BlueNova 52V RacPower Series User manual

User Manual
52V RacPower Range
BN52V-100-5.2k BP
with CAN communication
Document Revision No.
Ver. 1.0.1
Revision Date
2021-04-01
Approved by
J.P. Verster

User Manual
RacPower® BN52V-100-5.2k BP
2 Erica Way Office: [phone]
Somerset West Business Park Technical Support: [e-mail]
Somerset West, 7130 Website: www.bluenova.co.za
A. DOCUMENT SCOPE
Congratulations on purchasing a high quality BlueNova® product.
This document covers structural information, installation instructions, troubleshooting, safety & maintenance
instructions, storage guidelines as well as emergency & first aid procedures specific to:
-BlueNova® 52V RacPower product range, consisting of BN52V-100-5.2k
If you are unsure whether this document is applicable to your battery, or if you have any questions or comments,
kindly contact BlueNova® Technical Support:
Office: [phone] E-mail: [e-mail]
Please do not discard this document as it contains valuable information that might have to be referenced at a
later stage.
B. STRUCTURAL OVERVIEW
The BlueNova® 52V RacPower range has been designed to be installed in 19” (11U) server racks.
The weight & dimensions of each enclosure in this range is listed below:
Dimensions (L x W x H)
Weight (net)
1
BN52V-100-5.2k BP RacPower
435 x 480 x 150mm
41kg
Note: The dimensions above are the dimensions of the main chassis (excluding the front panel) in each case.
For a more detailed overview of dimensions, please see latest product data sheets.
Diagram: BN52V-50-5.2k RacPower

User Manual
RacPower® BN52V-100-5.2k BP
2 Erica Way Office: [phone]
Somerset West Business Park Technical Support: [e-mail]
Somerset West, 7130 Website: www.bluenova.co.za
C. FRONT INTERFACE PANEL
Diagram: Front Interface Panel (BN52V-100-5.2k)
SYSTEM START / SHUT DOWN / RESET:
FUNCTION
OPERATION
Start
Keep the RESET button depressed for 3 seconds while the battery is off.
LED’s on the panel will then flash from left to right.
Shut down
Keep the RESET button depressed for 3 seconds while the battery is on.
LED’s on the panel will then flash from right to left.
Reset
Press the RESET button for 6 seconds while the battery is on.
COMMUNICATION PORTS:
COMPONENT
FUNCTION / DESCRIPTION
RS232 (RJ11)
Not active
CAN Ports (RJ45 x 2)
Serial communication via CAN Bus.
PIN configuration as follows:
-7 : CAN-H
-8 : CAN-L
RS485 Ports (RJ45 x 2)
Pin configuration as follows:
-1/8 : A
-2/7 : B
-3/6 : GND
-4/5 : NC
STATE-OF-CHARGE:
COMPONENT
FUNCTION / DESCRIPTION
State-of-charge indicator
0% –25% SoC
25% –50% SoC
50% –75% SoC
75% –100% SoC

User Manual
RacPower® BN52V-100-5.2k BP
2 Erica Way Office: [phone]
Somerset West Business Park Technical Support: [e-mail]
Somerset West, 7130 Website: www.bluenova.co.za
D. INSTALLATION
1. VOLTAGE-BASED INSTALLATION
The following values highlighted in blue must be set on the inverter/charger:
Parameter
Cell V
Value
Comment
V high set
3.53 V
56.4 V
Typical bulk/absorption charge setpoint.
V float
3.44 V
55.0 V
Floating voltage set point.
V reconnect
3.06 V
49.0V
Mains or generator must reconnect to charge batteries.
V low set
2.9 V
46.5V
Inverter must switch off the load.
•Maximum Continuous Charge Current limit = 50 A
•Recommended Charge Current = 10 A
•Maximum discharge Current limit = 100 A
•Recommended discharge current limit = 50 A
IMPORTANT: Inverter/charger voltage calibration
Some inverters/chargers have been known to return inaccurate results when measuring voltage.
In such cases, the inverter/charger should be calibrated as follows:
Compare the voltage values displayed by the inverter/charger with that of a calibrated voltmeter.
If the actual voltage differs by more than 100mV from that measured by the inverter/charger, apply this
difference to the highlighted values above (i.e. if actual voltage = 56V while inverter voltage = 56.5V,
the voltage difference = 0.5V should be subtracted from each of the set values above).
Note: Some inverters/chargers have pre-programmed lead-acid related algorithms & functionalities such as auto-
desulfation and equalisation. These functionalities should be disabled, where possible.

User Manual
RacPower® BN52V-100-5.2k BP
2 Erica Way Office: [phone]
Somerset West Business Park Technical Support: [e-mail]
Somerset West, 7130 Website: www.bluenova.co.za
2. PARALLEL CONNECTION
Address
DIP Switch Number
Master
/ Slave
(CAN)
Definition
(RS485)
Parallel Configuration
Inverter Protocol
configuration
#1
#2
#3
#4
#5
#6
Inverter
OFF
OFF
Victron250
ON
OFF
Victron500,
SMA,
Studer
OFF
ON
Goodwe
ON
ON
Reserved
Note:
Ensure to have the same
protocol configuration on
all parallel units.
1
ON
OFF
OFF
OFF
Master
Pack1
2
OFF
ON
OFF
OFF
Slave 1
Pack2
3
ON
ON
OFF
OFF
Slave 2
Pack3
4
OFF
OFF
ON
OFF
Slave 3
Pack4
5
ON
OFF
ON
OFF
Slave 4
Pack5
6
OFF
ON
ON
OFF
Slave 5
Pack6
7
ON
ON
ON
OFF
Slave 6
Pack7
8
OFF
OFF
OFF
ON
Slave 7
Pack8
9
ON
OFF
OFF
ON
Slave 8
Pack9
Diagram: Parallel Connection

