.
• The Day&Night function doesn’t work.
-Please check if the AGC of EXPOSURE menu is set to OFF.
-The Auto Day&Night doesn’t work in AGC OFF status.
Trouble shooting
If there are problems in operation, please refer to the items below.
If the problem persists, please contact the agent you purchased this product from.
