Rider’s Manual (US Model)
R 1150 RS
BMW Motorrad
On-board
documentation
consisting of
Rider's Manual
and Maintenance
Instructions


This symbol indicates pre-
cautions and measures which
are essential in pro-tecting
the rider or other persons
from severe or fatal injury.

Specific instructions and safety
precautions intended to pre-
vent damage to the motorcycle.
Disregarding them may render
the warranty invalid.

Specific instructions on how to
operate, control, adjust or look
after items of equipment on the
motorcycle.
Important notes
10rsbku2.book Seite 86 Montag, 13. Januar 2003 2:05 14

1
Introduction
i
Welcome to BMW
We congratulate you on your
choice of a motorcycle from
BMW and welcome you to the
community of BMW riders.
Familiarize yourself with your
new motorcycle, so that you
can ride it safely and confidently
in all traffic situations.
To make sure of this, please
read this Rider’s Manual care-
fully before starting to use your
new motorcycle. It contains
important information on how to
operate the controls and how to
make the best possible use of
all the motorcycle’s technical
features.
In addition, it contains useful
hints and information on the
correct equipment for machine
and rider, to ensure maximum
reliability and safety, and advice
on how to maintain the value of
your motorcycle.
If you have any questions con-
cerning your motorcycle, your
BMW motorcycle retailer will
gladly provide advice and assis-
tance.
We hope you enjoy reading this
Rider’s Manual and wish you
many a pleasant, safe journey
on your BMW motorcycle.
Best wishes,
BMW Motorrad
Welcome to BMW
10rsbku2.book Seite 1 Montag, 13. Januar 2003 2:05 14

i
2
Introduction
General information and
controls
General view, left side ........... 4
General view, right side......... 5
Cockpit ................................. 6
Indicator and warning lights .. 7
Ignition switch and steering
lock ....................................8-9
Adjusting windshield ........... 10
Hazard warning flashers ...... 11
Left handlebar fitting ........... 12
Right handlebar fitting ......... 13
Adjusting handlebars .....14-15
Seat ...............................16-17
System case ..................18-19
Safety check
Checklist........................ 20-21
Engine oil ....................... 22-23
Fuel................................ 24-25
Handlebar levers ............26-27
Brake system
- general ........................ 28-29
Brake system - without
BMW Integral ABS ......... 30-33
Brake system - with
BMW Integral ABS ......... 34-36
Clutch ................................. 37
Lights............................. 38-42
Shock-absorber settings..... 43
Suspension spring preload . 44
Wheels...........................45-46
Accessories and tires.......... 47
Loading..........................48-49
Contents
10rsbku2.book Seite 2 Montag, 13. Januar 2003 2:05 14

3
i
Introduction
Starting – Riding – Parking
First time out ................. 50-51
Important notes ............. 52-53
Side stand ..................... 54-55
Main (center) stand........ 56-57
Running in ..................... 58-59
Before you start............. 60-61
Starting ......................... 62-63
Indicator and
warning lights ................ 64-65
Rider information
Display (FID) .................. 66-67
Riding and
changing gear ............... 68-69
Brake system
- general........................ 70-71
- with BMW Integral ABS 72-78
BMW Integral ABS
- Troubleshooting chart .......79
Arrive safely!
Arrive safely....................80-81
Service worldwide ............... 82
Environmental protection .... 83
BMW rider’s equipment....... 84
BMW motorcycle equipment85
Training means extra safety. 86
Concluding thoughts........... 87
Index ..............................88-92
Contents
10rsbku2.book Seite 3 Montag, 13. Januar 2003 2:05 14

1
General information and controls
4
987
1243 5 6
10
11
12
1Front forks, shock-absorber
setting (b43)
2Reservoir for clutch fluid (b37)
3Oil filler neck, engine (b23)
4Lifting handle (b56, 57)
5Helmet holder, left
6Storage compartment for tool-
kit (supplied) (bMaintenance
Instructions, Chapter 2)
7Rear suspension strut,
shock-absorber setting (b43)
8Rear suspension strut,
spring preload (b44)
OA Optional accessories
9Power socket, 12VOA
Provision for connecting
additional equipment –
max. load 5 A
10 Primary spark plug, left
(bMaintenance Instructions,
Chapter 2)
11 Secondary spark plug, left
(bMaintenance Instructions,
Chapter 2)
12 Oil level sight glass, engine
(b23)
( ) Figure in parentheses
bpage number for description
General view, left side
10rsbku2.book Seite 4 Montag, 13. Januar 2003 2:05 14

