BMW Motorrad F 850 GS Adventure 2019 Installation and maintenance manual

Rider's Manual
F 850 GS Adventure
BMW Motorrad

Vehicle data/dealership details
Vehicle data
Model
Vehicle Identification Number
Colour code
Date of first registration
Registration number
Dealership details
Person to contact in Service department
Ms/Mr
Phone number
Dealership address/phone number (com-
pany stamp)

Welcome to BMW
We congratulate you on
your choice of a vehicle from
BMW Motorrad and welcome
you to the community of BMW
riders. Familiarise yourself with
your new vehicle so that you can
ride it safely and confidently in all
traffic situations.
About these operating
instructions
Read these operating instructions
carefully before starting to use
your new BMW. They contain
important information on how to
operate the controls and how to
make the best possible use of all
your BMW's technical features.
In addition, they contain informa-
tion on maintenance and care to
help you maintain your vehicle's
reliability and safety, as well as its
value.
The record of the maintenance
work you have had performed on
your vehicle is a precondition for
generous treatment of goodwill
claims.
If the time comes to sell your
BMW, please remember to hand
over these operating instructions
to the new owner. They are an
important part of the vehicle.
Suggestions and criticism
If you have questions concern-
ing your vehicle, your authorised
BMW Motorrad dealer will gladly
provide advice and assistance.
We hope you will enjoy riding
your BMW and that all your jour-
neys will be pleasant and safe
BMW Motorrad.
01 40 9 446 871
*01409446871*
*01409446871*
*01409446871*

Table of Contents
1 General instructions ... . 7
Overview..................... 8
Abbreviations and
symbols...................... 8
Equipment ................... 9
Technical data . . . . . . . . . . . . . . . 9
Currency .................... 10
Additional sources of inform-
ation......................... 10
Certificates and operating
licences ..................... 10
Data memory................ 10
Intelligent emergency call
system ...................... 14
2 General views .. .. .. .. .. . 19
General view, left side . . . . . . . 21
General view, right side . . . . . 23
Underneath the seat . . . . . . . . 24
Multifunction switch, left . . . . 25
Multifunction switch,
right......................... 27
Instrument panel . . . . . . . . . . . . 28
Instrument cluster with Con-
nectivity ..................... 29
3 Status indicators . . . . . . . 31
Overview, displays. . . . . . . . . . . 32
Warning indicator lights . . . . . 36
Overview, displays with con-
nectivity ..................... 55
Indicator lights with Con-
nectivity ..................... 61
4 Operation................ 85
Ignition switch/steering
lock ......................... 86
Ignition with Key-
less Ride .................... 87
Electronic immobiliser
EWS ........................ 91
Emergency off switch (kill
switch) ...................... 91
Intelligent emergency
call .......................... 92
Lights ....................... 95
Daytime riding light . . . . . . . . . . 97
Hazard warning flashers . . . . . 99
Turn indicators . . . . . . . . . . . . . . 99
Multifunction display . . . . . . 100
SETUP.................... 102
Date and time . . . . . . . . . . . . . 103
General settings in the mul-
tifunction display . . . . . . . . . . 105
Antilock Brake System
(ABS)...................... 107
Traction control (ASC/
DTC)...................... 108
Electronic Suspension Ad-
justment (DESA) . . . . . . . . . 110
Riding mode . . . . . . . . . . . . . . 113
PRO riding mode . . . . . . . . . 116
PRO riding mode with con-
nectivity ................... 118
Cruise-control system . . . . . 119
Tyre pressure control
(RDC) ..................... 122
Heated handlebar grips . . . 122
Seat....................... 124
Operating instructions . . . . . 125

