Bosch HEA578B 1 Series User manual

[en] Instruction manual
Built-in cooker
HEA578B.1

en
3
Table of contents
[en]Inst ructi on manual
8Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
(Important safety information . . . . . . . . . . . . . . . 4
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Halogen lamp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Cleaning function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
]Causes of damage . . . . . . . . . . . . . . . . . . . . . . . . 6
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
7Environmental protection . . . . . . . . . . . . . . . . . . 6
Saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Environmentally-friendly disposal . . . . . . . . . . . . . . . . . 7
*Getting to know your appliance . . . . . . . . . . . . . 8
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Buttons and display . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Types of heating and functions . . . . . . . . . . . . . . . . . . 9
Temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Hob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Cooking compartment . . . . . . . . . . . . . . . . . . . . . . . . 10
_Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Control accessories . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Inserting accessories . . . . . . . . . . . . . . . . . . . . . . . . . 11
Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . 12
KBefore using for the first time. . . . . . . . . . . . . . 13
Initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Cleaning the cooking compartment and accessories 13
1Operating the appliance . . . . . . . . . . . . . . . . . . 13
Switching the appliance on and off . . . . . . . . . . . . . . 13
Setting the heating function and temperature . . . . . . 13
Rapid heating. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
OTime-setting options . . . . . . . . . . . . . . . . . . . . . 14
Setting the cooking time . . . . . . . . . . . . . . . . . . . . . . 14
Setting the end time . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Setting the timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Setting the time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
AChildproof lock. . . . . . . . . . . . . . . . . . . . . . . . . . 17
Activating and deactivating . . . . . . . . . . . . . . . . . . . . 17
QBasic settings. . . . . . . . . . . . . . . . . . . . . . . . . . . 17
List of basic settings . . . . . . . . . . . . . . . . . . . . . . . . . 17
Changing the basic settings. . . . . . . . . . . . . . . . . . . . 18
FSabbath mode . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Starting Sabbath mode . . . . . . . . . . . . . . . . . . . . . . . 18
DCleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Suitable cleaning agents . . . . . . . . . . . . . . . . . . . . . .19
Keeping the appliance clean . . . . . . . . . . . . . . . . . . .20
.Cleaning function. . . . . . . . . . . . . . . . . . . . . . . . 20
Before running the cleaning function . . . . . . . . . . . . .20
Setting the cleaning function . . . . . . . . . . . . . . . . . . .21
After running the cleaning function . . . . . . . . . . . . . . .21
pRails. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Detaching and refitting the rails . . . . . . . . . . . . . . . . .21
qAppliance door . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Removing and fitting the appliance door . . . . . . . . . .22
Removing the door cover . . . . . . . . . . . . . . . . . . . . . .23
Removing and installing the door panels . . . . . . . . . .23
3Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . 25
Rectifying faults yourself . . . . . . . . . . . . . . . . . . . . . . .25
Maximum operating time . . . . . . . . . . . . . . . . . . . . . .25
Replacing the bulb in the top of the cooking
compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
4Customer service . . . . . . . . . . . . . . . . . . . . . . . . 26
E number and FD number . . . . . . . . . . . . . . . . . . . . .26
PProgrammes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Cookware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Preparing food . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Programmes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Setting a programme . . . . . . . . . . . . . . . . . . . . . . . . .29
JTested for you in our cooking studio. . . . . . . . 30
General information . . . . . . . . . . . . . . . . . . . . . . . . . .30
Cakes and pastries. . . . . . . . . . . . . . . . . . . . . . . . . . .31
Bakes and gratins . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Poultry, meat and fish . . . . . . . . . . . . . . . . . . . . . . . . .34
Vegetables and side dishes . . . . . . . . . . . . . . . . . . . .37
Desserts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Acrylamide in foodstuffs . . . . . . . . . . . . . . . . . . . . . . .37
Slow cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Drying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Preserving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Proving dough . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Keeping warm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Test dishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Produktinfo
Additional information on products, accessories,
replacement parts and services can be found at
www.bosch-home.com and in the online shop
www.bosch-eshop.com

