Bluesound Professional A860 User manual

WHAT’S IN THE BOX
CONNECT
SPEAKER WIRES TO SPEAKER CONNECTOR AND INSTALL TO A860
CONNECT
ANALOG SOURCE USING GLOBAL INPUT
NOTES
• Download the latest A860 Owner’s manual from the Manuals/Downloads tab of www.bluesoundprofessional.com/product/A860
• Visit support.bluesound.com for further assistance and information about getting the most out of the A860.
External Device
x1 / x2 / x3 / x4
A860 Multi-Channel Amplier
Quick Setup Guide
Speaker connector x 4 12V Trigger connector x 1 Input/output connector x 10
NOTE: Connected speakers are for illustration purposes only. Speakers to be connected are dependent upon availability.
Mains AC cord x 2 Feet x 4 Screws x 4

©2019 BLUESOUND PROFESSIONAL, A DIVISION OF LENBROOK INDUSTRIES LIMITED
All rights reserved. Bluesound and Bluesound logo are trademarks of Bluesound Professional, a division of Lenbrook Industries Limited.
No part of this publication may be reproduced, stored or transmitted in any form without the written permission of Bluesound Professional.
A860QSENV07  AUG 2019
POWER UP!
Mains AC Power
1
3
2
CONNECT
ANALOG SOURCES USING LOCAL INPUT
External Device
x1 / x2 / x3 / x4
NOTE: The number of sources are for illustration purposes only. Sources to be connected are dependent upon availability.
NOTE: Adjust corresponding Gain control
of active Global or Local inputs.