5 TFT display ... .. .. .. .. 127
General instructions . . . . . . . 128
Principle................... 129
Pure Ride view . . . . . . . . . . . . 135
General settings . . . . . . . . . . . 136
Bluetooth.................. 138
My vehicle ................ 141
On-board computer . . . . . . . 144
Navigation................. 144
Media ..................... 146
Telephone ................ 147
Display software
version .................... 148
Display licence informa-
tion........................ 148
6 Anti-theft alarm. . . . . . . 149
Overview.................. 150
Activation ................. 150
Alarm function. . . . . . . . . . . . . 152
Deactivation . . . . . . . . . . . . . . . 153
Programming . . . . . . . . . . . . . . 153
7 Adjustment . .. .. .. .. .. . 155
Mirrors .................... 156
Headlight.................. 156
Windscreen . . . . . . . . . . . . . . . 157
Clutch..................... 157
Brakes .................... 158
Shift mechanism . . . . . . . . . . 159
Spring preload . . . . . . . . . . . . 160
Damping .................. 161
8 Riding.................. 163
Safety instructions . . . . . . . . 164
Comply with checklist . . . . . 167
When changing the load
status:..................... 167
Always before riding
off: ........................ 167
Every 3rd refuelling
stop: ...................... 167
Starting.................... 167
Runningin ................ 171
Shifting gear . . . . . . . . . . . . . . 172
Off-roading . . . . . . . . . . . . . . . . 173
Brakes .................... 174
Parking your motor-
cycle ...................... 176
Refuelling ................. 177
Securing motorcycle for
transportation . . . . . . . . . . . . . 181
9 Engineering
details ................. 183
General instructions . . . . . . . 184
Antilock Brake System
(ABS)...................... 184
Traction control (ASC/
DTC)...................... 187
Riding mode . . . . . . . . . . . . . . 189
Tyre pressure control
(RDC) ..................... 191
Gear Shift Assistant . . . . . . . 192
10 Maintenance .. ... ... . 195
General instructions . . . . . . . 196
Toolkit..................... 196
Service tool kit . . . . . . . . . . . . 197
Front-wheel stand . . . . . . . . . 197
Engine oil ................. 198
Brake system . . . . . . . . . . . . . 200
Clutch..................... 205
Coolant.................... 206
Tyres...................... 208
Rims and tyres . . . . . . . . . . . . 208
Wheels.................... 209
Air filter.................... 218
Lighting ................... 219

Body panels . . . . . . . . . . . . . . . 222
Jump-starting . . . . . . . . . . . . . 223
Battery .................... 224
Fuses ..................... 228
Diagnostic connector . . . . . . 229
Chain...................... 230
11 Accessories .. .. .. .. . 233
General instructions . . . . . . . 234
Power sockets . . . . . . . . . . . . 234
Cases ..................... 235
Topcase................... 237
Navigation system . . . . . . . . . 239
12 Care .................. 245
Care products . . . . . . . . . . . . . 246
Washing the vehicle . . . . . . . 246
Cleaning easily damaged
components . . . . . . . . . . . . . . . 247
Care of paintwork . . . . . . . . . 248
Vehicle preservation . . . . . . . 248
Laying up the motor-
cycle ...................... 248
Restoring motorcycle to
use........................ 249
13 Technical data . . . . . . 251
Troubleshooting chart . . . . . 252
Screw connections . . . . . . . . 254
Fuel....................... 256
Engine oil ................. 256
Engine .................... 257
Clutch..................... 258
Transmission . . . . . . . . . . . . . . 258
Final drive ................. 259
Frame..................... 259
Chassis and
suspension................ 259
Brakes .................... 260
Wheels and tyres. . . . . . . . . . 261
Electrical system . . . . . . . . . . 263
Dimensions . . . . . . . . . . . . . . . 265
Weights ................... 266
Performance figures . . . . . . . 266
14 Service ............... 267
BMW Motorrad Service . . . 268
BMW Motorrad Service
history..................... 268
BMW Motorrad mobility
services ................... 269
Maintenance work . . . . . . . . . 269
Maintenance schedule . . . . 271
Maintenance confirma-
tions....................... 272
Service confirmations . . . . . 286
15 Appendix. . . . . . . . . . . . . 289
Declaration of conform-
ity for electronic immobil-
iser........................ 290
Certificate for electronic
immobiliser . . . . . . . . . . . . . . . . 296
Declaration of conformity
for Keyless Ride . . . . . . . . . . . 298
Certificate for Key-
less Ride .................. 303
Declaration of conformity
for tyre pressure control
(RDC) ..................... 305
Certificate for tyre pressure
control (RDC) . . . . . . . . . . . . . 312
Declaration of conformity
for TFT instrument
cluster..................... 313
Certificate for TFT instru-
ment cluster . . . . . . . . . . . . . . . 319