en Intended use
4
8Intended use
Intended use Read these instructions carefully. Only then
will you be able to operate your appliance
safely and correctly. Retain the instruction
manual and installation instructions for future
use or for subsequent owners.
This appliance is only intended to be fully fitted
in a kitchen. Observe the special installation
instructions.
Check the appliance for damage after
unpacking it. Do not connect the appliance if it
has been damaged in transport.
Only a licensed professional may connect
appliances without plugs. Damage caused by
incorrect connection is not covered under
warranty.
This appliance is intended for domestic use
only. The appliance must only be used for the
preparation of food and drink. The appliance
must be supervised during operation. Only
use this appliance indoors.
This appliance is intended for use up to a
maximum height of 2000 metres above sea
level.
This appliance may be used by children over
the age of 8 years old and by persons with
reduced physical, sensory or mental
capabilities or by persons with a lack of
experience or knowledge if they are
supervised or are instructed by a person
responsible for their safety how to use the
appliance safely and have understood the
associated hazards.
Children must not play with, on, or around the
appliance. Children must not clean the
appliance or carry out general maintenance
unless they are at least 15 years old and are
being supervised.
Keep children below the age of 8 years old at
a safe distance from the appliance and power
cable.
Always slide accessories into the cooking
compartment the right way round.
~"Accessories" on page 11
(Important safety
information
Impor t ant saf et y informat i on General information
:Warning – Risk of fire!
■Combustible items stored in the cooking
compartment may catch fire. Never store
combustible items in the cooking
compartment. Never open the appliance
door if there is smoke inside. Switch off the
appliance and unplug it from the mains or
switch off the circuit breaker in the fuse box.
Risk of fire!
■Loose food remnants, fat and meat juices
may catch fire. Before using the appliance,
remove the worst of the food remnants from
the cooking compartment, heating elements
and accessories.
Risk of fire!
■A draught is created when the appliance
door is opened. Greaseproof paper may
come into contact with the heating element
and catch fire. Do not place greaseproof
paper loosely over accessories during
preheating. Always weight down the
greaseproof paper with a dish or a baking
tin. Only cover the surface required with
greaseproof paper. Greaseproof paper
must not protrude over the accessories.
:Warning – Risk of burns!
■The appliance becomes very hot. Never
touch the interior surfaces of the cooking
compartment or the heating elements.
Always allow the appliance to cool down.
Keep children at a safe distance.
Risk of serious burns!
■Accessories and ovenware become very
hot. Always use oven gloves to remove
accessories or ovenware from the cooking
compartment.
Risk of burns!
■Alcoholic vapours may catch fire in the hot
cooking compartment. Never prepare food
containing large quantities of drinks with a
high alcohol content. Only use small
quantities of drinks with a high alcohol
content. Open the appliance door with care.

