bora PG11 User manual

EN
PG11UMEN-000
www.bora.com
Operating and installation instructions PG11
Gas glass ceramic cooktop with 2 cooking zones
1034765

Operating and installation instructions: Original Translation
Manufacturer
BORA Lüftungstechnik GmbH
Rosenheimer Str. 32
83064 Raubling
Germany
Contact
T +49 (0) 8035 / 907-240
F +49 (0) 8035 / 907-249
[email protected]
www.bora.com
The distribution and duplication of this document, as well as the use and disclosure of its contents are prohibited unless
expressly authorised.
© BORA Lüftungstechnik GmbH, 2014
All rights reserved.

EN
3
Table of Contents
www.bora.com
Table of Contents
1 General 4
2 Safety 6
2.1 General safety precautions.............................. 6
2.2 Safety instructions, operation.......................... 7
2.3 Safety instructions, assembly.......................... 8
2.4 Safety instructions, disassembly and disposal ... 8
2.5 Safety instructions, spare parts....................... 9
2.6 Use as intended............................................... 9
3 Technical data 10
4 Device description 11
4.1 Structure ....................................................... 11
4.2 Operating panel and operating principle ....... 11
4.3 Functional principle ....................................... 12
4.3.1 Suitable cookware ......................................... 12
4.3.2 Power levels .................................................. 12
4.4 Safety devices ............................................... 12
4.4.1 Safety thermocouple ..................................... 12
5 Installation 13
5.1 Checking the deliverables ............................. 13
5.2 Tool and aids ................................................. 13
5.3 Assembly instructions ................................... 13
5.3.1 Safety distances ............................................ 13
5.4 Cut-out dimensions ....................................... 14
5.5 Installing the cooktop.................................... 15
5.5.1 Installing the control box behind the
floor unit fixed front panel............................. 15
5.5.2 Installing the cooktop.................................... 17
5.6 Power connection.......................................... 18
5.7 Handover to user........................................... 18
6 Gas installation 19
6.1 Ventilation ..................................................... 19
6.2 Gas connection.............................................. 19
6.2.1 Additional installation notes for
Australia and New Zealand (AUS/NZS) ......... 20
6.2.2 Gas connection AUS/NZS............................. 20
6.3 Leak test of the gas connection .................... 22
6.4 Changing the gas type................................... 22
6.5 Handover to user........................................... 22
6.6 Nozzle table...................................................23
7 Operation 24
7.1 Ignite the gas burner ..................................... 24
7.2 Adjusting the power level .............................. 24
7.3 Correct use of the gas hob............................ 25
7.4 Use the gas cooktop with a
BORA cooktop extractor................................ 25
8 Cleaning and Maintenance 26
8.1 Cleaning agents............................................. 26
8.2 Maintaining the cooktop................................ 26
8.3 Cleaning the cooktop .................................... 26
8.3.1 Cleaning of the gas burners .......................... 27
8.3.2 Cleaning the control knobs............................ 27
9 Troubleshooting 28
10 Decommissioning,
disassembly and disposal 29
10.1 Decommissioning .......................................... 29
10.2 Disconnect the device from the gas supply... 29
10.3 Disassembly .................................................. 29
10.4 Disposing of the product in an
environmentally friendly way ......................... 29
11 Warranty, After Sales Service
and spare parts 30
11.1 Warranty ........................................................ 30
11.2 After Sales Service ........................................ 30
11.3 Spare parts.................................................... 30

