Body Break 1612907US User manual

1612907US
OWNER’S MANUAL
ASSEMBLY‧OPERATION‧MAINTENANCE
WARRANTY‧PART ORDERING
▲CAUTION: Exercise of a strenuous nature, as is customarily done on this equipment, should not
be undertaken without first consulting a physician. No specific health claims are made or implied as
they relate to the equipment.
IMPORTANT: Read all instructions carefully before using this product. Retain this owner’s
manual for future reference.
MAURICE PINCOFFS CANADA 6050 Don Murie Street Niagara Falls, Ontario L2E 6X8

CUSTOMER SERVICE 1-888-707-1880 1 MAURICE PINCOFFS CANADA INC ©2009
TABLE OF CONTENTS
Safety Precautions……………………… 2
Before you begin………………………... 4
Assembly………………………….…….. 5
Operation and adjustment…….………. 8
Folding………………………………….. 14
Parts list………………………….……… 15
Overview Drawing……………………… 18
Trouble Shooting……………………….. 20
Treadbelt Adjustment………………….. 21
Treadmill Lubrication ………………… 22
Cleaning and Maintenance…………….. 23
Training Guidelines ……………………. 25
Exercise Routine…………………………28
Warranty…………………………………30

CUSTOMER SERVICE 1-888-707-1880 2 MAURICE PINCOFFS CANADA INC ©2009
IMPORTANT SAFETY INFORMATION
THIS UNIT IS INTENDED FOR HOUSEHOLD USE ONLY
READ ALL INSTRUCTIONS BEFORE USING THIS TREADMILL
▲CAUTION: Before starting any exercise program, it is recommended that you consult your physician.
▲WARNING: Connect this unit to a properly grounded outlet only.
▲DANGER: To reduce the risk of electric shock, always unplug the treadmill from the electrical outlet immediately
after using and before cleaning.
WARNING
To reduce the risk of burns, fire, electric shock, or injury to persons:
1. Use 120 volt a.c. household current on a dedicated circuit.
Grounding Instructions
This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current
to reduce the risk of electric shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding
plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and
ordinances. See diagram below for grounding methods.
2. It is the responsibility of the owner to ensure that all users of this treadmill are adequately informed of all warnings and precautions.
3. The use of an extension cord with this product is not recommended. If an extension cord is needed, use a short (less than 10 feet)
heavy gauge (14 gauge or better) extension cord with a three prong (grounded) plug and receptacle.
4. Never leave the treadmill unattended when plugged in. Remove the safety key and unplug the unit from the outlet when not in use
and before removing or replacing parts.
5. Never operate the treadmill if it has a damaged cord or plug, if it is not working properly, if it has been dropped, damaged, or
exposed to water. Never move the treadmill belt while the power is turned off.
6. Do not pull the treadmill by the power supply cord or use cord as a handle. Keep cord away from heated surfaces and open flames.
7. Fitness equipment must always be installed and used on a flat surface. Do not use outdoors or near water. Do not place the unit on
a loose rug or uneven surface. It is recommended to use an equipment mat to prevent the unit from moving while it is being used,
which could possibly scratch or damage the surface of your floor. It is recommended to have a minimum of 3 metres safe clearance
on all sides of the treadmill while in use.
8. Keep the treadmill indoors, away from moisture and dust. Do not put the treadmill in a garage, covered patio or near water.
9. Do not operate the treadmill where aerosol products are used or where oxygen is being administered.
10. Read, understand and test the emergency stop procedure before using the treadmill (see operation and adjustment on page 8)
11. Do not insert any objects into any openings.
12. Inspect and properly tighten all parts of the treadmill regularly.
13. Keep children and pets away from this equipment at all times while exercising.
14.Handicapped individuals should have medical approval and close supervision when using this treadmill.
15. Do not place hands or feet under the treadmill. Always keep hands and legs off of the treadmill when others are using it.
16. Never turn on treadmill while standing on treadbelt. Always hold the handrails while using the treadmill. Always return the
treadmill to the slowest speed to provide for safe dismount and low speed restart.
17. To disconnect, turn all controls to the off position, then remove plug from outlet.
18.Do not attempt to raise, lower or move the treadmill until it is properly assembled. See assembly on page 5 and to fold and move the
treadmill on page 14. Care must be taken when lifting or moving the equipment, so as not to injure your back. Always use proper
lifting techniques.
19. Use the treadmill only for its intended use as described in this manual. Do not use any attachments that are not recommended by
the manufacturer.
20. User weight should not exceed 265lbs (120 kg).
21. Never allow more than one person on the treadmill at once.

