Rider's Manual
R 1150 RT
R 850 RT
10r22bkg3.book Seite 85 Montag, 30. Januar 2006 9:20 09

dWarning:
This symbol stands for
precau-tions and measures
which are essential in order to
protect the rider or other
persons from possibly severe
or fatal injury.
eAttention:
Instructions and precautions
specifically intended to prevent
damage to the motorcycle.
Disregarding them may render
the warranty invalid.
LNote:
Specific instructions on how to
operate, control, adjust or look
after items of equipment on the
motorcycle.
Important notes
10r22bkg3.book Seite 87 Montag, 30. Januar 2006 9:20 09

1
Introduction
i
Welcome to BMW
We congratulate you on choos-
ing a new Boxer model from
BMW and welcome you to the
worldwide community of BMW
riders.
Familiarize yourself with your
new bike, so that you can ride it
safely and confidently in all traf-
fic situations.
To make sure of this, please
read this Rider’s Manual care-
fully before starting to use your
new motorcycle. It contains
important information on how to
operate the controls and how to
make the best possible use of
all the motorcycle’s technical
features.
In addition, it contains useful
hints and information on the
correct equipment for machine
and rider, to ensure maximum
reliability and safety, and advice
on how to maintain the value of
your motorcycle.
If you have any questions con-
cerning your motorcycle, your
BMW Motorrad dealer will
gladly provide advice and
assistance.
We hope you enjoy reading this
Rider’s Manual and wish you
many a pleasant, safe journey
on your BMW motorcycle.
Best wishes
BMW Motorrad
Welcome to BMW
10r22bkg3.book Seite 1 Freitag, 27. Januar 2006 12:43 12

i
2
Introduction
General information and con-
trols
General view, left side...........4
General view, right side.........5
Cockpit .................................6
Telltale and warning lights.....7
Ignition switch and steering
lock....................................8-9
Left handlebar fitting ...........10
Right handlebar fitting .........11
Seats .............................12-13
System case ..................14-15
Adjusting the windshield .....16
Hazard warning flashers......17
Safety check
Checklist........................18-19
Engine oil.......................20-21
Fuel................................22-23
Handlebar levers............24-25
Brake system
- general ........................26-27
- with BMW Integral
ABS ............................28-31
Clutch................................. 32
Lights.............................33-35
Shock absorbers ................ 36
Suspension spring
preload ............................... 37
Wheels...........................38-39
Loads.............................40-41
Contents
10r22bkg3.book Seite 2 Freitag, 27. Januar 2006 12:43 12

i
3
Introduction
Starting – Riding – Parking
First time out ................. 42-43
Important notes............. 44-45
Side stand..................... 46-47
Centre stand ................. 48-49
Running in..................... 50-51
Before you start............. 52-53
Starting ......................... 54-55
Telltale and warning
lights.................................56-57
Rider Information Display
(RID) .............................. 58-59
Riding, gear shifts.......... 60-61
Brake system
- general........................ 62-63
- with BMW Integral
ABS............................ 64-70
BMW Integral ABS fault
table ...................................... 71
Arrive safely
Arrive safely....................72-73
Service worldwide...............74
Environmental protection ....75
BMW rider’s equipment.......76
BMW motorcycle
accessories.........................77
Training means extra
safety ..................................78
Concluding thoughts...........79
Contents
10r22bkg3.book Seite 3 Freitag, 27. Januar 2006 12:43 12

4
General information and controls
1
General view, left side
1Storage compartment
2Reservoir for clutch fluid
3Engine oil filler (b21)
4Power socket, 12V
Provision for connecting
additional equipment –
max. load 5 A
5Lifting handle (b48-49)
6Dual seat lock (b12)
7Suspension strut,
shock absorber adjustment
(b36)
8Primary spark plug, left
9Secondary spark plug,
only R 1150 RT
10 Oil level sight glass, engine
(b21)
( ) Figure in bracketsbpage number for
description
54
3
2
16
7
8
9
10
10r22bkg3.book Seite 4 Freitag, 27. Januar 2006 12:43 12

5
General information and controls
1
14
13
18 15
19
12
11
17 16 20
11 Storage compartment for
toolkit (supplied)
12 Fuse box
13 Fuel filler cap (b22)
14 Brake fluid reservoir,
front brake (b30)
15 Type plate/vehicle
identification number
( ) Figure in bracketsbpage number for
description
16 Primary spark plug, right
17 Secondary spark plug,
only R 1150 RT
18 Brake fluid reservoir, rear
brake (b31)
19 Handwheel for adjusting
suspension strut (b37)
20 Helmet holder
General view, right side
10r22bkg3.book Seite 5 Freitag, 27. Januar 2006 12:43 12

