Product Description
Thank you for choosing NEAR®Orbit Pendant Loudspeakers. You have purchased
one of the finest pendant loudspeakers available today, the NEAR Model OPS1.
Please familiarize yourself with this product by reading and reviewing the descrip-
tions and diagrams in this manual.
All NEAR products include similar technical and design aspects that are unique to
the market. NEAR invented and patented the "spiderless" woofer (MLS™), which
features a high-gauss ferrofluid to guide the voice coil through the magnetic field.
The benefits over conventional woofers with cloth spiders are several, including the
ability to constantly adjust voice coil alignment, extend linear excursion, and the
most efficient path for cooling the voice coil.
In addition, the use of metal-alloy cone structures provides several benefits over the
usual paper or plastic cone, such as elimination of cone flex or "break-up" in the
operating ranges, additional thermal path for the voice coil to stay cool, and an
extremely stable cone structure unaffected by changes in temperature.
The NEAR OPS1Pendant Loudspeaker is a full-range, wide dispersion system
providing overhead sound coverage where ceiling structures are high but the sound
needs to be closer to the audience/listener. An optional cable kit (CK10), suitable
for safety or main drop cable, is available.
Settings for both 70V and 100V high-impedance systems, as well as a low-impedance
(16-ohm) position, are provided.
The OPS1features a removable snap-lock input connector, providing easy wire
connection for input as well as loop-through to the next speaker.
IMPORTANT
The OPS1is not an outdoor speaker. Do not expose the speaker to rain or
moisture. The OPS1should be installed by qualified personnel.
! WARNING !
YOU MUST USE A SAFETY CABLE AND SECURELY TIGHTEN ALL
HARDWARE, CABLE CLAMPS, AND INSTALL EYEBOLTS AS DIRECTED
IN THESE INSTRUCTIONS. FAILURE TO DO SO MAY RESULT IN
PROPERTY DAMAGE, INJURY OR DEATH,AND LEGAL LIABILITY TO
YOU AND YOUR COMPANY.
54-2090-01D.qxp:54-2090-01B.qxd 9/9/09 4:52 PM Page 2

Product Diagrams
OPS1Front Drawing
1. Tap Selection Switch
2. Coaxial Driver Assembly
3. Grille Retention Slot
4. Bass Tuning Vent (x2)
5. Perforated Steel Grille
OPS1Rear Drawing
6. Snap-Lock Input Connector
7. Suspension Points (x3)
8. Safety Cable Attachment Point
Package Contents
(1) Orbit Pendant Speaker
(1) Snap-Lock Input Connector
(1) Quick-Snap Clip
(3) Suspension Cables with Forged Eyebolts
(1) Separate Eyebolt
(4) Nuts (may be installed onto eyebolts)
(1) Installation and Use Manual
OPS1Front Drawing
(grille partially shown)
OPS1Rear Drawing
1
54-2090-01D.qxp:54-2090-01B.qxd 9/9/09 4:52 PM Page 3

Selecting Power Level
Select the power level using the front-mounted selector switch. The speaker grille
must be removed prior to selecting the power level. See Speaker Grille Installation &
Removal section for proper grille removal procedures.
Selecting Power Level
The front-mounted selector switch (under grille)
is used to set the appropriate power level or imped-
ance for your system. Using a small flat-blade screw-
driver, turn the knob until the slot points to the
power level you require.
70V/100V Systems
Both power setting scales for 70V and 100V systems
are labeled on the speakers. On the 100V scale, the
last position clockwise is marked with a (not avail-
able) symbol. Do not use this position in 100V
systems.
16
Ω
Systems
The fully counterclockwise position of the setting switch is the 16-ohm position.
This setting is suitable for use with low-impedance amplifiers that typically support
4- or 8-ohm speakers. The speaker’s higher, 16-ohm impedance makes it easier to
combine multiple speakers into series-parallel networks while keeping the total sys-
tem impedance at a level suitable for low-impedance amplifiers.
Speaker Grille Installation & Removal
Installation
The speaker grille fits tightly! Make sure the tap set-
tings are correct prior to re-installing the grille. Push
the speaker grille in until it can go no further. Then,
slap around the edge of the grille to seat the grille.
The grille is properly seated when it is flush with the
edge of the bezel.
Removal
Insert a pocketknife blade between the grille and the
bezel about 1/4" deep and then gently pry the grille
upwards. Do this in multiple places around the
circumference of the grille to free the grille.
2
54-2090-01D.qxp:54-2090-01B.qxd 9/9/09 4:52 PM Page 4

