IKEA LAGAN User manual

LAGAN
GB

ENGLISH
Please refer to the last page of this manual for the full list of IKEA
appointed After Sales Service Provider and relative national phone
numbers.

ENGLISH 4
LANGUAGE
COUNTRY

Contents
Safety information 4
Safety instructions 6
Installation 9
Product description 10
Daily use 11
Hints and tips 12
Care and cleaning 12
Troubleshooting 13
Technical data 14
Electrical connection 15
Gas connection 16
Energy efficiency 18
Environmental concerns 19
IKEA guarantee 19
Subject to change without notice.
Safety information
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible if
an incorrect installation and use causes injuries and damages.
Always keep the instructions with the appliance for future
reference.
Children and vulnerable people safety
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
•Children between 3 and 8 years of age and persons with
very extensive and complex disabilities shall be kept away
unless continuously supervised.
•Children of less than 3 years of age should be kept away
unless continuously supervised.
•Do not let children play with the appliance.
•Keep all packaging away from children and dispose of it
appropriately.
•Keep children and pets away from the appliance when it
operates or when it cools down. Accessible parts are hot.
ENGLISH 4

•If the appliance has a child safety device, it should be
activated.
•Children shall not carry out cleaning and user maintenance of
the appliance without supervision.
General Safety
•WARNING: The appliance and its accessible parts become
hot during use. Care should be taken to avoid touching
heating elements.
•Do not operate the appliance by means of an external timer
or separate remote-control system.
•WARNING: Unattended cooking on a hob with fat or oil can
be dangerous and may result in fire.
•NEVER try to extinguish a fire with water, but switch off the
appliance and then cover flame e.g. with a lid or a fire
blanket.
•CAUTION: The cooking process has to be supervised. A short
term cooking process has to be supervised continuously.
•WARNING: Danger of fire: Do not store items on the cooking
surfaces.
•Metallic objects such as knives, forks, spoons and lids should
not be placed on the hob surface since they can get hot.
•Do not use a steam cleaner to clean the appliance.
•If the supply cord is damaged, it must be replaced by the
manufacturer, the Authorised Service Centre or similarly
qualified persons in order to avoid a hazard.
•Where the appliance is directly connected to the power
supply, an all-pole isolating switch with a contact gap is
required. Complete disconnection in compliance with the
conditions specified in overvoltage category III must be
guaranteed. The earth cable is excluded from this.
•When you route the mains cable, make sure that the cable
doesn't come into direct contact (for example using insulating
ENGLISH 5

sleeving) with parts that can reach temperatures of more than
50°C above room temperature.
•WARNING: Use only hob guards designed by the
manufacturer of the cooking appliance or indicated by the
manufacturer of the appliance in the instructions for use as
suitable or hob guards incorporated in the appliance. The
use of inappropriate guards can cause accidents.
Safety instructions
Installation
Warning! The appliance must be
installed by the authorised
installer.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Keep the minimum distance from other
appliances and units.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Seal the cut surfaces with a sealant to
prevent moisture to cause swelling.
• Protect the bottom of the appliance from
steam and moisture.
• Do not install the appliance adjacent to
a door or under a window. This prevents
hot cookware falling from the appliance
when the door or the window is opened.
• If the appliance is installed above
drawers make sure that the space,
between the bottom of the appliance
and the upper drawer, is sufficient for air
circulation.
• The bottom of the appliance can get hot.
Make sure to install a non-combustible
separation panel under the appliance to
prevent access to the bottom.
Refer to the Assembly Instructions.
Electrical Connection
Warning! Risk of fire and electric
shock.
• All electrical connections should be made
by the authorised installer.
• The appliance must be earthed.
• Before carrying out any operation make
sure that the appliance is disconnected
from the power supply.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Make sure the appliance is installed
correctly. Loose and incorrect electricity
mains cable or plug (if applicable) can
make the terminal become too hot.
• Use the correct electricity mains cable.
• Do not let the electricity mains cable
tangle.
• Make sure that a shock protection is
installed.
• Use the strain relief clamp on the cable.
• Make sure the mains cable or plug (if
applicable) does not touch the hot
appliance or hot cookware, when you
connect the appliance to the near
sockets.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug (if applicable) or to the mains
cable. Contact our Authorised Service
ENGLISH 6

Centre or an electrician to change a
damaged mains cable.
• The shock protection of live and
insulated parts must be fastened in such
a way that it cannot be removed without
tools.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains
plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device which lets you disconnect
the appliance from the mains at all poles.
The isolation device must have a contact
opening width of minimum 3 mm.
Gas connection
Warning! Risk of fire and
explosion
• All gas connections should be made by
the authorised installer.
• Before installation, make sure that the
local distribution conditions (nature of the
gas and gas pressure) and the
adjustment of the appliance are
compatible.
• Make sure that there is air circulation
around the appliance.
• The information about the gas supply is
on the rating plate.
• This appliance is not connected to a
device, which evacuates the products of
combustion. Make sure to connect the
appliance according to current
installation regulations. Pay attention to
requirements regarding adequate
ventilation.
Use
Warning! Risk of injury, burns
and electric shock.
• Remove all the packaging, labelling and
protective film (if applicable) before first
use.
• This appliance is for household use only.
• Do not change the specification of this
appliance.
• Make sure that the ventilation openings
are not blocked.
• Do not let the appliance stay unattended
during operation.
• Set the cooking zone to “off” after each
use.
• Do not put cutlery or saucepan lids on
the cooking zones. They can become hot.
• Do not operate the appliance with wet
hands or when it has contact with water.
• Do not use the appliance as a work
surface or as a storage surface.
• When you place food into hot oil, it may
splash.
Warning! Risk of fire and
explosion
• Fats and oil when heated can release
flammable vapours. Keep flames or
heated objects away from fats and oils
when you cook with them.
• The vapours that very hot oil releases
can cause spontaneous combustion.
• Used oil, that can contain food remnants,
can cause fire at a lower temperature
than oil used for the first time.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
Warning! Risk of damage to the
appliance.
• Do not keep hot cookware on the control
panel.
• Do not let cookware to boil dry.
• Be careful not to let objects or cookware
fall on the appliance. The surface can be
damaged.
ENGLISH 7