EN
4
General
www.bora.com
INFO BORA Holding GmbH, BORA Vertriebs
GmbH & Co KG, BORA APAC Pty Ltd and BORA
Lüftungstechnik GmbH - hereinafter referred
to as BORA - shall not assume any liability for
damage caused by non-compliance with these
documents nor by improper assembly!
The electricity and gas connections must be
implemented by a certified engineer.
Assembly must only take place in compliance
with the applicable norms, regulations and
laws. All safety and warning information and
handling instructions in the operating and
assembly instructions must be followed.
Validity of the operating and assembly
instructions
This manual is valid for several versions of the device. For
this reason, it is possible that individual features are
described in the manual that do not apply to your device.
Other applicable documents
Additional documents are valid as well as these operating
and assembly instructions, and likewise need to be obser-
ved.
Please observe all documents included in the scope of
delivery.
INFO BORA cannot assume any liability for damage
caused by non-compliance with these docu-
ments!
Guidelines
These devices meet the following EC guidelines:
2004/108/EC EMC Directive
2006/95/EC Low-Voltage Directive
2009/125/EC Ecological Design Directive
2011/65/EC RoHS Directive
2009/142/EC Gas Appliances Directive
1 General
Target group
These operating and assembly instructions are intended
for the following target groups:
Target group Requirements
Users The Device may be used by chil-
dren from the age of 8 as well as
by people with limited physical,
sensory or mental capabilities or a
lack of experience and/or knowl-
edge, provided they are super-
vised, have been instructed in the
safe use of the device and have
understood the dangers involved.
Children must be supervised. All
safety and warning information
and handling instructions in the
operating manual must be fol-
lowed.
Ambitious Diyers Ambitious Diyers may carry out all
the necessary carpentry and
assembly work themselves provi-
ding that they have the necessary
skills and knowledge. They must
not connect the current and gas
themselves.
Assembly
expert
The assembly expert must carry
out all the necessary carpentry
and assembly work taking existing
regulations into account. The cur-
rent and gas connections must be
approved for the system in use by
a certified electrician before use.
Electrical
expert
The electrical connection must
only be executed by a certified
electrician. He/she also assumes
responsibility for the proper elec-
trical installation and commission-
ing.
Expert
gas connection
The gas connection must only be
implemented by a certified gas
engineer. He/she also assumes
responsibility for the proper gas
installation and commissioning.
Tab. 1.1: Target groups

EN
5
General
www.bora.com
Depiction of information
We used standard formatting, numbering, symbols, safety
instructions, terms and abbreviations so that you can work
quickly and safely when using this manual.
Instructions are marked with an arrow.
 Always perform all instructions in the prescribed
order.
Enumerations are indicated with a square bullet point at
the start of the line.
 Enumeration 1
 Enumeration 2
INFO Information notes point to special features
that must be taken into account.
Safety and warning instructions
The safety and warning instructions in this manual are em-
phasised with symbols and signal words.
Safety and warning instructions are structured as follows:
WARNING SYMBOL AND SIGNAL WORD!
Type and source of the danger
Results of non-compliance
 Measures to minimise risk
Please note:
 The warning symbol draws your attention to the risk.
 The signal word indicates the severity of that risk.
Warning
symbol
Signal word Risk
DANGER Indicates an immediate, haz-
ardous situation which
causes death or serious
injury if not respected.
WARNING Indicates a potentially haz-
ardous situation which can
cause death or serious
injury if not respected.
CAUTION Indicates a possible hazard-
ous situation which can
cause minor injury if not
respected.
— CAUTION Indicates a situation which
can cause minor injury if not
respected.
Tab. 1.2: Meaning of the warning symbols and signal
words

EN
6
Safety
www.bora.com
 Set the cooktop extractor to a low setting for about
15 minutes or activate the automatic after-run after
every use in the recirculated air mode.
When there are children and people with
special needs in the house
 This device may be used by children from the age of 8
as well as by persons with limited physical, sensory or
mental capabilities or a lack of experience and/or
knowledge, provided they are supervised, have been
instructed in the safe use of the device and have
understood the dangers involved.
 Do not leave children unattended when they are near
the device.
 Children must not play with the device.
 Use the child safety lock in order to prevent children
from switching on the cooktop or changing the set-
tings when they are unattended.
 Do not store any objects that could be of interest to
children in storage spaces above or behind the device.
Otherwise, the children will be tempted to climb onto
the device.
 Keep children and other persons away from the coo-
king surfaces.
Unauthorised modifications
Due to unauthorised modifications
The device can constitute a hazard.
 Do not make any changes to the device.
Cleaning and Maintenance
The device must be cleaned at regular intervals. Dirt can
lead to damage or odour nuisance.
Remove dirt immediately.
 Any work involving cleaning and user maintenance
must not be carried out by children unless they are
supervised at all times while doing so.
 Do not use a steam cleaner for cleaning. Steam can
cause a short circuit on live parts and thus lead to pro-
perty damage (see the Cleaning chapter).
 Do not place any hot cookware in the area of the con-
trol panel so as not to damage the underlying
electronics.
 When cleaning the device, water must not penetrate
the interior of the device. Use only a slightly damp
cloth. Never spray the device with water. Water penet-
ration can cause damage!
 Whenever possible, clean the cooktop after every use.
 Clean the cooktop only after it has cooled down.
 When cleaning, only use non-abrasive cleaning agents
to prevent scratching and abrasion on the surface.
 Make sure that the base of the cookware as well as
the cooking zone are clean and dry.
 Always lift (do not drag!) the cookware to prevent
scratching and abrasion on the surface.
2 Safety
2.1 General safety precautions
INFO The product complies with the mandatory
safety provisions.
The user is responsible for cleaning, care and
safe use of the device. Any improper use may
lead to personal injury and property damage.
 This operating and installation instructions contain
important information concerning assembly and opera-
tion. It protects you from injury and prevents damage
to the product. You can find contact data to get
further information and answers to questions about
the use of the product on the last page of this opera-
ting and installation instructions.
 The term "device" is used to refer to cooktop, cooktop
extractor or cooktop with integrated cooktop extrac-
tor.
 Read this operating and installation instructions in full
before you assemble the device and start to use it.
 Always keep these operating and installation instruc-
tions to hand so it is available when needed.
 After selling the device, pass on the operating and ins-
tallation manual to the new owner.
 Carry out all work with great care and attention.
 Check the device for visible damage after unpacking.
 Do not install a damaged device.
 Do not use the device until installation is complete.
Only in this way a safe operation can be guaranteed.
 Make sure contact with hot cooking surfaces is not
possible.
 Avoid over-cooking.
 Pay attention to the residual heat indicator.
 Turn the device off after use. Do not rely on the pan
size recognition.
 Keep pets away from the device.
Recirculated air mode
INFO Every time the device is used for cooking, sup-
plementary moisture is released into the room
air.
INFO In the recirculated air mode, only a small
amount of moisture is removed from the coo-
king vapours.
 Make sure that the room is sufficiently ventilated to
the outside air in the recirculated air mode, e.g.
through an open window.
 Ensure a normal and comfortable indoor climate
(45-60% humidity), e.g. through natural ventilation
openings or domestic ventilation systems.