6
General information and controls
1
1Front fog lamp switch
2Speedometer
3Distance recorder
(odometer)
4Trip distance recorder
5Rotary reset knob for trip
distance recorder
6Revolution counter (b50)
7Rider Information Display
(RID) (b58-59)
8Headlight range control
rotary button
9Telltale and warning
lights (b7)
10 Ignition switch and steering
lock (b8)
11 Radio displayOE
(bSupplementary Rider’s
Manual)
( ) Figure in bracketsbpage number for
description
OE Optional extra
Cockpit
35
4
2
167
11 8
9
10
10r22bkg3.book Seite 6 Freitag, 27. Januar 2006 12:43 12

7
General information and controls
1
3
2
1
10
8
9
5*
467
Telltale and warning lights
1Left turn indicator repeater
green s
2Warninglight batterycharge
red r(b56)
3Warning light Tank capac-
ity/when app. 4 litres
remain in tank orange m
(b23, 56)
4Neutral indicator (gearbox)
green k(b53)
5Warning light ABS red l
(b56, 68)
( ) Figure in bracketsbpage number for
description
6Warning light, general
red e (b56, 68)
7Warning light engine oil
pressure red p (b56)
8Telltale light Right turn indi-
cator repeater green t
9Telltale light fog lamp green t
10 High-beamheadlighttelltale
blue q
*ndepending on national-market
specification
10r22bkg3.book Seite 7 Freitag, 27. Januar 2006 12:43 12

8
General information and controls
1
Keys
You will receive two master
keys and one spare key.
The key number is on the
accompanying plastic tag.
LNote:
Ignition switch and steering
lock, tank filler cap lock and du-
alseat lock are all operated with
the same key. The key also fits
the storage compartment and
System cases.
dWarning:
Only RESIDUAL BRAKING
FUNCTIONALITY is available
when the ignition is switched
off (b67)
Ignition switch and steering lock
10r22bkg3.book Seite 8 Freitag, 27. Januar 2006 12:43 12

9
General information and controls
1
Ignition switch and steering lock
Key positions
dWarning:
Never turn the key to OFF or
Iwhile riding the
motorcycle!
ON Operating position,
ignition, lights and all
electrical circuits
switched on
R * Ignition and lights off,
steering lock disengaged
(handlebars can be turned
freely to left or right)
* The key can be removed in these
positions
•Turn the handlebars to full left
lock.
eAttention:
Engage the steering lock with
the handlebars in this position
only.
OFF* Ignition and lights off,
steering locked
I* *Parking light on,
steering locked
LNote:
Switch the parking light on
only for limited periods. Note
state of battery charge.
10r22bkg3.book Seite 9 Freitag, 27. Januar 2006 12:43 12

10
General information and controls
1
dWarning:
To prevent air from entering
the clutch system:
•Do not turn the fitting on the
handlebar.
1Cold start lever
(increased engine speed)
(b54-55)
2High/low (dipped) headlight
switch
FHigh (main) beam
GLow (dipped) beam
FHeadlight flasher
OE Optional extra
3Hazard warning flasher
switch
4Rocker switch, electric
windshield adjustment
(b16)
5Audio system handlebar
remote controlOE
(bSupplementary Rider’s
Manual)
6Horn button
7Left turn indicator switch
•Press
–Turn indicators flash
To switch off:
•Press turn indicator
cancel switch 12
Left handlebar fitting
5
4
3
2
1
76
10r22bkg3.book Seite 10 Freitag, 27. Januar 2006 12:43 12

11
General information and controls
1
B
C
11
12
B
C
8910
A
dWarning:
To prevent air from entering
the brake system:
•Do not turn the fitting on the
handlebar.
8Switch forheatedhandlebar
gripsOE
AHeating off
B50% (centre position)
C100%
9Starter button
10 Emergency off (kill) switch
for ignition (b52)
11 Flashing turn indicator
switch, right
•Press
–Turn indicators flash
To switch off:
•Press turn indicator can-
cel switch 12
12 Turn indicator cancel switch
•Press
–Left/right indicators off
OE Optional extra
Right handlebar fitting
10r22bkg3.book Seite 11 Freitag, 27. Januar 2006 12:43 12

