bObsweep bObi Classic User manual

bObi Classic
OWNER’S MANUAL

bObi Classic
OWNER’S MANUAL
Model SW603002
Manual Version 2020.1

Congratulations!
Congratulations on your new intelligent oor cleaner! bObi is now
at your service. To see bObi at her best, please read the Quick
Start Guide and this manual thoroughly.
Welcome to the bObsweep family and Happy Sweeping!
If you have any questions or concerns, feel free to contact our helpful support team at
[email protected] or 1-888-549-8847.
Our business hours are Monday – Friday, 9 a.m. – 5 p.m. Pacic Time.

Important Safety
Instructions
With the exception of the mopping
cloth, do not immerse any part of
bObi into water or other liquids.
Do not mutilate or incinerate the
battery, as it will explode at high
temperatures.
Do not use bObi outdoors.
Do not expose bObi, her
charging station, or remote to
temperatures higher than 113° F
(45° C), moisture, or humidity.
Flip bObi’s power switch OFF and unplug her from the
outlet when she is not in use and before conducting
maintenance.
bObi is not intended for use by persons (including
children) with reduced physical or mental capabilities,
or lack of experience and knowledge, unless under
the close supervision of a person responsible for
their safety.
Leaks from the battery cells can occur under extreme
usage or temperature conditions. If the liquid gets on
the skin, wash quickly with water. If the liquid gets
into the eyes, ush them immediately with clean
water for a minimum of 10 minutes, and seek medical
attention.
bObi is composed of electronic components that in
rare and unintended cases can cause hazards of
heating, re, and other malfunctions. Furthermore,
because bObi is capable of autonomous movement,
her use poses the risk of collision with property, pets,
and persons. Unintended removal of articles — such
as small valuables, jewelry, or hair of persons or pets
lying on the oor — may also occur.
If bObi, her remote control, or her charging station
has been damaged in any way, do not operate
them. Contact our helpful support team at
[email protected] or or 1-888-549-8847.
Do not dispose of your battery
in re. Old batteries should be
recycled safely through your
local recycler.
Do not let bObi pick up
anything that is burning or
smoking, such as cigarettes,
matches, or hot ashes.
Do not handle bObi, her remote,
or her charging station with wet
hands; use only on dry surfaces.
Do not pull or carry the charging
station by the cord, use the cord
as a handle, close a door on the
cord, or pull the cord around sharp
edges or corners. Keep the cord
away from heated surfaces. To
unplug the cord, grasp the plug,
not the cord.
Do not attempt to open the
charging station. Repairs on the
station should only be carried out
by our qualied technicians.

Declaration of Conformity
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation. The manufacturer is not responsible
for any radio or TV interference caused by unauthorized modications or change to this equipment.
Such modications or change could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warranty
Every bObi Classic purchased from an authorized seller includes a 1-year limited warranty, 5-year
subsidized repair plan, and lifetime of customer support. The warranty covers the battery, labor, and
non-consumable parts; it does not cover postal charges and consumable parts such as brushes, lters,
and mopping cloths.
To activate bObi’s warranty, register her online at www.bobsweep.com/warranties. To purchase
additional coverage plans, go to www.bobsweep.com/coverageplans.

Table of
Contents
FullCommand™
Remote
31. Remote Buttons
33. Syncing the Remote
35. Navigating bObi
38 Cleaning
Schedule
39. Setting the Current
Time and Day
41. Setting the Cleaning
Schedule
43. Auto-Resume Mode
46 Maintenance
47. Dustbin
49. Filter
51. Main Brush
53. Side Brush
55. Sensors
57. Front Wheel
60 Parts and
Accessories
61. Mop
63. Edge Sensors
65. Battery
68 Troubleshooting
69. Edge Sensors
71. Brushes
73. Power System
75. Wheels
77. Dustbin
80 Home Checkup Test
81. Putting bObi in
Checkup Mode
83. Home Checkup
Test Steps
4Getting Started
5. Box Contents
7. bObi’s Anatomy
9. Get to Know bObi
14. Get bObi Started
22 Charging
23. Charging bObi
25. Charging Station
27. Syncing the Charging
Station
30
End User
License
Agreement
86 94
FAQs

Getting Started
5 Box Contents
7 bObi’s Anatomy
9 Get to Know bObi
14 Get bObi Started
Let’s start at the very beginning.
We’ll walk you through the basics and
help you get bObi started for the very
rst time.
4