CUSTOMER SERVICE 1-888-707-1880 3 MAURICE PINCOFFS CANADA INC ©2009
22. Warm up 5 to 10 minutes before each workout and cool down 5 to 10 minutes afterward. This allows your heart rate to gradually
increase and decrease and will help prevent straining muscles.
23. Never hold your breath while exercising. Breathing should remain at a normal rate in conjunction with the level of exercise being
performed.
24. Start your program slowly and very gradually increase your speed and distance.
25. Always wear suitable clothing and footwear while exercising. Do not wear loose fitting clothing that could become entangled with
the moving parts of your treadmill. Do not walk or jog barefoot, in stocking feet or loose fitting shoes or slippers.
26. This treadmill is intended for in-home use only. Do not use the treadmill in any commercial, rental or institutional setting.
▲WARNING: Before beginning any exercise program consult your physician. This is especially important for individuals over the
age of 35 or persons with pre-existing health problems. Read all instructions before using any fitness equipment. We assume no
responsibility from personal injury or property damage sustained by or through the use of this product.
SAVE THESE INSTRUCTIONS

CUSTOMER SERVICE 1-888-707-1880 4 MAURICE PINCOFFS CANADA INC ©2009
Before you begin.
Thank you for purchasing our product. Even though we go to great efforts to ensure the quality of each product we
produce, occasional errors and /or omissions do occur. In any event should you find this product to have either a defective
or a missing part please contact us for a replacement.
This product has been designed for home use only. Product liability and guarantee conditions will not be applicable to
products being subjected to professional use or products being used in a gym center.
This exercise equipment was designed and built for optimum safety. However, certain precautions apply whenever you
operate a piece of exercise equipment. Be sure to read the entire manual before assembly and operation of this
machine.
Before reading further, please familiarize yourself with the parts that are labeled in the drawing below.
MAX. USER WEIGHT LIMIT 120 KGS (265 LBS)
Safety Key
Handgrip tube
Handpulse
Console
Upright
Main frame
Walking belt
Wheel
Circuit breaker
On / off switch
Motor cover
Foot rail
Adjustment bolts

CUSTOMER SERVICE 1-888-707-1880 5 MAURICE PINCOFFS CANADA INC ©2009
Assembly
It will take two people to assemble your unit.
Set the treadmill in a cleared area and remove all packing material. Do not dispose of the material until your
assembly is completed. Note: The underside of your treadmill’s walking belt is coated with a lubricant. During
shipping, a small amount of lubricant may be transferred to the top of the waling belt or the shipping carton.
This does not affect the treadmill’s performance. If you notice any lubricant on the top of the walking belt,
simply wipe off the lubricant with a soft cloth and a mild, non abrasive cleaner.
For the sake of familiarizing yourself with the parts identified in the instructions, first study the overview
drawing.
Assembly only requires the included wrenches.
HARDWARE CHECK LIST
#44. Safety Key (1pc)
#104. Lubricant (1pc)
#100. 5/16" × 18 × 1.5T
Flat Washer (4pcs)
#99. 5/16" × 15m/m
Button Head Socket Screw
(12pcs)
#101. 5/16" × 23 × 1.5T
Curved Washer (4pcs)
#103. M6 Allen Wrench (1pc)
#102. Combination M5 Allen Wrench &
Phillips Head Screw Driver (1 pc)

CUSTOMER SERVICE 1-888-707-1880 6 MAURICE PINCOFFS CANADA INC ©2009
ASSEMBLY INSTRUCTION
STEP 1
Remove the treadmill from carton and lay it on the flat ground.
STEP 2
Connect Lower Computer Wire (53) to the Extension Computer Wire(54).
STEP 3
Install Right Upright (4) into the Frame Base (2). Fasten securely using 4 of the 5/16"×15m/m Button Head
Socket Bolt (99), 2 of the 5/16"×18×1.5T m/m Flat Washer (100) and 2 of the 5/16"×23×1.5Tm/m Curved
Washer (101) by using the Combination M5 Allen Wrench & Phillips Head Screw Driver (102).
Repeat for the Left Upright (5).

