BORCAD Medical SELLA SLA-AX User manual

BORCAD Medical a.s., CZ - 739 45 Fryčovice 673
T: [phone], F: [phone], W: www.borcadmedical.com
Multifunctional Chair SELLA
UN-PACKING MANUAL
INSTRUCTION MANUAL
SLA-20171204-EN

2
BORCAD Medical a.s.
739 45 Fryčovice 673, tel.: [phone] www.borcadmedical.com
Content
Introduction...................................................................................................................3
1 Un-packing manual....................................................................................................6
2 Overview of the basic parts......................................................................................14
2.1 Overview of the basic product versions.............................................................15
3 General instructions.................................................................................................17
3.1 Standards .........................................................................................................17
3.2 General information’s........................................................................................17
3.3 General safety...................................................................................................18
3.4 Use...................................................................................................................19
3.5 Setting the chair................................................................................................19
3.6 Basic positions of the chair................................................................................20
4 Operating the chair ..................................................................................................20
4.1 Moving and braking...........................................................................................21
4.2 Lifting and lowering...........................................................................................23
4.3 Positioning the bed............................................................................................24
4.4 Adjusting the multifunctional armrests...............................................................25
4.5 Height adjustment of the headrest.....................................................................26
4.6 Safety step........................................................................................................26
4.7 Help with getting on/off......................................................................................27
4.8 Hook .................................................................................................................28
5 Accessories .............................................................................................................29
5.1 SLA-ZP-037 Armrests standard (pair)...............................................................29
5.2 SLA-ZP-038 Armrests for blood donation (pair).................................................29
5.3 SLA-ZP-001 Table ............................................................................................30
5.4 SLA-ZP-024 Table with safety barrier................................................................30
5.5 SLA-ZP-023 Table safety lock...........................................................................30
5.6 SLA-ZP-020 Table holder..................................................................................31
5.7 SLA-ZP-005-X Stacking pocket.........................................................................31
5.8 SLA-ZP-102 Holder of infusion stand................................................................32
5.9 SLA-ZP-003 Telescopic Infusion stand .............................................................32
5.10 SLA-ZP-011.10-X Side support (pair)..............................................................33
5.11 SLA-ZP-010-X Headrest, big...........................................................................33
5.12 SLA-ZP-013-X Prolonged stripe for headrest..................................................33
5.13 SLA-ZP-019 Urine bag holder.........................................................................34
5.14 SLA-ZP-119 Urine bag holder.........................................................................34
5.15 SLA-ZP-018 Independent adjustment of backrest...........................................35
5.16 SLA-ZP-006 Independent adjustment of legrest..............................................35
5.17 SLA-ZP-043 Oxygen bottle holder...................................................................36
5.18 SLA-ZP-044-X Patient’s belt ...........................................................................36
6 Care.........................................................................................................................37
6.1 Cleaning and Disinfection..................................................................................37
7 Maintenance............................................................................................................38
7.1 Technical specification......................................................................................39
7.2 Transportation and storage...............................................................................40
7.3 Ambient conditions for operation.......................................................................40
7.4 Service repairs..................................................................................................41
7.5 Environmental protection and disposal of the product.......................................42

3
BORCAD Medical a.s.
739 45 Fryčovice 673, tel.: [phone] www.borcadmedical.com
Introduction
Please read carefully this complete instruction manual which was designed to
familiarize you with its correct use and with the parameters of your new
transportation chair. Please always follow the instructions of this manual and
use the chair always only in accordance with these instructions.
Please keep these instructions always near the chair throughout its operation
course. Every person operating the chair must read and understand the
contents of these instructions.
Very important information is marked throughout the manual by the following
symbols:
Logo
Meaning
EU legislation compliant product
Quality management systems certification authority
marking
Quality management systems certification authority
marking
The upholstery meets the requirements on resistance
to ignition according to BS 7176 in the Medium hazard
category.
The upholstery meets the requirements of BS EN
1021-1, BS EN 1021-2, BS 5852 –resistance to
ignition sources 5