EN
7
Safety
www.bora.com
WARNING!
Danger of fire caused by objects on the
cooktop!
The cooktop and its touchable parts become
hot when the cooking zone is switched on
and while it is cooling down. Objects on the
cooktop can heat up and ignite.
 Do not leave any objects on the cooktop.
WARNING!
Risk of burns caused by hot objects!
The cooktop and its touchable parts become
hot when the cooking zone is switched on and
while it is cooling down. Objects (pot lid, cook-
top extractor cover) on the cooktop become
hot very quickly and can lead to serious burns.
 Do not leave any objects on the cooktop.
 Use suitable aids (pot cloths, thermal
glove).
WARNING!
Risk of burns caused by hot cookware!
Handles protruding over the worktops can
induce children to grab them.
 Do not turn the handles on the pots or
pans to one side over the worktop.
 Prevent children from pulling down hot
pots and pans.
 A special stove guard for children (available
in specialist shops) reduces the danger.
WARNING!
Risk of burns!
Liquids between the cooking zone and base of
the pot can scald the skin when steaming up.
 Make sure that the cooking zone and the
base of the pot are always dry.
CAUTION!
Damage caused by hard and pointed objects!
Hard and pointed objects may cause damage
to the glass ceramic plate of the cooktop.
 Do not use the cooktop surface as a
kitchen worktop.
 Do not use any hard and pointed objects
when working on the cooktop.
2.2 Safety instructions, operation
Cooktop
DANGER!
Danger of fire caused by leaving the cooktop
unattended!
Oil or fat in the pot can quickly heat up and
ignite.
 Never leave oil or fat to heat up unattended.
 Never extinguish oil and fat fires with water.
 Suffocate the fire, for example by using a lid.
DANGER!
Danger of explosion caused by flammable
materials!
Flammable materials (spray) in the vicinity of
the cooktop can explode and cause serious
injury.
 Do not place any flammable materials in
the vicinity of the cooktop.
DANGER!
Danger of electric shock!
Cracks, ssures or fractures in the glass
ceramic panel can damage the underlying
electronics. This can cause an electrical
shock.
 If there are any cracks, fissures or
fractures in the glass ceramic, switch the
device off immediately.
 Safely disconnect the device from the
mains using miniature or automatic circuit
breakers, fuses or contactors.
DANGER!
Danger of fire caused by an open flame!
An open ame can ignite inammable objects.
 Turn the gas flame down to the lowest set-
ting if you quickly remove pots or pans
from the heat.
 Never leave an open flame unattended.
 Suffocate a fire, for example, by using a lid
or a special fire blanket.
 Turn off the gas supply and switch off the
fuse of the electrical wiring.
WARNING!
Risk of burns caused by a hot cooktop!
The cooktop and its touchable parts become
hot during operation. After turning o the
cooking zone, allow it to cool down to less
than 60°C rst. Touching hot surfaces can
lead to serious burns.
 Do not touch the hot cooktop.
 Keep children away from the hot cooktop
unless they are under constant supervision.

