Boracay HSA-D01K Parts list manual
Boracay RF 2.4G Wireless Keyboard Mouse and Dongle Getting Started Manual V0.1
Page 1 of 9
Boracay
Getting Started Manual
RF 2.4G Wireless Keyboard / Mouse & Dongle
Keyboard Model: HSA-D01K
Mouse Model: HSA-D01M
Dongle Model: HSA-D01D
Keyboard
Mouse Dongle
Boracay RF 2.4G Wireless Keyboard Mouse and Dongle Getting Started Manual V0.1
Page 2 of 9
Keyboard Battery inserting
Mouse Battery inserting
Dongle inserting
Boracay RF 2.4G Wireless Keyboard Mouse and Dongle Getting Started Manual V0.1
Page 3 of 9
1.Feature & Specification
HSA-D01K / HSA-D01M
2.4GHz RF, Rang: 2.405GHz ~ 2.470GHz.
Maximum 2 Mbps transmission baud rate.
Wireless operating distance up to 10 m
The Keyboard product offers Fn key function as well as supports standard keyboard
functions.
Resolution: 1000 CPI.
Tracking Up to 30ips.
Accelerated Speed: Up to 10g.
Frame rate：Max 4000 fps.
Low power consumption design/Low battery indicated function.
Voltage supplied to device: 3VDC for HSA-D01K (AAA battery *2)
Voltage supplied to device: 1.5VDC for HSA-D01M (AA battery *1)
Product Applications
Laptop PC, Desktop PC, Support OS: Window XP/Vista/WIN7/Win 8/Win 10
HSA-D01D
2.4GHz RF, Rang: 2.405GHz ~ 2.470 GHz.
Bulit-in 1.8V and 3.3V LDO
Compatible with USB1.1/2.0 protocol
FSK modulation type
Support Standard KB function
Mouse report=125 Hz
8 x 18 keys, Keyboard Phantom key detection.
Boracay RF 2.4G Wireless Keyboard Mouse and Dongle Getting Started Manual V0.1
Page 4 of 9
2.Keyboard Fn Key Function
LED indicator: Num Lock, Caps Lock, Power & Low Battery (Left to Right)
Function Fn LED Behavior
1 Keyboard Lock Fn + Esc Num Lock Blinking 3 times
2 Sleep Fn + F1
3 Search Fn + F2
4 Task View Fn + F3
5 Setting APP Fn + F4
6 Calculator Fn + F5
7 Media select Fn + F6
8 Play/Pause Fn + F7
9 Pre-Track Fn + F8
10 Next Track Fn + F9
11 Mute Fn + F10
12 Volume down Fn + F11
13 Volume Up Fn + F12
14 Win key Lock Fn + Win key Power LED Blinking 3 times
Boracay RF 2.4G Wireless Keyboard Mouse and Dongle Getting Started Manual V0.1
Page 5 of 9
3.Mouse Function Description
Note:
Federal Communication Commission Interference Statement
This Class B digital apparatus complies with Part 15 of the U.S. Federal Communications
Commission (FCC) rules, Canadian ICES-003, and RSS-247. Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Tested to comply with FCC (U.S. Federal Communications Commission) Standards.
For home or office use. The term "IC:" before the certification/registration number only signifies
that the Industry Canada technical specifications were met.
Wireless Keyboard: HSA-D01K
Wireless Mouse: HSA-D01M
Dongle: HSA-D01D.
Left Key
Middle Ke
y
& Wheel
Right Key
Power & Low Battery