CUSTOMER SERVICE 1-888-707-1880 7 MAURICE PINCOFFS CANADA INC ©2009
STEP 4
Connect The Extension Computer Wire (54) to the Upper Computer Wire (55).
Connect the Speed Adjustment Switch W/Wire (106) to the Upper Speed Wire (107)
Connect Incline Adjustment Switch W/Wire (108) to the Upper Incline Wire (109)
STEP 5
Attach the Console Support (6) into the Right and Left Upright (4, 5). Fasten securely using 4 of the 5/16"×
15m/m Button Head Socket Bolts (99) by using the Combination M5 Allen Wrench & Phillips Head Screw
Driver (102).
NOTE: Ensure that all nuts and bolts are firmly tightened

CUSTOMER SERVICE 1-888-707-1880 8 MAURICE PINCOFFS CANADA INC ©2009
TREADMILL OPERATION
Your treadmill features a walking belt coated with a lubricant. IMPORTANT: Never apply silicone spray or
other substances to the walking belt or walking board. Such substances will deteriorate the walking belt and
cause excessive wear.
How to plug in the power cord.
GROUNDING INSTRUCTIONS.
This product must be grounded. No plug adapter should be
used with this product.
▲WARNING: Improper connection of the equipment
grounding conductor can result in a risk of an electric
shock. Check with a qualified electrician if you are in doubt
as to whether the product is properly grounded. Do not
modify the plug provided with the product, if it will not fit
the outlet; have a proper outlet installed by a qualified
electrician. The use of an extension cord with this product
is not recommended. If an extension cord is needed, use a
short (less than 10 feet) heavy gauge (14 gauge or better)
extension cord with a three prong (grounded) plug and
receptacle. IMPORTANT: If the power cord is damaged, it
must be replaced with a manufacturer recommended power
cord.
1. Plug the indicated end of the power cord into the
socket of the treadmill. See drawing below
2. Plug the power cord into an appropriate outlet
that is properly installed and grounded. See
drawing below. Important: The treadmill is not
compatible with GFCI-equipped outlets.
Note: Your power cord and outlet may appear different.

CUSTOMER SERVICE 1-888-707-1880 9 MAURICE PINCOFFS CANADA INC ©2009
MONITOR INSTRUCTIONS
▲CAUTION: Before operating the console, read the following precautions:
•Do not stand on the walking belt when turning on the treadmill
•Always wear the safety key
•Adjust the speed in small increments to avoid sudden jumps in speed
•To reduce the possibility of electric shock, keep the console dry. Avoid spilling liquids on the console
and place only sealed water bottles in the water bottle holders.
TO OPERATE TREADMILL
CAUTION: To avoid injury, hold onto Handrail while mounting and dismounting treadmill. Hold onto
handrail and place feet on side rails before starting. Step onto treadbelt only at slowest speed.
Before operating the console make sure that the power cord (48) is properly plugged in and the on / off button
(47) is on.
1. Hold onto handrail and place feet on siderails before starting treadmill. (Do not stand on treadbelt).
2. Attach the magnet end of the safety key (44) onto the monitor and attach the clip end of the safety key
(44) to your clothing (ie: waistband). If you should slip or fall while exercising the safety key will pull
out of the console, shutting off the treadmill.
3. Choose which program you want to select, manual (P1), pre-set (p2-p6), user (U1-U2) or heart rate
control. Press the “Program” button until the desired program is displayed, then press “ENTER” to accept
the program. You can set the user weight by pressing the “FAST” / “SLOW” buttons before choosing the
program you want to select or simply press the “SELECT” button to enter the program mode.
A- Manual mode P0: Press the “PROGRAM” up or down buttons to choose the manual program.
Before beginning your exercise program, you can set the time, distance or the calorie range. Press
the “SELECT” button until time, distance or calorie is displayed. Press the “FAST” or “SLOW”
button to set the desired value then press “SELECT” to accept the value.
B- Program mode P2-P6: Press the “PROGRAM” up or down button to choose your desired preset
program P2-P6. Before beginning you exercise program you can set the time to count down from
99:00 to 0. Press the “SELECT” button to display time, press the “FAST” or “SLOW” button to
set the desired time. Now press the “SELECT” button to accept the time value. You can set your
maximum speed of the profiles from 1kmph to 16kmph. After you have pressed the “SELECT”
button to accept the time, the speed will be flashing. Press the “FAST” or “SLOW” button to set
your maximum speed. Now press the “SELECT” button to accept the maximum speed value. You
may change the speed and incline while you are exercising (same as manual) but the next segment
of the program will resume its original position. All of the programs have a three minute warm up
and cool down period. You can press “START or STOP” buttons at any time.
C- User Program mode: Press the “PROGRAM” button until the U1 or U2 is displayed. You can set
your own profile program up to a maximum of two users. Press the “SELECT” button to display
time, press the “FAST” or “SLOW” button to set the desired time. Now press “SELECT” button
to accept the time value. You will need to set the speed and incline value for each of the 20
segments. Press “FAST” or “SLOW” button to set the speed, then press the “UP” or “DOWN”
button to set the incline. After the speed and incline is set press the “SELECT” button to accept
each of the segments. Note: you will need to do this step 20 times. The computer will
automatically save your profiles.