EN
8
Safety
www.bora.com
DANGER!
Danger of electric shock!
The connection cable can be damaged if it
comes into contact with hot cooking zones.
A damaged connection cable can cause a
(fatal) electrical shock.
 Make sure that the connection cable does
not come into contact with hot cooking
surfaces.
 Make sure that the connection cable is not
caught or damaged.
DANGER!
Danger of explosion caused by gas!
A gas leakage can cause an explosion and
serious injury.
 Keep away from sources of ignition (open
flames, radiant heaters).
 Turn off the gas supply and switch off the
fuse of the electrical wiring.
 Seal leakages immediately.
CAUTION!
Back injury caused by heavy loads!
When removing and inserting the device,
incorrect handling may cause injuries to the
limbs and the trunk.
 Always lift the device out of the packaging
with two persons.
 Always place the device onto the worktop
cut-out with two persons.
 Use suitable aids to prevent damage to the
limbs and the trunk.
 Check the device for visible damages before installing it.
 Do not install a damaged device.
 A damaged device may put your safety at risk!
Repair and maintenance work may only be carried out by
specialists authorised by the manufacturer.
2.4 Safety instructions, disassembly
and disposal
Disassembly of the device may only be carried out by
trained personnel who are familiar with and comply
with common national regulations and supplementary
regulations of the local utility companies.
Work on electrical parts may only be carried out by trained
electrical personnel.
Work on the gas connection may only be carried out by an
authorised gas fitter in accordance with legal applicable
regulations. Comply with local regulations of the utility
companies.
CAUTION!
Damage caused by substances containing
sugar and salt!
Substances containing sugar and salt and
juices can damage the cooking zone when
they are spilled on its hot surface.
 Make sure that no food or drinks
containing sugar or salt and juices are
spilled onto the hot cooking zones.
 Immediately remove food or drinks
containing sugar or salt and juices
from the hot cooking zone.
2.3 Safety instructions, assembly
Installation and assembly of the device may only be
carried out by trained personnel who are familiar with
and comply with common national regulations and
supplementary regulations of the local utility companies.
Work on electrical parts must only be carried out by
trained electrical personnel.
The electrical safety of the device is only guaranteed if it
is connected to a properly installed protective conductor
system. Make sure that these basic safety precautions
have been taken.
The gas connection may only be carried out by an autho-
rised gas fitter in accordance with legal applicable regulati-
ons. Comply with local regulations of the utility companies.
Cooktop
DANGER!
Danger of electric shock!
Connecting the device incorrectly to the mains
poses a risk of electric shock.
 Make sure that the device has a fixed
connection to the mains voltage.
 Make sure that the device is connected to
a properly installed protective conductor
system.
 Make sure that technical equipment is
provided to allow for all of the device's
poles to be disconnected from the mains
with a contact opening width of at least
3 mm (miniature and automatic circuit
breakers, fuses, contactors).

EN
9
Safety
www.bora.com
2.6 Use as intended
The device is solely intended for preparing food in private
households.
This device is not designed for:
 use outdoors
 installation in vehicles
 heating the room
 use in non-fixed installation sites (e.g. on ships)
 use with an external timer or separate remote control
system.
Not using the device as described in this operating and
assembly manual is considered not using the device as
intended, as is using it beyond the purpose described here.
BORA shall not assume any liability for damages caused by
improper use or incorrect operation.
All misuse is prohibited!
INFO BORA Holding GmbH, BORA Vertriebs GmbH &
Co KG, BORA APAC Pty Ltd and BORA Lüftungs-
technik GmbH shall not assume any liability
for damage arising from non-adherence to the
safety and warning instructions.
DANGER!
Danger of electric shock!
Disconnecting the device incorrectly from the
mains poses a risk of electric shock.
 Safely disconnect the device from the
mains using miniature or automatic circuit
breakers, fuses or contactors.
 Use a suitable measuring device to ensure
that the device is de-energised.
DANGER!
Risk of suffocation!
Parts of the packaging (e.g. lms, polystyrene)
can be fatal to children.
 Store packaging materials away from the
reach of children.
 Dispose of packaging correctly and
promptly.
2.5 Safety instructions, spare parts
WARNING!
Risk of injury and damage to property!
Incorrect parts can lead to injury to persons or
damage to device! Modications, attachment
parts or conversions to device can impair
safety.
 Only use original spare parts when carrying
out repairs.