Declaration of conformity
for intelligent emergency
call ........................ 322
Declaration of conform-
ity for anti-theft alarm sys-
tem ....................... 328
16 Index ................. 334

General instructions
Overview ............................ 8
Abbreviations and symbols . . . . . . . . . . 8
Equipment........................... 9
Technicaldata....................... 9
Currency............................ 10
Additional sources of informa-
tion ................................. 10
Certificates and operating
licences............................. 10
Datamemory ....................... 10
Intelligent emergency call
system.............................. 14
1
7
z General instructions

Overview
Chapter 2 of this Rider's Manual
will provide you with an initial
overview of your motorcycle. All
maintenance and servicing work
on the vehicle is documented in
Chapter 14. The record of the
maintenance work you have had
performed on your vehicle is a
precondition for generous treat-
ment of goodwill claims.
If the time comes to sell your
BMW, please remember to hand
over these operating instructions
to the new owner. They are an
important part of the motorcycle.
Abbreviations and
symbols
CAUTION Low-risk hazard.
Non-avoidance can lead to
slight or moderate injury.
WARNING Medium-risk
hazard. Non-avoidance can
lead to fatal or severe injury.
DANGER High-risk haz-
ard. Non-avoidance leads
to fatal or severe injury.
ATTENTION Special
notes and precautionary
measures. Non-compliance can
lead to damage to the vehicle or
accessory and, consequently, to
voiding of the warranty.
NOTICE Specific instruc-
tions on how to operate,
control, adjust or look after items
of equipment on the vehicle.
Indicates the end of an
item of information.
Instruction.
Result of an activity.
Reference to a page with
more detailed informa-
tion.
Indicates the end of a
passage relating to spe-
cific accessories or items
of equipment.
Tightening torque.
Technical data.
NV National-market version.
OE Optional equipment.
The vehicles are as-
sembled complete with
all the BMW Motorrad
optional equipment ori-
ginally ordered.
1
8
z General instructions

OA Optional accessories.
You can obtain
BMW Motorrad
optional accessories
through your authorised
BMW Motorrad dealer;
optional accessories
have to be retrofitted to
the vehicle.
ABS Anti-lock brake system.
ASC Automatic Stability Con-
trol.
EWS Electronic immobiliser.
D-
ESA
Electronic chassis and
suspension adjustment.
DTC Dynamic Traction Con-
trol (optional extra only
in combination with Pro
riding modes).
DWA Anti-theft alarm.
RDC Tyre pressure monitor-
ing.
Equipment
When you purchased your BMW
motorcycle, you chose a model
with individual equipment. These
operating instructions describe
the optional equipment (OE)
offered by BMW and selected
optional accessories (OA).
This explains why the manual
may also contain descriptions
of equipment that you might
not have selected. Please
note, too, that on account of
country-specific differences, your
motorcycle might not be exactly
as illustrated.
If your motorcycle contains
equipment that has not been
described, its description can be
found in a separate manual.
Technical data
All dimensions, weights and
power ratings stated in the
operating instructions are quoted
to the standards and comply with
the tolerance requirements of the
Deutsches Institut für Normung
e.V. (DIN).
Technical data and specifications
in this rider's manual serve as
reference points. The vehicle-
specific data may deviate from
these, for example as a result of
selected optional equipment,
the national-market version or
country-specific measuring
procedures. Detailed values
can be taken from the vehicle
registration documents and
signs on the vehicle, or can be
obtained from your authorised
BMW Motorrad Retailer or
another qualified service partner
or specialist workshop. The
specifications in the vehicle
documents always have priority
1
9
z General instructions