CUSTOMER SERVICE 1-888-707-1880 10 MAURICE PINCOFFS CANADA INC ©2009
D- Heart Rate Control:
Heart Rate Control:
Heart Rate Control H1-H2: H1= (200-age) * 60% = Target heart rate
H2= (200-age) * 80% = Target heart rate
Select your heart rate program by pressing the “H.R.C.1 or H.R.C. 2” button. Press the “mode”
button to set the time using the “fast” of “slow” button, if you do not set the time range the monitor
will count up. Press “mode” to set “age” in the pulse window, use the “fast” or “slow” button to
change the range. The computer will calculate your Target Heart Rate following the chart above.
Should you wish to change the Target Heart Rate press “mode” button and set your heart rate target
in the pulse window. Press “fast” or “slow” button to change the heart rate. Press “start” button to
begin your program.
Note: If the computer does not have the heart rate input, the LCD will display
” ♥? ” and the will not change position until the computer receives the heart rate from the handpulse.
If your heart rate does not reach the set heart rate value, the treadmill will increase the incline height
automatically till you reach the set value, then the computer will adjust the incline to maintain your
Target Heart Rate.
Select your heart rate program by pressing the “PROGRAM” up or down buttons.
The pre-set value of time is 20:00. Press the “FAST” of “SLOW” button to change the time then
press “SELECT” button to accept. Should you wish to change the Target Heart Rate press “FAST”
or “SLOW” button to change the heart rate, the range is between 30 to 120. Press the “SELECT”
button to accept your new value. Press the “FAST” / “SLOW” button or “UP” / “DOWN” button to
change the maximum speed. The pre-set value is 1.0 and the range is from 0.6 kmph to 10.0 kmph.
Press the “SELCET” button to accept your new value. Press the “FAST” / “SLOW” button or “UP” /
“DOWN” button to change the maximum incline level. The pre-set value is 0 and the range is from 0
to 10. Press “SELECT” button to accept your new value. Press “START” button to begin your
program.
4. Press the “START” button to start the treadbelt, the monitor will beep three times. The belt will begin to
move at 1.kmph (+/-0.2m). Carefully step onto the treadbelt. To change the walking belt speed, press the
“FAST” or “SLOW” buttons.
5. To stop your exercise program in the manual mode, press the “STOP” button to stop the walking belt. A
series of beeps will indicate the end of the programs
Note: If the monitor does not detect any signal for four minutes, the monitor will automatically shut off.

CUSTOMER SERVICE 1-888-707-1880 11 MAURICE PINCOFFS CANADA INC ©2009
WINDOW DISPLAY
Pace: Displays the time you spend per mile during your workout.
Time: Displays your elapsed workout time in minutes up to 99:00.
Counts down from your preset target time to 5:00 during your workout.
Target / Displays the user’s current heart rate in beats per minutes during the workout.
Actual Heart To display your heart rate, you must hold both handrails.
Rate Note: This is a rough guide used for comparison of different exercise sessions, which
cannot be used for medical purposes.
Distance: Displays the distance traveled in M up to 99.99. M.
Counts down from your preset target distance to 0 during your workout.
Calories: Displays the cumulative calories burned at any given time during your workout.
Counts down from your preset calorie target to 0 during your workout.
Note: This is a rough guide used for comparison of different exercise sessions, which
cannot be used for medical purposes.
Speed: Displays the current speed in M per hour.
Incline: Displays your current elevation position from 0 to 15.

