Bodet SCOREPAD Rink hockey User manual

1
Ensure on delivery that the product has not been damaged in transport.
BODET Time & Sport
1 rue du Général de Gaulle
49340 Trémentines I France
Tel: [phone]
Réf.: 608109 B
www.bodet-sport.com
Control keyboard
User Manual - Rink hockey
BODET SCOREPAD

2
1. Rink hockey
1) Select on the home screen.
2) Select a conguration from the list:
RINK HOCKEY 1 National
RINK HOCKEY 2
RINK HOCKEY 3
RINK HOCKEY 4
RINK HOCKEY 5
RINK HOCKEY 6
Congurations identied by can only be edited with the club code.
The club Access code is “1234”. It can be changed in the “Club access” menu.
3) Screen in RINK HOCKEY 2x30 min match mode:
Pressing a game setting brings up a new window in which you can:
1 edit the length: duration of each period. The buzzer can be triggered at each end of period and the
timer reset.
2 edit colour of team shirts and game markings. A standard colour scheme is provided as well as a
palette to set your own colour.
3 edit the name of the team. After pressing LOCALS or VISITORS, press Config. team to edit the
conguration of the teams (edit team screen name, activate players, choice of colours, load a team,
create a new team or delete a team):
1
10 11
2 2
3 3
4 4
55 66
8
8
77
9
2
3 3
2

3
4 call a time-out. To start the countdown, press the START button. Add or delete a time-out by
pressing Correction .
5 modify a point from the team score.
6 assign a penalty to a player or to the team.
List of the penalties for the player:
>Minor: 2-minute penalty.
> Major: 4-minute penalty.
> Minor + Minor: 2-minute penalty + 2 minute.
List of the penalties for the team:
>Minor bench: 2-minute penalty.
>Major bench: 4-minute penalty.
>Minor bench + minor bench : 2-minute penalty + 2 minute.
7 modify a point from the team score.
8 display/modify/delete one or more penalties in progress.
9 add a goal.
10
edit the conguration settings (see next page for the list of settings).
11
go to the next period.
12
start a new match. Warning: the match in progress will be lost.

4
>ENTERING CONFIGURATION SETTINGS
1) Click to edit a conguration.
Note : All these settings are accessible from the Advanced Settings menu.
The list of editable settings is given below:
Rink hockey RINK HOCKEY
3
RINK HOCKEY
6
RINK HOCKEY
1 National
RINK HOCKEY
4
RINK HOCKEY
2
RINK HOCKEY
5
Before match
Horn before match
Horn before match OFF 3m OFF 3m OFF OFF
Horn before match OFF 1m OFF 1m OFF OFF
Pre-match duration OFF 60m OFF 60m OFF OFF
Match
Period number 2 2 2 2 2 2
Period duration 30:00 20:00 10:00 30:00 15:00 25:00
End period Horn 5s 5s 5s 5s 5s 5s
Show stopwatch instant game ON ON ON ON ON ON
Overtime
Overtime number 2 2 2 2 2 2
Overtime duration 10:00 10:00 2:30 10:00 10:00 10:00
Rest time 2:00 2:00 2:00 2:00 2:00 2:00
Rest time duration
Half time horn
Horn duration at end period OFF OFF OFF OFF OFF OFF
Horn N°1 before end OFF OFF OFF OFF OFF OFF
Inter period horn
Horn duration at end period OFF OFF OFF OFF OFF OFF
Horn N°1 before end OFF OFF OFF OFF OFF OFF
Half time duration 15:00 15:00 15:00 15:00 15:00 15:00
Inter period duration 2:00 2:00 2:00 2:00 2:00 2:00
Duration before overtime 2:00 2:00 2:00 2:00 2:00 2:00
Possession
Possession duration 45s 45s 24s 45s 45s 45s
Attack time OFF OFF 14s OFF OFF OFF
Horn 3s 3s 3s 3s 3s 3s
Possession auto start OFF OFF OFF OFF OFF OFF
Timer auto stop OFF OFF OFF OFF OFF OFF
Display keyboard ON ON ON ON ON ON
Time-Out
TO dots
Number of TO dots 1 1 1 1 1 1
Reset Time-out Half time Half time Half time Half time Half time Half time