User Manual
RacPower® BN52V-100-5.2k BP
2 Erica Way Office: [phone]
Somerset West Business Park Technical Support: [e-mail]
Somerset West, 7130 Website: www.bluenova.co.za
BlueNova® 52V RacPower batteries can be connected in parallel to each other to increase overall capacity ONLY
IF ALL the requirements below are met:
a. The nominal voltage of all parallel-connected batteries is the same (52V), and
b. The installed capacity for all batteries is the same, and
c. Each battery is operating within its warranty period.
A total of 6 units can be connected in parallel, for total installed capacity of 31.2kWh @C2, 25°C.
2.1 PARALLEL CONNECTION: STEP-BY-STEP INSTRUCTIONS
1. Ensure that all units are grounded by connecting each chassis to GROUND from the rear right panel.
Wire diameter should be equal to or exceed 1mm².
2. Connect the POSITIVE terminals of the first (top) unit to the second unit, then from the second unit to
the third etc. as illustrated above. Wire diameter should be equal to or exceed 8mm².
3. Connect the NEGATIVE terminals of the first (top) unit to the second unit, then from the second unit to
the third etc. as illustrated above. Wire diameter should be equal to or exceed 8mm².
4. Configure the dip switches for the master battery and slave batteries respectively.
5. Connect the RS485 ports of all parallel batteries with each other with a straight 1-to-1 pin RJ45 cable.
2.2 SWITCHING ON PARALLEL CONFIGURATIONS
1. After the system has been fully installed ensure that all the battery units are switched off.
All LED’s on the front panel should be off.
2. Switch on the first (master) unit. The rest of the batteries will then switch on automatically.
E. MAINTENANCE
1. General Guidelines
a. Do not short circuit the battery terminals.
b. Do not use the battery without a BlueNova® approved integrated BMS solution.
c. Do not disassemble, pierce, cut or in any way physically alter any part of the battery.
d. Do not burn, incinerate or otherwise subject the battery to extreme heat.

User Manual
RacPower® BN52V-100-5.2k BP
2 Erica Way Office: [phone]
Somerset West Business Park Technical Support: [e-mail]
Somerset West, 7130 Website: www.bluenova.co.za
2. Storage Instructions
a. Ensure that the battery is switched off when stored.
b. Disconnect the communication cable.
c. Always store batteries in a cool and well-ventilated area –ideally 25°C ± 3°C.
d. Store away from moisture and heat.
e. Do not store batteries upside down for overly long periods.
f. Check the open circuit voltage of stored batteries at least once per month. Recharge batteries sufficiently and
frequently enough to prevent the open circuit voltage falling below 40V.
g. The battery needs to be charged every 6 months if out of use.
h. Ensure that the stored battery’s state of charge is always above 50%. 100% SOC is optimal.
i. Don’t place more than 6 units on top of each other.
F. TROUBLESHOOTING
Please cross-reference the behaviour of the battery’s LED indicators with the table below to determine whether
your battery is operating correctly. Kindly contact BlueNova Technical Support for assistance if necessary.
Battery Status
State
SOC Indicators
RUN LED
ALM LED
Off
Sleep mode
OFF
OFF
OFF
OFF
OFF
OFF
Stand by
Normal
Indicates state-of-charge
ON
OFF
Warning
Indicates state-of-charge
ON
Flash 2
Protection
Indicates state-of-charge
OFF
ON
Charging
Normal
Indicates state-of-charge
Flash 1
OFF
Warning
Indicates state-of-charge
Flash 1
Flash 2
Protection
Indicates state-of-charge
OFF
ON
Discharging
Normal
Indicates state-of-charge
Flash 2
OFF
Warning
Indicates state-of-charge
Flash 2
Flash 2
Protection
Indicates state-of-charge
OFF
ON
BMS Failure
Sleep mode
OFF
OFF
OFF
OFF
OFF
Flash 2
Flash 1: LED flashes once every second / Flash 2 –LED flashes once every 2 seconds
G. EMERGENCY & FIRST AID
1. In case of fire
a. Evacuate danger zone. Open ventilation in the room if possible.
b. Extinguish fire with a CO2 fire extinguisher.
c. After the fire has been extinguished, immerse any remaining smoking cells completely in water.
Wear protective gear during this procedure.

User Manual
RacPower® BN52V-100-5.2k BP
2 Erica Way Office: [phone]
Somerset West Business Park Technical Support: [e-mail]
Somerset West, 7130 Website: www.bluenova.co.za
2. Skin contact
a. Wash the affected area immediately with soap and water.
b. If irritation persists, seek medical attention.
3. Eye contact
a. Rinse eyes immediately with clean water continuously for at least 15 minutes.
b. Seek medical attention immediately afterwards.
4. Ingestion
a. Refrain from taking any emetic or vomit-inducing medicine.
b. Seek medical attention immediately.