over the information provided in
this rider's manual.
Currency
The high safety and quality
standards of BMW motorcycles
are maintained by constant
development work on designs,
equipment and accessories.
Because of this, your motorcycle
may differ from the information
supplied in these instructions.
Nor can BMW Motorrad entirely
rule out errors and omissions.
We hope you will appreciate that
no claims can be entertained on
the basis of the data, illustrations
or descriptions in these operating
instructions.
Additional sources of
information
Authorised BMW Motorrad
dealer
Your BMW Motorrad Retailer will
be happy to answer any ques-
tions you may have.
Internet
The rider's manual for your
vehicle, operating and installation
instructions for any accessories
and general information on
BMW Motorrad, for example
relating to technology, are
available at www.bmw-
motorrad.com/service.
Certificates and
operating licences
The certificates for the vehicle
and the official operating licences
for any accessories are available
at www.bmw-motorrad.com/
certification.
Data memory
General
Control units are installed in the
vehicle. Control units process
data that they receive, for ex-
ample, from vehicle sensors, or
that they generate themselves or
exchange between each other.
Some control units are required
for the vehicle to function safely
or provide assistance during rid-
ing, for example assistance sys-
tems. In addition, control units
enable comfort or infotainment
functions.
Information on data that has
been stored or exchanged can
be obtained from the manufac-
turer of the vehicle, for example
via a separate booklet.
Personal reference
Each vehicle is identified with a
clear vehicle identification num-
ber. Depending on the country,
the vehicle identification num-
1
10
z General instructions

ber, the number plate and the
corresponding authorities can
be referenced to ascertain the
vehicle owner. There are also
other ways to use data obtained
from the vehicle to trace the rider
or vehicle owner, for example
using the ConnectedDrive user
account.
Data protection rights
In accordance with applicable
data protection laws, vehicle
users have certain rights in re-
lation to the manufacturer of the
vehicle or in relation to compan-
ies which collect or process per-
sonal data.
Vehicle users have the right to
obtain full information at no cost
from persons or entities storing
personal data of the vehicle user.
These entities may include:
Manufacturer of the vehicle
Qualified service partners
Specialist workshops
Service providers
Vehicle users have the right to
request information on what per-
sonal data has been stored, for
what purpose the data is used,
and where the data comes from.
To obtain this information, proof
of ownership or use is required.
The right to information also in-
cludes information about data
that has been shared with other
companies or entities.
The website of the vehicle man-
ufacturer contains the applicable
data protection information. This
data protection information in-
cludes information on the right to
have data deleted or corrected.
The manufacturer of the vehicle
also provides their contact details
and those of the data protection
officer on their website.
The vehicle owner can also re-
quest that a BMW Motorrad Re-
tailer or another qualified service
partner or specialist workshop
read out the data that is stored in
the vehicle for a charge.
The vehicle data is read out us-
ing the legally prescribed socket
for on-board diagnosis (OBD) in
the vehicle.
Legal requirements for the
disclosure of data
As part of its legal responsib-
ilities, the manufacturer of the
vehicle is obligated to make its
stored data available to the rel-
evant authorities. This data is
provided in the required scope in
individual cases, for example to
clarify a criminal offence.
In the context of applicable laws,
public agencies are entitled in
individual cases to read out data
from the vehicle themselves.
1
11
z General instructions

Operating data in the vehicle
Control units process data to op-
erate the vehicle.
This includes, for example:
Status reports of the vehicle
and its individual components,
for example wheel revolutions,
wheel speed, deceleration
Environmental conditions, for
example temperature
The data is only processed in
the vehicle itself and is gener-
ally non-permanent. The data is
not stored beyond the operating
period.
Electronic components, for ex-
ample control units, contain com-
ponents for storing technical in-
formation. Information can be
temporarily or permanently stored
on the vehicle condition, com-
ponent loads, incidents or errors.
This information is generally used
to document the condition of a
component, a module, a system
or the surrounding area, for ex-
ample:
Operating conditions of system
components, for example filling
levels, tyre pressure
Malfunctions and faults in im-
portant system components,
for example light and brakes
Response of the vehicle in
special riding situations, for
example engagement of the
driving dynamics systems
Information on incidents result-
ing in damage to the vehicle
The data is necessary for the
provision of control unit functions.
Furthermore, the data is used to
detect and rectify malfunctions
and to enable the vehicle manu-
facturer to optimise vehicle func-
tions.
The vast majority of this data is
non-permanent and is only pro-
cessed in the vehicle itself. Only
a small amount of the data is
stored in incident or fault memor-
ies as required by events.
If services are accessed, for ex-
ample repairs, service processes,
warranty cases and quality assur-
ance measures, this technical in-
formation can be read out of the
vehicle together with the vehicle
identification number.
The information can be read out
by a BMW Motorrad Retailer or
another qualified service part-
ner or specialist workshop. The
legally stipulated socket for on-
board diagnosis (OBD) in the
vehicle is used to read out the
data.
The data is obtained, processed
and used by the relevant parts of
the retailer network. The data is
used to document the technical
conditions of the vehicle, to help
with error localization, to comply
with warranty obligations and to
improve quality.
1
12
z General instructions