CUSTOMER SERVICE 1-888-707-1880 12 MAURICE PINCOFFS CANADA INC ©2009
BUTTON FUNCTION
Program: There are a total of 10 programs to chose from: manual program, 5 pre-set speed/incline
programs, 2 user programs and 2 target heart rate control programs. Press the “PROGRAM”
buttons to select the desired program. Each program is divided into 20 segments with time
alternative of 10 to 99 minutes (increments of 1 minute). Ie: 20 minute program will have 20
segments of 1.0 minutes.
Enter: Press the “ENTER” button to select a different setting mode while in any mode.
Select: Press the “SELECT” button to choose the setting mode and accept the set value.
Fast: Press the “fast” button to increase your speed from 0. 6mph to 10mph.
In program mode, press the “fast” button to change the display between speed or incline.
Slow: Press the “slow” button to decrease your speed from 10mph to 0. 6mph.
In program mode, press the “slow” button to change the display between speed or incline.
Up: Press the “up” button to increase your incline level from 0 to 15.
In program mode, press the “up” button to change the display between speed or incline.
Down: Press the “down: button to decrease your incline level from 15 to 0
In program mode, press the “down” button to change the display between speed or incline.
5 preset speed: 2mph 4mph 6mph 8mph 10mph
5 pre-set incline: 2 4 6 8 10
Safety key: Attach the safety key in its position to turn on the computer. When the safety key is pulley away
from its position, the computer will shut down automatically.

CUSTOMER SERVICE 1-888-707-1880 13 MAURICE PINCOFFS CANADA INC ©2009
SPEED PROGRAMS
P1 SPEED PROFILE
P2 SPEED PROFILE
P3 SPEED PROFILE
P4 SPEED PROFILE
P5 SPEED PROFILE
＊
S
PEED PR
O
FILE
P1 INCLINE PROFILE
P2 INCLINE PROFILE
P3 INCLINE PROFILE
P4 INCLINE PROFILE
P5 INCLINE PROFILE
＊
I
NC
LI
N
E PR
O
FILE

CUSTOMER SERVICE 1-888-707-1880 14 MAURICE PINCOFFS CANADA INC ©2009
FOLDING AND MOVING YOUR TREADMILL
Before folding the treadmill, ensure that the treadmill is at its lowest incline position. Turn the power switch off, located on the
front of the motor cover and unplug the power cord.
CAUTION: You must be able to safely lift 20 kg (45lbs) in order to raise and lower the treadmill.
To decrease the possibility of injury, bend your legs and keep your back straight while you are raising or
lowering your treadmill.
To protect the floor or carpet from damage, place a mat under the treadmill. Keep the treadmill out of direct sunlight. Do not
leave the treadmill in the storage position in temperatures above 85 degrees Fahrenheit.
Unfolding
Hold the treadmill running deck with left hand. Pull the locking knob with your right hand and slowly lower the treadmill
running deck. The deck will lower unassisted when it reaches about waist high.
Folding
Lift the treadmill running deck with your left hand. Pull the locking knob with your right hand and slowly raise the treadmill
running deck until the treadmill is locked by the locking knob.
Moving
Before moving the treadmill, fold the treadmill to the stored position as described above. Step on the right foot base with your
right foot. Hold the left and right handgrip tubes and pull machine toward you. You can now easily move the treadmill to your
desired position.
To reduce the risk of injury, use extreme caution while moving the treadmill, do not attempt to move the treadmill over an uneven
surface.