Important safety information en
5
:Warning – Risk of scalding!
■The accessible parts become hot during
operation. Never touch the hot parts. Keep
children at a safe distance.
Risk of scalding!
■When you open the appliance door, hot
steam can escape. Steam may not be
visible, depending on its temperature. When
opening, do not stand too close to the
appliance. Open the appliance door
carefully. Keep children away.
Risk of scalding!
■Water in a hot cooking compartment may
create hot steam. Never pour water into the
hot cooking compartment.
:Warning – Risk of injury!
■Scratched glass in the appliance door may
develop into a crack. Do not use a glass
scraper, sharp or abrasive cleaning aids or
detergents.
Risk of injury!
■The hinges on the appliance door move
when opening and closing the door, and
you may be trapped. Keep your hands away
from the hinges.
:Warning – Risk of electric shock!
■Incorrect repairs are dangerous. Repairs
may only be carried out and damaged
power cables replaced by one of our
trained after-sales technicians. If the
appliance is defective, unplug the appliance
from the mains or switch off the circuit
breaker in the fuse box. Contact the after-
sales service.
Risk of electric shock and serious injury!
■The cable insulation on electrical
appliances may melt when touching hot
parts of the appliance. Never bring
electrical appliance cables into contact with
hot parts of the appliance.
Risk of electric shock!
■Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.
Risk of electric shock!
■A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in the
fuse box. Contact the after-sales service.
:Warning – Hazard due to magnetism!
Permanent magnets are used in the control
panel or in the control elements. They may
affect electronic implants, e.g. heart
pacemakers or insulin pumps. Wearers of
electronic implants must stay at least 10 cm
away from the control panel.
Halogen lamp
:Warning – Risk of burns!
The bulbs in the cooking compartment
become very hot. There is still a risk of burning
your skin for some time after they have been
switched off. Do not touch the glass cover.
Avoid contact with your skin when cleaning.
:Warning – Risk of electric shock!
When replacing the cooking compartment
bulb, the bulb socket contacts are live. Before
replacing the bulb, unplug the appliance from
the mains or switch off the circuit breaker in
the fuse box.
Cleaning function
:Warning – Risk of fire!
■Loose food remnants, fat and meat juices
may catch fire when the cleaning function is
in progress. Before you start the cleaning
function, always remove the worst of the
food residues and remnants from the
cooking compartment.Do not use the
cleaning function for cleaning accessories.
Risk of fire!
■The appliance will become very hot on the
outside during the cleaning function. Never
hang combustible objects, e.g. tea towels,
on the door handle. Do not place anything
against the front of the appliance. Keep
children away from the appliance.
:Warning – Risk of serious harm to health!
The appliance becomes very hot when the
cleaning function is in progress. The non-stick
coating on baking trays and tins is destroyed
and noxious gases are released. Never clean
non-stick baking trays or baking tins using the
cleaning function. In general, you must not use
the cleaning function for cleaning accessories.
:Warning – Risk of burns!
■The cooking compartment becomes
extremely hot during the cleaning function.
Never open the appliance door. Allow the
appliance to cool down. Keep children
away from the appliance.
Risk of burns!
■;The appliance will become very hot on
the outside during the cleaning function.
Never touch the appliance door. Allow the
appliance to cool down. Keep children
away from the appliance.

en Causes of damage
6
]Causes of damage
Ca u s e s of damage General information
Caution!
■Accessories, foil, greaseproof paper or ovenware on
the cooking compartment floor: do not place
accessories on the cooking compartment floor. Do
not cover the cooking compartment floor with any
sort of foil or greaseproof paper. Do not place
ovenware on the cooking compartment floor if a
temperature of over 50 ºC has been set. This will
cause heat to accumulate. The baking and roasting
times will no longer be correct and the enamel will
be damaged.
■Aluminium foil: Aluminium foil in the cooking
compartment must not come into contact with the
door glass. This could cause permanent
discolouration of the door glass.
■Water in a hot cooking compartment: do not pour
water into the cooking compartment when it is hot.
This will cause steam. The temperature change can
cause damage to the enamel.
■Moisture in the cooking compartment: Over an
extended period of time, moisture in the cooking
compartment may lead to corrosion. Allow the
cooking compartment to dry after use. Do not keep
moist food in the closed cooking compartment for
extended periods of time. Do not store food in the
cooking compartment.
■Cooling with the appliance door open: Following
operation at high temperatures, only allow the
cooking compartment to cool down with the door
closed. Do not trap anything in the appliance door.
Even if the door is only left open a crack, the front of
nearby furniture may become damaged over time.
Only leave the cooking compartment to dry with the
door open if a lot of moisture was produced whilst
the oven was operating.
■Fruit juice: when baking particularly juicy fruit pies,
do not pack the baking tray too generously. Fruit
juice dripping from the baking tray leaves stains that
cannot be removed. If possible, use the deeper
universal pan.
■Extremely dirty seal: If the seal is very dirty, the
appliance door will no longer close properly during
operation. The fronts of adjacent units could be
damaged. Always keep the seal clean.
~"Cleaning" on page 19
■Appliance door as a seat, shelf or worktop: Do not
sit on the appliance door, or place or hang anything
on it. Do not place any cookware or accessories on
the appliance door.
■Inserting accessories: depending on the appliance
model, accessories can scratch the door panel
when closing the appliance door. Always insert the
accessories into the cooking compartment as far as
they will go.
■Carrying the appliance: do not carry or hold the
appliance by the door handle. The door handle
cannot support the weight of the appliance and
could break.
7Environmental protection
En v i r on ment al pr ot ect i on Your new appliance is particularly energy-efficient.
Here you can find tips on how to save even more
energy when using the appliance, and how to dispose
of your appliance properly.
Saving energy
■Only preheat the appliance if this is specified in the
recipe or in the tables in the operating instructions.
■Leave frozen food to defrost before placing it in the
cooking compartment.
■Use baking tins that are dark-coloured, painted black
or have an enamel coating. These absorb the heat
particularly well.
■Remove any unnecessary accessories from the
cooking compartment.