• Do not activate the cooking zones with
empty cookware or without cookware.
• Do not put aluminium foil on the
appliance.
• Use only stable cookware with the
correct shape and diameter larger than
the dimensions of the burners.
• Make sure cookware is centrally
positioned on the burners.
• Do not use large cookware that overlap
the edges of the appliance. This can
cause damage to the worktop surface.
• Make sure the flame does not go out
when you quickly turn the knob from the
maximum to the minimum position.
• Use only the accessories supplied with
the appliance.
• Do not install a flame diffuser on the
burner.
• The use of a gas cooking appliance
results in the production of heat and
moisture. Provide good ventilation in the
room where the appliance is installed.
• Prolonged intensive use of the appliance
may call for additional ventilation, for
example opening of a window, or more
effective ventilation, for example
increasing the level of mechanical
ventilation where present.
• This appliance is for cooking purposes
only. It must not be used for other
purposes, for example room heating.
• Do not let acid liquids, for example
vinegar, lemon juice or limescale
remover, touch the hob. This can cause
matt patches.
• Discoloration of the enamel or stainless
steel has no effect on the performance of
the appliance.
Care and cleaning
Warning! Do not remove the
buttons, knobs or gaskets from
the control panel. Water may get
inside the appliance and cause
damage.
• Clean the appliance regularly to prevent
the deterioration of the surface material.
• Deactivate the appliance and let it cool
down before you clean it.
• Disconnect the appliance from the
electrical supply before maintenance.
• Do not use water spray and steam to
clean the appliance.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use any abrasive products, abrasive
cleaning pads, solvents or metal objects.
• Do not clean the burners in the
dishwasher.
Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
Disposal
Warning! Risk of injury or
suffocation.
• Contact your municipal authority for
information on how to discard the
appliance correctly.
• Disconnect the appliance from the mains
supply.
• Cut off the mains electrical cable close to
the appliance and dispose of it.
• Flat the external gas pipes.
ENGLISH 8

Installation
Warning! Refer to Safety
chapters.
General information
Warning! This appliance must be
installed, connected or repaired
only by a registered competent
person to the relevant gas
standard. Use only parts
provided with the product. Use
only original spare parts.
The manufacturer is not responsible for any
injury to persons and pets or damage to
property caused by a failure to comply the
following requirements.
Caution! During the installation,
you must refer to the Assembly
Instructions.
Warning! Installation process
must follow the laws, ordinances,
directives, and standards,
electrical safety rules, and
regulations, proper recycling in
accordance with the regulations,
in force in the country of use.
Ensure that the local distribution
conditions (nature of the gas and
gas pressure) and the adjustment
of the appliance are compatible
before proceeding with the
installation.
The parameters of adjustment
setting for this appliance are
stated on the rating plate (refer
to the Technical data chapter).
Warning! The appliance must be
earthed.
Warning! Risk of injury from
electrical current.
• The electrical mains terminal is under
voltage .
• Make sure that the electrical mains
terminal is free of voltage.
• Loose and inappropriate plug and
socket connections. May overheat the
terminal.
• Make sure that the clamping connections
are correctly installed.
• Secure the cable with the strain relief
clamp.
You must observe the minimum
distances to other appliances
and furniture cabinets or other
units according to Assembly
Instruction.
The minimum distance to be maintained
from cut out edge to lateral wall must be
100 mm.
If there is no oven beneath the hob insert a
dividing panel at a minimum distance of 5
mm from the bottom of the hob.
Protect the cut surfaces of the worktop
against moisture using a suitable sealant
included in the product in additional bag.
Seal the appliance to the worktop with no
gap. Do not use silicon sealant between the
appliance and the worktop. Do not install
the appliance next to the doors and under
windows. Otherwise, the hot cookware may
fall off the pan supports.
ENGLISH 9

min.
20 mm
0 mm
min.
18 mm
min.
28 mm
max.
R 5 mm
470±1
mm
550±1
mm
510 mm
594 mm
55 mm
min. 500 mm
min. 28 mm
min. 100 mm
For further information on the installation
refer to the Assembly Instruction.
Product description
Cooking surface layout
8
1
2
7
6
5
4
3
9
1Auxiliary burner
2Rapid burner
3Semi Rapid burner
4Semi Rapid burner
5Semi Rapid burner control knob
6Semi Rapid burner control knob
7Rapid burner control knob
8Auxiliary burner control knob
9Removable pan supports
Burner control knob
The hob burner control knobs are on the
right side of the hob.
ENGLISH 10