12
General information and controls
1
1
Dualseat
Removing dualseat
•Turn the key in the dualseat
lock to position 1and hold it
there
•Take off the rear section of
the seat
–Toolkit is then accessible
•Take off the front section of
the seat
•This gives access to the
fuses, and the rider's seat can
be adjusted
10r22bkg3.book Seite 12 Freitag, 27. Januar 2006 12:43 12

13
General information and controls
1
ABC
2
Adjusting seat height
eAttention:
When installing the dualseat,
make sure that it is firmly located.
•Take off the front section of
the seat
•Lift up seat holder 2, position it
to suit the rider's size and en-
gage it in the chosen position
There are three rider's seat
height positions:
A= high B= centre C= low
Locking the seats
eAttention:
When installing the dualseat,
make sure that it is firmly located.
•Push the rider's seat into its
catch
•Slide the rear section of the
seat into the guide and press
lightly to lock it into the seat
holder
Dualseat
10r22bkg3.book Seite 13 Freitag, 27. Januar 2006 12:43 12

14
General information and controls
1
System case
dWarning:
After an accident or if the
motorcycle has fallen over,
check that the system cases
are correctly secured!
Max. load per system case:
10 kg (22 lbs).
With System cases installed,
it is advisable not to exceed
130 km/h (80 mph).
Opening the system case
•Turn key in case lock to posi-
tion A
•Pull up the carrying handle 1
and catch 2
–The two indicators 3 turn red
•Opening the system case
Closing the system case
eAttention:
Risk of breaking the locking
tongue.
Before closing handle 1or lock-
ing system 2, turn the keyin the
case lock to position A.
•Turn key in case lock to posi-
tion A
•Push down catch 2 and carry-
ing handle 1
–The two windows 3will show
a black signal
•Lock the case and remove
the key
3
1
2
A
10r22bkg3.book Seite 14 Freitag, 27. Januar 2006 12:43 12

15
General information and controls
1
Removing System case
•Turn key in case lock to
position A
•Pull up carrying handle 1
–The two indicators 3turn red
•Remove the key and lift the
system case off its holder
Installing system case
eAttention:
Risk of breaking the locking
tongue.
Before closing handle 1or lock-
ing system 2, turn the key in the
case lock to position A.
dWarning:
Always make sure that the
cases are secured.
An incorrectly secured case
could be lost and endanger
other road users.
•Insert the system case into
the holder (arrows), making
sure that it is firmly seated in
the lower holder and the
upper hook
•Turn key in case lock to
position A
•Fold the carrying handle 1
down
–The two windows 3will show
a black signal
•Lock the case and remove
the key
System case
10r22bkg3.book Seite 15 Freitag, 27. Januar 2006 12:43 12

16
General information and controls
12A
B
A
B
1
Adjusting the windshield
dWarning:
Do not open the storage com-
partment 1 while riding the
motorcycle —risk of accident.
Adjusting the windshield
•Switching on the ignition
•Press rocker switch 2
•Adjust windshield according
to switch positions Aor B
10r22bkg3.book Seite 16 Freitag, 27. Januar 2006 12:43 12

17
General information and controls
1
Hazard warning lights
LNote:
You cannot activate the hazard
warning flashers if the ignition is
switched off.
Do not use the hazard warning
flashers for longer than abso-
lutely necessary.
Note state of battery charge.
Switching on the hazard
warning lights
•Switching on the ignition
–Hazard warning lights
switch 1up
•Operatehazardwarninglights
switch 1
–Hazard warning lights in oper-
ation
–The left/right flashing turn
indicator repeater on the tell-
tale light panel (b7) flashes
•Switch off the ignition
–The hazard warning lights
continue to operate
–The light in the hazard warn-
ing flasher switch goes out
Switching off the hazard
warning lights
•Operatehazardwarninglights
switch 1
–Hazard warning lights switch
off
–Left/right flashing turn indica-
tor repeater on the telltale
light panel (b7) off
Hazard warning flashers
1
10r22bkg3.book Seite 17 Freitag, 27. Januar 2006 12:43 12

2
18
Safety check
Checklist
Use the safety checklist –
before every journey
Please perform the safety
check accurately. If your motor-
cycle needs any routine mainte-
nance, you can then attend to it
before the journey starts
(bMaintenance Instructions),
or, for example have it carried
out by your authorised BMW
motorcycle dealer.
This is to ensure that your
motorcycle corresponds with
road-vehicle use and safety
laws.
Your vehicle must be in perfect
technical order: this is a basic
prerequisite for your safety and
the safety of other road users.
10r22bkg3.book Seite 18 Freitag, 27. Januar 2006 12:43 12