1
General information and controls
5
22 19
20
21
13 14 16
15 17 18
13 Seat lock (b16)
14 Helmet holder, right
15 Fuse box (bMaintenance
Instructions, Chapter 2)
16 Air filter (bMaintenance
Instructions, Chapter 2)
17 Fuel filler cap (b25)
18 Brake fluid reservoir forfront
brakes (b31, 35)
19 Type plate/vehicle identifi-
cation number
20 Primary spark plug, right
(bMaintenance
Instructions, Chapter 2)
21 Secondary spark plug, right
(bMaintenance
Instructions, Chapter 2)
22 Brake fluid reservoir for rear
brakes (b32, 36)
( ) Figure in parentheses
bpage number for description
General view, right side
10rsbku2.book Seite 5 Montag, 13. Januar 2003 2:05 14

1
General information and controls
6
1Reset knob for
trip meter
2Trip distance recorder
3Speedometer
4Odometer
5Adjusting knob for wind-
shield (b10)
6Tachometer (b58)
7Rider Information Display
(FID) (b66, 67)
8Indicator and warning lights
(b7)
9Ignition switch and steering
lock (b8, 9)
( ) Figure in parentheses
bpage number for description
Cockpit
52
1673 4
8
9
10rsbku2.book Seite 6 Montag, 13. Januar 2003 2:05 14

1
General information and controls
7
1 2 4
3567
9 8
1Indicator lights Left turn
indicator repeater green s
2Warning light battery charge
red r(b64)
3Warning light Tank capac-
ity/when approx. 1.06 gal
(4 liters) remain in tank
orange m (b24, 25)
4Indicator lights Transmis-
sion neutral indicator green
k(b61)
OE Optional equipment
5Warning light ABS lred OE
(b64)
6Warning light engine oil
pressure red p (b65)
7Indicator light Right turn
indicator repeater green t
8General warning light
red e (b64)
9High-beam headlight indi-
cator blue q
( ) Figure in parentheses
bpage number for description
Indicator and warning lights
10rsbku2.book Seite 7 Montag, 13. Januar 2003 2:05 14

1
General information and controls
8
Ignition key

If the motorcycle is fitted with
BMW Integral ABSOE, only RE-
SIDUAL BRAKING FUNCTION-
ALITY is available when the
ignition is switched off (b75).
You will receive two master
keys and one spare key.
The key number is on the
accompanying plastic tag.

The ignition switch and steering
lock, fuel filler cap and the hel-
met/seat lock are all operated
with the same key. System
casesOA with locks for the
same key can be ordered on re-
quest.
OA Optional accessories
OE Optional equipment
Ignition switch and steering lock
10rsbku2.book Seite 8 Montag, 13. Januar 2003 2:05 14

1
General information and controls
9
Key positions

Never turn the key to OFF or I
while riding the motorcycle!
ON Operating position,
ignition, lights and all
electrical circuits
switched on
R * Ignition and lights off,
steering lock disengaged
(handlebars can be turned
freely to left or right)
* The key can be removed in these
positions
• Turn the handlebars to full left
lock.

Engage the steering lock with
the handlebars in this position
only.
OFF* Ignition and lights off,
steering locked
I* *Parking light on,
steering locked

Switch the parking light on
only for limited periods. Note
state of battery charge.
Ignition switch and steering lock
10rsbku2.book Seite 9 Montag, 13. Januar 2003 2:05 14

1
General information and controls
10
1
B
A
B
A
Adjusting windshield

For safety reasons, do not re-
position the mechanically ad-
justable windshield while
riding the motorcycle.
Always halt the motorcycle
before adjusting.
• Briefly press adjusting knob 1
– The knob pops out
• Turn in direction Aor Bto
reposition
– Press knob 1back in
Adjusting windshield
10rsbku2.book Seite 10 Montag, 13. Januar 2003 2:05 14

1
General information and controls
11
Hazard warning lights

You cannot activate the hazard
warning flashers if the ignition is
switched off.
Do not use the hazard warning
flashers for longer than abso-
lutely necessary.
Note state of battery charge.
Switching on the hazard
warning lights:
• Switching on the ignition
– Hazard warning lights
switch 1up
• Actuate hazard warning lights
switch 1
– Hazard warning lights in oper-
ation
– The left/right flashing turn
indicator on the indicator light
panel (b7) flashes
• Switch off the ignition
– The hazard warning lights
continue to operate
– The light in the hazard warn-
ing flasher switch goes out
Switching off the hazard
warning lights:
• Actuate hazard warning lights
switch 1
– Hazard warning lights switch
off
– Left/Right flashing turn indica-
tor on the indicator light panel
(b7) off
Hazard warning flashers
1
10rsbku2.book Seite 11 Montag, 13. Januar 2003 2:05 14