4
BORCAD Medical a.s.
739 45 Fryčovice 673, tel.: [phone] www.borcadmedical.com
Pictogram
Meaning
Warning
Warning:
Dangerous electric voltage
This symbol introduces any information, that may help you to
avoid operative problems
B type accessory part
Production number
int x/y
Marking of intermittent operation, i.e. if the product has been
continuously operated for time period “x”, then it must rest
idle for time period “y”. For example int 10 / 20 means that
after 10 minutes of continuous use /positioning the product
must be out of use/not positioned for 20 minutes
IP X #
Constructional protection against water leakage, dangerous
touch contact and intrusion of foreign objects
Safe operational load
Safe patient load
Producer
Date of production
Follow the instructions manual.
Equipotentiality
Packaging material:
“Keep dry”
Packaging material:
“Fragile!“
Packaging material:
“This side up”
Temperature limitation

5
BORCAD Medical a.s.
739 45 Fryčovice 673, tel.: [phone] www.borcadmedical.com
Transportation marking:
„Relative air humidity“.
Transportation marking:
“Air pressure”.
Marking according to the directive EC 2002/96/EC (Directive
about the disposal of old electric and electronic appliances).
Symbol for: “Do not dispose of the product into communal
waste. Use special collection points for old electronic
appliances.“
Abbreviation
Meaning
REF
Catalogue number
ME
Medical
LED
Light emitting diodes
VA
Power intake units
VGA
Computer standard for computer imaging technology
USB
Universal serial bus
LCD
Liquid crystal display
IT
Information technology
PC
Personal computer
dB
Sound intensity unit
hPa
Pressure unit
ČSN
Protected marking of the Czech technical norms
Hz
Frequency unit in the SI system
Any potential queries please address to the authorized representative or directly
to the producer BORCAD Medical a.s.

6
BORCAD Medical a.s.
739 45 Fryčovice 673, tel.: [phone] www.borcadmedical.com
1 Un-packing manual
Cut the tapes and remove the upper cover.
Remove all boxes with accessories and the accessory equipment from the
bottom lid.

7
BORCAD Medical a.s.
739 45 Fryčovice 673, tel.: [phone] www.borcadmedical.com
Remove the equipment i fit is a part of your order (Telescopic infusion stand,
Side support (pair).

8
BORCAD Medical a.s.
739 45 Fryčovice 673, tel.: [phone] www.borcadmedical.com
Pull out the chair from the bottom slots and move out of the bottom lid.
Unless the chair is completely assembled, you may not use the lever
for adjusting the backrest or the lever for adjusting the backrest
separately!
+

9
BORCAD Medical a.s.
739 45 Fryčovice 673, tel.: [phone] www.borcadmedical.com
Installation of gas spring (for SLA-IB version)
Put gas spring on the back section and remove protective plastic tube.
Put a rope on the control head (it helps, when you push the control hook).

10
BORCAD Medical a.s.
739 45 Fryčovice 673, tel.: [phone] www.borcadmedical.com
Remove the protective caps from the gas spring and draw bar.
Use the pins to connect the gas spring lug to the fork at the bottom part of the
backrest. Define dimensional clearances using plastic washers and secure the
pin with the enclosed lock rings.

11
BORCAD Medical a.s.
739 45 Fryčovice 673, tel.: [phone] www.borcadmedical.com
Scheme of the connection between the gas spring lug and the backrest lug
Similarly, connect the draw bar lug with the backrest fork situated on the other
side of the chair.
1x PE washer,
thickness 1
mm
1x PE washer,
thickness 2
mm
Gas spring
lug
1x PE washer,
thickness 1
mm
1x PE washer,
thickness 2
mm
Lock
ring
Lock
ring
Backrest
direction

12
BORCAD Medical a.s.
739 45 Fryčovice 673, tel.: [phone] www.borcadmedical.com
Undo the leatherine connection at the fork where the gas spring lug is fixed and
move the cable into correct position.
Cut the tape securing the gas spring head under the seat.
Correct cable
position
Leatherine
split

13
BORCAD Medical a.s.
739 45 Fryčovice 673, tel.: [phone] www.borcadmedical.com
Remove the seat part from the box with accessories and put the seat into the
chair frame. Pay attention to the seat orientation.
Connect the infusion rod holder to the chair if it is included.
First remove the infusion holder plug
Then screw the infusion holder to the pin of the right rear wheel and put the
plug back.
Front seat
edge
direction

