BorMann BCD2700 User manual

Original instructions
CORDLESS IMPACT WRENCH
GB
BCD2700 Art.-Nr.: 017264

2
B1
7
10
10
5
1
3
82
4
11
13
12 6
B2 B3
7

3
B4
B6
B5
B7
B8
3
2
9
11 12
11
13
1

4
1. Proper usage
This cordless impact wrench is suitable for
loosening and tightening screw connection
during assembly and repairs, and for loosening
bolts when changing tyres.
2. Safety instructions and warnings
The equipment complies with the safety
regulations required for electrical equipment.
Read through the instructions for use before
starting up the equipment.
Improper use can lead to personal injury and
property damage.
Persons, who are not familiar with the
instructions, may not operate the equipment.
Keep the instructions for use in safe custody.
Children and youths are not permitted to operate
the equipment.
3. General Power Tool Safety Warnings
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock,re and/
or serious injury.
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers to
your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do not use
any adapter plugs with earthed (grounded)
power tools. Unmodied plugs and matching
outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or
grounded surfaces, such as pipes, radiators,
ranges and refrigerators. There is an increased
risk of electric shock if your body is earthed or
grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil,
sharp edges and moving parts. Damaged
or entangled cords increase the risk of electric
shock.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and
use common sense when operating a power
tool. Do not use a power tool while you are
tired or under the inuence of drugs, alcohol
or medication. A moment of inattention while
operating power tools may result in serious
personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment

5
such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the o-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools
with your nger on the switch or energising
power tools that have the switch on invites
accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool
may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing
or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving
parts.
g) If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce dust-
related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the switch
does not turn it on and o. Any power tool
that cannot be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions
to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may aect the power tool’s operation.
If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
f) Use the power tool, accessories and tool
bits etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the
power tool for operations dierent from those
intended could result in a hazardous situation.
5) Battery tool use and care
a) Recharge only with the charger specied by
the manufacturer. A charger that is suitable for
one type of battery pack may create a risk of re
when used with another battery pack.
b) Use power tools only with specically
designated battery packs. Use of any other
battery packs may create a risk of injury and re.
c) When battery pack is not in use, keep it
away from other metal objects, like paper
clips, coins, keys, nails, screws or other small
metal objects, that can make a connection
from one terminal to another. Shorting the
battery terminals together may cause burns or a
re.
d) Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If
GB

6
contact accidentally occurs, ush with water. If
liquid contacts eyes, additionally seek medical
help. Liquid ejected from the battery may cause
irritation or burns.
6) Service
a) Have your power tool serviced by a
qualied repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
4. Specic Safety Warnings
· Use suitable detectors to determine if utility
lines are hidden in the work area or call the
local utility company for assistance. Contact
with electric lines can lead to re and electric
shock. Damaging a gas line can lead to explosion.
Penetrating a water line causes property damage.
· Switch o the power tool immediately when
the tool is in insert jams. Be prepared for high
reaction torque that can cause kickback. The
tool insert jams when:
-the power tool is subject to overload or -it
becomes wedged in the workpiece
· Hold the power tool with a rm grip. High
reaction torque can briey occur while driving in
and loosening screws.
· Secure the workplace. A workpiece clamped
with clamping devices or in a vice is held more
secure than by hand.
· Keep your workpiece clean. Blends of
materials are particularly dangerous. Dust
from light alloys can burn or explode.
· Always wait until the power tool has come to
a complete stop before placing it down. The
tool insert can jam and lead to loss of control
over the power tool.
· Avoid unintentional switching on. Ensure
the On/O switch is in the o position before
inserting battery pack. Carrying the power tool
with your nger on the On/O switch or inserting
the battery pack into power tools that have the
switch in accidents.
· Do not open the battery. Danger of short-
circuiting.
· Protect the battery against heat, e.g., also
against continuous sun irradiation and re.
There is danger of explosion.
· In case of damage and improper use of the
battery, vapors may be emitted. Provide
for fresh air and seek medical help in case
of complaints. The vapors can irritate the
respiratory system.
· When the battery is defective, liquid can
escape and come into contact with adjacent
components. Check any parts concerned.
Clean such parts or replace them, if required.