1 FullCommand™ Remote
2 Charging Adapter
3 Charging Station
4 Microber Mopping Cloths (2)
5 Mop Attachment
6 Battery
7 Filter
8 Phillips Head Screwdriver
9 Syncing Tool
10 Side Brush Screws (2)
11 Blindfold Stickers (4)
12 Cleaning Tool
13 Main Brush
14 Side Brush
15 Main Brush Holders (2)
16 Owner’s Manual, Quick Start Guide, and Warranty Card
17 bObi Classic™
Quick Start
Getting Started Box Contents
Bob comes with the following items. You can purchase replacement parts and accessories at
www.bobsweep.com/shop. 1 2 3
6
7
4
12 14
17
9
15 16
5
810
11
13
5

Top View Bottom View
Quick Start
Getting Started
bObi’s Anatomy
RL
Edge Sensors
UV Lamp
Battery
Main Brush
Left Wheel
Dustbin
Side Brush
Front Wheel
Power Switch
Transmitter
Charging Indicator
1 2 3
Cover Buttons
1 GO! - Sends bObi to clean.
2 JUICE - Sends bObi to her charging station.
3 WAFFLE - Sends bObi to clean localized mess.
Right Wheel
Charging Inlet
Covered with clear plastic when bObi rst arrives
Touch Sensors
Wall Sensors
Rubber Brush
87

Who is bObi?
bObi is an autonomous robotic vacuum cleaner, at your service! She can vacuum, sweep, and
mop all the same time — and at the end of her cleaning session, she automatically returns to her
charging station for a power nap. Set bObi to clean on a schedule and she’ll clean on her own
even when you’re not around.
How does bObi nd her way around?
bObi doesn’t store any data about your home; instead, she uses a network of reactionary sensors
to detect obstacles. To maximize her coverage, she may spiral outward, zigzag across a small
area, or follow along walls. If she seems to be ignoring some spaces or spending too much time
on others, don’t worry! bObi will efciently clean your home over the course of a full cycle — just
check her dustbin for the evidence!
Should I pick up bObi?
You may pick up bObi while she’s cleaning, but it’s best to let her work in her own way. Moving
her around, manipulating her movements, or picking her up may confuse her and disrupt her
cycle.
Quick Start
Getting Started
Get to Know bObi
FullCommand™ Remote
If you wish to control bObi’s movements manually, you may use the
navigational buttons on her remote.
blOck™
You can keep bObi away from obstacles that she nds difcult to
navigate, such as areas with cords or high ledges, by using blOck*.
Charging Station
bObi automatically returns to her charging station when low on battery. If
bObi is having trouble nding her station, try re-syncing it and relocating
it to a more easily accessible location with more space around it.
Mop Attachment
bObi may have a tough time climbing over elevated surfaces while
mopping. Remove bObi’s mop when she is not cleaning smooth
surfaces. Do not let her climb onto carpet or rugs when mopping.
* Available to purchase separately.

Unique Furniture
bObi is designed to maneuver
around furniture of most
shapes and sizes, but she
may nd it difcult to clean
under chairs with narrow legs
or around furniture that is too
low for her sensors to detect.
Specialty furniture, such as
desk chairs with wheels or
stools with circular bases,
may also confuse her — but
don’t worry, bObi usually
nds her way around with
time.
Easy Fix
Use blOck*, bObi’s add-on
accessory, to keep bObi
away from areas she finds
particularly challenging.
blOck emits a digital
barriers that bObi won’t
cross.
Quick Start
Getting Started
Get to Know bObi
Dark-Colored
Carpet
If bObi repeatedly backs up
or displays an error message
while cleaning dark carpet,
then you’ll need to deactivate
the edge sensors. To do so,
simply use bObi’s blindfold
stickers to cover her edge
sensors. Just remember that
while bObi’s edge sensors
are deactivated, she will not
be able to detect edges or
stairs!
Shag Carpet
bObi’s main and side brushes
are not designed to clean shag
carpet or rugs with long bers.
If you’d like bObi to clean shag
carpet or long-bered rugs,
you may remove her main and
side brushes and allow her to
vacuum without it.
Inclines
Sometimes bObi will attempt
to drive up angled surfaces,
get stuck for a few minutes,
and then decide to clean
somewhere else. As long
as bObi does not stop and
display an error message on
her remote’s screen, let her
continue cleaning and nd
her own way around. Take
note of the areas bObi nds
the most challenging and, if
possible, adjust your furniture
accordingly.
Navigating Difcult Obstacles
* Available to purchase separately.
1211