Environmental protection en
7
■Open the appliance door as infrequently as possible
when the appliance is in use.
■It is best to bake several cakes one after the other.
The cooking compartment stays warm. This reduces
the baking time for the second cake. You can place
two cake tins next to each other in the cooking
compartment.
■For longer cooking times, you can switch the
appliance off 10 minutes before the end of the
cooking time and use the residual heat to finish
cooking.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly
manner.
This appliance is labelled in accordance with
European Directive 2012/19/EU concerning
used electrical and electronic appliances
(waste electrical and electronic equipment -
WEEE). The guideline determines the
framework for the return and recycling of used
appliances as applicable throughout the EU.

en Getting to know your appliance
8
*Getting to know your
appliance
Get t i ng to know your appl i ance In this chapter, we will explain the indicators and
controls. You will also find out about the various
functions of your appliance.
Note: Depending on the appliance model, individual
details and colours may differ.
Control panel
You can set your appliance's various functions on the
control panel. Below, you will see an overview of the
control panel and the layout of the controls.
Note: On some appliances, the control knobs can be
pushed in. To push the control knob in and engage it or
to release it again, turn it to the "Off" position.
Buttons and display
You can use the buttons to set various additional
functions on your appliance. You will be able to see the
values for these on the display.
--------
Display
The cooking compartment temperature you set using
the temperature selector will be shown on the display.
In addition, you can read the settings for the time-setting
options. The value that can be set at the present time or
that is elapsing will be shown in large digits on the
display. To use the individual time-setting options, touch
the vbutton several times.If there is a red bar above or
below a symbol, this means that the value being shown
in large digits on the display refers to the function that
this symbol represents.


# #
(Buttons and display
The buttons are touch keys with sensors
underneath. Simply touch a symbol to select the
function it represents.
The display shows symbols for active functions
and the time-setting options.
0Function selector
Use the function selector to set the heating
function or other functions.
You can turn the function selector clockwise or
anti-clockwise from the "Off" position.
8Temperature selector
Use the temperature selector to set the
temperature for the heating function or select the
setting for other functions.
You can also turn the temperature selector
clockwise and anti-clockwise. It does not have an
"Off" position.
@Hotplate control
You can use the four hotplate controls to control
the output provided by each individual hotplate.
The symbol above each of the controls shows you
which hotplate is set using that control.
Symbol Meaning
vTime-setting options Tap the symbol repeatedly to select
the time v, timer t, duration yand
end time {.
A
@
Minus
Plus
Reduce setting values.
Increase setting values.
BInterior lighting Switch the interior lighting on or off.
GRapid heating Start or cancel Rapid heating for the
cooking compartment.
DChildproof lock Lock and unlock the oven functions
on the control panel.