EN
10
Technical data
www.bora.com
3 Technical data
Parameter Value
Supply voltage 220 - 240 V
Frequency 50/60 Hz
Power consumption 5.75 kW
Power rating 0.8 W
Fuse protection, minimum 1 x 0.5 A
Dimensions (width x depth x
height) cooktop pan support
370 x 540 x 47 mm
370 x 540 x 42 mm
Control box dimensions
(width x depth x height)
174 x 147 x 66 mm
Weight (incl. accessories/
packaging)
12.4 kg
Cooktop
Power levels Continuous
Front high-power burner 600-4000 W
Back normal burner 350-1750 W
Cooktop energy consump-
tion
Front high-power burner 600-4000 W 58.1%
Back normal burner 350-1750 W 56.3%
Total (average) 57.2%
Tab. 3.1: Technical data
Device dimensions
370
255
540
47
42
Fig. 3.1 Device dimensions
174
147
66
42
20
90
Fig. 3.2 Control box dimensions

EN
11
Device description
www.bora.com
4.2 Operating panel and operating
principle
1 32
Fig. 4.2 Control knobs
[1] Control knob for the front hob
[2] Power level sleeve
[3] Control knob for the back hob
Display panel Display Meaning
Power levels Small
flame
Minimal gas output
Large
flame
Maximum gas output
0 position No gas output
Tab. 4.1: Signicance of the power levels
Knob operation
The control box is equipped with two control knobs.
The control knobs are used to ignite the burner, switch
hobs on and off and regulate the relevant hob. To operate
the appliance, set the control knob to the corresponding
power level.
The cooking zone indicator is not active for gas cooktops
because the cooktop function can be monitored based on
the active burner flame.
4 Device description
Observe all safety and warning information during operation
(see the Safety chapter).
The cooktop with control box has the following features:
 High-power front burner
 Normal back burner
 Two control knobs
 Cast iron pan support
4.1 Structure
1 2
345
Fig. 4.1 Cooktop with control box
[1] High-power front burner
[2] Normal back burner
[3] Pan support
[4] Control knob for the back hob
[5] Control knob for the front hob

EN
12
Device description
www.bora.com
4.3.2 Power levels
The power output of gas cooktops results in food being
quickly heated. A slight adjustment is needed in comparison
to conventional cooking systems when selecting the power
level in order to avoid burning food.
Activity Power level
Keeping cooked meals warm Minimal flame
Browning chopped vegetables,
fried eggs, veal, poultry
Medium flame
Grilling prawns, corn on the cob,
schnitzel, beef, fish or burgers
Large flame
Heating water and searing Maximum flame
Tab. 4.3: Recommendations for power levels
The specifications provided in the table are standard
values.
4.4 Safety devices
4.4.1 Safety thermocouple
The gas burners are equipped with a safety thermocouple.
This thermocouple monitors the burner flame when the gas
supply is active. If the burner flame goes out unintentionally,
the appliance interrupts the gas supply. The appliance does
not automatically ignite the burner.
4.3 Functional principle
If a cooking zone is switched on, the flame generates heat,
which directly heats the base of the cookware. The power
levels can be continuously adjusted.
4.3.1 Suitable cookware
INFO The heating and heat through time for the
base of the cookware as well as the cooking
results are significantly influenced by the
structure and material of the cookware.
Cookware with this symbol is suitable for gas
cooktops.
Suitable cookware is made of:
 Copper
 Stainless steel
 Aluminium
 cast iron
 Adhere to the dimensions in the table:
Burner position Recommended
pan diameter
Minimum
pan diameter
Normal burner 140-200 mm 120 mm
High-power
burner
180-240 mm 160 mm
Tab. 4.2: Pan diameters

EN
13
Installation
www.bora.com
5.2 Tool and aids
The following tools are required for the correct installation
of the cooktop:
 Pencil
 Drill or cordless drill with Forstner bit Ø30mm
 Drilling template (included in scope of delivery)
 Phillips screwdriver Z2
 Silicone sealant for sealing cutting surfaces
5.3 Assembly instructions
5.3.1 Safety distances
 Maintain the following safety distances:
1
3
2
Fig. 5.1 Minimum distance
[1] Minimum distance of 50 mm at the back from of the worktop
cut-out to the rear edge of the worktop.
[2] Minimum distance of 50 mm from the left and right of
the worktop cut-out to the adjacent cabinet or wall.
For ergonomic reasons and to ensure efficient cooktop
extraction, a minimum distance of 300 mm is recommended.
[3] Minimum distance of 700 mm between the worktop and the
wall unit. A minimum distance of 1000 mm is recommended
for ergonomic reasons.
5 Installation
 Observe all safety and warning information
(see the Safety chapter).
 Follow the enclosed manufacturer‘s information.
INFO The cooktop must not be installed above
cooling devices, dishwashers, stoves, baking
ovens, washing machines or driers.
INFO The contact surface of the worktops and wall
sealing strips must be made of a heat-resistant
material (up to approx. 100 °C).
INFO Worktop cut-outs must be moisture-sealed
using suitable means or, where necessary,
fitted with a thermal insulator.
5.1 Checking the deliverables
Name Quantity
Control box adjustment plates 6
Control knobs 2
Operating and installation instructions 1
Fixing nuts 2
Cooktop mounting screws 4
Control box fixing screws 2
Drilling template 1
Height adjustment plate set 1
Allen key 1
Cooktop 1
Power level sleeve 2
Mounting bracket 1
Cooktop mounting straps 4
Cleaning instructions for glass ceramic 1
Glass ceramic scraper 1
Pan support 1
Air baffle 1
Cylindrical/conical transition piece 1
Cylindrical/cylindrical transition piece 1
Seal 2
Tab. 5.1: Scope of delivery
 Check the scope of delivery for damage and make
sure it is complete.
 If there are any missing or damaged parts, please
notify BORA After Sales Service immediately.
 Do not under any circumstances install parts which
are damaged.
 Dispose of transport packaging in the proper manner
(see the Decommissioning and Disposal chapter).

