BluePoint Security AdTrap AT1000 User manual

Copyright © 2009-2014 BluePoint Security, Inc.
AT1000
User’s Manual
Version 2.0

AdTrap User’s Manual | Page 2
User’s Manual
Version 2.0
Table of Contents
TECHNICAL SPECS ............................................................................................................................................3
SAFETY REQUIREMENTS...................................................................................................................................3
GETTING STARTED ...........................................................................................................................................4
About your AdTrap ............................................................................................................................4
What’s in the Box?.............................................................................................................................4
What about Security? ........................................................................................................................4
ADTRAP LEDs AND PORTS ................................................................................................................................5
INSTALLING YOUR AdTrap................................................................................................................................5
Installation Proxy Mode: ....................................................................................................................6
AdTrap Setup Utility:.........................................................................................................................7
Installation Inline Mode: ....................................................................................................................8
ADTRAP SETTINGS..........................................................................................................................................10
Access AdTrap Settings: ...................................................................................................................10
Settings:...........................................................................................................................................10
AdTrap Rules:...................................................................................................................................13
Reports: ...........................................................................................................................................14
Updates: ..........................................................................................................................................14
AdTrap Anyhere .............................................................................................................................................15
Basic Troubleshooting....................................................................................................................................17
Factory Reset:..................................................................................................................................17
I’m not getting on the Internet: .......................................................................................................17
If Internet status light is flashing: .....................................................................................................17
No Internet status light? ..................................................................................................................17
I can get on the Internet, but everything is slow; .............................................................................18

AdTrap User’s Manual | Page 3
TECHNICAL SPECS
Power Supply;
Input: 100-240v-50/60 Hz @0.5A
Output: DC 5v @3A
Input Size: 5.5mm
Weight 7oz
CE Approved
Up to 350 Megabits per second Bandwidth
2x Gigabit Ethernet Ports
SAFETY REQUIREMENTS
CAUTION - Risk of Shock
Voltage inside this unit. No user serviceable parts inside.
Refer service to qualified personnel only!
Do not use product near water (i.e. wet basement, bathtub, sink or near a swimming pool,
etc.), to avoid risk of electrocution.
Avoid using and/or connecting the equipment during an electrical storm, to avoid risk of
electrocution.
Do not locate the equipment within 6 feet (1.9 m) of a flame or ignition source (i.e. heat
registers, space heaters, fireplaces, etc.).
Use only power supply and power cord included with the equipment.
In areas of high surge events or poor grounding situations and areas prone to lightning strikes,
additional surge protection may be required on the AC and Ethernet.

AdTrap User’s Manual | Page 4
GETTING STARTED
About your AdTrap
Can handle up to 350Mbps
Automatically stays updated as advertisers change their ad schemes
Blocks advertisements from music and video streams, mobile apps and web pages
Works with ANY Internet browser
Protects your privacy, prevents tracking and profiling techniques used by advertisers
What’s in the Box?
Make sure you have the following items before proceeding. Call AdTrap for assistance if anything is
missing;
(1) AdTrap Unit
(1) Power Cord
(1) Network Cable
(1) Quick Instruction Sheet
What about Security?
Having a high-speed, always-on connection to the Internet requires a certain amount of responsibility
to other Internet users—including the need to maintain a reasonably secure system. While no system
is 100% secure, you can use the following tips to enhance your system’s security:
Keep your operating system updated with the latest security patches. Run the system update
utility at least weekly.
Avoid opening email containing attachments, or opening files sent through chat rooms,
whenever possible.
Install a virus checker and keep it updated.
If you connect your AdTrap to a wireless LAN, make sure you enable security and encryption on
the wireless router/switch. Consult the documentation and technical support of the wireless
equipment provider for help.