Getting to know your appliance en
9
Types of heating and functions
Use the function selector to set the types of heating and
other functions.
To make sure you always use the right type of heating
to cook your food, we have explained the differences
and applications below.
--------
Note: For each heating function, the appliance specifies
a default temperature or level. You can accept this
value or change it in the appropriate area.
Other functions
Your new oven has yet more functions; see below for a
brief description of these.
--------
Type of heating Temperature Use
<3D hot air 30-275 °C For baking and roasting on one or more levels.
The fan distributes the heat from the ring heating element in the back panel evenly
around the cooking compartment.
6Hot air gentle 30-275 °C An intelligent heating type for the gentle preparation of meat, fish and pastries.
The appliance optimally controls the supply of energy to the cooking compartment.
The food is prepared in phases using residual heat. This means that it remains more
succulent and browns less. Energy can be saved, depending on the preparation and
food.
This heating function is used to determine the energy efficiency class.
$Pizza setting 30-275 °C For cooking pizza and dishes that require a lot of heat from underneath.
The bottom heating element and the ring heating element in the back panel heat up.
$Bottom heating 30-250 °C For cooking in a bain marie and for baking food for extra time.
Heat is emitted from below.
OKeep-warm 60-100 °C For keeping cooked food warm.
BDefrost 30-60 °C For gently defrosting frozen food.
;Slow cook 70-120 °C For gentle and slow cooking of seared, tender pieces of meat in ovenware without a
lid.
Heat is emitted evenly from above and below at low temperatures.
(Grill, large area Grill settings:
1 = low
2 = medium
3 = high
For grilling flat items, such as steaks or sausages, for making toast, and for browning
food.
The whole area below the grill element becomes hot.
7Circulated air grilling 30-275 °C For roasting poultry, whole fish and larger pieces of meat.
The grill element and the fan switch on and off alternately. The fan circulates the hot
air around the food.
%Top/bottom heating 30-275 °C For traditional baking and roasting on one level. Especially suitable for cakes with
moist toppings.
Heat is emitted evenly from the top and bottom.
Function Use
%Programmes For many types of food, the appliance has preprogrammed setting values that you can
use.
~"Programmes" on page 27
qPyrolytic self-cleaning The pyrolytic self-cleaning function cleans the cooking compartment almost by itself.
~"Cleaning function" on page 20

en Getting to know your appliance
10
Temperature
Use the temperature selector to set the temperature in
the cooking compartment. It can also be used to select
the grill and cleaning settings, for example.
The settings will appear on the display.
Notes
■The temperature can be set in 1 degree increments
up to 100 °C, and in 5 degree increments thereafter.
■When cooking at very high temperatures, the
appliance lowers the temperature slightly after an
extended period.
Temperature indicator
The line at the bottom of the display turns red from left
to right as the cooking compartment heats up.
When you are preheating the appliance, the optimal
time to place your food in the cooking compartment is
as soon as the entire line has turned red.
Residual heat
When the appliance is switched off, the temperature
indicator shows the residual heat in the cooking
compartment. The lower the temperature drops, the
shorter the line.
Notes
■The temperature indicator only shows the increasing
temperature for heating functions for which a
temperature is set. For grill settings, for example, the
indicator shows a full line from the beginning.
■If the temperature in the cooking compartment is too
high when the appliance is started, œwill appear on
the display for some heating functions. Switch off the
appliance and allow it to cool down before switching
it back on again.
■Due to thermal inertia, the actual temperature inside
the cooking compartment may differ slightly from the
temperature that is displayed.
Hob
Your hob comes with its own instruction manual.Please
read this carefully to ensure that you are able to use the
hob safely and correctly.
It contains important safety information, detailed set-up
instructions and plenty of information on caring for and
cleaning your hob.
Cooking compartment
Various functions in the cooking compartment make
your appliance easier to use. For example, the cooking
compartment is well lit and a cooling fan prevents the
appliance from overheating.
Opening the appliance door
If you open the appliance door when the appliance is in
operation, the appliance will continue to operate as
before.
Interior lighting
With most heating functions and other functions, the
interior lighting in the cooking compartment will remain
lit while the oven is in operation. Once the oven has
finished cooking the food, the lighting will go out.
By pressing the button for the interior lighting, you can
switch on the lighting without heating the oven. This
makes it easier to clean your appliance, for example.
Cooling fan
The cooling fan switches on and off as required. The
hot air escapes above the door.
Caution!
Do not cover the ventilation slots. Otherwise, the
appliance may overheat.
So that the cooking compartment cools down more
quickly after operation, the cooling fan continues to run
for a certain period afterwards.