EN
14
Installation
www.bora.com
Surface installation
B
<R5
> 74 516
> 700
Fig. 5.4 Surface installation
12
10 ... 40
Fig. 5.5 Surface mounting cut
Cut-out dimensions when installing cooktops or cooktops
and the cooktop extractor next to each other:
Cooktops / cooktop extractor A in mm B in mm
1/0 374 346
2/0 745 717
3/0 1116 1088
1/1 485 457
2/1 856 828
3/2 1338 1310
4/2 1709 1681
Tab. 5.2: Cut-out dimensions
5.4 Cut-out dimensions
Preparing the worktop
 Create the worktop cut-out taking into account the
specified cut-out dimensions.
 Make sure that the cutting surfaces of the
worktops are properly sealed.
 Comply with the instructions of the
worktop manufacturer.
Flush installation
A
B
544
R5
<R5
> 74 516
> 700
Fig. 5.2 Flush installation
6
14
10 ... 40
Fig. 5.3 Dimension of groove for ush installation
INFO If the induction glass ceramic wok is used,
the groove dimensions must be increased to
7 mm for flush installation.

EN
15
Installation
www.bora.com
5.5.1 Installing the control box behind the
floor unit fixed front panel
Fig. 5.7 Installed control box and cooktop
1
2
34
65
Fig. 5.8 Control box structure
[1] Control box
[2] Adjustment plates
[3] Fixed front panel (not included in scope of delivery)
[4] Power level sleeve
[5] Nuts
[6] Control knobs
 Draw the bore holes accordingly with the aid of the
drilling template provided.
5.5 Installing the cooktop
INFO A gap of one millimetre should be planned
between the built-in appliances.
INFO A gap of two millimetres should be planned
around the built-in appliances.
INFO The mounting rail supplied with the cooktop
should be installed between the cooktops as
well as between the cooktops and the cooktop
extractor.
INFO Cable protection (a false floor) should be
mounted below the appliance. This needs to
be removable for maintenance work.
> 20
100
7
Fig. 5.6 Side view of the cable protection and ventilation
 Cross bars on the kitchen unit in the area of the
worktop cut-out may need to be removed.
 The drawers and/or shelves in the floor unit must be
removable for maintenance and cleaning purposes.

EN
16
Installation
www.bora.com
Secure the control box
 Position the control box [1] with the attached
adjustment plates [2] from the back into the bore
holes in the fixed front panel.
 Attach the two power level sleeves [4] to the front
of the fixed front panel.
Fig. 5.10 Tighten the xing nuts
 Screw on the fixing nuts [5] with the mounting bracket
and tighten the fixing nuts with max. 10 Nm.
 Insert the lens from the front into the power level
sleeve.
 Put on the control knob [6].
Adjust the control knob
For fine adjustment, the distance between the control
knob and the power level sleeve can be set.
Fig. 5.11 Position control knob
18,5 mm
Fig. 5.12 Distance of the control knob
1
2
90
5
5
>105
37
Ø6
Ø30
Fig. 5.9 Drilling template
[1] Worktop
[2] Fixed front panel
 Pre-drill the bore holes to prevent tearing out the fixed
front panel.
Determine the number of adjustment plates
 The total dimensions of the adjustment plates [2] and
the fixed front panel [3] should be 36 mm.
 The total dimensions of 36 mm must be adhered to in
order to ensure that the control box [1] functions
smoothly.
Panel
thickness
[mm]
Total
thickness
of adjust-
ment
plates
[mm]
Adjustment plates [quantity]
10 mm 5 mm 3 mm 2 mm
34 2 - - - 1
33 3 - - 1 -
32 4 - - - 2
31 5 - - 1 1
30 6 - - 2 -
29 7 - 1 - 1
28 8 - 1 1 -
27 9 - 1 - 2
26 10 1 - - -
25 11 - 1 2 -
24 12 1 - - 1
23 13 1 - 1 -
22 14 1 - - 2
21 15 1 1 - -
20 16 1 - 2 -
19 17 1 1 - 1
18 18 1 1 1 -
17 19 1 1 - 2
16 20 1 1 1 1
15 21 1 1 2 -
14 22 1 1 1 2
13 23 1 1 2 1
Tab. 5.3: Adjustment plate overview