AdTrap User’s Manual | Page 5
ADTRAP LEDs AND PORTS
Power: Connector for the power cord
LAN: 1 Gigabit port for the router or home computer
WAN: 1 Gigabit port for the modem
ON
ON
ON
ON
ON
Self Test
Mode…
Flash
Flash
Off/ON
Off/ON
Off/ON
Off
ON
AdTrap is
boo ng up…
Flash
Flash
Flash
ON
Internet
found,
con nuing to
boot…
Flash
Flash
ON
ON
AdTrap is
ready
LED LIGHT SEQUENCE

AdTrap User’s Manual | Page 6
INSTALLING YOUR ADTRAP
There are two ways to connect the AdTrap to your network. Proxy Mode or Inline Mode.
Installation Proxy Mode:
Proxy Mode

AdTrap User’s Manual | Page 7
*AdTrap Setup Utility is a program that eases the configuration of the AdTrap in proxy mode and
has shortcuts to settings and updates. The setup utility does not install anything on your computer. The
main function is to scan your network for an AdTrap and configure your computer to use the AdTrap as a
proxy server. You can use this utility to gain access to the settings page for advanced options and whitelist
pages you want to see ads on.
*AdTrap Setup Utility is a program that eases the configuration of the AdTrap in proxy mode and
has shortcuts to settings and updates. The setup utility does not install anything on your computer. The
main function is to scan your network for an AdTrap and configure your computer to use the AdTrap as a
proxy server. You can use this utility to gain access to the settings page for advanced options and whitelist
pages you want to see ads on.

AdTrap User’s Manual | Page 8
Installation Inline Mode:
Inline Mode

AdTrap User’s Manual | Page 9

AdTrap User’s Manual | Page 10
ADTRAP SETTINGS
Use:
To monitor various configuration options and operational status of the AdTrap
Access AdTrap Settings:
1. The Default Access is located on a label at the bottom of your AdTrap. In your browser
address bar, type in the Web Admin address provided on the label. Choose one of them.
Settings - Proxy Mode
(Connected to an all-in-one modem & router)
Option A
Download the setup utility for your Operating system and click Settings
These following options will only work if your AdTrap is already enabled or proxy
settings have been set.
Option B
In your browser type in http://adtrap.local:10001
Settings - Inline Mode
(Connected between your router and modem)
Option A
Download the setup utility for your Operating system and click settings
Option B
In your browser type in http://setup.getadtrap.com
Option C
In your browser type in http://192.168.211.1:10001
2. Once you are in the Login page use the default username and password provided on the
bottom of the AdTrap.
Username = admin
Password = password
3. Go to the top of the page drop-down menu and select Settings.
Settings:
Welcome
The welcome screen can be bypassed by selecting one of the drop down menu
choices from the top of the page.

AdTrap User’s Manual | Page 11
Steps:
1. Choose which configuration the AdTrap is connected
2. Choose to change your password and your time zone
3. Gives you information about your network and setup
4. Gives you the opportunity to download the setup utility
AdTrap Anywhere
Adtrap can be used on your mobile device over your carrier’s data plan. The phones
data get transferred from your data plan to your home network through the AdTrap
then back to your phone again. Even though this seems like a long process, with the
ads removed, you lose no internet speed. See the AdTrap Anywhere section for
further instructions.
Firewall
A firewall is a set of related programs and rules that protects the resources of a
private network from users from other networks. (The term also implies the security
policy that is used with the programs.) An enterprise with an intranet that allows its
workers access to the wider Internet installs a firewall to prevent outsiders from
accessing its own private data resources and for controlling what outside resources
its own users have access to.
Forwarding Ports
Port forwarding allows remote computers (for example, computers on the Internet)
to connect to a specific computer or service within a private local-area network
(LAN)
1. Log into your AdTrap Settings.
2. Click Settings then Firewall.
3. Click Add Port Forward.
4. Type in the name of the rule in the Rule Comment section.
5. Type in the IP address in the Destination IP. This address is usually the next
device after the AdTrap which is your router IP address. ie 192.168.211.xxx.
6. Type in the port or the port series in the Destination TCP port. This works for
TCP ports only.
7. Click Create on the bottom of the page.
8. Click Apply Configuration and you are all done.