In addition, the manufacturer has
various product monitoring ob-
ligations arising from product li-
ability legislation. To meet these
obligations, the vehicle manu-
facturer requires technical data
from the vehicle. The data from
the vehicle can also be used to
check warranty claims from the
customer.
Error and incident memories in
the vehicle can be reset dur-
ing servicing or repair work by
a BMW Motorrad Retailer or an-
other qualified service partner or
specialist workshop.
Data input and data transfer
in the vehicle
General
Depending on the equipment,
comfort and customised settings
can be stored in the vehicle and
can be changed or reset at any
time.
This includes, for example:
Settings of the windscreen po-
sition
Chassis and suspension set-
tings
If required, data can be entered
in the entertainment and commu-
nication system of the vehicle, for
example using a smartphone.
Depending on the individual
equipment, this includes:
Multimedia data, such as music
for playback
Contacts data for use in con-
nection with a communication
system or an integrated naviga-
tion system
Entered destinations
Data on the use of internet
services. This data can be
stored locally in the vehicle
or is located on a device that
is connected to the vehicle,
for example smartphone, USB
stick, MP3 player. If this data is
stored in the vehicle, the data
can be deleted at any time.
This data is transferred to third
parties only if personally reques-
ted within the context of using
online services. This depends on
the selected settings when using
the services.
Incorporation of mobile end
devices
Depending on the equipment,
mobile end devices connected to
the vehicle, for example smart-
phones, can be controlled using
the operating elements of the
vehicle.
The image and sound of the mo-
bile end device can then be out-
put via the multimedia system.
At the same time, specific in-
formation is transferred to the
mobile end device. Depending
on the type of integration, this in-
cludes, for example, position data
and additional general vehicle in-
1
13
z General instructions

formation. This enables optimal
use of the selected apps, for ex-
ample navigation or music play-
back.
The type of additional data pro-
cessing is determined by the
provider of the respective app.
The scope of the possible set-
tings depends on the corres-
ponding app and the operating
system of the mobile end device.
Services
General
If the vehicle has a wireless con-
nection, this enables the ex-
change of data between the
vehicle and other systems. The
wireless connection is enabled by
the vehicle's own transmitter and
receiver unit or using personally
integrated mobile end devices,
for example smartphones. On-
line functions can be used using
this wireless connection. These
include online services and apps
that are provided by the vehicle
manufacturer or by other pro-
viders.
Services of the vehicle manu-
facturer
For online services of the vehicle
manufacturer, the individual
functions are described at
suitable points, for example
rider's manual, website of the
manufacturer. At the same time,
information is also provided on
the relevant data protection law.
Personal data may be used to
provide online services. Data
is exchanged using a secure
connection, for example with
the IT systems provided by the
vehicle manufacturer.
Obtaining, processing and us-
ing personal data outside of the
normal provision of services re-
quires legal permission, contrac-
tual agreement or consent. It is
also possible to have the entire
data connection activated or de-
activated. Statutory functions are
excluded from this.
Services from other providers
When using online services from
other providers, these services
are subject to the responsibil-
ity and the data protection and
operating conditions of the indi-
vidual provider. The vehicle man-
ufacturer has no influence on the
content that is exchanged in this
instance. Information on the type,
scope and purpose of the data
capture and use of personal data
as part of the services of third
parties can be ascertained from
the individual provider.
Intelligent emergency
call system
with intelligent emergency
callOE
1
14
z General instructions