Step 1: Install bObi’s Battery
Quick Start
Getting Started
Get bObi Started: bObi will be ready to clean in just 3 easy steps.
RL
Parts You’ll Need: Battery Phillips Head
Screwdriver
1. Remove the 2 screws on the battery cover
using a Phillips head screwdriver.
3. Replace the screws on the battery cover.
2. Plug the battery into its socket, then slide
the battery into the compartment.
1413

Step 2: Charge bObi
Allow bObi to fully charge before using her for the rst time.
Quick Start
Getting Started
Get bObi Started: bObi will be ready to clean in just 3 easy steps.
1. Plug the charging adapter into the side
of the charging station. The station’s
power light will turn on.
2. Place bObi on her charging station
with the metal nodes on her front resting
against the plates on her station.
When bObi Is Charging:
The charging indicator’s center
light will flash to indicate that
she is charging.
Parts You’ll Need: Charging Charging
Adapter Station
When bObi Is Fully Charged:
The light remains still.
1615

Insert 2 x AAA batteries to turn
on bObi’s remote.
Step 3: Prepare bObi’s Remote
Setup bObi’s remote so that she can respond to its commands.
Quick Start
Getting Started
Get bObi Started: bObi will be ready to clean in just 3 easy steps.
Parts You’ll Need: FullCommand™ AAA Batteries x2
Remote (not included)
Make sure to remove the
clear plastic covering on
bObi’s power switch.
Quick Tip:
1817

bObi is now ready to clean!
Quick Start
Getting Started
Get bObi Started: bObi will be ready to clean in just 3 easy steps.
OR
2. Press the GO! button on bObi’s cover or FullCommand™
remote, and she will clean on her default Deep Clean
mode.
1. Flip bObi power switch ON.
Make sure to remove the clear plastic covering on the power switch.
Quick Tip:
19

Charging
23 Charging bObi
25 Charging Station
27 Syncing the Charging Station
bObi automatically returns to her
charging station when low on battery.
To maximize bObi’s chance of nding
her station, it’s best to place it in an
easily accessible location with plenty
of space around it. If bObi continues
to have trouble nding her station,
you may need to sync it.
22

Quick Start
Charging
Charging bObi
Charging bObi Using the Charging Station
Place bObi on her charging station with the metal nodes on her
front resting against the plates on her station. Make sure the
station is plugged in and the station’s power light is on.
Charging bObi Using the Adapter
Plug the charging adapter directly into the inlet on bObi’s side.
Sending bObi to Her Charging Station
Press the JUICE button on her FullCommand™ remote or cover.
Charging bObi
When bObi Is Charging:
Charging indicator’s center light will flash to indicate that she is charging.
When bObi Is Fully Charged:
The light remains still.
2423

Quick Start
Charging Station
Position the charging station against a wall on a hard, at surface. Make sure there is at least 10 feet
(3 m) of open space to the front and 2 feet (0.6 m) of open space to the sides of the station.
Charging
Charging Station
2 feet (0.6 m)
10 feet (3 m)
2 feet (0.6 m)
Standby Mode
After a minute of idling with her power
switch ON, bObi will enter standby
mode to conserve her battery. In
standby mode, bObi will beep once
every 2 minutes. To mute the beeps
bObi makes in standby mode, turn
her power switch OFF or place bObi
on her charging station.
Conserving bObi’s Battery
To conserve bObi’s battery, turn her
power switch OFF and remove her
from her charging station when she is
not in use. bObi should not sit on her
station for more than 5 days.
When bObi is charging, the charging indicator’s center light will flash to
indicate that she is charging.
When bObi is fully charged, the light remains still.
2625

Quick Start
Syncing the Charging Station
bObi is smart and will automatically search for her charging station when her battery power reaches 15%.
You will need to sync the station if bObi is having trouble nding it.
1. Plug the charging adapter into the side of
the charging station. The station’s power
light will turn on.
2. Using the syncing tool, press the SYNC
button on the back of the charging station
while at the same time ipping bObi’s
power switch ON.
Charging
Syncing the Charging Station
bObi will chirp twice to let you know the sync was successful. If bObi does not chirp,
repeat the process.
Parts You’ll Need: Charging Charging
Adapter Station
!Make sure bObi is not on the charging
station during the sync.
Quick Tip:
27

FullCommand™
Remote
31 Remote Buttons
33 Syncing the Remote
35 Navigating bObi
You can set bObi’s cleaning schedule,
select her cleaning modes, and
control her movements all from her
FullCommand™ remote.
30