AdTrap User’s Manual | Page 12
General
This is where you can setup the main functions of the AdTrap.
General
Timezone –Set up the Timezone for your location. This will also set up the
time when the AdTrap updates for 1am your local time.
Hardware
CPU Clock –Default is 720MHz. Use this to speed up the processor.
LED Status –Use these to turn off LEDS.
Configuration
DHCP Server –Check this box to enable the AdTrap to automatically assign
an IP address to a computer from a defined range of numbers (i.e., a scope)
configured for a given network.
DHCP Range Start –Starting IP address of your DHCP server.
DHCP Range End –Ending IP address of your DHCP server.
AdTrap Is Hooked Up - Sets the way the AdTrap is configured in your network.
AdTrap Ad Blocking –Enables or disables adblocking for the AdTrap.
Web Traffic Logging –Enables or disables the web traffic logging located on
the reports page. This does not affect ad blocking.
Password
Use this to change your password.
Updates
AdTrap Updates –Enable or disable automatic updates.
Ad Signatures –
Networking –LAN (ETH1)
DHCP –Allows the AdTrap to receive a DHCP IP address.
LAN IP –Sets a static IP address if DHCP is not checked.
Subnet Mask –Sets your subnet mask.
Gateway –Sets your Gateway. This is usually a node or device that controls
the traffic on your network.
Networking WAN (ETH0)
DHCP –Allows the AdTrap to receive a DHCP IP address.
WAN IP –Sets a static IP address if DHCP is not checked.

AdTrap User’s Manual | Page 13
Subnet Mask –Sets your subnet mask.
Gateway –Sets your Gateway. This is usually a node or device that controls
the traffic on your network.
MAC Address –Allows you to change your MAC Address.
Networking –DNS SERVERS
Use DNS SERVERS from DHCP –This uses the default DHCP servers.
DNS SERVER 1 –Allows you to change to a preferred DNS server.
DNS SERVER 2 –Allows you to change to a preferred DNS server.
Welcome
This allows you to go through the welcome sections again.
AdTrap Rules:
The AdTrap rules lets you add or remove ad blocking for specific sites.
Allowed Websites
Search –Use this tool to search the list of Allowed Websites already placed in your allowed
websites table
Add Website –Enter the domain of the website that you would like to be bypassed and see
the ads.
Allowed Websites –This is a list of user specific websites that have been added to the
AdTrap.
Blocked Websites
Search –Use this tool to search the list of Blocked Websites already placed in your allowed
websites table.
Add Website –Enter the domain of the website that you would like to be blocked
Blocked Websites –This is a list of user specific websites that have been added to the
AdTrap.

AdTrap User’s Manual | Page 14
Reports:
The AdTrap has an advanced logging system in which you can see which ads are being blocked at
any time.
Real-time Blocked Ads
As you are browsing the internet, you can view this page to see what add links are being
blocked in real time. There is a whitelist section of the table in which you can click and save
which would be added to the allowed list of your AdTrap
History Blocked Ads
This allows you to see the History of the blocked ads and allows you to download the data
Privacy Blocked Ads
This allows you to see which websites that were blocked that tried to take your privacy
information.
Ad Visualizer
This allows you to see all the pictures of the blocked ads in one page.
Updates:
The AdTrap is set up to check and download updates automatically at 1am local time. This is based
on the time zone set up in the General section.

AdTrap User’s Manual | Page 15
AdTrap Anywhere
Installing AdTrap Anywhere on your iDevices (iPhones, iPads)
1. If you are in proxy mode, you must log into your router and forward TCP port 5555
to the AdTrap IP address.
2. Use iCloud or any other backup program and backup your iPhone.
3. You’ll need to put your phone into supervised mode with Apple Configurator, this is
a limitation imposed by Apple. https://itunes.apple.com/us/app/apple-
configurator/id434433123?mt=12
4. Plug in to machine with configurator, flip supervision switch to on, then click
prepare.
5. Restore your data once it’s back up.
6. Log into the AdTrap.
7. Click Settings then AdTrap Anywhere.
8. Enable AdTrap Anywhere.
9. Change the username.
10. Change the password and confirm.
11. Copy down the hostname and the port number.
12. Wait 2 hours for DNS to start propagating.
a. To test the DNS, copy(Ctrl+C) the AdTrap Anywhere Hostname located on
your AdTrap Anywhere settings table;
i. Windows –open your command prompt and type in “nslookup ” and
paste(Ctrl+V) the previously copied AdTrap Anywhere Hostname
next to it, click enter.
ii. Mac –Open terminal and type in “nslookup ” and paste(Ctrl+V) the
previously copied AdTrap Anywhere Hostname next to it, click
enterGo to your idevice
13. Click the “download mobileconfig”; it should offer to install; allow it.
14. You can remove the mobileconfig profile like this:
http://www.baylor.edu/its/index.php?id=88047, Just remove the one that says
AdTrap Anywhere. Leave the other one.