14
BORCAD Medical a.s.
739 45 Fryčovice 673, tel.: [phone] www.borcadmedical.com
2 Overview of the basic parts
1
Back part
2
Seat
3
Footrest
4
Safety step
5
Control lever for function help with getting on /getting off
6
Plastic chassis cover
7
Front wheels 7a –small, 7b - large
8
Rear wheels
9
Headrest adjustable for height
10
Handle of the back part with a hook + Control lever for adjusting bearing
area
11
Multifunctional armrest
12
Armrest release lever
13
Lift pedal –only in models with lift
14
Central brake (if equipped)
2
12
4
3
11
10
7a
6
8
5
7b
13
14

15
BORCAD Medical a.s.
739 45 Fryčovice 673, tel.: [phone] www.borcadmedical.com
2.1 Overview of the basic product versions
SLA-AX
SLA-CX
SLA-DX
Fixed chassis with large
front wheels
Fixed chassis with front
turning wheels
Chassis with lift and
turning wheels
SLA-IX
SLA-JX
SLA-MX
Chassis with lift and
front large wheels and
getting off aid
Chassis with lift and
front turning wheels
and getting off aid
Chassis with stroke, with
large front and rear
wheels, without a central
brake, with a high footrest.

16
BORCAD Medical a.s.
739 45 Fryčovice 673, tel.: [phone] www.borcadmedical.com
SLA-BX
Chassis with lift and front
large wheels
Color versions of cushioned parts (X)
Type
Color (X):
A
Apricot -orange
B
Baltic - blue
C
Crème
F
Schwarz - black
D3
Pastel orange

17
BORCAD Medical a.s.
739 45 Fryčovice 673, tel.: [phone] www.borcadmedical.com
3 General instructions
3.1 Standards
The product meets the requirements of valid standards EN 60 601-1 and EN
60 601-1-2. According to the Directive on Medical instrumentation 93/42/EEC
the chair is classified as medical instrument of 1st class.
3.2 General information’s
According to the Act on Means of Medical Instrumentation the product may only
be operated by persons with adequate qualification.
Performance of servicing works: BORCAD Medical a.s. authorized service may
only responsibly evaluate the safety technological features if the operators,
repairs, alternations, etc., had been performed only at the producer authorized
locations and the product is operated in full conformity with the instruction
manual.

18
BORCAD Medical a.s.
739 45 Fryčovice 673, tel.: [phone] www.borcadmedical.com
3.3 General safety
See to correct fixation and setting of accessories
Do not dismantle and/or interfere with motors, control unit, etc.
Structural alternations reserved!
Never use other than original accessories. All original accessories are
marked with original label containing the name and brand of the
manufacturer, serial number or batch ID and date of manufacture.
Fire Extinguishing Information
Warning:
Note
Danger of frostbite by contact of CO2 with human skin!
Do not use halotron extinguisher in closed rooms without ventilation –danger to
your health!
Use
Do not use
Powder extinguisher
Foam extinguisher
CO2 extinguisher
Water extinguisher
Halotron extinguisher

19
BORCAD Medical a.s.
739 45 Fryčovice 673, tel.: [phone] www.borcadmedical.com
3.4 Use
The essential functions are lying, sitting, supporting and transporting the
patient.
This transportation chair serves for sitting, laying and transportation of
paralyzed or disabled persons. Assistants of these people have, due to
adequate design of the chair, maximal support for their work. It is necessary for
hygienic reasons to clean the cushioning before use.
Any other use, such as transportation trolley for equipment, with
unacceptable accessories is not approved!
3.5 Setting the chair
The chair is not designed for persons heavier than 150 Kg.
Check the position of the person sitting in the chair in order to
prevent injury resulting from handling/adjustments.
During lowering to the lowest position no objects that could collide
with the chair or block it may be present nearby!
When stopping the chair, it must be braked using the central brake,
alternatively the rear wheel brake to prevent spontaneous
movement. When setting the chair ensure that all wheels are in
contact with the ground.
Before a person is seated and/or before any further handling the
brakes on the chair must be engaged!

20
BORCAD Medical a.s.
739 45 Fryčovice 673, tel.: [phone] www.borcadmedical.com
3.6 Basic positions of the chair