CUSTOMER SERVICE 1-888-707-1880 15 MAURICE PINCOFFS CANADA INC ©2009
KEY NO. PART NO. DESCRIPTION O'TY
1 290701 Main Frame 1
2 290702 Frame Base 1
3 290703 Incline Bracket 1
4 290704 Right Upright 1
5 290705 Left Upright 1
6 290706 Console Support 1
7 290707 Outer Slide 1
8 290708 Inner Slide 1
9 290709 Locking Knob 1
10 290710 Incline Motor 1
11 290711 Drive Belt 1
12 290712 Motor Bracket 1
13 290713 Motor 1
14 290714 Tread Belt 1
15 290715 Tread Deck 1
16 290716 Front Roller W/Pulley 1
17 290717 Rear Roller 1
18 290718 Magnet 1
19 290719 Front Wheel Sleeve 2
20 290720 Rear Wheel Sleeve 2
21~1 290721-1 Top Console Computer 1
21~2 290721-2 Console Bottom Cover 1
21~3 290721-3 Lower Book Rack 1
21~5 290721-5 Console Stopper 1
21~9 290721-9 STOP Button 1
21~10 290721-10 START Button 1
22 290722 Handgrip Cap 2
23 290723 Frame Base Cap (L) 1
24 290724 Frame Base Cap (R) 1
25 290725 Motor Top Cover 1
26 290726 Rear Adjustment Base (L) 1
27 290727 Rear Adjustment Base (R ) 1
28~1 290728-1 Handpulse Top Cover 2
28~2 290728-2 Handpulse Bottom Cover 2
28~3 290728-3 650m/m_Handpulse Wire 1
29 290729 Handpulse End Cap 2
30 290730 Motor Cover Anchor 4
31 290731 Ø38_Button Head Plug 2
32 290732 Frame Base End Cap 2
33 290733 Front Transportation Wheel 2
34 290734 Rear Transportation Wheel 2
35 290735 Rubber Cushion 6
36 290736 Console Support Foam 2
37 290737 Foot Rail 2
38 290738
N
on Slip Foot Grip Left 1
39 290739
N
on Slip Foot Grip Right 1
40 290740 Handgrip Foam 2
41 290741 □21.4×21.4_Square End Cap 1

CUSTOMER SERVICE 1-888-707-1880 16 MAURICE PINCOFFS CANADA INC ©2009
KEY NO. PART NO. DESCRIPTION O'TY
42 290742 □25.4×25.4_Square End Cap 1
43 290743 □20 × 40_Square End Cap 2
44 290744 800m/m_Safety Key 1
45 290745 Power Socket 1
46 290746 Breaker 1
47 290747 On/Off Switch 1
48 290748 Power Cord 1
49 290749 20cm × 764 × 764 _Connecting Wires (Black) 1
50 290750 20cm × 764 × 764 _Connecting Wires (White) 1
51 290751 10cm × 764 × 764 _Connecting Wires (Black) 1
52 290752 Controller (with transformer) 1
53 290753 Lower Computer Cable 1150mm 1
54 290754 Extension Computer Cable 1200mm 1
55 290755 Upper Computer Cable 800mm 1
56 290756 1000 m/m_Sensor W/Cable 1
57 290757 Motor Bottom Cover 1
58 290758 1/2" × 1"_Hex Head Bolt 2
59 290759 3/8" × 3-3/4"_Button Head Socket Bolt 1
60 290760 3/8" × 1-3/4"_Hex Head Bolt 1
61 290761 3/8" × 1-1/2"_Hex Head Bolt 1
62 290762 3/8" × 3/4 "_Hex Head Bolt 4
63 290763 M8 × 60 m/m_Hex Head Bolt 1
64 290764 M8 × 12 m/m_Hex Head Bolt 2
65 290765 5/16" × 1"_Button Head Socket Bolt 2
66 290766 3/8" × 4"_Button Head Socket Bolt 1
67 290767 3/8" × 2"_Flat Head Socket Bolt 4
68 290768 1/2" × 28m/m_Carriage Bolt 2
69 290769 M8 × 3"_Socket Head Cap Screw 2
70 290770 1/4" × 1"_Flat Head Socket Screw 6
71 290771 3 × 12 m/m_Sheet Metal Screw 2
73 290773 5 × 16m/m_Tapping Screw 10
74 290774 3.5 × 12 m/m_Sheet Metal Screw 16
75 290775 1/2" × 8T_Nyloc Nut 4
76 290776 3/8" × 7T_Nyloc Nut 6
77 290777 5/16" × 7T_Nyloc Nut 2
78 290778 M8 × 7T_Nyloc Nut 1
79 290779 3/8" ×2T_Split Washer 6
80 290780 M8 × 1.5T_Split Washer 2
81 290781 1/2"× 26× 2T_Flat Washer 2
82 290782 3/8"× 19× 1.5T_Flat Washer 6
83 290783 3/8"×25 × 2T_Flat Washer 5
84 290784 5×13 × 1.0T_Flat Washer 2
85 290785 Ø50×Ø13 × 3T_Nylon Washer 4
86 290786 Ø10×Ø25 × 3T_Nylon Washer 2
87 290787 Ø6.5×Ø25 × 1.5T_Concave Washer 8
88 290788 M5_Star Washer 4
89 290789 5 × 2T_Speed Nut Clip 4
90 290790 4× 19m/m_Sheet Metal Screw 4
91 290791 4× 12m/m_Sheet Metal Screw 12