AdTrap User’s Manual | Page 16
Android Devices (Your device must be rooted)
2. If you are in proxy mode, you must log into your router and forward TCP port 5555
to the AdTrap IP address.
3. Log into your AdTrap.
4. Click Settings then AdTrap Anywhere
5. Enable AdTrap Anywhere.
6. Change the username.
7. Change the password and confirm.
8. Copy down the hostname and the port number.
9. Wait 2 hours for Hostname DNS to start reporting on servers.
a. To test the DNS, copy(Ctrl+C) the AdTrap Anywhere Hostname located on
your AdTrap Anywhere settings table;
i. Windows –open your command prompt and type in “nslookup ” and
paste(Ctrl+V) the previously copied AdTrap Anywhere Hostname
next to it, click enter.
ii. Mac –Open terminal and type in “nslookup ” and paste(Ctrl+V) the
previously copied AdTrap Anywhere Hostname next to it, click enter.
10. Go to your Android Device.
11. Go to play store and download/install proxyDroid.
12. Open proxy droid and grant permission to open.
13. Click Host and type in your hostname from step 7.
14. Click Port and type in port from Step 7.
15. Enable Authentication.
16. Type in the username and password from step 5 & 6.
17. Enable Proxy and you should be all done.

AdTrap User’s Manual | Page 17
Basic Troubleshooting
Factory Reset:
Use the factory reset to restore the AdTrap to its original state. This will also reset the
password. The updates and rules of the AdTrap will not be affected.
Steps:
1. Unplug all cables including the power.
2. Plug in the power cable only to the AdTrap.
3. On the front of the AdTrap, look for the green number 1 light to be ON. This will take 15-
30 seconds.
4. Once the light is on, wait 5 seconds.
5. Unplug the power and plug it in again.
6. Repeat steps 3-5 until you see all 4 lights flashing and wait 5 seconds.
7. Your AdTrap is now successfully reset. Unplug power and continue installing your
AdTrap.
I’m not getting on the Internet:
It may take over 5 minutes to establish a connection the first time you power up your AdTrap.
Always leave your AdTrap plugged into AC power and connected to your network.
Check the front panel lights:
The power light should be on.
The heartbeat light should be flashing.
The internet light should be flashing or on.
Check your cable connections:
Connectors should be pushed in all the way and not be pinched, kinked, or bent
sharply.
If Internet status light is flashing:
1. With everything connected, log into the AdTrap.
2. Click on the update tab and then click the update button. AdTrap will look for updates
and also does integrity check of the file system.
3. Wait 2 minutes and the Internet should be working. The 4th Internet light should also be
solid.
No Internet Status Light?
1. Do you have a blinking Heartbeat light (Light 1)?

AdTrap User’s Manual | Page 18
a. No - Unplug and plug in power on AdTrap and wait 30 seconds for Heartbeat
light.
b. Yes - Continue to Step 2.
2. Turn off modem, Adtrap and router. Reset the modem (Some modems have a battery
pack which needs to be removed or a reset button)
3. Wait about 2 minutes for modem to turn on and then turn on AdTrap and router
4. Once you have Internet light, wait about 2 more minutes and check for Internet
connectivity.
I can get on the Internet, but everything is slow;
1. If the website you are visiting is very popular, that site may be having trouble servicing
all the requests. If other sites download quickly, wait for a few minutes and try again. If
you notice all network activity is slow. Restart all your devices on the network.
2. If the network still seems slow, go into the AdTrap settings and make sure all the
updates are current.
3. Please contact AdTrap technical support if you need any additional help.
[e-mail]
Toll Free [phone]
Monday through Friday from 10-6 Pacific Time
AT1000
Version 2.0
www.getadtrap.com
Copyright ©2009-2014 BluePoint Security, Inc. All rights reserved
All information contained in this document is subject to change without notice. AdTrap reserves the right to make changes to
equipment design or program components, as progress in engineering, manufacturing methods, or other circumstances may warrant.
AdTrap and the AdTrap logo, are trademarks of BluePoint Security, Inc. All other trademarks and registered trademarks in any part of this document are the property
of their respective owners.