Principle
The intelligent emergency call
system enables manual or auto-
matic emergency calls, for ex-
ample in the event of an acci-
dent.
The emergency calls are re-
ceived by an emergency call
centre that is commissioned by
the vehicle manufacturer.
For information on operating the
intelligent emergency call system
and its functions, please refer to
"Intelligent emergency call".
Legal basis
Processing of personal data us-
ing the intelligent emergency call
system is in line with the follow-
ing regulations:
Protection of personal data:
Directive 95/46/EC of the
European Parliament and of the
Council.
Protection of personal data:
Directive 2002/58/EC of the
European Parliament and of the
Council.
The legal basis for the activa-
tion and function of the intelli-
gent emergency call system is
the concluded ConnectedRide
contract for this function, as well
as the corresponding laws, or-
dinances and directives of the
European Parliament and of the
European Council.
The relevant ordinances and dir-
ectives regulate the protection of
natural persons during the pro-
cessing of personal data.
The processing of personal data
by the intelligent emergency call
system satisfies the European
directives for the protection of
personal data.
The intelligent emergency call
system processes personal data
only with the agreement of the
vehicle owner.
The intelligent emergency call
system and other services with
additional benefits may only pro-
cess personal data with the ex-
press permission of the person
affected by the data processing,
for example the vehicle owner.
SIM card
The intelligent emergency call
system is operated by mobile ra-
dio using the SIM card installed
in the vehicle. The SIM card is
permanently logged into the mo-
bile phone network to enable
rapid connection setup. Data is
sent to the vehicle manufacturer
in the event of an emergency.
Improving quality
The data that is transferred in
an emergency is also used by
the manufacturer of the vehicle
1
15
z General instructions

to improve product and service
quality.
Location determination
The position of the vehicle can
be determined exclusively by
the mobile phone network pro-
vider based on the mobile phone
site locations. The provider can-
not link the vehicle identifica-
tion number and phone number
of the installed SIM card. Only
the manufacturer of the vehicle
can link the vehicle identification
number and phone number of
the installed SIM cards.
Log data of emergency calls
The log data of emergency calls
is stored in a memory of the
vehicle. The oldest log data is
regularly deleted. The log data
includes, for example, information
on when and where an emer-
gency call was made. In excep-
tional cases, the log data can be
read out of the vehicle memory.
As a rule, log data is only read
out following a court order, and
this is only possible if the corres-
ponding devices are connected
directly to the vehicle.
Automatic emergency call
The system is designed so that,
following a sufficiently serious
accident, which is detected by
sensors in the vehicle, an emer-
gency call is automatically activ-
ated.
Sent information
When making an emergency call
using the intelligent emergency
call system, the system forwards
the same information to the des-
ignated emergency call centre as
is forwarded to the public emer-
gency operations centre by the
statutory emergency call system
eCall.
In addition, the intelligent emer-
gency call system sends the fol-
lowing additional information to
an emergency call centre com-
missioned by the vehicle man-
ufacturer and, if required, to the
emergency services:
Accident data, for example the
direction of impact detected
by the vehicle sensors, to as-
sist the emergency services
response.
Contact details, for example the
phone number of the installed
SIM card and the phone num-
ber of the rider, if available, to
enable rapid contact with those
involved in the accident if re-
quired.
Data storage
The data for an activated
emergency call is stored in
the vehicle. The data contains
information on the emergency
1
16
z General instructions

call, for example the location and
time of the emergency call.
The voice recordings of the
emergency call are stored at the
emergency call centre.
The voice recordings of the cus-
tomer are stored for 24 hours in
case details of the emergency
call need to be analysed. After
this, the voice recordings are
deleted. The voice recordings
of the employee of the emer-
gency call centre are stored for
24 hours for quality assurance
purposes.
Information on personal data
The data that is processed as
part of the intelligent emergency
call is processed exclusively to
carry out the emergency call. As
part of its statutory obligation,
the manufacturer of the vehicle
provides information about the
data that it has processed and
any data that it still has stored.
1
17
z General instructions

1
18
z General instructions