CUSTOMER SERVICE 1-888-707-1880 17 MAURICE PINCOFFS CANADA INC ©2009
KEY NO. PART NO. DESCRIPTION O'TY
92 290792 Belt Guide 2
93 290793 5× 16m/m_Tapping Screw 26
94 290794 5× 19m/m_Tapping Screw 6
95 290795 Cylinder 1
96 290796 M8 × 1"_Flat Head Countersink Bolt 2
97 290797 3 × 10 m/m_Self Tapping Screw 4
98 290798 3/8" × 3"_Hex Head Bolt 1
99 290799 5/16" × 15m/m_Button Head Socket Bolt 12
100 2907100 5/16" × 18 × 1.5T_Flat Washer 4
101 2907101 5/16" × 23 × 1.5T_Curved Washer 4
102 2907102 Combination M5 Allen Wrench & Phillips Head Screw Driver 1
103 2907103 M6 (66*88)_Allen Wrench 1
104 2907104 Lubricant 1
105 2907105 Ø38_Indentation End Cap 2
106 2907106 Speed Adjustment Switch W/Cable 1
107 2907107 700m/m_Speed Cable (Upper) 1
108 2907108 Incline Adjustment Switch W/Cable 1
109 2907109 700m/m_Incline Cable (Upper) 1
110 2907110 4 × 38m/m_Sheet Metal Screw 2
111 2907111 400m/m_Console Ground Wire 1
121 2907121 Wire Tie Mount 4
122 2907122 3.5 × 16m/m_Tapping Screw 4
123 2907123 Sensor Rack 1
124 2907124 End Cap 1
125 2907125 Towel 1
126 2907126 M5 × 10m/m_Phillips Head Screw 3
127 2907127 M5_Split Washer 3

CUSTOMER SERVICE 1-888-707-1880 18 MAURICE PINCOFFS CANADA INC ©2009
EXPLODED DIAGRAM
21-2
67
32
89
67
100
99
93
23
93
73
93
33 75
73
19
34
20
67
93
79
101
99
89
2
93
93
57
89
33
77
65
19
79
99
101
31
100
53
99
99
36 109
40
22
108
84
73
111
28-1
28-2
97
29
97
28-3
55
84
73
88
6
93
76
82
81
85
3
85
76
82
68
77
65
75
59
68
81
75
85
82
73
34
95 20
89
76
73
75
24
54
67
32
85
21-10
28-2 29
28-1 55
107
36
54
99
44
21-5
124
106
22
40
125
74
31
21-9
21-3
21-1

CUSTOMER SERVICE 1-888-707-1880 19 MAURICE PINCOFFS CANADA INC ©2009
87
88 91
93
82
76
8
41
61
93
93
58
42
76
82
60
7
121
122
98
30
94
56
123
43
48
93
121
122
35
35
93
76
122
83
121
122
121
82
105
9
1
35
93
17
69
26
27
69
105
51
93
93
35
93
58 93
30
86
94
49
35
50
35 87
91
87
87 91 70
980721PM1650
102 103 104
93
91
91
91
96
91
87
92
70
87
96
15
14
90
87
93
126
80
30
94
64
80
83
79
12
126
127
47 46
45
94
88
30
127
43
52
94
83
79
11
94
62 62
13
88
127
126
73
66
10
16
70
18
63
78
73
70 37
91
70
87
91
91
70
90
38
39
25
73
90
37
90
73