EN
17
Installation
www.bora.com
 If applicable, insert the height adjustment plate [2].
2
1
Fig. 5.15 Mounting brackets
[1] Screw
[2] Mounting bracket
 Fasten the cooktop [1] using the mounting brackets
[2].
 Tighten the mounting bracket screws [1] with
max. 10 Nm.
 Verify that the alignment is correct.
 Seal the devices with black heat-resistant silicone
sealing compound after the installation work is
completed.
Connecting the cooktop and the control box
 Create the connection between the cooktop and the
control box.
 Firstly connect the yellow/green earthing cable to the
indicated point on the control box.
Earthing symbol
 Now connect the multi-pin, colour-coded plugs on
the relevant cooking zone to the corresponding
colour-coded sockets on the control box.
5.5.2 Installing the cooktop
1
2
Fig. 5.13 Insert the mounting rail and cooktop
[1] Cooktop
[2] Mounting rail
 Place the mounting rail [2] in the worktop cut-out.
 Insert the cooktop [1].
 Align the cooktop [1] exactly.
 Align the mounting rail [2] so that it is positioned
evenly under the cooktop and the cooktop extractor
PL540.
1
2
Fig. 5.14 Cooktop and height adjustment plates
[1] Cooktop
[2] Height adjustment plates

EN
18
Installation
www.bora.com
1
L1
2
N PE
220 - 240 V~
Fig. 5.16 Connection diagram 1-phase
 Create the connection between the cooktop and the
control box.
 Verify that the installation was done correctly.
 Switch on the main switch/automatic circuit breaker.
 Put the cooktop into operation
(see the Operation section).
 Check all the functions are working correctly.
5.7 Handover to user
Once installation is done:
 Explain the important functions to the user.
 Explain all safety-relevant aspects of operation and
handling to the user.
 Provide the user with the accessories and operating
and installation instructions to be kept in a safe place.
 Create a connection to the gas hose:
 Remove both protective caps from the gas taps on the
control box.
 Check that the o-ring inside each gas tap is firmly in
place.
 Remove both protective caps on the gas supply lines
on the gas cooktop.
 Connect the colour-coded gas supply lines to the
corresponding colour-coded gas taps.
 Secure a locking spring on each connection and
ensure that this is engaged.
5.6 Power connection
 Observe all safety and warning information
(see the Safety chapter).
 Observe all national and regional laws and regulations
as well as the supplementary regulations of the local
utility companies.
INFO INFO The power connection may only be es-
tablished by a certified specialist. He/she also
assumes responsibility for the proper installa-
tion and commissioning.
The power supply line for use (pre-assembled) must be at
least Type H05VV-F or H05VVH2-F.
 Cross-section: 3G1.5 mm² with 1-phase connection
 If the connection line has been damaged this must be
replaced by a special connection line. This may only
be done by an authorized member of the After Sales
Service team.
Establishing the power connection
 Switch off the main switch/automatic circuit breaker
before connecting the cooktop.
 Protect the main switch/automatic circuit breaker
from being switched on without permission.
 Make sure the device is not energised.
 Only connect the cooktop using a permanent
connection to a power supply cable.