7
5. Description of symbols
Pay attention to all the signs and symbols shown
in these instructions and on your tool.
Make a note of these signs and symbols. If you
interpret the signs and symbols correctly, your
work with the machine will be safer and better.
Important.
Read the instructions for use before
starting the machine.
Wear safety goggles.
Wear ear protection.
Wear good quality, strong gloves.
Always use breathing apparatus when
machining materials which generate
dust.
End of life machines contain valuable
materials and therefore they should
not be placed in household waste.
We would ask you to play your part in
protecting resources and help protect
the environment by returning this
machine to a return point (if one is
available) when it reaches the end of its
life.
6. Layout
1. Tool holder
2. Rotational direction switch
3. On/O switch
4. Handle
5. Battery pack
6. Battery charger
7. Pushlock button
8. LED Lamp
9. Battery capacity indicator
10. Button for power adjustment
11. socket
12. Bolt
13. Rubber sleeve
7. Before starting the equipment
Important. Always remove the battery
from machine before doing any work on the
machine!
7.1 Charging the battery pack
1. Remove the battery pack (5) from the handle,
pressing the pushlock buttons (7) downwards to
do so.
2. Check that your mains voltage is the same as
that marked on the rating plate of the battery
charger. Plug the mains plug of the charger (6)
into the mains socket outlet.
3. Push the battery pack onto the battery charger.
The red LED will come on to indicate that the
battery pack is being charged. When the charging
process is nished, the red LED will extinguish
and green LED will be permanently lit. The time
it takes to fully recharge an empty battery is
approximately 1 hour.
4. The temperature of the battery pack may rise
slightly during the charging operation. This is
normal.
If the battery pack fails to become charged,

8
please check
• whether there is voltage at the socket-outlet
• whether there is proper contact at the
charging contacts on the charger.
If the battery still fails to become charged, please
return
• the charger
• the battery pack
to our Customer Service Department.
To ensure that the battery pack provides long
service you should take care to recharge it
promptly.
You must recharge the battery pack when you
notice that the power Cordless Impact Driver
.
Never fully discharge the battery pack. This will
cause the battery pack to develop a defect.
ATTENTION
Please charge the battery pack regularly, for
example, once every 6 months.
Changing the Tool
Before any work on the power tool (e.g.,
maintenance, tool change, etc.) as well
as during transport and storage, set the
rotational direction switch to the center
position. Unintentional actuation of the On/O
switch can lead to injuries.
7.2 Install the socket (B5-B7)
- Push the socket(11) in tool holder(1).
- Slide the bolt (12) in the hole.
- Put the rubber sleeve on.
8. Starting Operation
8.1 Inserting the Battery
Use only original this brand Li-ion batteries
with the voltage listed on the nameplate of
your power tool. Using other batteries can lead
to injuries and pose a re hazard.
Set the rotational direction switch to the center
position to protect the power tool against
accidental starting. Insert the charged battery
into the handle so that it can be felt to engage
and faces ush against the handle.
8.2 Direction switch
You can toggle between right and left rotation by
pushing the direction of rotation
switch.
The direction changed may only be performed
in standstill mode!
8.3 Switching On and O
To start the machine, press the On/O switch
and keep it pressed. To switch o the machine,
release the On/O switch.
8.4 Adjusting the Speed
The speed of the switched on power tool can
be variably adjusted, depending on how far the
On/O switch is pressed. Light pressure on the
On/O switch results in a low rotational speed.
Further pressure on the switch results in an
increase in speed.
8.5 Adjusting the power
This tool can work with dierent power by
adjusting the button(10).
8.6 Battery capacity indicator (B8)
The 3 color LEDs will indicate the status of battery
capacity as soon as you press the ON/OFF button.
All LEDs illuminate:
The battery is fully charged.
Two LEDs illuminate:
The battery has an adequate remaining charge.
One LED:
The battery is empty, recharge the battery.
8.7 LED lamp
The LED lamp (8) can be used in poor lighting

9
conditions to illuminate the area where you want
to work. The LED lamp (8) will be lit automatically
as soon as you press the ON/OFF switch (3)
9. Technical data
Rechargeable battery: 20V d.c. /3Ah Li-ion
Rating voltage ( DC) DC 20 V
No-load speed: 0-1600/0-2100/0-2500/min
Maximum torque 300 Nm
Battery charging voltage: 21 V d.c.
Battery charging current : 3500 mA
Mains voltage for charger:
220-240VAC 50-60Hz 90W
WARNING! This machine produces an
electromagnetic eld during operation. This eld
may under some circumstances interfere with
active or passive medical implants. To reduce
the risk of serious or fatal injury, we recommend
persons with medical implants to consult their
physician and the medical implant manufacturer
before operating this machine.
10. Cleaning and maintenance
Always remove the battery from machine before
doing any work on the cordless wrench!
10.1 Cleaning
• Keep all safety devices, air vents and the motor
housing free of dirt and dust as far as possible.
Wipe the equipment with a clean cloth or blow it
with compressed air at low pressure.
• We recommend that you clean the device
immediately each time you have nished using it.
• Clean the equipment regularly with a moist
cloth and some soft soap. Do not use cleaning
agents or solvents; these could attack the plastic
parts of the equipment. Ensure that no water can
seep into the device.
10.2 Maintenance
Please charge the battery pack regularly, for
example, once every 6 months.
11. Repairs
Only use accessories and spare parts
recommended by the manufacturer. If the
equipment should fail some day in spite of our
quality controls and your maintenance, only
have it repaired by an authorized electrician.
12. Environmental protection
End of life electrical equipment must not
be placed in household waste. Please
take it to a return point. Find out about
your nearest return point from your
council or sales outlet.