5
Duration TO 60s 60s 60s 60s 60s 60s
Horn TO
Horn duration before end T-O 10s 10s 10s 10s 10s 10s
Horn end T-O ON ON ON ON ON ON
Horn at start ON ON ON ON ON ON
Duration short TO 30s 30s 30s 30s 30s 30s
Points and Fouls
Total team fouls
Total fouls 5 5 5 5 5 5
Reset total fouls 2 2 2 2 2 2
Points per player OFF OFF OFF OFF OFF OFF
Cards and penalties
Activation of penalties ON ON ON ON ON ON
Blue card time 2:00 2:00 2:00 2:00 2:00 2:00
Red card time 4:00 4:00 4:00 4:00 4:00 4:00
Display player number OFF OFF OFF OFF OFF OFF
End penalty horn OFF OFF OFF OFF OFF OFF
Nb simultaneous penalties 3 3 3 3 3 3
Various
Beeper buttons ON ON ON ON ON ON
Statistic software OFF OFF OFF OFF OFF OFF
Maintain result 10s 10s 10s 10s 10s 10s
HDMI
HDMI display ... ... ... ... ... ...
Sponsors logo ... ... ... ... ... ...
Wallpaper ... ... ... ... ... ...
Team logo ON ON ON ON ON ON
Display penalties ON ON ON ON ON ON
Below is an explanation of each parameter:
Rink hockey Comments
Before match
Horn before match
Horn before match Choose the before-match duration at which the horn sounds
Horn before match Choose the before-match duration at which the horn sounds
Pre-match duration Choose the before-match duration.
Game
Period number Choose the number of periods
Period duration: Choose the number of periods
End of period horn Choose the duration of the horn when the game period is over
Display game clock Function enabled using the ON/OFF button
Extra time
Extra time number Choose the extra time number

6
Extra time duration Choose the duration of extra time
Rest time Choose the duration of rest time.
Rest time duration
Half-time horn
Horn duration at end period Select the duration of the horn before the end of each half time.
Horn N°1 before end Horn before the end of Half time
Inter-period horn
Horn duration at end period Choose the duration of the horn before the end of each inter-period
Horn N°1 before end Horn before the end of the inter-period time
Half-time duration Choose the duration of half time
Duration between periods Choose the duration of the inter-period time
Duration before extra time Choose the duration before the extra time
Possession
Possession time Choose the duration of time possession
Attack time Choose the duration of attack time
Buzzer Choose the duration of the horn
Start possession auto. Function enabled using the ON/OFF button
Stop time auto. Function enabled using the ON/OFF button
Display keyboard Function enabled using the ON/OFF button
Time-out
TO dots
Number of TO dots Select the number of time out dots
Reset Time-out Reset time outs at half time or between each period
Duration TO Select the duration of each time out
Horn TO
Horn duration before end T-O Select the duration of the horn at the end of each time out.
Horn end T-O Function enabled using the ON/OFF button
Horn at start Function enabled using the ON/OFF button
Short T-O duration Choose the duration of the short time out
Points and Fouls
Total team fouls
Total fouls
Function enabled using the ON/OFF button
Select the period for the total team fouls reset
Select the number for the total team fouls
Points per player Function enabled using the ON/OFF button
Cards and penalties
Activation penalties Function enabled using the ON/OFF button
Blue card time Select the duration of the blue card
Red card time Select the duration of the red card
Display player number Function enabled using the ON/OFF button
End of penalty buzzer Function enabled using the ON/OFF button
No. simultaneous penalties
Function enabled using the ON/OFF button
Select the number of simultaneous penalties

7
Miscellaneous
Beeper buttons Function enabled using the ON/OFF button
Statistical software Function enabled using the ON/OFF button
Maintain result
Function enabled using the ON/OFF button
Choose the display duration in seconds
HDMI
HDMI display Select HDMI display mode
Sponsor logos Choose the sponsor logos to display
Wallpaper Select the wallpaper for HDMI display
Team logos
Function enabled using the ON/OFF button
Choose the teams logo display
Display penalties Function enabled using the ON/OFF button