3
Speaker Wiring
Wiring is terminated at a snap-lock input
connector. There are two positive and two
negative terminals to accommodate daisy-
chaining of speakers in a system. All wiring
should be done prior to installation and then
plugged into the rear of the OPS1.
Daisy-Chaining
The OPS1’s snap-lock input connector allows
for easy daisy-chaining of speakers by providing
a second terminal of each polarity. Refer to
the figures for proper wiring for daisy-chaining
of terminals.
Speaker Phasing
Keep the same polarity terminals wired together to ensure correct phasing. In order
to provide the best possible sound, all of the speakers in a system need to be push-
ing out and pulling in at the same time.
If the connections to one speaker in a system are reversed from the others, that
speaker’s movement will be out of sync with the other speakers. This will result in
a loss of low frequency response and will effect the overall performance of the
system.
54-2090-01D.qxp:54-2090-01B.qxd 9/9/09 4:52 PM Page 5

4
Speaker Installation
Speaker Assembly
1. Screw one nut onto each of the three (3) eye-
bolts. These nuts are used as spacers and
should be threaded on as far as they can go.
2. Screw in eyebolts with captured cable sec-
tions into the three (3) threaded anchor
points. Make these connections secure but do
not over tighten.
3. Snap the loops of the three (3) free ends of
the cable sections into the quick-snap clip.
4. Connect the quick-snap clip to the drop cable
loop (not included).
5. A separate eyebolt and nut are provided for
installing the safety cable attachment point.
Thread the nut on to the eyebolt as far as it
will go and thread this assembly into the safe-
ty point on the top of the speaker. Make this
connection secure but do not over tighten.
1. 2.
3. 4.
5.
Accessory
CK10 (Cable Kit, 10')
The CK10 is a 10-foot cable with one looped end, a forged eyebolt (with 1/4-20" x
1/2" thread), and an adjustable cable clamp. It is suitable for use as a drop cable or
safety cable. The CK10 is available in black, white, or silver.
Cables
A BACKUP SAFETY CABLE FOR THE
PRIMARY DROP CABLE IS REQUIRED
FOR THE PROPER INSTALLATION OF
THIS SPEAKER.
SEE THE INSIDE FRONT COVER FOR
IMPORTANT WARNING INFORMATION.
Use wire rope or other drop line rated for at least 100 lbs. to ensure a safety margin.
If using wire rope with a coating, it is important that the coating be stripped away
where any clamping device is being used so that the bare wire cores of the cable are
being clamped. The anchor point of the building structure must be able to handle
100 lbs. and all clamping hardware must be very securely tightened unless otherwise
instructed. Use only one OPS1on a set of safety & suspension rigging.
54-2090-01D.qxp:54-2090-01B.qxd 9/9/09 4:52 PM Page 6

Specifications
5
SPECIFICATIONS OPS1
Frequency Response (-10 dB)*45 Hz to 19 kHz
LF Driver 6-1/2" MDT Metal-Alloy Cone
(MLS Voice Coil Centering System)
HF Driver 20 mm (3/4") Polycarbonate Dome
Sensitivity (1W/1m) 89.5 dBspl
Dispersion 140°
Impedance Ratings Low (16 ohms) / High (70V/100V)
Power Input (Max.) 100W @ 16 ohms; 32W @ 70V/100V
Power Settings (in watts)†70V: 32, 16, 8, 4, 2, 1W
100V: 32, 16, 8, 4, 2W
Enclosure Material Fire-rated (94VO) ABS
Grille Material Powder-Coated Perforated Metal
Terminations 4 Terminal Snap-Lock Input Connector
Product Weight 10 lb.
Speaker Dimensions 15" dia. x 9-1/4" D
Included Accessories
(1) Quick-Snap Clip; (1) Snap-Lock Input Connector;
(3) Suspension Cables w/Forged Eyebolts; (4) Nuts; (1) Separate Eyebolt
Optional Accessories Cable Kit (CK10)
Enclosure Finish & Color Textured Off-white or Dark Gray
Listings UL/C-UL Listed
*Free Space Response, 16-ohm input
†Front panel, switch-selected.