EN
19
Gas installation
www.bora.com
Country Regulation/guidelines
Germany: DVGW-TRGI 2008 or TRF 1996
Austria: ÖVGW guideline G1
Switzerland: SvgW Gas Regulations G1
EKAS guideline no. 1942:
Liquid gas, part 2
Regulations of the Vereinigung
Kantonaler Feuerversicherungen (VKF)
Netherlands/
Belgium/
France:
Regulations of standard NBN D 51-003
Regulations and connection
requirements of the
gas supply company (G.D.F.) and
electricity supply company (E.D.F)
Tab. 6.1: Country requirements (information supplied
without liability)
6.1 Ventilation
This appliance is not connected to a flue gas evacuation
device. It must be positioned and connected in accordance
with the applicable installation conditions. Suitable
ventilation measures must be adhered to in particular.
 Always ensure sufficient ventilation during operation
(of the appliance).
6.2 Gas connection
This gas cooking appliance corresponds to device class 3.
It is equipped with a flexible connection tube.
 The installation of a security gas socket in the adjacent
enclosure is recommended.
 The connection of liquid gas (LPG) is performed with
the interconnection of a sealed connection socket
pipe D: 8x1mm
 The connection to the gas supply is to be created with
flexible and seamless pipes made from stainless steel.
 The connection with a security gas socket is to be
created in accordance with DIN 3383 with a maximum
length of 1500 mm.
 The connection bracket and connection pieces must
be equipped with a 1/2 inch external thread in
accordance with the regulatory country requirements
(see table 6.2 Connection bracket).
6 Gas installation
 Observe all safety and warning information (see the
Safety chapter).
 Observe all national and regional laws and regulations,
as well as the supplementary regulations of the local
gas supply companies.
 Follow the enclosed manufacturer‘s information.
INFO Taking into account the applicable valid
regulations, the cooktop must be connected to
the gas line with an upstream stopcock.
INFO The gas supply pipe can be connected after
the gas cooktop has been installed.
INFO The hose connection must be laid in such a
way that it is not subject to deformation,
buckling or abrasion.
INFO The stopcock and gas supply pipe connections
must be accessible.
INFO It must be possible to inspect the entire length
of the hose line once installed.
INFO Only compatible connection pieces are to be
used for the hose line.
INFO The gas connection hose line must not come
into contact with smoke or the flue outlet of
an oven.
INFO The hose line must not come into contact with
hot surfaces on the cooktop or other devices.
The gas connection may only be carried out by an
authorised gas fitter in accordance with applicable legal
and local regulations. Comply with local regulations of
the utility companies.

EN
20
Gas installation
www.bora.com
6.2.1 Additional installation notes for
Australia and New Zealand (AUS/NZS)
 Adhere to all previous information in this section
 In addition, adhere to the requirements of the currently
applicable version of the regulations:
NZS5261 AS5601/AG601
6.2.2 Gas connection AUS/NZS
Check the extended scope of delivery
Name Quantity
Gas regulator with test point for natural gas
(NG)
1
Test point adapter for liquid gas (LPG) 1
Tab. 6.3: Extended scope of delivery for AUS/NSZ
Create the gas connection
 The connection must be created with a rigid pipe that
is resistant to bending as specified in AS5601.
 The connection with a security gas socket is to be
created in accordance with AS/NZS 1869
(AGA authorised) with a diameter of 10 mm,
class B or D and a length of no more than 1,200 mm
in accordance with AS5601.
 Connect the appliance as follows:
 Switch off the main switch/automatic circuit breaker
before connecting the cooktop.
 Protect the main switch/automatic circuit breaker
from being switched on without permission.
 Make sure the device is not energised.
 Check the gas type and gas pressure of the gas supply
pipe.
 Ensure that the appliance is equipped with the correct
nozzle type in order to guarantee a correct burner
flame and safe operation.
 Connect the appliance as follows:
 Set the control knob to the 0 position.
 Close the gas supply.
 Switch off the main switch/automatic circuit breaker
before connecting the cooktop.
 Protect the main switch/automatic circuit breaker
from being switched on without permission.
 Make sure the device is not energised.
 Check the gas type and gas pressure of the gas supply
pipe.
 Ensure that the appliance is equipped with the correct
nozzle type in order to guarantee a correct burner
flame and safe operation.
 Remove the protective cap from the connection tube.
 Use a security gas socket to connect this directly to
the connection bracket of the gas cooktop in a
gas-tight manner using a permitted security bracket.
 If using a connection bracket, screw this on securely
with the attached seal.
ISO 228-1
ISO 7-1
(EN10226)
ISO 228-1
ISO 228-1
Tab. 6.2: Connection bracket
 Only use the type of connection bracket permitted in
your country.
 ISO 228-1/ISO7-1(EN10226): cylindrical/conical
 ISO 228-1/ISO 228-1: cylindrical/cylindrical
 Connect the appliance to the gas supply pipe.
 Tighten all connections so that they are secure.
 Verify that the installation was done correctly.
 Check the correct functioning of the stopcock.
 Check the tightness of the gas connection by
conducting a leak test (see Leak test section).
 Switch on the main switch/automatic circuit breaker.
 Put the cooktop into operation (see the Operation
chapter).
 Check all the functions and the burner flame are
working correctly.