1
General information and controls
12

To prevent air from entering
the clutch system:
• Do not turn the handlebar
controls on the handlebar.
1Lever for cold start
(fast idle)
(b62, 63)
2Hazard warning flasher
switch (b11)
3Horn button
4Left turn indicator switch
•Press
– Turn indicators operate
To switch off turn indicators:
• Press turn indicator can-
cel switch 9
5High/low (dipped) beam
headlight switch
FHigh-beam headlight
GLow (dipped) beam
FHeadlight flasher
Left handlebar fitting
1 2
5
4
3
10rsbku2.book Seite 12 Montag, 13. Januar 2003 2:05 14

1
General information and controls
13
678
10 9

To prevent air from entering
the brake system:
• Do not turn the handlebar
controls on the handlebar.
6Switch for heated handlebar
gripsOE
OHeating off
.50% (center position)
.. 100%
7Starter button
8Emergency off (kill) switch
for ignition (b60)
9Turn indicator cancel switch
•Press
– Left/right turn indicators
off
10 Turn indicator switch, right
•Press
– Turn indicators operate
To switch off turn indicators:
• Press turn indicator cancel
switch 9
OE Optional equipment
Right handlebar fitting
10rsbku2.book Seite 13 Montag, 13. Januar 2003 2:05 14

1
General information and controls
14

To ensure that no air enters
the brake or clutch hydraulic
circuits:
• Do not turn the handlebar
controls on the handlebar.

When adjusting the handle-
bars, attention must be paid
to insure that the individual
handlebars are positioned
symmetrically. Make sure that
lines and cables run correctly.
Avoid damage to electrical
wiring.
Retaining screw 1 must
always be tightened to the
correct torque value.
If you do not have a suitable
torque wrench, have the han-
dlebars adjusted by an autho-
rized BMW Motorcycle
retailer.
Adjusting handlebars
1
10rsbku2.book Seite 14 Montag, 13. Januar 2003 2:05 14

1
General information and controls
15
A
B
Adjusting reach A/B
• Slacken, but do not fully
remove screw 1
• Remove holder from serra-
tions
• Move in direction Aor Buntil
reach is correct
• Re-assemble the holder cor-
rectly in its retaining serra-
tions
Tighten the retaining screw 1to
a torque of 20 Nm
Adjusting handlebars
10rsbku2.book Seite 15 Montag, 13. Januar 2003 2:05 14

1
General information and controls
16
Removing seat
• Turn the key in the helmet/
seat lock to position Aand
hold it in this position
• Lift off the rear seat in the
direction indicated by
arrow 1.
– You now have access to the
toolkit, the emergency kit and
the on-board documentation.
You can also remove the front
seat.
• Remove the front seat by pull-
ing it up and to the rear, in the
direction indicated by
arrow 2.
– You now have access to the
fuses
(bMaintenance Instructions,
Chapter 2)
A
2
1
Seat
3
10rsbku2.book Seite 16 Montag, 13. Januar 2003 2:05 14

1
General information and controls
17
AB
C
Adjusting seat
Front seat

When installing the seat, make
sure that it is firmly locked.
Make sure the seat is at the
same height in the front and
rear mounts.
– Remove the rear seat
• Take off the front seat
There are three rider's seat
height positions:
•A= high B= center
C= low
• Guide the front seat into the
appropriate catches at front
and rear
Rear seat

When installing the seat, make
sure that it is firmly locked.
• Working from the rear, slide
the rear seat into position at
the top and press gently into
the holder (arrow) to secure
Seat
10rsbku2.book Seite 17 Montag, 13. Januar 2003 2:05 14

1
General information and controls
18
A3
2
1

After an accident or if the
motorcycle has fallen over,
check that the system cases
are correctly secured!
Max. load per system case:
22 lb (10 kg).
With System cases installed,
it is advisable not to exceed
80 mph (130 km/h).
Opening System case
• Turn key in case lock to posi-
tion A
• Pull up the carrying handle 1
and catch 2
– The two indicators 3 turn red
• Open the System case
Closing System case

Risk of breaking the locking
tongue.
Before closing handle 1or lock-
ing system 2, turn the key in the
case lock to position A.
• Turn key in case lock to posi-
tion A
• Push down catch 2and
carrying handle 1
– The two indicators 3turn
black
•Lockthecaseandremovethe
key
OA Optional accessories
System caseOA
10rsbku2.book Seite 18 Montag, 13. Januar 2003 2:05 14
